Audiotrak MAYA1010 User manual

MAYA1010
First Edition June. 2004
Index
1. Introduction 2
2. What’s in the Box 2
3. Key Features 3
4. System Requirements 4
5. Exterior Features 5
1. Breakout Box 5
2. PCI Card 5
3. I/O Cable 6
6. Hardware Installation 7
1. Preparation for hardware installation 7
2. Installing the MAYA1010 PCI card 8
7. Software Installation 9
8. MAYA1010 Panel 13
1. File 13
2.Config 14
3. Mapper 14
4. DirectWIRE 3.0 15
5. Control Panel 15
6. Mixer Panel 17
9. Configuring MAYA 1010 18
1. Windows Multimedia Setup 18
2. 5.1 Surround Sound for DVD Player Applications 18
3. ASIO 2.0 Applications 19
4. Sonar 20
5. Cakewalk 20
6. Sound Forge 20
10. DirectWIRE 3.0 22
1. What is DirectWIRE? 22
2. DirectWIRE Panel 22
3. DirectWIRE Examples 23
11. Circuit Diagram of MAYA1010 26
12.Specifications 27
13.Warranty 29
All features are subject to change without prior notice
- 1 -
1

MAYA1010
1. Introduction
Thank you for choosing the AUDIOTRAK MAYA1010. MAYA1010 is a unique
PCI multimedia digital audio interface also with a breakout box. We designed
MAYA1010 with many powerful functions that will satisfy both beginners and
professionals looking for high quality digital audio solutions.
Even if you are an experienced professional, please take some time to read
through this user manual and familiarize yourself with the MAYA1010’s features
and operation. You may also want to refer to your audio software’s
documentation to better understand how the MAYA1010’s features are
integrated with the program. Your experience and enjoyment of your MAYA1010
will be greatly enhanced by a good working knowledge of your audio software.
2. What’s in the Box
Your MAYA1010 package contains the following:
· MAYA1010 Breakout Box
· MAYA1010 PCI Interface Card
· MIDI I/O, Digital I/O Cable Connector
· User Manual
· Windows driver software CD
- 2 -
2

MAYA1010
3. Key Features
1. Supports up to 24Bit/96kHz sampling rate
MAYA1010 supports up to 96KHz sampling rate for digital recording. Full
24Bit/96KHz bandwidth with full duplex operation is available over 10
simultaneous inputs and outputs. The MAYA1010 will prove its value in Multi-
track Recording, Mastering or DVD Audio applications.
2. Professional digital recording device
MAYA1010 is a professional digital recording device for hard disk recording
applications. MAYA1010 is fully compatible with multi-track recording software
such as Sonar/Cakewalk, Cubase, Logic, and Nuendo; mastering software such
as Sound Forge and Wave Lab; software sampler like GigaStudio, EXS, and
Halion and most of Virtual Instruments such as Reason and Reactor.
3. Multimedia / 7.1 channels surround sound device
MAYA1010 delivers ultra high-quality sound and adds unique features to your
Windows audio system. MAYA1010 supports all popular audio formats such as
MPEG, MP3, WAV, and multimedia formats such as DVD, Video CD, Flash and
Internet Broadcasting.
Digital audio is becoming more and more popular and with MAYA1010, you can
complete your Desk Top Music Production System easily. MAYA1010 will be the
center of your DTMP system providing professional studio quality sound, and
easy access to the world of digital music and multimedia.
4. DirectWIRE3.0 support
DirectWIRE3.0 is AUDIOTRAK’s unique application that allows you to virtually
patch all of your digital audio internally between various software programs. In
this latest version, support for patching hardware inputs and mixing multiple
audio streams at the inputs has been added. With E-WDM, MAYA1010 can
simplify the hassles of wiring externally for inter-driver/inter-application audio
data transfer. Especially when you use software synthesizers or virtual
instruments, DirectWIRE 3.0 will help simplify your setup.
- 3 -
3

MAYA1010
4. System Requirements
MAYA1010 is a multimedia digital audio device with many functions, not just a
simple soundcard. So although MAYA1010 has low CPU dependability, to take
full advantage of MAYA1010, your computer needs to meet the minimum
system requirements. Faster CPU, faster hard disk, and larger amounts of RAM
are generally recommended.
Minimum System Requirements
1. I Intel Pentium III CPU or equivalent AMD CPU
2. Motherboard with Intel chipsets(BX,820,815 and so on) or VIA chipsets
3. At least 256MB of RAM
4. One available PCI slot
5. Microsoft Windows 98SE, Windows ME, Windows 2000 or Windows XP
operating system
6. Ultra DMA66/100 and 5400rpm hard disk drive
7. Active speakers or speakers with powered amplifier.
- 4 -
4

MAYA1010
5. Exterior Features
1. Breakout Box
1) MIC inputs (Input 1~2) – Two 1/4” TRS phone jack type MIC input ports
2) Line Inputs (Input 1~8) – Eight analog line input ports with balanced
TRS phone connector
3) Line Outputs (Output 1~8) – Eight analog line output ports with
unbalanced TS phone connector
4) Headphone Outputs (Output 7~8) – Two 1/4” TRS phone jack type
headphone output ports
2. PCI Card
1) D-Sub Connector - Connects MAYA1010 PCI card with the breakout
box
2) Cable Connector - Connects with included MIDI I/O and coaxial digital
I/O cable
3) Digital Optical Output -Digital output via optical connector
- 5 -
5

MAYA1010
3. I/O Cable
1) Connector – Connects to MAYA1010 PCI card’s cable connector
2) DIG I/O - Coaxial digital (S/PDIF) input and output connectors
3) MIDI I/O - Standard MIDI input and output connectors
- 6 -
6

MAYA1010
6. Hardware Installation
MAYA1010 requires multiple installation steps:
· PCI card installation
· Driver installation
Also you need to understand how to connect MAYA1010 to other external
devices such as MIC, amp, mixer, and recording devices such as MD or DAT
players.
1. Preparation for hardware installation
MAYA1010 PCI card and other components in the computer can easily be
damaged by electrical shock. You need to use an anti-static device that can
discharge the static electricity of your body to avoid potential static damage to
the cards.
1) MAYA1010 PCI card is packaged in an anti static plastic pouch. Do not
open the pouch until you’re ready to install the card.
2) Turn off the computer and remove the power cable from your computer’s
power supply.
3) Remove the cover. Make sure that you have an available PCI slot in your
motherboard to install MAYA1010. Please refer to your computer’s user
manual on how to remove the cover.
4) To avoid possible static shock to the computer parts, discharge it by
touching the computer case or something grounded. We recommend
you to use an anti-static device such as an anti-static wrist band.
5) When you need to hold the MAYA1010 PCI card, please hold it on the
guide or edge of card. Do not grab the card by the board.
- 7 -
7

MAYA1010
2. Installing MAYA1010 PCI card
1) Look for an empty PCI slot. If you do not know which one is a PCI slot,
please read the following:
2) The PCI slot is the most common and is used for a wide range of
devices from the soundcard to the modem. Usually, the PCI slot is the
white-colored slot. It should not be too hard to find the PCI slot for
MAYA1010.
3) If there is a guide blocking the empty slot, please remove the guide
using the proper screwdriver.
4) Put the MAYA1010 PCI card into the slot and make sure it is placed in
the slot correctly. Insert the card into the slot and then tighten the screw.
Close the case.
5) connect it to the breakout box using the provided cable.
6) Connect the I/O cable’s connector to the MAYA1010 PCI card.
- 8 -
8

MAYA1010
7. Software Installation
After completing the hardware installation, you need to install the Windows
driver. The installation steps in Windows 98SE, Windows ME, Windows 2000
and Windows XP vary, but they are similar between the different versions of
Windows. The installation steps shown below are based on Windows XP
installation.
Note: Depending on your system, you may need the Windows installation CD.
Note: MAYA1010 installs several drivers during its installation process.
Windows will repeatedly prompt you to reboot the system, but unless the driver
installation is completely finished, DO NOT reboot the system. After complete
installation, restart your computer.
1. Turn on your computer. Windows will automatically detect a new device and
prompt you with Found New Hardware Wizard screen. Choose “Install from a
list or specific location” and click Next.
2. Choose “Search for the best driver in these locations” and specify the
location of the driver. Insert the provided driver CD into the CD-Rom drive and
select “Include this location in the search” and click Browse to find the driver’s
location. For example, it is E:\AUDIOTRAK\MAYA1010\, if E:\ is your CD-Rom
drive.
- 9 -
9

MAYA1010
3. During installation in Windows 2000 and Windows XP, you will be prompted
with a message warning that the driver software has not passed Windows Logo
testing. Select Continue Anyway and proceed with the installation. The driver is
completely tested and verified by AUDIOTRAK, and safe to use.
4. When you see the Completing the Found New Hardware Wizard screen, click
Finish to complete the installation.
5, Windows will automatically continue to install the MAYA1010 Audio driver.
- 10 -
10

MAYA1010
6. Again, choose “Search for the best driver in these locations” and specify the
location of the driver. Select “Include this location in the search” and click
Browse button to find the driver’s location. For example, it is
E:\AUDIOTRAK\MAYA1010\, if E:\ is your CD-Rom drive.
7. During installation in Windows 2000 and Windows XP, you will again be
prompted with the Windows Digital Signature warning screen. Once again,
select Continue Anyway and proceed with the installation.
8. Once the installer has finished copying the files. You will see the Installation
Complete screen. Click Finish.
9. After you complete both driver installations, you will be prompted to shut
down and restart your computer. Click Yes.
- 11 -
11

MAYA1010
10. After restarting Windows, you will see the MAYA1010 panel icon in your
system tray (lower right corner of your desktop). Click on the icon to open the
MAYA1010 panel.
11. Go to Device Manager, check the devices under ‘Sound, video and game
controllers’. You will see the MAYA1010 Audio and MAYA 1010 Controller if you
have completed the installation process correctly. Your MAYA1010 is ready to
use.
NOTE: You can see 2 MIDI devices on MIDI Music Playback item of Sounds
and Audio devices properties. But you can use only “1-MAYA1010 MIDI” device.
- 12 -
12

MAYA1010
8. MAYA1010 Panel
The MAYA1010’s driver software provides a simple yet powerful interface with
your computer. The panel gives you a multi-channel software mixer with ten
virtual outputs from your audio software. Each output may be routed to any of
the MAYA1010’s eight analog or two digital outputs.
The MAYA1010 panel is installed in your system when you complete the driver
installation. To open the panel, double click the icon, which is the
AUDIOTRAK logo, in the system tray.
While the MAYA1010 panel gives you great deal of control, you may find that
the default settings work just fine for your needs. Just to be safe, though, we’ll
cover all the features of the panel in detail.
The MAYA1010
panel features pull down menus for configuration.
1. File
1) Close Windows (ALT-F4):Closes the MAYA1010 panel window. Note
that this does not shut down the panel. You may open the panel again by
clicking the
icon in the system tray.
2) Exit: Shuts down the MAYA1010 panel completely.
- 13 -
13

MAYA1010
2. Config
1) Mouse Wheel: Configures the mouse wheel for volume change
adjustment. Default value is ±1.5dB per step. You can configure the
steps to your preference.
Configuration Step 1 Step 2 Step 3 Step 4
Change/Step ±1.5dB ±3.0dB ±6.0dB ±12.0dB
2) Latency: Configures the latency setting for MAYA1010. Generally, for
multi-track recording we recommend higher latency for stability. For
software synthesizers and mastering software, we recommend lower
latency. The optimal latency setting will depend on your application and
your computer system.
3) Factory Default: Allows you to revert back to the factory default setting
for all configurations.
4) Always On Top: This enables the MAYA1010 panel to be always
displayed on the top.
3. Mapper
Enables you to choose the input and output port when you select “MAYA 1010
2ch” device in Sounds and Audio Devices Properties as shown below.
- 14 -
14

MAYA1010
4. DirectWIRE 3.0
Clicking this menu will open the DirectWIRE 3.0 screen. DirectWIRE 3.0 is a
unique feature of the E-WDM driver that transfers digital audio data internally
within different applications. MME, Multi-MME, ASIO and GSIF indicate the
different drivers supported by MAYA1010. The numbers along the column
designate the channel number of the inputs and outputs.
Please refer to Section 10, Using DirectWIRE 3.0 on page 21 for more detailed
instructions and examples on using DirectWIRE 3.0.
5. Control Panel
You can come back to the panel control screen by clicking this menu. It is also
the default screen you see when you first launch the panel. Basic functions of
MAYA1010 are controlled from this screen.
1) INPUT: You can change the input monitoring level on all channels (1~8,
S/PDIF) by clicking and dragging the fader bar. The number on the
bottom shows the relative amount in dB. Clicking this number enables
you to mute the channel.
You can control gain from -60dB to +15dB (0.5dB per step) on input ch
1/2. Also, input ch 1/2 supports +12V phantom power microphone. To
use the microphone you must change the input level to “M” (microphone)
from “L” (line input). After selecting “M”, you can select “12” (12V) on
each channel for phantom power.
- 15 -
15

MAYA1010
2) OUTPUT: You can change the output monitoring level on all channels
(1~8, S/PDIF) by clicking and dragging the fader bar. The number on the
bottom shows the relative amount in dB. Clicking this number enables
you to mute the channel.
H·P: Output ch 1/2 can be used for headphone output.
MIX OUT: Hear sounds from the mixer panel. Please refer to Section 6.
on page 17, for more information on the Mixer Panel. You can mix
output to ch 1/2 if you select H·P or to S/PDIF.
3) MASTER: You can adjust all input / output monitoring levels by clicking
and dragging the fader in the master control panel. Again the number on
the bottom shows you the relative monitoring level in dB. Clicking this
number enables you to mute the channel.
LINK: You can control volume of left and right channels independently by
deselecting this button.
- 16 -
16

MAYA1010
4) S / R: You can configure the sampling rate in this panel.
Auto: Automatically sets the sampling rate to your audio file’s sampling
rate.
22~96: You can set the sampling rate manually from 22kHz to 96kHz.
5) MASTER CLOCK: Allows you to choose the digital clock source for
MAYA1010.
INT: Sets the MAYA1010’s internal clock as the master clock. If other
devices are set as slave, you need to use this setting.
EXT: When MAYA1010 receives digital data from an external digital
device through S/PDIF coaxial digital input, the ‘LOCKED’ indicator will
tell you that MAYA1010 is receiving the data. You can then select Digital
to use the incoming digital audio data as the clock source. External
device becomes the master and MAYA1010 becomes the slave.
6. Mixer Panel
Clicking this menu opens the mixer screen of MAYA1010 panel.
You can control panning, mixing and mute within this screen.
- 17 -
17

MAYA1010
9. Configuring MAYA1010
MAYA1010 is a premium multimedia audio device for professional audio. It is
simple to configure MAYA1010 for use in games to DVD surround sound. You
can also configure MAYA1010 for hard disk recording using professional digital
audio software. This chapter includes the setup guide for some common
applications. MAYA1010 supports applications that use WDM, MME, ASIO,
GSIF and Direct Sound.
NOTE: Only the basic setup options for the applications are shown in this
chapter. For more detailed setup options please refer to the software manual.
1. Windows Multimedia Setup
To configure MAYA1010 for Windows multimedia applications:
Go to Control Panel →Sounds and Audio Device Properties →Audio tab.
Select “2-Maya 1010 10ch” driver as your playback device.
2. 5.1 Surround Sound for DVD Player Applications
To configure MAYA1010 for 5.1 channel surround sound DVD player:
Go to Control Panel →Sounds and Audio Device Properties →Audio tab.
Select “6-Maya 1010 10ch” driver as your playback and recording device.
NOTE: You must check “Enable DMA” in your DVD-Rom drive settings. If not,
you may not get a crisp image during DVD playback.
Set speaker configurations in your software DVD player to “6 Speaker.” You’re
ready to enjoy DVD with 5.1 channel surround sound.
This is an example of 5.1 channel surround sound route for MAYA1010. The
order may vary for different versions of Windows.
MAYA1010
Output 1 2 3 4 5 6
Speaker Front
Left Front Right Center Woofer
Surround
Left Surround Right
- 18 -
18

MAYA1010
PowerDVD 5.0 supports 8 channel surround speaker outputs as shown below.
However, most of DVD titles only have 5.1 surround sounds. You can enjoy
Dolby Digital DVD with just 6 speaker setting.
3. ASIO 2.0 Applications
1) Cubase VST
After launching Cubase VST, go to Options -> AudioSetup →System.
Select “ASIO 2.0 – MAYA1010” as ASIO device and “MAYA1010 Clock” as
Audio clock source.
- 19 -
19

MAYA1010
2) Nuendo or Cubase SX / SL / SE
After launching Nuendo or Cubase, go to Device →Device Setup →VST
Multitrack. Select “ASIO 2.0 – MAYA1010” as ASIO device and “MAYA1010
Clock” as Audio clock source.
3) Logic
After launching Logic, go to Options>Preference >Audio Driver 2. And
check “ASIO” and select “ASIO 2.0 – MAYA1010”.
- 20 -
20
