Repair Manual
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and
0BN, Rear Final Drive 0BP
Engine ID CJW
B
CJW
C
CJW
E
CTW
A
CTW
B
CAT
A
CNR
B
CCG
A
Edition 12.2012
Service
Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
List of Workshop Manual Repair Groups
Repair Group
00 - General, Technical Data
34 - Controls, Housing
39 - Final Drive, Differential
39 - Final Drive, Differential
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2017 Audi AG, Ingolstadt D3E802DF810

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Contents
00 - General, Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 Component Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Transfer Case Designation 0BU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2 Code Letters, Transmission Allocation and Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Front Final Drive Designation 0BM and 0C1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Code, Transmission Allocation, Ratios and Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 Rear Final Drive Designation 0BN and 0BP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2 Code, Transmission Allocation, Ratios and Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 General Repair Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.2 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
34 - Controls, Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Fastener Tightening Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Transfer Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Transfer Case Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Transfer Case, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Transfer Case, Transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Transmission Carrier and Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.1 Transmission Carrier and Console Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Transmission Carrier and Console, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . 17
3.3 Bonded Rubber Bushing in Transmission Carrier and Console, Removing and Installing
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 Transfer Case, Checking Transmission Fluid Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5 Transfer Case Shaft Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Transfer Case Shaft Seals Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 Input Shaft Seal, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.3 Front Flange Shaft and Driveshaft Seal, Transfer Case Installed, Removing and Installing
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.4 Rear Output Flange and Driveshaft Seal, Transfer Case Installing, Removing and
Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6 Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
39 - Final Drive, Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
1.1 Fastener Tightening Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2 Rear Final Drive 0BN and 0BP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.1 Rear Final Drive Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.2 Rear Final Drive, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3 Rear Final Drive Axle Oil Level, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4 Shaft Seals, Rear Final Drive 0BN and 0BP, Removing and Installing . . . . . . . . . . . . . . . . 43
4.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.2 Left Flange Shaft Seal, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.3 Right Flange Shaft Seal, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.4 Flange Shaft and Driveshaft Seal on Rear Final Drive, Final Drive Removed, Removing and
Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5 Rear Final Drive Bonded Rubber Bushing, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
5.1 Bonded Rubber Bushing Installed Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2 Bonded Rubber Bushing, Flange Shaft and Drivehaft, Removing and Installing . . . . . . . . 48
5.3 Rear Bonded Rubber Bushing, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6 Rear Driveshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.2 Rear Driveshaft Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.3 Rear Drive Shaft, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7 Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
39 - Final Drive, Differential . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
1.1 Fastener Tightening Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
2 Front Final Drive 0BM and 0C1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
2.1 Front Final Drive Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
2.2 Front Final Drive, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
2.3 Front Final Drive, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
2.4 Front Final Drive, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
3 Axle Oil Level in Front Final Drive, Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
4 Shaft Seals, Front Final Drive 0BM and 0C1, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . 91
4.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
4.2 Shaft Seals, Rear Final Drive 0BN and 0BP Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
4.3 Left Flange Shaft Seal, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
4.4 Right Flange Shaft Seal, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
4.5 Seal for Flange/Driveshaft on Front Final Drive, Replacing (Final Drive Removed) . . . . . . 95
4.6 Left Flange Shaft Dust Cap, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
4.7 Right Flange Shaft Dust Cap, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
5 Left Flange Shaft Needle Bearing, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
6 Bonded Rubber Bushing on Front Final Drive, Replacing . . . . . . . . . . . . . . . . . . . . . . . . . . 100
6.1 Bonded Rubber Bushing Installed Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
6.2 Bonded Rubber Bushing, Flange Shaft and Drivehaft, Removing and Installing . . . . . . . . 100
6.3 Bonded Rubber Bushing in Front Housing, Removing and Installing . . . . . . . . . . . . . . . . 101
6.4 Bonded Rubber Bushing on Left Housing, Removing and Installing . . . . . . . . . . . . . . . . . . 102
7 Front Driveshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
7.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
7.2 Front Driveshaft Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
7.3 Front Driveshaft, Removing and Installing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
8 Special Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
9 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
00 – General, Technical Data
1 Component Overview
(Edition 12.2012)
1 - 8-Speed Automatic Trans‐
mission 0C8
2 - Transfer Case 0BU
❑ Transfer case identifica‐
tion. Refer to
⇒ “2 Transfer Case Des‐
ignation 0BU”,
page 2 .
❑ Removing and Instal‐
ling. Refer to
⇒ “2 Transfer Case”,
page 10 .
3 - Rear Driveshaft
❑ Removing and Instal‐
ling. Refer to
⇒ “6 Rear Driveshaft”,
page 51 .
4 - Rear Final Drive 0BN or
0BP
❑ Rear final drive designa‐
tion. Refer to
⇒ “4 Rear Final Drive
Designation 0BN and
0BP”, page 5 .
❑ Removing and Instal‐
ling. Refer to
⇒ “2 Rear Final Drive
0BN and 0BP”,
page 39 .
5 - Front Driveshaft
❑ Removing and Instal‐
ling. Refer to
⇒ “7 Front Driveshaft”,
page 104 .
6 - Front Final Drive 0BM or
0C1
❑ Front final drive designation, refer to ⇒ “3 Front Final Drive Designation 0BM and 0C1”, page 3
❑ Removing and Installing. Refer to ⇒ “2 Front Final Drive 0BM and 0C1”, page 67 .
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
1. Component Overview 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Transfer Case Designation 0BU
⇒ “2.1 General Information”, page 2
⇒ “2.2 Code Letters, Transmission Allocation and Capacities”,
page 2
2.1 General Information
The transfer case 0BU is allocated to the 8-speed automatic
transmission 0C8.
Code letters, allocation
⇒ “2.2 Code Letters, Transmission Allocation and Capacities”,
page 2 .
Location on Transfer Case
Transfer case 0BU, code letters and manufacture date -arrow-.
Transfer Case Identification
• -A- Transfer case date of manufacture.
• -B- Code letters “MTP”.
• -C- transfer case “0BU” with part number.
Example MTP 11 11 2009
I I I I
Code let‐
ters
Day Month Year of pro‐
duction
(2009)
Additional data depend on the manufacturing.
2.2 Code Letters, Transmission Allocation and Capacities
Transfer Case 0BU
Code letters MTQ/LXY MTP/LXW MGF/MTR
Allocation Type Audi Q7 from MY 07 Audi Q7 from MY 07 Audi Q7 from MY 07
Engine 4.2L - 250 kW TDI 3.0L - 165 kW, 176
kW TDI
3.0L - 204 kW, 239
kW TDI
3.0L - 200 kW and
245 kW TFSI
Throat length mm 155.7 mm 127.4 mm 191.2 mm
Capacity 0.60 liters
The following information can be found in the Parts Catalog:
♦ Allocation to the corresponding vehicle via engine code for the automatic transmission as well as the
PR number
♦ Transmission fluid specification
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
2 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
3 Front Final Drive Designation 0BM
and 0C1
⇒ “3.1 General Information”, page 3
⇒ “3.2 Code, Transmission Allocation, Ratios and Capacities”,
page 3
3.1 General Information
The front final drive 0BM/0C1 is assigned to automatic transmis‐
sion 0C8.
Allocation. Refer to
⇒ “3.2 Code, Transmission Allocation, Ratios and Capacities”,
page 3 .
Location on Front Final Drive
Front final drive 0BM and 0C1, code letters and manufacture date
-arrow-.
Front Final Drive Identification
• -A- Front final drive date of manufacture.
• -B- code letters “MUU”.
• -C- Front final drive “0BM,” with part number.
Exam‐
ple:
I 289 0344
I I I
Year of manu‐
facture -2009-
I = 2009,
K = 2010,
L = 2011,
M = 2012 ...
Day of manufac‐
ture
-289. calendar day-
(always three
digits)
day of manufacture
serial number
Additional data depend on the manufacturing.
3.2 Code, Transmission Allocation, Ratios and Capacities
Front Final Drive 0C1 0BM
Code letters MUK MUN MUU
Allocation Type Audi Q7 from MY 07 Audi Q7 from MY 07 Audi Q7 from MY 07
Engine 4.2L - 250 kW TDI 3.0L - 165 kW, 176
kW TDI
3.0L - 204 kW, 239
kW TDI
3.0L - 200 kW and
245 kW TFSI
Ratio: Z2: Z1Final Drive 34 : 13 - 2.615 36 : 11 - 3.272 37 : 10 - 3.700
Capacity 0.8 liters 0.6 liters
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
3. Front Final Drive Designation 0BM and 0C1 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Front Final Drive 0C1 0BM
Code letters MUK MUN MUU
The following information can be found in the Parts Catalog:
♦ Flange shaft allocation
♦ Allocation to the corresponding vehicle via engine code and PR number
♦ Transmission fluid specification
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
4 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
4 Rear Final Drive Designation 0BN
and 0BP
⇒ “4.1 General Information”, page 5
⇒ “4.2 Code, Transmission Allocation, Ratios and Capacities”,
page 5
4.1 General Information
The front final drive 0BN/0BP is assigned to automatic transmis‐
sion 0C8.
Allocation. Refer to
⇒ “4.2 Code, Transmission Allocation, Ratios and Capacities”,
page 5 .
Location on Rear Final Drive
Rear final drive 0BN, 0BP, code letters and date of manufac‐
ture-arrow-.
Rear Final Drive Identification
• -A- Rear final driven “0BP” with part number.
• -B- Code letters “MEY”.
• -C- Rear final drive date of manufacture.
Exam‐
ple:
I 275 0284
I I I
Year of manu‐
facture -2009-
I = 2009,
K = 2010,
L = 2011,
M = 2012 ...
Day of manufac‐
ture
-275. calendar day-
(always three
digits)
day of manufacture
serial number
Additional data depend on the manufacturing.
4.2 Code, Transmission Allocation, Ratios and Capacities
Rear Final Drive 0BN 0BP
Code letters MEZ MEX MEY
Allocation Type Audi Q7 from MY
07
Audi Q7 from MY 07 Audi Q7 from MY
07
Engine 4.2L - 250 kW TDI 3.0L - 165 kW, 176
kW TDI
3.0L - 204 kW, 239
kW TDI
3.0L - 200 kW and
245 kW TFSI
Ratio: Z2: Z1Final Drive 34 : 13 - 2.615 36 : 11 - 3.272 37 : 10 - 3.700
Capacity 1.1 liters 0.9 liters
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
4. Rear Final Drive Designation 0BN and 0BP 5

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Rear Final Drive 0BN 0BP
Code letters MEZ MEX MEY
The following information can be found in the Parts Catalog:
♦ Flange shaft allocation
♦ Allocation to the corresponding vehicle via engine code and PR number
♦ Transmission fluid specification
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
6 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
5 General Repair Information
⇒ “5.1 Cleaning”, page 7
⇒ “5.2 Components”, page 7
5.1 Cleaning
Carefulness, cleanliness and the correct tools are required for
transmission repairs to be successful. The usual basic safety pre‐
cautions also, naturally apply when carrying out vehicle repairs.
A number of generally applicable instructions for individual repair
procedures, which are otherwise mentioned at various points in
the Repair Manual, are summarized here under the topic “Com‐
ponents”. Refer to ⇒ “5.2 Components”, page 7 . They apply
to this repair manual.
5.2 Components
Transmission
♦ Make sure that the alignment sleeves between the transfer
case and transmission are positioned correctly when installing
the transfer case.
♦ Clean the contact surfaces when installing the brackets as well
as any waxed components. Contact surfaces must be free of
grease and wax.
♦ For the correct bolts and other components, refer to Parts
Catalog.
♦ When replacing a transfer case, the gear oil must be filled up
to lower edge of filler hole. Refer to
⇒ “4 Transfer Case, Checking Transmission Fluid Level”, page
21 .
♦ Capacities and specification in the transfer case. Refer to
⇒ “2 Transfer Case Designation 0BU”, page 2
♦ When replacing a front final drive, the gear oil must be filled
up to lower edge of filler hole. Refer to
⇒ “3 Axle Oil Level in Front Final Drive, Checking”,
page 90 .
♦ Capacities and Specifications, Front Final Drive. Refer to
⇒ “3.2 Code, Transmission Allocation, Ratios and Capacities”,
page 3 .
♦ When replacing a rear final drive, the gear oil must be filled up
to lower edge of filler hole. Refer to
⇒ “3 Rear Final Drive Axle Oil Level, Checking”, page 42 .
♦ Capacities and Specifications, Rear Final Drive. Refer to
⇒ “4 Rear Final Drive Designation 0BN and 0BP”, page 5 .
Sealant
♦ Thoroughly clean housing joint surfaces before applying the
Sealant - AMV 174 004 01- .
♦ Apply the Sealant - AMV 174 004 01- evenly and not too thick.
O-Rings, Shaft Seals, Sealing Rings and Seals
♦ Replace the O-rings.
♦ The open side of the shaft seals point toward the fluid to be
sealed in.
♦ When installing the new shaft seals, make sure the sealing lip
does not run on the same point as the sealing lip of the old
seal (use insertion depth tolerances).
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
5. General Repair Information 7

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
♦ Lightly lubricate O-rings before installing to prevent them from
being crushed when inserting.
Shaft Seals
Prior to Installing:
Lightly coat the outer circumference with oil and then fill the space
between the sealing lips -arrow- halfway with Sealing Grease - G
052 128 A1- .
After Installing:
♦ Check the transmission fluid level in the transfer case. Refer
to
⇒ “4 Transfer Case, Checking Transmission Fluid Level”, page
21 .
♦ Check transmission fluid level in front final drive
⇒ “3 Axle Oil Level in Front Final Drive, Checking”,
page 90 .
♦ Check transmission fluid level in the rear final drive. Refer to
⇒ “3 Rear Final Drive Axle Oil Level, Checking”, page 42 .
Fasteners
♦ Do not overstretch the circlips.
♦ Always replace damaged or stretched circlips.
♦ The circlips must fit completely inside the groove.
Bolts and Nuts
♦ Tighten and loosen the bolts and nuts for securing covers and
housings in a diagonal sequence.
♦ The tightening specifications stated apply to non-oiled nuts
and bolts.
♦ Always replace self-locking nuts and bolts.
♦ Make sure the contact surfaces and visible surfaces on the
nuts and bolts are waxed after assembling.
♦ Use a wire brush to clean the threads of bolts that were
screwed in with locking compound. Next, use Locking Fluid -
AMV 185 101 A1- to install the bolts.
♦ Threaded holes into which self-locking bolts or bolts coated
with locking fluid are screwed, must be cleaned (e.g. tap).
Otherwise there is a risk that the bolts will shear the next time
they are removed. Pay attention to the thread pitch when
cleaning with a thread cutter.
Bearings
♦ Install needle bearings with lettered side (thicker metal) racing
the fitting tool.
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
8 Rep. Gr.00 - General, Technical Data

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
34 – Controls, Housing
1 Specifications
⇒ “1.1 Fastener Tightening Specifications”, page 9
1.1 Fastener Tightening Specifications
Component Bolt Size Nm
Balance weight 1,2 - 32
Balance weight 1,3 - 50
Bracket to transfer case 4
- 20
-50 + 90°1
Transfer case 1- 20 + 90°
Transmission carrier 1- 50 + 90°
Transmission fluid filler plug on the transfer case 5- 20
•1 Replace
•2 For bolt tightening clarification, refer to ⇒ “2.1 Transfer Case Overview”, page 10 and see item -10-
•3 For bolt tightening clarification, refer to ⇒ “2.1 Transfer Case Overview”, page 10 and see item -11-
•4 For bolt tightening clarification, refer to
⇒ “3.1 Transmission Carrier and Console Overview”, page 17 and see items -4, 5 and 6-
•5 Insert the transmission fluid filler plug using Locking Fluid - AMV 185 101 A1-
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
1. Specifications 9

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
2 Transfer Case
⇒ “2.1 Transfer Case Overview”, page 10
⇒ “2.2 Transfer Case, Removing and Installing”, page 11
⇒ “2.3 Transfer Case, Transporting”, page 15
2.1 Transfer Case Overview
1 - Bolt
❑ Tightening specifica‐
tion, refer to -Item 7-
⇒ Item 7 (page 17) .
2 - Transmission Carrier
❑ Removing and Instal‐
ling. Refer to
⇒ “3.2 Transmission
Carrier and Console,
Removing and Instal‐
ling”, page 17 .
3 - Bolt
❑ Tightening specifica‐
tion, refer to -Item 6-
⇒ Item 6 (page 17) .
4 - Bolt
❑ 20 Nm + 90°
❑ Quantity: 12
❑ Replace
5 - Alignment Sleeve
❑ Quantity: 2
6 - Transfer Case
❑ Removing and Instal‐
ling. Refer to
⇒ “2.2 Transfer Case,
Removing and Instal‐
ling”, page 11 .
❑ Replace shaft seals.
Refer to
⇒ “5 Transfer Case
Shaft Seals”,
page 22 .
7 - O-ring
❑ Replace
❑ Diameter 28 mm
❑ Color: green
8 - Locking Ring
❑ Replace
❑ Diameter 28 mm
❑ Color: silver
9 - Balance Weight
❑ Installed depending on the version.
10 - Bolt
❑ 32 Nm
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
10 Rep. Gr.34 - Controls, Housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
❑ Self-locking
❑ Replace
11 - Bolt
❑ 50 Nm
❑ Self-locking
❑ Replace
12 - Balance Weight
❑ Installed depending on the version.
13 - Bracket
❑ Removing and Installing. Refer to
⇒ “3.2 Transmission Carrier and Console, Removing and Installing”, page 17 .
14 - Bolt
❑ Tightening specification, refer to -Item 4- ⇒ Item 4 (page 17) .
15 - Bolt
❑ Tightening specification, refer to -Item 5- ⇒ Item 5 (page 17) .
2.2 Transfer Case, Removing and Installing
Special tools and workshop equipment required
♦ Engine/Gearbox Jack - Gearbox Support - 3282-
♦ Engine/Gearbox Jack - VAG1383A-
♦ Counterhold - Kit - Multiple Use - T10172- with adapters -
T10172/6-
♦ Engine Support - Basic Set - T40091-
♦ -T40093/6- from the Engine Support - Supplement Kit -
T40093A-
♦ Grease for Clutch Disc Shaft Splines - G 000 100-
Removing
– Activate the vehicle lift mode if the vehicle has air suspension.
Refer to ⇒ Rep. Gr. 43 .
– Remove the rear drive axle. Refer to
⇒ “6.3 Rear Drive Shaft, Removing and Installing”,
page 52 .
– Remove the bolts and the rear noise insulation -2-.
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
2. Transfer Case 11

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
– Disconnect electrical connectors -1, 2, 3- from the transmis‐
sion.
Vehicles with a 3.0L TFSI Engine:
– Remove the bolts -1, 2 and 3-.
– Remove the bracket -4-.
Vehicles with a 3.0L TDI Engine:
– Remove bolts -arrows- on the particulate filter mount.
Vehicles with a 4.2L TDI Engine:
– Remove left and right bolts -arrows- on the particulate filter
mount.
All Vehicles:
– Remove the bolts -arrows- that connect the front driveshaft to
the transfer case.
– Use the Counterhold - Kit - Multiple Use - T10172- and adapt‐
ers -T10172/6- .
– Tie the front driveshaft to the body.
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
12 Rep. Gr.34 - Controls, Housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
– Slide the -T40093/6- onto the -T40091/1- .
– Slide the -T40091/1- into the -T40091/4- and -T40091/5- tight‐
en it with the bolts -arrows-.
– Tighten the adapter to the body using the bolts -A-.
• Tighten the left adapter -T40091/5- to 30 Nm with an M10 x
30 bolt.
• Tighten the right adapter -T40091/4- to 23 Nm with an M8 x
30 bolt and washer.
– Attach the Engine/Gearbox Jack - Gearbox Support - 3282- to
the transfer case with an M8 x 20 bolt -arrow A- and an M10
x 20 bolt -arrow B-.
– Attach the -3282/45- to the right Engine/Gearbox Jack - Gear‐
box Support with an M8 nut.
– Fit the -3282/45- onto the left Engine/Gearbox Jack - Gearbox
Support with a washer -1-.
– Remove the bolts -1 and 2- from the Engine/Gearbox Jack -
Gearbox Support.
– Lower the transfer case using the Engine/Gearbox Jack - VAG
1383A- to dimension -a-, between the body and the Engine/
Gearbox Jack - Gearbox Support -1-.
• -a- = approximately 50 mm
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
2. Transfer Case 13

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
– Install the -T40091/6- with the -T40091/7- in the -T40093/6- .
– Attach the -T40091/6- with the -T40091/8- to the automatic
transmission housing.
– Tighten the nut -A- to prevent the -T40091/6- from turning.
– Remove the bolts connecting the transmission to the transfer
case -arrows 1- and -arrows 2-.
– Remove the transfer case from the transmission.
– If replacing the transfer case, remove the Engine/Gearbox
Jack - Gearbox Support -arrows- and bracket -bolts 1 and 2-.
Refer to
⇒ “3.1 Transmission Carrier and Console Overview”,
page 17 .
Installing
Install in reverse order of removal. Note the following:
• Tightening specifications. Refer to
⇒ “2.1 Transfer Case Overview”, page 10 .
– Make sure the alignment sleeves fit correctly between the
transfer case and the transmission.
– Grease the splines on the transfer case and each transmission
drive axle with Grease for Clutch Disc Shaft Splines - G 000
100- .
– Be careful not to kink the lines when sliding the transfer case
and the transmission together.
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
14 Rep. Gr.34 - Controls, Housing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
– Align the transfer case bolting flange so that it is parallel to the
flange/transmission. To do this, adjust the transfer case via the
Engine/Gearbox Jack - Gearbox Support - 3282- spindles.
– Push the transfer case all the way onto the transmission mak‐
ing sure the drive axle splines/transfer case engage with the
output shaft/transmission.
Note
♦ If necessary turn the rear output flange/driveshaft back and
forth.
♦ If the tooth position is correct and it is guided centered, the
transfer case slides against the transmission as far as the stop.
♦ Do not pull the transfer case against the transmission by the
bolts otherwise the transfer case will tilt.
– Tighten the bolts -arrows 1- and -arrows 2- to the tightening
specification.
– Lift the transfer case slightly using the Engine/Gearbox Jack -
VAG 1383A- .
– Tighten the bolts -1 and 2- on the Engine/Gearbox Jack -
Gearbox Support. Refer to
⇒ “3.1 Transmission Carrier and Console Overview”,
page 17 .
– Attach the rear driveshaft with the new bolts to the transfer
case. Refer to
⇒ “6.3 Rear Drive Shaft, Removing and Installing”,
page 52 .
– Attach the front driveshaft to the transfer case with new bolts.
Refer to
⇒ “7.3 Front Driveshaft, Removing and Installing”,
page 105 .
– Install the exhaust system without tension. Refer to ⇒ Rep.
Gr. 26 .
– Install the rear noise insulation. Refer to ⇒ Rep. Gr. 50 .
– If the vehicle has air suspension, deactivate the lift mode. Re‐
fer to ⇒ Rep. Gr. 43 .
2.3 Transfer Case, Transporting
Special tools and workshop equipment required
♦ Engine/Gearbox Support Shackle (2 pc.) - 10-222A/12-
♦ Shop Crane - VAS 6100-
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
2. Transfer Case 15

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Procedure
– Attach the Engine/Gearbox Support Shackle (2 pc.) - 10-222A/
12- to the lifting eye on the transfer case, as illustrated.
– Attach the Shop Crane - VAS 6100- to the Engine/Gearbox
Support Shackle (2 pc.) - 10-222A/12- and lift the transfer case
off the Engine/Gearbox Jack - VAG 1383A- .
Audi Q7 2007 ➤
Transfer Case 0BU, Front Final Drive 0BM, 0C1 and 0BN, Rear Final Drive 0BP - Edition 12.2012
16 Rep. Gr.34 - Controls, Housing
