Audi A6 2011 Operating instructions

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Repair Manual
Audi A6 2011 ➤
Audi A6 Avant 2011 ➤
Audi A7 Sportback 2011 ➤
Audi A7 Sportback USA 2011 ➤
7-Speed Dual Clutch Transmission 0CK
Engine ID CYN
B
CPN
B
Edition 11.2015
Service
Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
List of Workshop Manual Repair Groups
Repair Group
00 - General, Technical Data
30 - Clutch
34 - Controls, Housing
35 - Gears, Shafts
39 - Final Drive, Differential
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2016 Audi AG, Ingolstadt D4B804AF109

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Contents
00 - General, Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 General Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Start/Stop System Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.3 Road Test with Testing Equipment Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.4 Safety Precautions when Tow Starting and Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Repair Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1 Guidelines for Clean Working Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2 General Repair Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.3 ATF Pump, Deactivating and Draining the Hydraulic Pump Reservoir . . . . . . . . . . . . . . . . 7
4.4 Contact Corrosion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.5 Transmission Control Module Safety Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Electrical Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.1 Component Location Overview - Electrical Components . . . . . . . . . . . . . . . . . . . . . . . . . . 9
30 - Clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1 Clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
34 - Controls, Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1 Selector Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Overview - Operating Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.2 Overview - Selector Lever Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 Overview - Selector Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.4 Emergency Release from P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.5 Selector Lever Handle, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.6 Button in Handle, Moving Into Installation Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.7 Selector Mechanism, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.8 Selector Mechanism, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.9 Selector Lever Cable, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1.10 Selector Lever Cable, Checking and Adjusting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
1.11 Shift Lock Solenoid N110 , Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
1.12 Selector Lever Sensor System Control Module J587 , Removing and Installing . . . . . . . . 34
1.13 Drive Position Sensor G676 , Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1.14 Selector Shaft Seal, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2 Transmission, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.1 Transmission, Removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.2 Transmission, Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
2.3 Transmission Tightening Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
3 Transmission, Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4 Securing on Engine and Transmission Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5 Subframe Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.1 Overview - Subframe Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.2 Tunnel Crossmember, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.3 Transmission Support with Transmission Mount, Removing and Installing . . . . . . . . . . . . 71
5.4 Transmission Mount, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6 Transmission Fluid Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
6.1 Overview - Transmission Fluid Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
6.2 Transmission Fluid Pump, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
7 ATF Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7.1 Overview - ATF Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
7.2 ATF Cooler, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8 Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.1 Transmission Fluid Level, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
8.2 Transmission Fluid, Draining and Filling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
9 Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
9.1 ATF Level, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
9.2 ATF, Draining and Filling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
10 Mechatronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
10.1 Overview - Mechatronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
10.2 Oil Pan, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
10.3 Mechatronic, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
11 Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
35 - Gears, Shafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
1 Gears and Shafts, Disassembling and Assembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
39 - Final Drive, Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
1 Transmission Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
1.1 Component Location Overview - Transmission Control Module . . . . . . . . . . . . . . . . . . . . 104
2 Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
2.1 Component Location Overview - Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
2.2 Left Seal, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
2.3 Right Seal, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
3 Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
3.1 Overview - Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
3.2 Left Flange Shaft, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
3.3 Right Flange Shaft, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
4 Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
5 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
00 – General, Technical Data
1 Identification
(Edition 11.2015)
The following details can be found on the transmission housing
-arrows-:
♦ Codes
♦ Serial Number
♦ Production Date
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
1. Identification 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Technical Data
⇒ “2.1 Capacities”, page 2
2.1 Capacities
Capacities Automatic Transmission
Fluid
Transmission Fluid
Original fill‐
ing by the
manufac‐
turer
Refer to ⇒ Fluid Capaci‐
ty Tables; Rep. Gr. 03
Refer to ⇒ Fluid Capaci‐
ty Tables; Rep. Gr. 03
ATF
change
quantity
Refer to ⇒ Maintenance
Intervals; Rep. Gr. 03
Refer to ⇒ Maintenance
Intervals; Rep. Gr. 03
Change In‐
terval
⇒ Maintenance Intervals; Rep. Gr. 03
Lubricant For ATF and MTF transmission fluid for S tronic
transmission 0CK. Refer to the Parts Catalog
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
2 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3 Safety Precautions
⇒ “3.1 General Safety Precautions”, page 3
⇒ “3.2 Start/Stop System Safety Precautions”, page 3
⇒ “3.3 Road Test with Testing Equipment Safety Precautions”,
page 4
⇒ “3.4 Safety Precautions when Tow Starting and Towing”, page
4
3.1 General Safety Precautions
Observe the following to Avoid Personal Injury and Vehicle Dam‐
age:
WARNING
There is a risk of injury and accident from accidentally engag‐
ing a gear when the engine is running.
♦ Before work is done when the engine is running, place the
selector lever in the “P” position and press the parking
brake button to engage the electro-mechanical parking
brake.
To Prevent Personal Injury and Damage to Electrical and Elec‐
tronic Components, Observe the Following:
♦ Connect and disconnect test equipment only when the ignition
is off.
Caution
Risk of damaging electronic components when disconnecting
the battery.
♦ Complete the steps for disconnecting the battery.
♦ Always turn off the ignition before disconnecting the bat‐
tery.
– Disconnect the battery. Refer to ⇒ Electrical Equipment; Rep.
Gr. 27 ; Battery; Battery, Disconnecting and Connecting .
3.2 Start/Stop System Safety Precautions
Pay Attention to the following When Working on a Vehicle with
Stop/Start System:
WARNING
There is a risk of injury if the engine starts automatically in ve‐
hicles with the Start/Stop System.
♦ For vehicles with an activated Start/Stop System (recog‐
nizable from a notification in the instrument cluster), the
motor can be started automatically if needed.
♦ Make sure the Start/Stop System is disabled when work‐
ing on the vehicle (turn off ignition, if needed, turn the
ignition back on).
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
3. Safety Precautions 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3.3 Road Test with Testing Equipment
Safety Precautions
If Testing Equipment Must Be Used during a Road Test, Observe
the Following:
WARNING
Distraction and testing equipment that is not secured properly
can cause accidents.
The passenger airbag could pose a risk if it deploys in a colli‐
sion.
• Operating testing equipment while driving is a distraction.
• Testing equipment that is not secured probably increases
the risk of injury.
♦ Always secure testing equipment on the rear seat using a
strap and have a second person in the rear seat operate
it.
3.4 Safety Precautions when Tow Starting
and Towing
Caution
Move the selector lever to “N” when towing the vehicle. Do not
drive longer than 50 km and do not drive faster than 50 km/h
(31 mph) because this will damage the transmission.
Note
The engine cannot be tow started, for example, if the battery is
too weak or if the starter is not working.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
4 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4 Repair Information
⇒ “4.1 Guidelines for Clean Working Conditions”, page 5
⇒ “4.2 General Repair Information”, page 5
⇒ “4.3 ATF Pump, Deactivating and Draining the Hydraulic Pump
Reservoir”, page 7
⇒ “4.4 Contact Corrosion”, page 7
⇒ “4.5 Transmission Control Module Safety Functions”,
page 8
4.1 Guidelines for Clean Working Condi‐
tions
♦ Always clean connection places and surrounding areas with
engine or brake cleaner before loosening and dry cleaned pla‐
ces.
♦ Clean the transmission and transmission components using
Cleaning Solution - D 009 401 04- .
♦ Use lint-free cloths when cleaning, for example, the “ X70 / ”
cloth made by Kimberly-Clark Professional.
♦ Seal all open lines and connections immediately with clean
plugs or caps from the Engine Bung Set - VAS6122- .
♦ Place removed parts on a clean surface and cover them. Use
foil and paper. Use a lint-free cloth!
♦ Carefully cover or plug unpacked components if repairs can‐
not be performed immediately.
♦ Only install clean components: Install replacement parts im‐
mediately after removing them from their packaging.
♦ Protect the disconnected connectors from dirt and moisture
and only connect when they are dry.
4.2 General Repair Information
♦ Carefulness, cleanliness and the correct tools are required for
transmission repairs to be successful. The usual basic safety
precautions also, naturally apply when carrying out vehicle re‐
pairs.
♦ Some general repair information that applies to several pro‐
cedures throughout this manual is summarized here. They
apply to this repair manual.
Guided Fault Finding, On Board Diagnostics (OBD) and Test In‐
struments
♦ Determine the cause of the malfunction as accurately as pos‐
sible using Guided Fault Finding, OBD and Test Instru-
ments before starting any repairs on the transmission using
the Vehicle Diagnostic Tester .
Special Tools and Equipment
For a complete list of special tools used in the Repair Manual.
Refer to Workshop Equipment and Special Tools.
Oil, Environmental and Disposal Regulations
♦ Handle transmission fluid, axle oil and other fluids with care.
♦ Dispose of the drained fluids properly.
♦ Follow the legal environmental and disposal regulations.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
4. Repair Information 5

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Follow the information provided on oil packaging.
Transmission
♦ Do not run engine or tow the vehicle when the oil pan is re‐
moved or when there is no transmission fluid.
♦ Always clean the connection locations and the area around
them before loosening.
♦ During installation, make sure that the alignment bushings are
fitted correctly.
O-Rings, Gaskets, Seals
♦ O-rings, gaskets and seals must be replaced.
♦ After removing gaskets, examine contact surface on housing/
shaft for burr resulting from removal or for other signs of dam‐
age.
♦ Thoroughly clean housing joint surfaces before assembling.
♦ Replace paper gaskets, thoroughly clean sealing surfaces and
completely remove old seals.
♦ Lightly coat the seals with ATF along outer circumference and
along the sealing lip.
♦ Coat the O-rings with transmission fluid or Vaseline before in‐
serting them so they are not crushed during installation.
♦ Do not use any other lubricants in the gear oil area. Otherwise
there is a danger of malfunction of the transmission hydraulics.
♦ The open side of the seals point toward the fluid to be sealed
in.
♦ When installing the new shaft seals, make sure the sealing lip
does not run on the same point as the sealing lip of the old
seal (use insertion depth tolerances).
♦ Follow the guidelines for clean working conditions. Refer to
⇒ “4.1 Guidelines for Clean Working Conditions”, page 5 .
Fasteners
♦ Do not overstretch the circlips.
♦ Replace damaged or stretched circlips.
♦ The circlips must fit completely inside the groove.
Bolts and Nuts
♦ Loosen the bolts opposite the tightening sequence.
♦ Nuts and bolts which secure covers and housings should be
loosened and tightened crosswise in stages if no tightening
sequence is specified.
♦ Replace the self-locking nuts.
♦ Use a wire brush to clean the threads of bolts that were
screwed in with locking compound. Install the bolts with Lock‐
ing Fluid - AMV 185 101 A1- .
♦ The tightening specifications stated apply to non-oiled nuts
and bolts.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
6 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4.3 ATF Pump, Deactivating and Draining
the Hydraulic Pump Reservoir
WARNING
The system is under pressure.
The ATF transmission “7 speed S tronic Transmission 0CK” is
equipped with an electronic ATF pump and a hydraulic pres‐
sure reservoir.
The electronic ATF pump can start up at any time.
The ATF system also remains under pressure with the ignition
switched off due to the hydraulic pressure reservoir.
♦ The electronic ATF pump must be deactivated every time
before opening the transmission, and the hydraulic pres‐
sure reservoir is drained.
♦ When the system status is not clear, for example the
cause of a faulty transmission control module or transmis‐
sion is unknown, only loosen the mechatronic bolts to a
minimal degree, so that the oil pressure in the pressure
reservoir can decrease slowly.
♦ Disconnect the Transmission Control Module - J217- con‐
nector before removing the oil pan.
♦ Wear protective eyewear.
ATF Pump, Deactivating and Draining the Hydraulic Pump Res‐
ervoir
– Connect the Vehicle Diagnostic Tester with the vehicle and
start the Diagnostic mode.
♦Select Vehicle Test
♦02-Transmission Electronics, Functions
♦02 ATF Pressure Reduction/Disabling the ATF Pump or
02-ATF Level ⇒ Draining ATF
4.4 Contact Corrosion
Contact corrosion can occur if unsuitable fasteners (bolts, nuts,
washers, etc.) are used.
For this reason, only fasteners with a special surface coating may
be installed.
Furthermore, only rubber/plastic parts and adhesive made of
electrically non-conductive materials are used.
If there are doubts about whether parts can be used or not, then
use new parts. Refer to the Parts Catalog.
Note
♦ Only original replacement parts are recommended, they are
checked and compatible with aluminum.
♦ The use of Audi accessories is recommended.
♦ Damage resulting from contact corrosion is not covered by the
warranty.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
4. Repair Information 7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4.5 Transmission Control Module Safety
Functions
If one or more components and/or sensors malfunction, the au‐
tomatic control module will activate the appropriate replacement
function. This guarantees the non-destructive operation of the
transmission with respective implications on shift function and
quality.
When malfunctions are detected by the transmission, a distinction
is made between 4 possible statuses.
♦ 1.: The fault is stored and a substitute program permits further
driving (in some cases with restrictions). The driver is not no‐
tified of this status, because it is neither critical for the driving
safety nor for the transmission. The selector lever position in‐
dicator in the instrument cluster provides a normal display of
the current selector lever position arrow. The driver will only
notice the fault - if it is noticed at all - in terms of handling
problems and will then automatically consult Audi Service.
♦ 2. Certain selector lever positions will flash in the transmission
range display in the instrument cluster. The driver is shown
that a desired gear selection is currently not possible. This is
the case if, for example, a reverse drive (selector lever position
“R” and the vehicle rolls backwards) is engaged in the driving
gear “D”. The selector lever position “D” in the selector lever
position indicator in the instrument cluster will blink in this
case. The transmission control module prevents engaging the
1st gear in order to avoid damaging the transmission. The 1st
gear is engaged after the vehicle comes to a standstill.
♦ 3. The selector lever position display in the instrument cluster
is completely illuminated and blinks. The selector lever posi‐
tion can be recognized in the instrument cluster, for example,
“D” is highlighted. The transmission was overloaded in this
case and the maximum temperature in the transmission was
exceeded (overheating), for example, due to towing a trailer
with an excessively high load.
♦ 4. A fully illuminated, flashing transmission range display in
instrument cluster is an indication of a serious fault in the
transmission. In the display in the instrument cluster, you can
no longer recognize which position is selected on the selector
lever. The status is critical for driving safety or for the trans‐
mission. Under certain conditions, all gears can no longer be
engaged. Through the blinking gear selection indicator, the
driver is told to visit an Audi service dealer.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
8 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
5 Electrical Components
Refer to
⇒ “5.1 Component Location Overview - Electrical Components”,
page 9
5.1 Component Location Overview - Electri‐
cal Components
DSG Transmission Mechatronic - J743- . Refer to
⇒ “1.1 Component Location Overview - Transmission Control
Module”, page 104
Transmission Park Selector Switch - F305- . Refer to
⇒ “1.3 Overview - Selector Mechanism”, page 14
Shift Lock Solenoid - N110- . Refer to
⇒ “1.3 Overview - Selector Mechanism”, page 14
Selector Lever Sensor System Control Module - J587- with Tip‐
tronic Switch - F189- . Refer to
⇒ “1.3 Overview - Selector Mechanism”, page 14
Drive Position Sensor - G676- and Drive Position Sensor 2 -
G869- . Refer to
⇒ “1.3 Overview - Selector Mechanism”, page 14
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
5. Electrical Components 9

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
30 – Clutch
1 Clutch
All work procedures for the dual clutch are described under: ⇒ S
tronic Transmission Internal Components; Rep. Gr. 30 ; Clutch
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
10 Rep. Gr.30 - Clutch

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
34 – Controls, Housing
1 Selector Mechanism
⇒ “1.1 Overview - Operating Cables”, page 11
⇒ “1.2 Overview - Selector Lever Handle”, page 13
⇒ “1.3 Overview - Selector Mechanism”, page 14
⇒ “1.4 Emergency Release from P”, page 16
⇒ “1.5 Selector Lever Handle, Removing and Installing”,
page 16
⇒ “1.6 Button in Handle, Moving Into Installation Position”,
page 18
⇒ “1.7 Selector Mechanism, Removing and Installing”,
page 20
⇒ “1.8 Selector Mechanism, Checking”, page 22
⇒ “1.9 Selector Lever Cable, Removing and Installing”,
page 25
⇒ “1.10 Selector Lever Cable, Checking and Adjusting”,
page 28
⇒ “1.11 Shift Lock Solenoid N110 , Removing and Installing”,
page 32
⇒ “1.12 Selector Lever Sensor System Control Module J587 ,
Removing and Installing”, page 34
⇒ “1.13 Drive Position Sensor G676 , Removing and Installing”,
page 34
⇒ “1.14 Selector Shaft Seal, Replacing”, page 36
1.1 Overview - Operating Cables
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
1. Selector Mechanism 11

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1 - Bolt
❑ 8 Nm
❑ Quantity: 2
2 - Cable Mounting Bracket
3 - Selector Lever Cable
❑ Do not bend
❑ Removing and instal‐
ling. Refer to
⇒ “1.9 Selector Lever
Cable, Removing and
Installing”, page 25 .
❑ The selector lever cable
must be replaced if the
rubber grommet is dam‐
aged.
❑ Lubricate the ball socket
lightly with Polycarba‐
mide Grease - G 052
142 A2- before instal‐
ling.
❑ Make sure the rubber
grommet on the trans‐
mission side is not twis‐
ted when installing.
❑ Adjusting. Refer to
⇒ “1.10.1 Selector Lever
Cable, Adjusting”,
page 28 .
❑ Bring into installed posi‐
tion. Refer to
⇒ “1.10.2 Selector Lever
Cable, Bringing into Ba‐
sic Setting”, page 29 .
4 - Clip
❑ For selector lever cable
5 - Gearshift Lever
6 - Bolt
❑ 13 Nm
❑ For selector lever cable adjustment
❑ On the gearshift mechanism
7 - O-Ring
❑ Replace after removing
8 - Clip
❑ For selector lever cable
❑ Replace after removing
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
12 Rep. Gr.34 - Controls, Housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1.2 Overview - Selector Lever Handle
1 - Selector Lever Transmis‐
sion Range Position Display
Unit - Y26-
❑ Removing and instal‐
ling. Refer to ⇒ Electri‐
cal Equipment; Rep. Gr.
96 ; Lamps; Selector
Lever Transmission
Range Position Display
Unit Y26, Removing and
Installing. .
2 - Multimedia System Control
Head - E380-
❑ Removing and instal‐
ling. Refer to ⇒ Com‐
munication; Rep. Gr.
91 ; Infotainment-Sys‐
tem; Multimedia System
Control Head E380, Re‐
moving and Installing .
3 - Selector Lever Boot
❑ Removing and installing
together with the selec‐
tor lever handle. Refer
to
⇒ “1.5 Selector Lever
Handle, Removing and
Installing”, page 16
4 - Selector Lever Handle
❑ Removing and instal‐
ling. Refer to
⇒ “1.5 Selector Lever
Handle, Removing and
Installing”, page 16 .
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
1. Selector Mechanism 13

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
1.3 Overview - Selector Mechanism
Selector Mechanism
WARNING
There is a risk of injury and accident from accidentally engag‐
ing a gear when the engine is running.
1 - O-Ring
❑ Replace after removing
2 - Selector Lever Cable
❑ Do not bend
❑ Removing and instal‐
ling. Refer to
⇒ “1.9 Selector Lever
Cable, Removing and
Installing”, page 25 .
3 - Bolt
❑ For selector lever cable
adjustment
❑ Tightening specification
-item 6-
⇒ Item 6 (page 12) .
4 - Transmission Park Selector
Switch - F305-
❑ Consists of two micro-
switches on the circuit
board on the Shift Lock
Solenoid - N110- .
❑ Can only be replaced to‐
gether with the Shift
Lock Solenoid - N110- .
Refer to
⇒ “1.11 Shift Lock Sol‐
enoid N110 , Removing
and Installing”,
page 32 .
5 - Shift Lock Solenoid - N110-
❑ Removing and instal‐
ling. Refer to
⇒ “1.11 Shift Lock Sol‐
enoid N110 , Removing
and Installing”,
page 32 .
6 - Cap
❑ Via the Shift Lock Solenoid - N110-
7 - Selector Lever Sensor System Control Module - J587- with Tiptronic Switch - F189-
❑ Removing and installing. Refer to
⇒ “1.12 Selector Lever Sensor System Control Module J587 , Removing and Installing”, page 34 .
8 - Nut
❑ 8 Nm
❑ Quantity: 4
❑ For securing the shift mechanism to the body
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
14 Rep. Gr.34 - Controls, Housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
9 - Seal
10 - Selector Mechanism
❑ Can only be replaced as a unit
❑ Removing and installing. Refer to ⇒ “1.7 Selector Mechanism, Removing and Installing”, page 20 .
• Perform “Guided Functions” using the Vehicle Diagnostic Tester after removing and installing the selector
mechanism.
11 - Clip
❑ For selector lever cable
12 - Noise Insulation
❑ Not equipped on all vehicles
❑ Allocation. Refer to the Parts Catalog.
13 - Lock Washers
❑ For the noise insulation
❑ Quantity: 4
❑ Replace after removing
Gearshift Mechanism on Transmission
1 - Bolt
❑ 3 Nm +90°
❑ Replace after removing
2 - Drive Position Sensor -
G676- and Drive Position Sen‐
sor 2 - G869-
❑ Removing and instal‐
ling. Refer to
⇒ “1.13 Drive Position
Sensor G676 , Remov‐
ing and Installing”, page
34 .
3 - Seal
❑ Replace after removing
4 - Seal
❑ For the selector shaft
❑ Replacing. Refer to
⇒ “1.14 Selector Shaft
Seal, Replacing”,
page 36 .
5 - Gearshift Lever
❑ Removing and instal‐
ling. Refer to
⇒ “1.14 Selector Shaft
Seal, Replacing”,
page 36 .
6 - Bolt
❑ 10 Nm +90°
❑ Replace after removing
7 - Cover
❑ For the selector shaft
8 - Bolt
❑ 8 Nm +60°
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
1. Selector Mechanism 15

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
❑ Replace after removing
1.4 Emergency Release from P
Note
♦ The selector lever will not move out of “P” if the battery is dis‐
connected or is discharged. The vehicle cannot be moved or
towed.
♦ The Shift Lock Solenoid - N110- will cancel out the lock when
the emergency release is activated.
Procedure
Note
The handle on the selector lever is not shown in the illustration. It
is not necessary to remove the handle in order to unlock the se‐
lector mechanism when it is in “P”.
– Remove the front ashtray insert, if equipped.
– Pry out the cap -1- inside the ashtray housing with a screw‐
driver in direction of -arrow-.
– Press the cylinder in direction of -arrow- on the Shift Lock Sol‐
enoid - N110- , for example using the screwdriver from the
vehicle tool kit, through the center opening in the ashtray
housing and at the same time, shift the selector lever out of
“P” while pressing the button on the selector lever.
Note
♦ This unlocks the locking lever -1- when the selector lever is in
“P”.
♦ If the cylinder -arrow- on the Shift Lock Solenoid - N110- is
covered by insulation or a wire, then move the insulation or the
wire to the side.
1.5 Selector Lever Handle, Removing and
Installing
Special tools and workshop equipment required
♦ Trim Removal Wedge - 3409-
♦ The cable ties or the assembly aid for the button on the handle.
The assembly aid is already installed at the factory when a
new handle is ordered.
Audi A6 2011 ➤ , Audi A6 Avant 2011 ➤ , Audi A7 Sportback 2011 ➤ , Audi ...
7-Speed Dual Clutch Transmission 0CK - Edition 11.2015
16 Rep. Gr.34 - Controls, Housing
