Foreword
Thank you for choosing an Audi - we·value your trust in us.
Your new Audi will allow you to experience the best in groundbreaking technolo-
gy and premium quality equipment avehicle has to offer. We recommend that
you read your Owner's Manual thoroughly so that you quickly become acquaint-
ed with your Audi and make useof all of its features .
In addition to explaining how the different features work, we provide many use-
ful tips and information concerning your safety, how to carefor your vehicle and
how to maintain your vehicle's value. We also give you useful tips and informa-
tion on how to drive your vehicle more efficiently and in an environmentally
friendly manner.
In the Owner's Manual, you will also find the Operating Manual for your Info-
tainment system and the vehicle maintenance schedule.
We hope you enjoy driving your Audi and we wish you safe and pleasant motor-
ing.
