audeeo AOFREE User manual

ITEM: AOFREE
QUICK START + INSTRUCTION GUIDE

Welcome to audeeo
Thank you for choosing this product. We are striving
for excellence in both aesthetics and acoustics.
But we could not do this without you.
Let's take sound to new heights together.
FREEDOM
TRUE WIRELESS
WITH CHARGING CASE

FREEDOM WIRELESS EARPHONES
1Welcome
1.1 What's In The Box
2Your Freedom Wireless Earphones
2.1 Getting To Know Your Earphones
2.2 Item Features
3Quick Start Guide
3.1 Charging & Powering ON
3.2 Bluetooth Pairing
4 Button Functions
5 All Features & Contents
6Specifications
7Troubleshooting
8Care &Maintenance
9Warranty & Legal
1Welcome
1.1 What's In The Box
GUIDE BOOKLET
TYP-C CABLE
EARPHONES
CHARGING CASE STATION

FREEDOM WIRELESS EARPHONES
ITEM: AOFREE
A
A
A
B
B
B
C
D
B
A
C
B
D
TOUCH BUTTON
CHARGING CONTACTS
Simply touch to pause /
play / call / hang up / reject
Small round metal pieces locat-
ed on both the LEFT & RIGHT
earphones & in the Charging
Case Station in the designated
earphones notches.
MULTI-FUNCTION BUTTON
MICRO USB CHARGING PORT
EARPHONES STATUS LIGHT
CHARGING CASE STATUS LIGHT
-Power on & o
-Pause & play music
-Answer & hand up calls
-Reject calls
-Previous & next track
-Increase & decrease volume
- Use of smartphone assistant:
• Google Assistant™ • Siri®
This is the area to plug-in and charge your
Charging Case Station. If the earphones are in the
Charging Case Station they will charge first.
Indicates if the earphones are on/o, pairing,
or charging. The light will be RED when
charging in the Charging Case Station
These 4 lights will illuminate one by one - blink-
ing GREEN when being charged. The blinking
light will remain a solid GREEN when that
percentage is full. When all 4 lights are a steady
GREEN the case is fully charged.
2Your Freedom Wireless Earphones
2.1 Getting To Know Your Earphones
2Your Freedom Wireless Earphones
2.2 Item Features

FREEDOM WIRELESS EARPHONES
ITEM: AOFREE
Connect the Typ-C cable (only use the provided cable) to a
computer USB port or a USB wall charger. Plug the other end of
the Typ-C cable into the Typ-C charging port (C) located on the
left side of the Charging Case Station. Each LED indicator light
(D) will blink GREEN until they reach their full percentage and
stay GREEN when full. Once the 4 LED lights are a steady
GREEN your Charging Case is fully charged.
Open the top of the Charging Case Station and place your
earphones in their initialled/designated areas. Once properly in
place the LED lights on the earphones will illuminate RED.
When the earphones are fully charged the RED LED light will
automatically turn o.
NOTE: please refer to the diagram on 2.2
3Quick Start Guide
3.2 Turning ON/OFF - 2 Options
1 1 2
1
1
2
2
The first option is when your earphones are turned o, touch
and hold the Multi-Function button (A) for 2 -3 seconds to turn
ON your earphones. If your earphones are already ON, touch
and hold the Multi-Function button (A) for 5 seconds to turn
OFF your earphones.
The second option is when you remove your earphones from
the Charging Case Station they will turn ON automatically.
When you put them back in the charging station and close the lid
they will turn OFF automatically and begin to charge if needed.
3Quick Start Guide
3.1 Charging & Powering ON
NOTE: please refer to the diagram on 2.2
2 - 3S

FREEDOM WIRELESS EARPHONES
Pick up both earphones from the Charging Case Station your
earphones will automatically enter pairing mode. They will
automatically pair to one another and the LEFT earphone will
flash GREEN & RED steadily. Your earphones are now waiting
to be paired to a device.
Ensure Bluetooth is enabled on your smartphone, tablet,
computer, or music device. The earphones will appear as
“audeeo Free” in the list of available Bluetooth devices.
Select “audeeo Free” and connect.
Ensure the earphones are turned o, then touch and hold the
Multi-Function button (A) for 2-3 seconds to turn the
earphones ON. The earphones will enter Bluetooth pairing
mode automatically and emit a tone as the LED indicator light
(B) will flash GREEN and RED. Make sure your device has
Bluetooth turned ON.
Ensure Bluetooth is enabled on your smartphone or music
device. Your device will start searching for wireless devices. The
earphones will appear as “audeeo Free” in the list of available
Bluetooth devices.
Select “audeeo Free” the LED lights will stop on the earphones
and will say "Connected" to indicate that is has been successfully
paired with your device.
BLUETOOTH
BLUETOOTH
audeeo Free
audeeo Free
BLUETOOTH
BLUETOOTH audeeo Free
audeeo Free
1
2
3
1
2
3
1
1 2 3
2 3
3Quick Start Guide
3.3 Bluetooth Pairing - Method 1
3Quick Start Guide
3.4 Bluetooth Pairing - Method 2
2 - 3S
NOTE: please refer to the diagram on 2.2 NOTE: please refer to the diagram on 2.2

FREEDOM WIRELESS EARPHONES
ITEM: AOFREE
(A) on the RIGHT or LEFT earphone once to answer the call, touch
the Multi-Function Button (A) once again to hang up the call.
REJECT CALLS
When there is an incoming call, touch and hold the Multi-Function
button (A) on the RIGHT or LEFT earphone for 2-3 seconds to
reject the call.
PAUSE & PLAY MUSIC
When playing music, touch the Multi-Function button (A) on the
LEFT or RIGHT earphone once to pause music, touch the button
once again to play music.
NEXT & LAST TRACK
When playing music, double touch the Multi-Function button(A)
on the RIGHT earphone to skip to the next track, double touch
the Multi-Function button(A) on the LEFT earphone to skip to the
previous track.
VOLUME UP & DOWN
When playing music, triple touch the Multi-Function button(A)
on the RIGHT earphone to increase the volume, triple touch the
Multi-Function button(A) on the LEFT earphone to decrease the
volume.
VOICE ASSISTANT
Hold the Multi Function Button(A) on either the LEFT or RIGHT
earphone for 1-2 seconds until you hear the “beep” prompt to
activate Voice Assistant (Google AssistantTM or Siri®) on your
smartphone.
NOTE: please refer to the diagram on 2.2
Remove either the RIGHT or LEFT earphone from the
Charging Case Station or only turning one of the earphone ON.
Turn ON by touching and holding the Multi-Function button (A)
until you hear the prompt. After a few seconds the earphones
will go into pairing mode (flashing GREEN & RED).
Open your Bluetooth setting on your device and pair again if
needed. The earphones will appear as “audeeo Free” in the list
of available Bluetooth devices. Select “audeeo Free” and
connect.
NOTE: Last track function and Volume up&down function will not work in
single earphone mode.
BLUETOOTH
audeeo Free
NOTE: please refer to the diagram on 2.2
2
1
3
4
5
6
1
2
3
1 2 3
4Button Functions
3Quick Start Guide
3.5 Single Earphone Mode
ANSWER & HANG UP CALLS
When there is an incoming call, touch the Multi-Function Button

FREEDOM WIRELESS EARPHONES
ITEM: AOFREE
RECHARGEABLE:
BUILT-IN MIC: BETTER AUDIO:
VOICE ASSISTANT
ACTIVATED & READY
TOUCH TECH:
lithium ion battery with
extended listening time
hands-free talking
with volume control enhanced acoustics treble & bass
Works with your phone’s
digital assistant
simply touch to pause
play / call / hang up
CONTENTS:
• FREEDOM WIRELESS EAR-
PHONES
• CHARGING STATION CASE
• TYP-C CHARGING CABLE
• MANUAL
MULTI DEVICE:
will work with any
Bluetooth®device
• mobile phones
• computers
• tablets
6Specifications
5All Features & Contents
EXTENDED TIME:
with charging case for
longer listening sessions
Specifications:
BLUETOOTH VERSION 5.0
FREQUENCY RESPONSE 2.4GHz - 2.48GHz
DRIVER UNIT 10mm
OPERATION RANGE 10m
EARPHONES BATTERIES 35mAh Lithium Ion Each
CHARGING CASE STATION 300mAh Lithium Ion
PLAY TIME Up to 3 hours
CHARGING CASE STATION SUPPLY
POWER FOR EARPHONES Up to 12 hours
CHARGING TIME About 1 hour
CHARGING CASE STATION CHARGE
TIME About 1.5 hours
NOTE: working time depends on volume levels
- lower volume will prolong your estimated battery life.
- higher volume will decrease your estimated battery life.

Troubleshooting:
NO POWER
• Recharge your earphones using the
included Charging Case Station and
Typ-C cable.
MUSIC IS NOT PLAYING
OVER BLUETOOTH
• Make sure your Bluetooth device has
A2DP profile. Check if both devices are
paired and connected over Bluetooth.
Restart the earphones to reconnect your
Bluetooth device.
BLUETOOTH DEVICE
WILL NOT
RECONNECT WITH THE
EARPHONES
• Navigate to your Bluetooth settings
menu on your Bluetooh device, tap
"audeeo Free" and select "Forget". Now
follow the steps to pair your device again.
THE BUTTONS ON
THE TRUE WIRELESS
EARPHONES ARE NOT
WORKING
• Turn your Freedom Wireless
Earphones OFF, reconnect after a few
seconds.
• Make sure that the Bluetooth function
is activated on your Bluetooth device.
POOR SOUND RECEP-
TION / QUALITY OF
AUDIO NOT AS GOOD
• Make sure your earphones are charged.
• Make sure you are within 10m of your
Bluetooth device.
7Troubleshooting & Customer Support
Troubleshooting continued:
ONE EARPHONE IS NOT
CONNECTED TO THE
OTHER ONE
• Power o both earphones by
touching the Multi-Function but-
ton for 2-3 seconds. • Then pow-
er both on by holding in the same
button Multi-function button for
2-3 seconds. The earphones will
connect automatically.
EARPHONES ARE NOT
CHARGING
• Make sure the headphones are
properly placed in the Charging
Case Station.
• Make sure the Charging Case
Station battery is fully charged.
• Make sure there is no dirt or
debris covering the charging con-
ductors within the Charging Case
Station or on the earphones.
7Troubleshooting Continued

9Warranty & Legal8Care & Maintenance
• DO NOT expose the unit to liquid, moisture, or humidity to avoid
damage to the product’s internal circuitry.
• DO NOT use abrasive cleaning solvents to clean the unit.
• DO NOT expose the unit to extremely high or low temperatures as
this will shorten the life of the electronic device, destroy the battery,
and/or distort certain plastic parts.
• DO NOT dispose of the unit in fire as they may explode or combust.
• DO NOT expose the unit to and/or use sharp objects on the Ear-
phones as this will cause scratches and damage.
• DO NOT attempt to disassemble the unit. In the event that the unit
does not function properly, return it to the store where it was purchased.
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. This warranty is limited to the original purchaser only.
• You must be able to prove the date of original purchase of the unit with a dated receipt.
• The warranty is not applicable if the product has been subject to physical abuse, improper
installation, modification or repair by unauthorized third party.
• The responsibility of supplier’s products shall be limited to the repair or replacement of the
product as its sole discretion.
• Specifically exempt from any warranty are limited-life consumable components subject to
normal wear and tear such as batteries, decorates and other accessories.
• A supplier will not take any responsibility if the failure of the unit has resulted from accident,
abuse, misuse, or any unauthorized repair, modification or disassemble.
• Modification and repair of the unit should be done by authorized and qualified service
personnel, Center or returned to the manufacturer.
• This warranty give you specific legal rights, and you may also have other rights which vary
under local laws.
The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by iHip Europe Ltd is under license.
Other trademarks and trade names are those of their respective owners.
This appliance should not be put into the domestic garbage at the end of its
useful life, but must be disposed of at a central point for recycling of electric and
electronic domestic appliances.
This symbol on appliance, instruction manual and packaging puts your attention
to this important issue. The materials used in this appliance can be recycled. By
recycling used domestic appliances you contribute an important push to the
protection of our environment. Ask your local authorities for information regarding
the point of recollection.
Siri®is a trademark of Apple Inc., registered in the U.S. and other countries.
Google Assistant is a trademark of Google Inc.

Manufactured & Distributed by:
iHip Europe Ltd., Chartwell House,
292-294 Hale Lane, London, UK, HA8 8NP
audeeo™ is a registered trademark of iHip Europe Ltd.
MADE IN CHINA
