AUDIOACCESS
MA-362
TWELVE CHANNEL AMPLIFIER
PRELIMINARY SERVICE MANUAL
Harman Consumer Group
250 Crossways Park Dr.
Woodbury, New York 11797

MA-362
Audioaccess®
Twelve
Channel
Amplifier
www.audioaccess.com
The Audioaccess MA-362 Twelve
Channel Amplifier represents a high value
approach while providing twelve channels
of clean amplifier power for multi-room
system applications.
Power to Spare
With a power rating of 50 Watts per
channel at 8 Ohms from 20Hz to 20kHz
with less than .05% THD, the MA-362
will drive virtually any in-wall loudspeaker
to room filling volume. Power into 4
Ohms is even more impressive at 75
Watts per channel. All channels may be
bridged if additional power is required.
Cool operation is ensured with a design
incorporating heat sinks, flow through
ventilation and low-noise fans.
After a series of careful evaluations
and tests, Madrigal has chosen to imple-
ment a conservative and proven design
philosophy with the MA-362 with the
added benefit of improved sound quality
and long component life. Power for each
channel is delivered by a pair of high
current output transistors capable of
delivering over 200 watts, much higher
power than the rated 50 watts per chan-
nel. For example, the output transistors
for each channel can handle up to 12
amps. At rated power, the MA-362 is
drawing only about 3 amps of current per
channel, ensuring its reliable performance.
Control Capabilities
Each pair of channels is controlled by a
Trigger Source Selector, a three-position
switch that selects signal sensing, voltage
trigger input or link (to the trigger signal
of the zone to the immediate left) as the
source for muting control within each
individual zone. A two position Signal Link
Selector, is also provided and is
used to link a zone to the Signal Input
connector of the zone to its left.
Installation Flexibility
Ease of installation, a hallmark of all
Audioaccess products is maintained in the
new MA-362. An external speaker termi-
nation board can be ordered in advance
to allow the installing dealer to “pre-wire”
all of the loudspeakers in the system before
the amplifier is delivered for final installa-
tion. Final hook up consists of plugging
the speaker termination board into a slot
in the rear panel of the amplifier.
Summary
The MA-362 features, performance
and reliability make it the perfect
amplifier choice for a wide variety of
multi-room audio system applications.
Simply Ingenious

A Harman International Company
Audioaccess®
Madrigal Audio Laboratories, Inc.
P.O.Box 781
Middletown, CT 06457-0781
Internet: www.madrigal.com
Fax: [phone] ©2002 Madrigal Audio Laboratories, Inc.
20202AA – SS/MA-362
Specifications
▲Rack mountable chassis
▲Discrete amplifier design for improved
sound quality
▲Signal Input Connector: six dual RCA jacks,
one per two channel
▲Four position switch to select Stereo, Bridged
Right, Bridged Left, or mono operation for
each zone
▲Independent level controls for each amp channel
▲Trigger Input, euro-style connector, accepts 3
to 24V AC or DC, to “unmute” amp channels
in the zone
▲Trigger Source Selector: three position switch
to select signal sensing, voltage trigger input
or link (to the trigger signal of the zone to the
immediate left) to control muting in the zone.
▲Plug-in Speaker Termination Board, a snap for
advance installations (available separately, not
included with the amplifier)
▲Signal Link Selector: two position switch to
link a zone to the signal input connector of
the zone to its left (excluding zone 1)
▲Power Switch on Front panel
▲Bi-color LED Power Indicator
Features
▲Number of Channels: 12, configured as 6
left/right pairs (zones)
▲Power Output (Unbridged): 50W @ 8Ω,
75W @ 4Ω, 20 - 20k Hz, All Channels Driven
▲Power Output (Bridged): 150W @ 8Ω,
20 - 20k Hz, All Channels Driven
▲THD+Noise: <0.05%, at rated power,
20 - 20k Hz
▲IMD: <0.05% (SMPTE)
▲Frequency Response: 20 - 20k Hz,
+0/-0.2 dB, at rated power, 4Ωload
▲Bandwidth: 5 – 75k Hz. +0, -3dB, at rated
power, 4Ωload
▲S/N: >100dB unweighted (ref: Rated Power),
unbridged into 8Ω
▲Crosstalk: <-70 dB (ref: Maximum Output)
between any two channels (no audible
crosstalk)
▲Protection: Short Circuit, Over Current, DC,
Thermal
▲Muting: Turn on, Turn off, Signal Sensing, and
Triggered per zone
▲Input impedance: 24kΩ
▲Input Sensitivity: 1.0 Vrms (with input trim at
minimum attenuation)
▲Input Level Trim Range: 20dB
▲Gain: 26dB
Dimensions and weight:
▲Height: 7" (178 mm)
(4 rack spaces, not including feet)
▲Width front panel: 19" (483 mm),
Width chassis: 1711⁄16" (450 mm)
▲Depth: 1711⁄16" (450 mm)
▲Weight: 60 lb (27.2 kg) (without carton)
Features, specifications and dimensions are subject to change.
Audioaccess TI-501 Speaker Termination Board (Sold separately)

FEATURES
The Audioaccess MA-362 Twelve Channel Amplifier represents a high value approach while providing twelve channels of
clean amplifier power for multi-room system applications.
Power to Spare
With a power rating of 50 Watts per channel at 8 Ohms from 20Hz to 20kHz with less than .05% THD, the MA-362 will
drive virtually any in-wall loudspeaker to room filling volume. Power into 4 Ohms is even more impressive at 75 Watts per
channel. All channels may be bridged if additional power is required. Cool operation is ensured with a design
incorporating heat sinks, flow through ventilation and low-noise fans. After a series of careful evaluations and tests,
Madrigal has chosen to implement a conservative and proven design philosophy with the MA-362 with the added benefit
of improved sound quality and long component life. Power for each channel is delivered by a pair of high current output
transistors capable of delivering over 200 watts, much higher power than the rated 50 watts per channel.
The output transistors for each channel can handle 12 amps of current. At rated power, the MA-362 draws 2.5 amps of
current, ensuring ample safe operating area headroom and reliable performance.
Zone Muting Control
Each pair of channels is controlled by a three-position Trigger Source switch to select signal sensing, voltage trigger or
link (to the trigger signal of the zone to the immediate left).
Unique Input Bussing
A two position Signal Link switch is also provided for each zone. This allows assignment of direct input to the zone, or to
share the source utilized by the zone to its left, eliminating the need for Y-cords to distribute common inputs to multiple
zones.
Installation Flexibility
Ease of installation, a hallmark of all Audioaccess products is maintained in the new MA-362. An external speaker
termination board can be ordered in advance to allow termination of loudspeakers before the amplifier is delivered for final
installation. At final, simply plug the speaker termination board onto the rear panel of the amplifier.
Summary
The MA-362 features, performance and reliability make it the perfect amplifier choice for a wide variety of multi-room
audio system applications.
Specifications:
• Number of Channels: 12, configured as 6 left/right pairs (zones)
• Power Output (Unbridged): 50W @ 81Ú2,
• 75W @ 41Ú2, 20 - 20k Hz, All Channels Driven
• Power Output (Bridged): 150W @ 81Ú2,
• 20 - 20k Hz, All Channels Driven
• THD+Noise: <0.05%, at rated power,
• 20 - 20k Hz
• IMD: <0.05% (SMPTE)
• Frequency Response: 20 - 20k Hz, +0/-0.2 dB, at rated power, 41Ú2 load
• Bandwidth: 5 — 75k Hz. +0, -3dB, at rated power, 41Ú2 load
• S/N: >100dB unweighted (ref: Rated Power), unbridged into 81Ú2
• Crosstalk: <-70 dB (ref: Maximum Output) between any two channels (no audible crosstalk)
• Protection: Short Circuit, Over Current, DC, Thermal
• Muting: Turn on, Turn off, Signal Sensing, and Triggered per zone
• Input impedance: 24k1Ú2
• Input Sensitivity: 1.0 Vrms (with input trim at minimum attenuation)
• Input Level Trim Range: 20dB
• Gain: 26dB

• Dimensions and weight:
Height: 7" (178 mm) (4 rack spaces, not including feet)
Width front panel: 19" (483 mm), Width chassis: 17 1/16" (450 mm)
Depth: 17 1/16" (450 mm). Weight: 60 lb (27.2 kg) (without carton)
Features, specifications and dimensions are subject to change.

MA362
Electrical/Mechanical Parts Lists
Note:
These parts lists may contain some part
numbers that are not valid, or No Longer
Available.
Descriptions and Reference Designators,
when included, should aid technicians in part
substitution.
If necessary, call the Parts department at
1-516-496-3400 ext. 6553 for assistance.

MA-362 Parts List
Parts No. Description Q'ty Designator
92-V1003 ASS'Y PCB- PX1275 MAIN AMP PCB 6 KIT
11-3/CQ203SP FUSE CLIP CQ-203SP FOR 5MM FUSE 24 EA F1,F2
ADB-KBPC602 DIODE BRIDGE KBPC602 200V 6A 6EA D1
AIC-TL071 IC TL071(TI) 12 EA U3,U4
AIC-TL072 IC TL072(JRC-NJM) 6EA U2
ARL-02-R002 RELAY 24V DPDT TRIH-24VDC-SB-2CM 6EA K1
ATR-2SB649A TR.2SB649A 12 EA Q13,14
ATR-2SB817E TR.B817E/SANKEN A1492) 2EA Q17,18
ATR-2SD1047E TR.D1047E/SANKEN C3856 2EA Q15,16
ATR-2SD669A TR.2SD669A 12 EA Q11,12
CN1-L25002-010 CNTR MALE L 2.5mm 2P EH A2502WR2 12 EA CN208B,GND
CN1-L25003-010 CNTR MALE L 2.5mm 3P EH A2502WR2 6EA CN16A
CN1-L50803-001 CNTR WAFER L 5.08mm 3P(5081-WR) 6EA CN15
CN5-OT7007M-02-G 2P header 6EA CN100
CNA-RMC003 CNTR MALE 1P L 6.3 PIN(G20) 24 EA CN11A-14A
ECE-050V688M-HP CAP ELE 50V 6800uF +-20% 22*51 105 12 EA C41,42
ELC-02-7001 COIL CHK 2uH +-10% L-R2U 12 EA L5,L6
ERB-102K152J RES MO 1W K 1K5 +-5% 15mm 12 EA R33,34
ERB-102K4R7J RES MO 1W K 4R7 +-5% 15mm 24 EA R47,48,49,50
ERB-202K122J-S RES MO 2W K 1K2 +-5% 15mm 12 EA R85,86
ERB-202PR10J RES MO 2W P 0.1 +-5% 24 EA R39,40,105, 106
ERB-251K101J RES MO 1/4W K 100 +-5% 6EA R93
ERB-251K222J RES MO 1/4W K 2K2 +-5% 12 EA R23,24
ERB-251K331J RES MO 1/4W K 330 +-5% 12 EA R37,38
ERB-251K470J RES MO 1/4W K 47 +-5% 36 EA R19,20,25,26 ,29,30
ERB-251K471J RES MO 1/4W K 470 +-5% 30 EA R17,18,35,36 ,84
ERB-251K681J RES MO 1/4W K 680 +-5% 12 EA R27,28
ERV-S06-501B01 VR SEMI ST S 6MMD 500B 12 EA VR3,VR4
FUS-07-6301S FUSE 5*20mm T6.3A/250V UTE 12 EA F1,F2
TRL-7002 THERMAL PROTECTOR 17AM024A5 6EA S3
WAS-R1068 WIRE ASY #28 2547 2P 200MM EH /G 6EA CN7B(R-CH)
WAS-R1069 WIRE ASY #24 2468 3P 100MM EH 6EA CN8B
WAS-R1070 WIRE ASY #28 2547 2P 150MM EH GRY 6EA CN9B(L-CH)
WAS-R1071 WIRE ASY #24 2468 6P 100MM EH 6EA CN10B
92-V1004
A
ASS'Y PCB-VAC1004A PX1275 I/O PCB 1 KIT
AIC-LF353 IC OP LF353N NS (DIP) 3EA U1
AIC-4N25 IC OPTOCOUPLER 4N25 3EA U5
CN5-OT058 CNTR SINGLE ROW L 3P 6EA CN2
ECQ-100V104J CAP MPP 100V 0.1u +-5% 3EA C53,54
ECE-025T106M-SK CAP ELE 25V 10uF +-20% 4*7 105C 6EA C3,4
ECE-050T225M-SK CAP ELE 50V 2.2uF +-20% 4*7 105C 3EA C51
JK3-S02-R002 JACK RCA S 2P 0860B-302-531 3EA JK1
SWS-R007 SW SLIDE 2P2T SS001-P022BQb-PA6 2EA S1
SWS-R008 SW SLIDE 2P3T SS016-P223MA-PB6 3EA S4
SWS-R009 SW SLIDE 4P4T SS001-P244Ojb-PA6 3EA S2
VRR-R023 VR ROT 10KA RD0971110046-11-15KQ 6EA VR1,VR2
TML-R0001 Mini T BLOCK HD515V-2P BLK 3EA CN5
TML-R0002 Mini T BLOCK HD515H-2P BLK 3EA CN5
CN1-L25002-010 CNTR MALE L 2.5mm 2P EH A2502WR2 3EA CN9A(L-CH)
CN1-L25002-011 CNTR MALE L 2.5mm 2P EH RED 3EA CN7A(R-CH)
CN1-L25003-010 CNTR MALE L 2.5mm 3P EH A2502WR2 3EA CN8A
CN1-L25006-010 CNTR MALE L 2.5mm 6P EH A2502WR2 2EA CN10A(ZONE 1 /3)
CN1-S25006-010 CNTR MALE S 2.5mm 6P EH A2502WV2-6 1EA CN10A(Rear Solder) ZONE 2 ONLY

TU2-S9010-100 TUBING S1 1mmD 10mm 6 PCS C53,54
WAS-R1067 WIRE ASY #24 2468 2P 50MM EH 1EA CN6A(ZONE 3)
WAS-R1072 WIRE ASY #24 2468 3P 50MM EH 1EA CN1A(ZONE 3)
91-V1004 ASS'Y PCB-VAC1004 I/O PCB AUTO INS 1 KIT
90-V1004 Bare I/O PCB FR4 180*87*1.6MM PX-1275 1EA
ECQ-100T104J CAP MPP 100V 0.1u +-5% TAP 3EA C53,54
ECQ-100T331J CAP PPNM 100V 330P +-5% TAP 6EA C1,2
ADD-1N4148*TAP52 DIODE Sw/ 1N4148 TAPING 52MM 3EA D17
ADD-1N4004*TAP52 DIODE RECTI 1N4004 TAPING 52MM 6EA D200,201
ELC-08-R001 COIL FER FB3560ST-650 6EA L1,L2
ERC-121Y102J RES CF 1/8W Y 1K +-5% 12 EA R1,2,97,98
ERC-121Y122J RES CF 1/8W Y 1.2K +-5% 6EA R7,8
ERC-121Y222J RES CF 1/8W Y 2K2 +-5% 6EA R200,69
ERC-121Y223J RES CF 1/8W Y 22K +-5% 9EA R70,71,72
ERC-121Y473J RES CF 1/8W Y 47K +-5% 12 EA R5,6,95,96
W00-22005 WIRE TINNER COPPER #22 5MM 3EA JP1.JP3,JP4
W00-22010 WIRE TINNER COPPER #22 10MM 3EA L3
92-V1004B ASS'Y PCB-VAC1004B PX1275 I/O PCB 1 KIT
AIC-LF353 IC OP LF353N NS (DIP) 3EA U1
AIC-4N25 IC OPTOCOUPLER 4N25 3EA U5
CN5-OT058 CNTR SINGLE ROW L 3P 6EA CN2
ECQ-100V104J CAP MPP 100V 0.1u +-5% 3EA C53,54
ECE-025T106M-SK CAP ELE 25V 10uF +-20% 4*7 105C 6EA C3,4
ECE-050T225M-SK CAP ELE 50V 2.2uF +-20% 4*7 105C 3EA C51
JK3-S02-R002 JACK RCA S 2P 0860B-302-531 Red/White 3EA JK1
SWS-R007 SW SLIDE 2P2T SS001-P022BQb-PA6 3EA S1
SWS-R008 SW SLIDE 2P3T SS016-P223MA-PB6 3EA S4
SWS-R009 SW SLIDE 4P4T SS001-P244Ojb-PA6 3EA S2
VRR-R023 VR ROT 10KA RD0971110046-11-15KQ 6EA VR1,VR2
TML-R0001 Mini T BLOCK HD515V-2P BLK 3EA CN5
TML-R0002 Mini T BLOCK HD515H-2P BLK 3EA CN5
CN1-L25002-010 CNTR MALE L 2.5mm 2P EH A2502WR2 3EA CN9A(L)
CN1-L25002-011 CNTR MALE L 2.5mm 2P EH RED 3EA CN7A(R)
CN1-S25002-010 CNTR MALE S 2.5mm 2P EH A2502WV2 1EA CN6B(ZONE4)
CN1-L25003-010 CNTR MALE L 2.5mm 3P EH A2502WR2 3EA CN8A
CN1-S25003-010 CNTR MALE S 2.5mm 3P EH A2502WV2 1EA CN1B(ZONE4)
CN1-L25006-010 CNTR MALE L 2.5mm 6P EH A2502WR2 3EA CN10A
TU2-S9010-100 TUBING S1 1mmD 10mm 6 PCS C53,54
91-V1004 ASS'Y PCB-VAC1004 I/O PCB AUTO INS 1 KIT
90-V1004 Bare I/O PCB FR4 180*87*1.6MM PX-1275 1EA
ECQ-100T104J CAP MPP 100V 0.1u +-5% TAP 3EA C53,54
ECQ-100T331J CAP PPNM 100V 330P +-5% TAP 6EA C1,2
ADD-1N4148*TAP52 DIODE Sw/ 1N4148 TAPING 52MM 3EA D17
ADD-1N4004*TAP52 DIODE RECTI 1N4004 TAPING 52MM 6EA D200,201
ELC-08-R001 COIL FER FB3560ST-650 6EA L1,L2
ERC-121Y102J RES CF 1/8W Y 1K +-5% 12 EA R1,2,97,98
ERC-121Y122J RES CF 1/8W Y 1.2K +-5% 6EA R7,8
ERC-121Y222J RES CF 1/8W Y 2K2 +-5% 6EA R200,69
ERC-121Y223J RES CF 1/8W Y 22K +-5% 9EA R70,71,72
ERC-121Y473J RES CF 1/8W Y 47K +-5% 12 EA R5,6,95,96
W00-22005 WIRE TINNER COPPER #22 5MM 3EA JP1.JP3,JP4
W00-22010 WIRE TINNER COPPER #22 10MM 3EA L3
92-V1005 ASS'Y PCB-VAC1005 PX1275 STB PCB 1 KIT
90-V1005 STB PCB FR4 190*66*1.6MM PX-1275 1EA
TML-R0003 MOLEX 15-24-7240(42385) HEADER 1EA CN12
TML-R0008 TML BLOCK 12P EK950V-12P-BK 2EA P1-P4,P5-P8
RM07P0019 INSULATOR FR700+9448 66*46.5*0.7 B 1EA
92-V1006 ASS'Y PCB-VAC1006 PX1275 AC PCB 1 KIT

90-V1006 AC PCB FR4 181.2*63.3*1.6MM PX-127 1EA
ADD-1N4004*TAP52 DIODE RECTI 1N4004 TAPING 52MM 1EA D101
ADD-1N4148*TAP52 DIODE Sw/ 1N4148 TAPING 52MM 4EA D103,104,107 ,108
ADZ-UZ4-3BM DIODE ZENER UZ-4.3BM 1/2W 4.1V-4.5 2EA D102,105
ATR-BF422 TR BF422 TAPING 1EA Q101
ECE-050T476M-KM CAP ELE 50V 47uF +-20% 105C 6.3*11 1EA C104
ECW-275V472K X-CAP HQX 0.0047uF/275V P=10MM 1EA C202
ECW-400V472M CAP Y-SUPPRESSOR 400V 4700pF +-20% 1EA C203
ERC-251Y103J RES CF 1/4W Y 10K +-5% 1EA R100
ERC-251Y223J RES CF 1/4W Y 22K +-5% 1EA R103
ERB-202K122J RES MO 2W K 1K2 +-5% 20mm 1EA R104
ERB-202K152J RES MO 2W K 1K5 +-5% 20mm 1EA R101
ELC-09-R002H COIL CM-MODE 0.75mH E-7243H RING C 1EA L201
11-3/CQ203SP FUSE CLIP CQ-203SP FOR 5MM FUSE 8EA F201-204
FUS-07-4001S FUSE 5*20mm T4A/250V UTE 4EA F201-204
CN1-L50802-001 CNTR WAFER L 5.08mm 2P(5081-WR) 7EA CN211B,212B, 213A,230_1,230_2,115_1,115_2
CN1-L50803-001 CNTR WAFER L 5.08mm 3P(5081-WR) 2EA CN200_1,200_ 2
CN1-S50802-001 CNTR WAFER S 5.08mm 2P(5081-WR) 2EA CN211A,212A
WAS-R1075 WIRE ASY 2P #24 2468 350MM EH 1EA CN208A-ZONE 3 CN208B
WAS-R1076 WIRE ASY 2P #24 2468 400MM EH 1EA CN209A-ZONE 2 CN208B
SWP-R003 SW PW PUSH TV-8 8212 CHILY 1EA S201
51-LM0615050 NTC THERMIXTOR LM0615050 2EA RT101,102
ARL-02-R001 RELAY 24V SPDT TRIH-24VDC-SB-1CE 1EA K201
92-V1007 ASS'Y PCB-VAC1007 PX1275 FAN PCB 1 KIT
90-V1007 FAN PCB CEM-1 44*84*1.6MM PX-1275 1EA
ATR-BC337-40 TR BC337-40 1EA Q304
ATR-BC556B TR BC556B TAPING 4EA Q301-303,305
ADZ-UZ12BM DIODE ZENER UZ-12BM 12V 1EA D301
ADD-1N4004*TAP52 DIODE RECTI 1N4004 TAPING 52MM 2EA D302,303
ERB-202P101J RES MO 2W P 100 +-5% 1EA R303
ERB-202P470J RES MO 2W P 47 +-5% 1EA R302
ERC-121Y223J RES CF 1/8W Y 22K +-5% 3EA R304,305,307
ERC-121Y562J RES CF 1/8W Y 5.6K +-5% 3EA R301,306,308
ECE-025T107M-SK CAP ELE 25V 100U +-20% 8*7 105C 1EA C301
TRL-R004 THERMALSTAR U-A HT1+FB5 NO 65C 2EA S301,302
CN1-S25002-010 CNTR MALE S 2.5mm 2P EH A2502WV2 4EA CN301,304A, 305A,306
CN1-S25402-702 CNTR MALE S 2.54MM 2P(XH) 3EA CN302,303,30 7
WAS-R1083 WIRE ASY 2P #24 300MM RED/BLK 2EA CN304A-304B, 305A-305B
WAS-R1084 WIRE ASSY 1P #22 100MM W/T250 RED 2EA S301
WAS-R1085 WIRE ASSY 1P #22 100MM W/T250 BLK 2EA S301
V
AC014-01/C1 MECH PARTS COMMON VAC014-01 1 KIT
501798 front panel, 482 mm, for model 1275
15060245 Plastic housing Molex mini-fit, 24-pin connector
15247240 Molex mini-fit plug, 24-pin
560041R3 transformer, tto-10051-03(24.4v-0-24.4v/4.8A)x3, 1275
3018-0070 Main chassis, 5/1500, 1250R/S, 1275
3018-0066 Rear panel, model 1275
3018-0003 top cover, 5/1500,1250R,1250S
3018-0005 front sub-panel 5/1500,1250R/S
RM05A1001 HANDLE PX1275 L-15004.BL 2EA REAR PANEL
RM05S1001 BKT FOR SINK PX1275 3018-0086 2EA SINK BKT
RM05S1005 BKT FOR PW SW 3018-0088 PX1275 1EA PW SW
RM05S1004 BKT FOR AC BOARD PX1275 4TTU-13 2EA
RM05S1003 BKT FOR XMER PX1275 3018-0020 2EA XMER
RM04B1001 BOSS M3*12 4EA I/O BOARD
71-JK/2AC-008A08 AC SOCKET 2AC-008A0810 1 pcs JK201
SM3R0+06SFB SCREW MACHINE 3*6 FLAT BLK 2EA ACIN*2 *2
SS3R0+06SBB SCREW TRIANGLE 3*6 BIND BLK 6EA I/O*4,ACB*2,

SM3R0+06SPB SCREW MACHINE 3*6 PAN BLK 6EA PW SW*4,FPNL *2
SS3R0+12SBB SCREW TRIANGLE 3*12 BIND BLK 4EA FOOT*4
SP3R0+06SBB SCREW TAPING 3*6 BIND BLK 32 EA BKT-SINK BKT
SN3R0+08SBB SCREW TAPING 3*8 N BLK 6EA RCA JACK
SM4R0+06SBB SCREW MACHINE 4*6 BIND BLK 3EA R-PNL-BOT*3
SM4R0+10SFB-S SCREW MACHINE 4*10 S FLAT BLK 10 EA COVER
SS4R0+08SBB-C SCREW TRIANGLE 4*8 BIND BLK C 13 EA F-CH*9,R-PNL *4
SS4R0+12SBB-C SCREW TRIANGLE 4*12 BIND BLK C 4EA XMER
N3R0D5R5D2R4TSN
+
NUT M3 NI + GEAR WASHER 12 EA FOOT*4,FAN*8
N4R0D7R0D3R5TSB
F
NUT M4 BLK F/NUT 4EA XMER
WAS-R1074 WIRE ASY W/42475 MOLEX *12 WIRE 1EA CN14
WAS-R1077 WIRE ASY 2P #18 1015 150MM 508 1EA CN211A-CN211 B
WAS-R1078 WIRE ASY 2P #18 1015 150mm 508 1EA CN212A-CN212 B
WAS-R1079 WIRE ASY 2P #18 1015 360mm 508-10m 1EA AC-CN213A
WAS-R1082 WIRE 1P #16 100MM GRN/YEL W/TML 1EA EARTH
ECW-275V104K X-CAP 14104 0.1uF/275V 1EA C201
TU1-B0070-020 TUBING SHRINK BLK 7MMD 20MM 3EA AC JACK
TU2-S9010-050 TUBING S1 1mmD 5mm 2 PCS C201
EMX-1002 CABLE TIE BINDING (YJ-80) 30 EA
RM09P0007 FOOT 4TSA-18A 50F*18H FOR PX1275 4EA
RM11P1002 KNOB 4TNJ-10 FA-1500 FOR PX1275 PW 1EA PW SW
13-4019 KNOB 10*10 FOR LEVEL 12 EA FOR I/O VR
ASY-TMLR0004 Molex 15-06-0245 Plug plus Wiring 1EA Assembly
SM-P6+32+08SSB SCREW P6-32*8 1EA EARTH
N30+06+32NI NUT 3m/m NI 1 pcs EARTH
RM09R0003 GASKET 30*40*12MM 1EA FOR LED
FAN-R002 DC24V FAN JF1225B1M-257 2EA
M09-R622 RUBBER FOOT NF-008 8EA FOR FAN
SM3R0+40SMB SCREW MACHINE 3*40 8EA FOR FAN
SS-R006 SCREW P6#32*6 BIND BLK 6EA
RM04S1001 BOSS STEEL #6-32 10MM 6EA VAC
ST3R0+10SBB SCREW TAPPING 3*10 BAND BLK 4EA FAN PCB
WAS-R1087 WIRE ASY 2P #24 300MM FOR FAN TO C 2EA
SM5R0+06SPB SCREW MACHINE 5*6 PAN BLK 4EA HANDLE
EMX-1005 CABLE TIE BINDING (YJ-185) 1EA
TU3-W0010-070 Glass tube blk 10*70mm 6EA
PKG-VAC014-01 PACKAGE VAC014-01 1 KIT
WPC-7008*D PW CORD AL201+501 SJT 16/3C 105 6F 1EA
RM901021 CARTON OUTER FOR PX1275 1EA
RM901022 CARTON INNER FOR PX1275 1EA
RM941006 EPE BUFFER FOR PX1275 2EA
RM930005 POLY BAG 30"*35"*0.08 1EA For Set
13-6006 POLY BAG 4x12"x0.08mm 2EA For PW Cord/Accessory
RM950012 MANUAL FOR PX1275 QUICK START 1EA
RM950013 M362 README FOR PX1275 1EA
RM950014 US CUSTOM INSTALL FOR PX1275 1EA
RM950015 SAFETY PRECAUTION FOR PX1275 1EA
RM950016 WARRANTY CARD FOR AUDIO ACCESS 1EA
13-6005 POLY BAG 10x14"*0.05mm 0.1 Kg For Manual
SUB-ASSAMBLIES
A
MP-working Module93-V1003), with heatsink & wire hardnes
s
1 KIT
IO-working Module-A 92-V1004A), with standoffs& wire hardn
e
1 KIT
IO-working Module-A 92-V1004B),with standoffs & wire hardn
e
1 KIT
STB-working Module 92-V1005) 1 KIT
AC-working Module 92-V1006) 1 KIT
FAN-working Module 92-V1007), with wire hardness 1 KIT
