Audio Technica AT831b User manual

AT831b Cardioid Condenser
Lavalier Microphone
Broadcast & Production
Features
• Clip-on lavalier mic provides crisp, full-sounding voice pickup
• Also excels as an instrument mic, especially for pickup of acoustic guitar with
included AT8444 instrument adapter
• Excellent gain before feedback and suppression of background noise
• Cardioid polar pattern reduces pickup of sounds from the sides and rear,
improving isolation of desired sound source
• Oers the convenience of battery or phantom power operation
• Rugged design and construction for reliable performance
• UniSteep® filter provides a steep low-frequency attenuation to improve sound
pickup without aecting voice quality
Description
The AT831b is a miniature clip-on/lavalier condenser microphone with a cardioid
polar pattern. It is designed for quality sound reinforcement, professional recording,
television and other demanding sound pickup applications.
The microphone is intended to be worn on the clothing or used as an instrument
mic for excellent yet unobtrusive sound pickup. The wide-range capability of the
microphone ensures clean, accurate reproduction with high intelligibility for speakers
and presenters as well as for instrument pickup. Its small size makes it ideal for use in
applications where minimum visibility is required.
The microphone requires 11V to 52V phantom power or a 1.5V AA battery for
operation. A battery need not be in place for phantom power operation.
The microphone’s cardioid polar pattern provides a 120° angle of acceptance.
The microphone includes a 1.8 m (6') permanently attached miniature cable. Its free
end connects to the provided AT8531 power module via a TA3F-type connector. The
output of the power module is a 3-pin XLRM-type connector.
A 3-position switch in the power module permits choice of o, on/flat response or on/
low-roll-o (via integral 80 Hz high-pass UniSteep® filter). The roll-o position reduces
the pickup of low-frequency ambient noise.
The microphone comes equipped with a power module, a clothing clip, an instrument
adapter, a windscreen, a battery and a protective carrying case.
Operation and Maintenance
The AT831b requires 11V to 52V phantom power or a 1.5V AA battery for operation. A
battery need not be in place for phantom power operation.
To install the battery, remove the cap from the top of the power module. Insert a
fresh 1.5V AA battery (“+” end toward the cap release button), then reassemble the
power module. For longest battery life, the switch should remain o except when the
microphone is in use. Alkaline batteries are recommended for longest life. Remove
the battery during long-term storage.
Output is low impedance (Lo-Z) balanced. The signal appears across Pins 2 and 3;
Pin 1 is ground (shield). Output phase is “Pin 2 hot”—positive acoustic pressure
produces positive voltage at Pin 2.
To avoid phase cancellation and poor sound, all mic cables must be wired
consistently: Pin 1-to-Pin 1, etc.
A 3-position switch in the power module permits choice of o, on/flat response, or
on/low-roll-o (via integral 80 Hz high-pass UniSteep® filter). The roll-o position
reduces the microphone’s sensitivity to popping in close vocal use. It also reduces the
pickup of low-frequency ambient noise (such as trac, air-handling systems, etc.),
room reverberation and mechanically coupled vibrations. To engage the UniSteep®
filter, slide the switch toward the “bent” line. To turn the microphone on without
engaging the UniSteep® filter, slide the switch toward the flat line.
For use as a lavalier, attach the microphone about six inches below the chin.
Anticipate movements that may cause the microphone to rub against or be covered
by clothing, and position the microphone to avoid it.
Avoid leaving the microphone in the open sun or in areas where temperatures exceed
110° F (43° C) for extended periods. Extremely high humidity should also be avoided.

AT831b
Audio-Technica Corporation
audio-technica.com
©2018 Audio-Technica P52749
Specifications
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚ 0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEND
Frequency in Hertz
Response in dB
10 dB
100
50 200 10k 5k
1k
500 2k 20k
Roll-off
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚ 0˚
150˚
120˚
90˚
30˚
60˚
12" or more on axis
LEGEND
Frequency in Hertz
Response in dB
10 dB
100
50 200 10k 5k
1k
500 2k 20k
Roll-off
frequency response: 40–16,000 Hz polar pattern
Fixed-charge back plate, permanently
polarized condenser
Cardioid
40-16,000 Hz
80 Hz, 18 dB/octave
Phantom: –44 dB (6.3 mV) re 1V at 1 Pa
Battery: –46 dB (5.0 mV) re 1V at 1 Pa
Phantom: 200 ohms
Battery: 270 ohms
Phantom: 135 dB SPL, 1 kHz at 1% T.H.D.
Battery: 121 dB SPL, 1 kHz at 1% T.H.D.
Phantom: 106 dB, 1 kHz at Max SPL
Battery: 92 dB, 1 kHz at Max SPL
65 dB, 1 kHz at 1 Pa
11-52V DC, 2 mA typical
1.5V AA/UM3
0.4 mA / 1200 hours typical (alkaline)
O, on-flat, on-roll-o
Microphone: 2.8 g (0.1 oz)
Power module: 139 g (4.9 oz)
Microphone: 25.0 mm (0.98") long,
10.2 mm (0.40") diameter
Power module: 84.0 mm (3.31") H x
63.0 mm (2.48") W x 22.0 mm (0.87") D
Power module: Integral 3-pin XLRM-type
1.8 m (6') long (permanently attached to
microphone), 2.6 mm (0.10") diameter,
2-conductor, shielded cable with TA3F-
type connector
M1
AT8531 power module; AT8419 clothing
clip; AT8444 instrument adapter; AT8116
windscreen; battery; protective carrying case
Element
Polar pattern
Frequency response
Low frequency roll-o
Open circuit sensitivity
Impedance
Maximum input sound level
Dynamic range (typical)
Signal-to-noise ratio1
Phantom power requirements
Battery type
Battery current / life
Switch
Weight
Dimensions
Output connector
Cable
Audio-Technica case style
Accessories furnished
In the interest of standards development, A.T.U.S.
oers full details on its test methods to other industry
professionals on request.
1 Pascal = 10 dynes/cm2= 10 microbars = 94 dB SPL
1Typical, A-weighted, using Audio Precision System One.
Specifications are subject to change without notice.
