Audio Technica ATH-CKS330XBT User manual

ATH-CKS330XBT
Wireless Headphones
User Manual
English
Safety precautions
Cautions for the product
Cautions for rechargeable battery
Notes on use
About water-resistant (drip-proof) performance
For a more comfortable Bluetooth communication experience
Part names and functions
Headphones
Remote controller
Accessories
Charging the battery
Power supply ON/OFF
Turning on the product
Turning off the product
Connecting via Bluetooth
Pairing a Bluetooth device
About pairing
Multipoint function
Connecting using multipoint
Wearing the product
Using the product
Listening to music
Power supply / control button operation
Volume button operation
Talking on the phone
Power supply / control button operation
Volume button operation
Low latency mode
Auto power off function
Indicator lamp display
Pairing
Connecting
Battery level
Charging
Voice guidance
Cleaning
Eartips
Eartip size
Replacing the eartips
Forced pairing mode / reset
If the product does not connect to a device (forced pairing mode)
If the product operates abnormally (reset)
Troubleshooting
Specifications
Headphones
Microphone
Communication specifications
Other
Trademarks

1
Although this product was designed to be used safely, failing to use it correctly may result in an accident. To ensure
safety, observe all warnings and cautions while using the product.
Cautions for the product
• Do not use the product near medical equipment. Radio waves may affect cardiac pacemakers and medical
electronic equipment. Do not use the product inside medical facilities.
• When using the product in aircraft, follow airline instructions.
• Do not use the product near automatic control devices such as automatic doors and fire alarms. Radio waves
may affect electronic equipment and cause accidents due to malfunction.
• Do not disassemble, modify or attempt to repair the product to avoid electric shock, malfunction or fire.
• Do not subject the product to strong impact to avoid electric shock, malfunction or fire.
• Do not handle the product with wet hands to avoid electric shock or injury.
• Disconnect the product from a device if the product begins to malfunction, producing smoke, odor, heat,
unwanted noise or showing other signs of damage. In such a case, contact your local Audio-Technica dealer.
• Do not allow the product to get wet to avoid electric shock or malfunction.
• Do not put foreign matter such as combustible materials, metal, or liquid in the product.
• Do not cover the product with a cloth to avoid fire or injury by overheating.
• Follow applicable laws regarding mobile phone and headphone use if using headphones while driving.
• Do not use the product in places where the inability to hear ambient sound presents a serious risk (such as at
railroad crossings, train stations, and construction sites).
• The product effectively shields external sound, so you may not hear sound around you clearly while wearing the
product. Adjust the volume to a level where you can still hear background sound and monitor the area around
you while listening to music.
• Store the eartips out of the reach of small children.
• When charging, make sure to use the included USB charging cable.
• Do not charge with devices that have quick-charge functionality (with a voltage of 5 V or more). Doing so may
cause the product to malfunction.
• To prevent damage to your hearing, do not raise the volume too high. Listening to loud sound for an extended
period may cause temporary or permanent hearing loss.
• Discontinue use if skin irritation results from direct contact with the product.
• If you begin to feel unwell while using the product, discontinue use immediately.
• When removing the product from your ears, check to make sure the eartips are still attached to the main unit. If
the eartips become lodged in your ears and you are unable to remove them, consult a physician at once.
• If you develop an itch from wearing the product, discontinue use.
Safety precautions

2
Safety precautions
Cautions for rechargeable battery
The product is equipped with a rechargeable battery (lithium polymer battery).
• If battery fluid gets into eyes, do not rub them. Rinse thoroughly with clean water such as tap water and consult
a doctor immediately.
• If battery fluid leaks, do not touch fluid with bare hands. If fluid remains inside the product, it may cause
malfunction. If battery fluid leaks, contact your local Audio-Technica dealer.
– If fluid gets in your mouth, gargle thoroughly with clean water such as tap water and consult a doctor
immediately.
– If your skin or clothing comes in contact with fluid, immediately wash the affected skin or clothing with water.
If you experience skin irritation, consult a doctor.
• To avoid leakage, generation of heat or explosion:
– Never heat, disassemble or modify the battery, nor dispose of it in a fire.
– Do not attempt to pierce with a nail, hit with a hammer or step on the battery.
– Do not drop the product or subject it to strong impact.
– Do not get the battery wet.
• Do not use, leave or store the battery in the following places:
– Area exposed to direct sunlight or high temperatures and humidity
– Inside of a car under the blazing sun
– Near heat sources such as heat registers
• Charge only with the included USB cable to avoid malfunction or fire.
• The internal rechargeable battery of this product cannot be replaced by the user. The battery may have reached
the end of its service life if the usage time becomes significantly shorter even after the battery has been fully
charged. If this is the case, the battery needs to be repaired. Contact your local Audio-Technica dealer for repair
details.
• When the product is disposed of, the built-in rechargeable battery needs to be discarded properly. Contact your
local Audio-Technica dealer to learn how to properly dispose of the battery.

3
Notes on use
• Be sure to read the connected device’s user manual before use.
• Audio-Technica will not be liable in any way for any loss of data in the unlikely event that such losses should
occur while using the product.
• On public transportation or in other public places, keep the volume low so as not to disturb other people.
• Minimize the volume on your device before connecting the product.
• When using the product in a dry environment, you may feel a tingling sensation in your ears. This is caused by
static electricity accumulated on your body, not by product malfunction.
• Do not subject the product to strong impact.
• Do not store the product in direct sunlight, near heating devices, or in hot, humid, or dusty places. Additionally,
do not allow the product to get wet.
• When the product is used for a long time, the product may become discolored due to ultraviolet light (especially
direct sunlight) and wear.
• If the product is placed in a bag while the USB charging cable is still connected, the USB charging cable may
become caught, severed, or broken.
• Make sure to hold the plug when connecting and disconnecting the USB charging cable. The USB charging
cable may become severed or an accident may occur if you pull on the cable itself.
• When you are not using the USB charging cable, disconnect it from the product.
• Do not charge the battery if the terminal of the USB charging cable is bent, loose, or damaged. Doing so may
cause heat generation, smoke emission, fire or electric shock.
• The magnetic clasp contains magnets. Do not bring a magnetic card close to the magnetic clasp. The card’s
magnetism may change and become unusable.
• Do not pull the magnetic clasp hard when attaching/removing it or adjusting the position. Doing so may damage
the cord.
• This product can be used to talk on the phone only when using a mobile telephone network. Support for
telephony apps that use a mobile data network is not guaranteed.
• If you use the product near an electronic device or transmitter (such as a mobile phone) which is not connected
with the product, unwanted noise may be heard. In this case, move the product away from the electronic device
or transmitter.
• If you use the product near a TV or radio antenna, noise may be seen or heard in the television or radio signal. In
this case, move the product away from the TV or radio antenna.
• To protect the built-in rechargeable battery, charge it at least once every 6 months. If too much time passes
between charges, the life of the rechargeable battery may be reduced, or the rechargeable battery may no longer
be able to be charged.
• Do not charge the battery when the battery jack or USB charging cable is wet. Corrosion of the battery jack or
USB charging cable may cause damage such as heat generation, smoke emission, fire, or electric shock.
• Charge the product in a well-ventilated place (10 to 35°C (50 to 95°F)) away from direct sunlight. Otherwise, the
battery may deteriorate, possibly resulting in shorter periods of continuous use or may fail to charge.
• If the product is wet with sweat, wipe off any moisture with a dry cloth before charging.
• Close the USB cap firmly after charging the product. Sweat or water may cause malfunction.

4
About water-resistant (drip-proof)
performance
• The water-resistant (drip-proof) performance is designed to protect the headphones if they get wet from rain, etc.
(equivalent to IPX2). JIS/IEC protection grade IPX2 means that the headphones are protected against water
droplets falling from above at a 15-degree angle. The headphones cannot be used in hot and humid places, such
as bathrooms.
• Although the product has water-resistant (drip-proof) capabilities equivalent to IPX2, the part where the sound
comes from is not water-resistant (drip-proof).
• Make sure to close the USB cap completely when using the product to maintain water-resistant (drip-proof). If
the USB cap is not closed completely, water may enter inside.
• The headphones are not waterproof. Submerging them in water may cause damage.

5
The effective communication range of this product varies depending on obstructions and radio wave conditions. For
a more enjoyable experience, please use the product as close as possible to the Bluetooth device. To minimize noise
and sound disruptions, avoid placing your body or other obstacles between the product’s antenna and the Bluetooth
device.
1
1
Antenna
For a more comfortable Bluetooth
communication experience

6
Part names and functions
Headphones
7
2 1
3
4
5
6
1Housing
2Left/right (L/R) indicator
3Bushing
4Magnetic clasp
5Neckband
6Microphone (for calls)
7Protrusion
The left bushing has a protrusion for distinguishing between the left and right.

7
Part names and functions
Remote controller
21
4
3
5
1Power supply / control button
Use to turn the power supply ON/OFF, play/pause music, and answer phone calls.
2Indicator lamp
Displays the operating status and battery level of the product.
3Volume buttons
Use to adjust the volume up or down (+/–).
4Battery jack
Use to connect the included USB charging cable and charge the product.
5USB cap

8
Part names and functions
Accessories
21 3
1USB charging cable (30cm (12"), USB Type-A / USB Type-C)
2Eartips (XS, S, M, L)
At the time of purchase, the M-size eartips are attached to the product.
3Magnetic clasp
The magnetic clasp is attached to the main unit at the time of purchase.

9
Charging the battery
• Fully charge the battery when using for the first time.
• When the rechargeable battery is running low, the voice guidance will play the message “Low battery”, and the
indicator lamp will flash in red. Charge the battery as soon as possible.
• It takes about 2 hours to charge the battery fully. (This time may vary depending on usage conditions.)
• When charging the product, charge it in a well-ventilated place (10 to 35°C (50 to 95°F)) away from direct
sunlight. Otherwise, the battery may deteriorate, possibly resulting in shorter periods of continuous use or failure
to charge.
1 Open the battery jack USB cap.
2 Connect the included USB charging cable (USB Type-C side) to the battery jack.
• The included USB charging cable is designed for exclusive use with the product. Do not use any other
USB charging cable.
• When inserting the USB charging cable into the USB port or battery jack, insert it directly (horizontally).
1 2
1USB Type-A
2USB Type-C
3 Connect the included USB charging cable (USB Type-A side) to the computer to start charging.
• While charging, the indicator lamp lights as follows. (It may take several seconds for the indicator lamp to
light.)
Indicator lamp Status
Lit red Charging
Off Charging complete
Flashing red Charging error[1]
[1] Charge the product in a well-ventilated place (10 to 35°C (50 to 95°F)) away from direct sunlight.
4 When charging is complete, disconnect the USB charging cable (USB Type-A side) from the
computer.
5 Disconnect the USB charging cable (USB Type-C side) from the battery jack and close the USB cap
firmly.

10
Charging the battery
• If you start to charge while the product is on, it will automatically turn off.
• When charging, make sure to use the included USB charging cable. The product may not charge with
cables other than the included USB charging cable.

11
Power supply ON/OFF
Turning on the product
1 Press and hold the power supply / control button (for about 3 seconds).
The indicator lamp lights in white, and then flashes. Voice guidance is played.
• It may take several seconds for the indicator lamp to light.
• See “Voice guidance” (p.21) for more information on voice guidance.
Turning off the product
1 Press and hold the power supply / control button (for about 3 seconds).
The indicator lamp lights in white, and then turns off.

12
Connecting via Bluetooth
To connect the product to a Bluetooth device, the product needs to pair (register) with the device.
Pairing a Bluetooth device
• Read the user manual for the Bluetooth device.
• Place the Bluetooth device within 1 m (3.3') of the product to perform pairing correctly.
• Wear the product to hear voice guidance during pairing.
1 Starting with the product turned off, turn it on.
• The indicator lamp will light in white, and then flash in white.
2 Use your Bluetooth device to begin the pairing process and search for the product. When your
Bluetooth device finds the product, “ATH-CKS330XBT” will be displayed on the device.
• For information about using your Bluetooth device, refer to the device’s user manual.
3 Select “ATH-CKS330XBT” to pair the product and your Bluetooth device.
• Some devices may ask for a passkey. In this case, enter “0000”. The passkey may also be called a
passcode, PIN code, PIN number, or password.
Bluetooth ON
ATH-CKS330XBT
The voice guidance will play the message “Bluetooth connected”, and the indicator lamp will
flash slowly in white. This indicates pairing was successfully completed.
About pairing
When connecting a new Bluetooth device, you need to pair it with the product. Once the Bluetooth device and the
product are paired, you do not need to pair them again. The product supports multipairing, in which a connection
history is saved. However, in the following cases you will need to pair again even if the Bluetooth device was paired
once:
• If the product is deleted from the Bluetooth device’s connection history.
• If the product is sent out for repair.

13
Connecting via Bluetooth
Multipoint function
The product supports multipoint, which allows two Bluetooth devices to be connected at the same time. While you
are listening to music with one device, you can answer a call that comes in from the other device. It is convenient if
you have two smartphones, for example.
• Audio-Technica does not guarantee the operation of all combinations of Bluetooth devices.
Connecting using multipoint
1 Pair with the first Bluetooth device.
2 After pairing with the first device, turn off its Bluetooth feature.
3 Pair with the second Bluetooth device.
4 Turn on the Bluetooth feature of the first Bluetooth device.
• If the product does not connect, restart its power.
• Up to two Bluetooth devices can be connected at the same time with multipoint. To connect a third
Bluetooth device, disconnect one of the connected devices.

14
Insert the side of the product marked “L” (left) into the left ear and the side marked “R” (right) into the right ear.
• When you are not using the product, you can use the included magnetic clasp to hold the left and right cables
together.
1
1Magnetic clasp
• The magnetic clasp contains magnets. Keep the magnetic clasp away from magnetic objects such as
credit cards. Failure to do so may change the card’s magnetic properties and render it unusable.
• Do not pull with excessive force when attaching/removing the magnetic clasp or when adjusting its
position. Doing so may damage or break the cable.
Wearing the product

15
Using the product
The product can use Bluetooth wireless technology to connect to your device and play music, receive phone calls,
etc. Use the product for whichever of these purposes suits your needs. Note that Audio-Technica cannot guarantee
the operation of displays, such as the battery level display, or applications via Bluetooth devices.
Listening to music
• To connect for the first time, pair the product and your device via Bluetooth wireless technology. If you have
already paired the product and your Bluetooth device, turn on the Bluetooth device’s Bluetooth connection
before turning on the product.
• Use your Bluetooth device to start playback, referring to the device’s user manual as necessary.
1 Turn on the product and insert the product in your ears.
2 Start playback on your Bluetooth device.
3 Adjust the volume by pressing the volume buttons (+/–).
4 Press the power supply / control button to stop playback.
• Playback will be started or stopped with every press.

16
Using the product
Power supply / control button operation
1
1Power supply / control button
Operation Function
Press Starts or pauses playback.
Press (twice)
Depending on the connected device, activates the device’s
speech recognition function (such as Siri for compatible iOS
devices).
• The controls explained above may not be available on some smartphones.
Volume button operation
1
1
Volume buttons
Operation Function
Press Increases/decreases the volume by 1 level. [1][2]
Press and hold (about 2 seconds) Plays the next/previous track.
[1] A beep is heard when the volume is at the maximum or minimum level.
[2] The volume control of some Bluetooth devices may not work well with the product.
• The controls explained above may not be available on some smartphones.

17
Using the product
Talking on the phone
If your Bluetooth device supports telephone features, you can use the product to talk on the phone.
1 Turn on the product and insert the product in your ears.
2 Make/receive calls with your Bluetooth device.
• When your Bluetooth device receives a phone call, the product sounds a ringtone.
• If a call is received while you are listening to music, music playback is paused.
3 Adjust the volume by pressing the volume buttons (+/–).
4 Press the power supply / control button to end the call.
• If the call was received while listening to music, playback is resumed.
• Music playback may not be resumed on some Bluetooth devices. In this case, music playback must be
started manually.

18
Using the product
Power supply / control button operation
1
1Power supply / control button
Operation Function
Press Answers the call.
Ends the call.
Press and hold (about 2 seconds)
Rejects the call when pressed and held.
When pressed and held during a call, the call switches between
the product and your Bluetooth device. [1]
[1] When you hear a confirmation tone, release the power supply / control button.
• The controls explained above may not be available on some smartphones.
Volume button operation
1
1
Volume buttons
Operation Function
Press Increases/decreases the call volume by 1 level.
• The controls explained above may not be available on some smartphones.

19
Using the product
Low latency mode
Low latency mode reduces sound delay when playing games or watching videos.
• Bluetooth communication can be easily affected by obstacles and radio wave conditions.
1 Press the power supply / control button three times in a row.
With every three presses, the voice guidance will play the message “Low latency mode” or
“Low latency mode off”, and low latency mode will be switched ON/OFF.
• Low latency mode cannot be switched ON/OFF during a call or during voice input using the speech
recognition feature.
Auto power off function
The product automatically turns off after 5 minutes of not being connected to a device. The product also
automatically turns off after 30 minutes in the “Waiting to be connected” status.
