Audiotrak AUDIOTRAK MAYA EX7 User manual

WARRANTY
Ego Systems Inc. warrants the return policy to its original purchaser as follows; All the EGO
SYSTEMS INC.’s products, under normal use, will be free from faulty as long as the purchaser
owns this product.
The terms of warranty is 15 months to EGO SYSTEMS INC. distributors considering a 3-month
temporary stock period ahead of being sold to the end user.
Therefore, the actual terms of warranty is 12 months to the end user.
EGO SYSTEMS INC. will, at its sole option, repair or replace a product, which is found to be
defective. This warranty shall be invalid if, in the sole opinion of EGO SYSTEMS INC., a product
failure is the result of misuse, abuse, modification, or misapplication. Except as expressly provided
above, EGO SYSTEMS INC. products are provided, 'as is' without any kind of warranty. No claim
is made for merchantability or fitness for any purpose. In no event will EGO SYSTEMS INC. be
liable for any direct, indirect, consequential, or incidental damages arising out of use of the product.
The purchaser must contact EGO SYSTEMS INC. or its regional representative to receive prior approval
before returning a faulty unit.
To obtain warranty service, the buyer or his authorized dealer must send the email to sale[email protected]
or [e-mail] before returning the product. EGO SYSTEMS INC. will then issue an
authorization number.
All such returns must be shipped to EGO SYSTEMS INC.' headquarters in Seoul, Korea as being
packaged in the original or equivalent protective packaging material (Rack, PCI card, Power
Cables, connection cables), with freight prepaid and adequate insurance.
Any Shipments without freight prepaid will not be accepted.
If the returned product is deemed to be defective, the repaired or replacement product will be back
to you at no extra charge via the carrier chosen by EGO SYSTEMS INC.
TRADEMARKS
AUDIOTRAK, MAYA EX7 are trademarks of EGO SYStems Inc. Windows is a trademark of Microsoft
Corporation. Other product and brand names are trademarks or registered trademarks of their respective
companies.
RADIO FREQUENCY INTERFERENCE AND COMPATIBILITY
NOTE: This equipment has been tested and found to comply with the limits for EN55022 Class
A:1998+A1:2001, EN55024:1998 of CE Test Specifications

This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in
accordance with the instruction, it may cause interference to radio communications. This device also
complies with part 15 class A of the FCC Rules. Operation is subject to the following two conditions; This
device may not cause harmful interference, and must accept any interference received, including
interference that may cause undesired operation.
CORRESPONDENCE
For technical support inquiries, contact your nearest dealer or contact us directly. Direct all other
correspondence to:
Ego Systems Inc.
3003N. First St., Suite 303,
San Jose, CA 95134, USA
Website: www.audiotrak.net E-mail: [email protected]
Technical Support (English only)
[email protected]
First Edition Jan. 2003
All features and specifications subject to change without notice.
2

CONTENTS
1. OVERVIEW................................................................................................................ 4
2. FEATURES ................................................................................................................. 5
3. SYSTEM REQUIREMENT ...................................................................................... 5
4. HARDWARE INSTALLATION ............................................................................... 6
5. DRIVER INSTALLATION ....................................................................................... 7
6. SURROUND SPEAKER INSTALLATION........................................................... 12
1) 7.1 CHANNEL SPEAKER CONFIGURATION ................................................................. 12
2) 5.1 CHANNEL SPEAKER CONFIGURATION ................................................................. 12
7. WORKING WITH APPLICATIONS..................................................................... 13
1) WINDOWS AUDIO SETTING ...................................................................................... 13
2) WINDVD4 ............................................................................................................... 16
3) EMERSYS MAVEN 3D PRO........................................................................................ 18
4) PCDJ ...................................................................................................................... 19
5) BPM STUDIO........................................................................................................... 21
SPECIFICATION......................................................................................................... 23
3

1. Overview
Thank you for choosing AUDIOTRAK MAYA EX7.
MAYA EX7 is the premier external audio solution featuring a set of 8 discrete RCA
outputs in a compact, portable slim design.
The stereo S/PDIF optical output is the ideal way to transfer digital audio data to
external recorders or amplifiers without the loss of audio quality.
MAYA EX7’s four pairs of stereo outputs deliver numerous analog audio output options.
MAYA EX7's eight analog outputs fully support 7.1 surround sound when combined
with the included software DVD player. The 102/100dB 24-bit 96kHz eight channels
digital to analog converter produces pristine sound quality in any environment.
Play a DVD movie with the MAYA EX7 and included DVD software player, and enjoy
the hottest surround sound environment. Simply connect the MAYA EX7 directly to a
7.1 surround speaker system. No 7.1 surround sound home theater receiver is required.
You can also enjoy Hollywood movies on your notebook computer, with the same audio
reproduction that moviemakers intended to reproduce in the theater - 7.1 theatrical
surround sound. Or listen to MP3s and other stereo music in a virtual surround sound
environment with up to 7.1 channels of surround sound.
For DJs, MAYA EX7 makes a great companion for DJ software like PCDJ or BPM
Studio Pro. The MAYA EX7 also plays back multiple tracks of audio from popular
software synthesizers and samplers. MAYA EX7's all 8 ports have individual green
LEDs to display output signal activity.
The MAYA EX7 is the ideal portable audio solution for audiophiles, DVD enthusiasts,
musicians, and DJs. MAYA EX7's compact design and USB connectivity lets you to
take your high-quality, multi-channel audio project on the road, or remain stationed at
your desktop PC.
4

2. Features
102/100dB 24-bit 96kHz High Fidelity 8 Channel Digital to Analog Converter
Plug In with Analog Outputs(8) plus an Optical Digital Output
Transfer Pure Audio to Digital Devices with Optical Digital Output
Compose Seamlessly with all DJ Music Software
Emulate Multi-Channel Surround Sound with SRS TruSurround XT
with Enhanced Bass and Dialog *
Experience Stereo Audio Sources with Expanded 7.1 Channel Surround
Sound *
Connect to Your Notebook or Desktop PC USB port
Easy Installation, Simple Operation, and Portable Design
* These Functions will work only with the WinDVD 4.0(included)
3. System Requirement
Most of all, your system has to have at least one available USB port to use MAYA EX7.
Minimum system requirement
Intel Pentium II 450 MHz CPU or equivalent AMD CPU
Windows 98SE, 2000, XP operating system
1 open USB port
64MB of Ram
DVD Rom
5
