Audiovox APS-596C User manual

128-8804b
1 of 16
Page1
Model APS-596C
InstallationManual
Remote Control Vehicle
Security System
Rev B: New Format
PATENTED: www.voxxintl.com/company/patents
Table Of Contents:
BeforeYouBegin Page 2
Wire Harnesses Quick View Page 3
MountingOf TheMajorComponents Page 4
8 Pin Power Harness Wiring Page 5 - 6
Wiringthe 11PinAccessoryInput/OutputConnector Page 6 - 7
4PinWhiteConnectorShockSensorHarness Page 8
2 Pin LED / Valet Connectors Page 8
3 Pin Door Lock/Unlock Connector & Wiring Page 8 - 10
4PinUpgradeTelematic Module Page 10
CompletingTheInstallation Page 10
DomeDelayLearningProceedure Page 10
AdjustingTheShock Sensor Page 10 - 11
Final Steps Wire Dressingand Operation Explanation Page 11
DBIPort Information Page 11
ProgrammingTransmitters Page 12
ProgrammingAlarmFeatureBank2 Page 12
SelectableFeatures Page 13
CircuitWiringLayout Page 14
Notes Page 15-16

128-8804b
2 of 16
Page2
Before You Begin
PROFESSIONAL INSTALLATION IS
STRONGLYRECOMMENDED
Rolldownwindow to avoidlockingthekeysin the vehicleduringinstallation.
Avoidmountingcomponents or routing wiresnearhotsurfacesor near moving
partslikethesteeringwheel as it may prevent proper operation of the vehicle.
Tapeorloomwiresunderthehoodanddashforprotectionaswellappearance.
Usegrommets whenroutingwiresthroughmetal surfacestopreventchafing
andshorting.
UseaDigitalMultiMeterfortestingandverifyingcircuits. DONOTUSEA
"TEST LIGHT" OR "COMPUTER SAFE PROBE" as these can set off air bags
ordamagesensitivevehiclecomputers and electronics.
For technical support go to www.prestigecarsecurity.com
or call 1 800 225 6074
This device complies with FCC Rules Part 15 Operation is subject to the following two conditions
(1) This device may not cause harmful interference and
(2) This device must accept any interference that may be received, including interference that
may cause undesired operation.
NOTE:The manufacturer is not responsible for any radio or TV interference caused by unautho-
rized modifications to this equipment. Such modifications could void the user’s authority to
operate the equipment

128-8804b
3 of 16
Page3
3 Pin Door Lock Output Harness Part #1122906
2
3
11 Pin Main Wiring Harness Part # 1122916
1
2
3
4
5
6
7
8
9
10
11
1
2
3
8 Pin Power Input / Output Harness Part #1122393
4
5
Red/White +12 Volt ModuleInput
Orange GroundOutputWhileArmed(-) 300mA
White/Black +12VoltsSiren Output
6
7
8
Green/White IlluminationEntryOutput(-)300mA
DarkBlue Channel3Trunk Output(-)300mA
Black ChassisGround
White (+)Parking LightOutput15A Max
Red (+)12VoltInputParking Lts & Module
Red Neg.Lock/Pos.Unlock 300mAMax.
Red/Black Neg.2ndUnlock Output (-) 300mA
Green Pos.Lock/Neg.Unlock 300mAMax.
Green /Black Channel 4 Output (-) 300mA
Orange/White Gnd. Output When Disarmed (-) 300mA
Purple Pos. Door Trigger Input
White/Blue Programmable Headlight Out (-) 300mA
Blue/Black Alternate Channel 3 Output (-) 300mA
Black /White Horn Output (-) 300mA
DarkGreen NegativeHood/TrunkTriggerInput
Brown Neg. Door Trigger Input
Yellow IgnitionInputSwitched+12 Volts
Lt.Green Add. Neg. Trigger Input
Lt.Blue/ Green Channel 5 Output (-) 300mA
1

128-8804b
4 of 16
Page4
MOUNTINGOF THEMAJOR COMPONENTS
Control Module: Part # 1365043
Selecta mounting locationinside the passengercompartment ( upbehind the dash), andsecureusing the
two screws provided. The control module can also be secured in place using cable ties.
Do Not mountthe controlmodulein theenginecompartment,as itisnot waterproof.You shouldalso avoid
mounting the unit directly onto factory installed electronic components. These components may
causeRFinterference, which can resultinpoor transmitter rangeorintermittent operation.
Siren: Part # AS9903
Selecta mounting locationin the enginecompartment that iswell protected fromaccess below thevehicle.
Avoidareas nearhighheat components ormovingpartswithinthe engine compartment.To prevent water
retention, the flared end of the siren must be pointed downward when mounted. Mount the siren to the
selectedlocationusing the screws andbracketprovided.
Hood or Trunk Pin Switch: (Optional) Part#1363699
An optional pin switch should be used for protecting the hood or trunk (or hatchback ) of the vehicle. The
switch must always be mounted to a grounded, metal surface of the vehicle. It is important to select a
location where water cannot flow or collect, and to avoid all drip gutters on hood and trunk fender walls.
Chooselocationsthat areprotectedby rubber gasketswhen the hoodortrunk lidisclosed. The pin switch
can be mounted using an optional bracket or can be directly mounted by drilling a ¼ “ diameter mounting
hole. Keep in mind that when properly mounted, the plunger of the pin switch should depress at least ¼ “
when the hood or trunk lid is closed.
Push-Button Program Switch/LED/Receiver/Antenna Assembly: Part # 1181201
TheSuperheterodyneReceiverAntennaAssemblyprovidedwiththisunitallows routingfrombelowthedash
board for maximum operating range. Choose a location above the belt line (dashboard) of the vehicle for
bestreception. Special considerations must be made forwindshieldglassas some newer vehicles utilize
a metallic shielded window glass that will inhibit or restrict RF reception. In these vehicles, route the
antenna toward a rear window location for best reception. Secure the antenna with double stick tape
provided.
6 Pin Receiver Harness Part # 1123908
Red,Green,Black, Gray, Blue, Plug InHarnessFor Receievr RX,TX,5 VDC, Ground, LED &Valet
ShockSensor: Part # AS9492a
Selecta solidmountingsurfaceforthe shocksensor onthefirewall insidethe passengercompartment, and
mountthe sensor usingthe two screwsprovided. The shocksensor can alsobe secured toany fixed brace
behind the dash using tie straps.
Whichevermountingmethod is selected,makecertain that thesensitivityadjustment isaccessiblefor use
later in the installation.
STARTERINHIBITRELAY: Part # 1363731
Select a mounting location within 12" of the ignition switch's low current start solenoid wire. Secure the relay to an
existing harness in the chosen location using a cable tie around the relay's wiring harness.
Wire the relay as per the diagram found later in this manual.
CAUTION! Do not wire tie the metal bracket to an existing wiring harness as vibration may cause
chaffingandshorting damaging thefactorywiring. Ifan existing harnessisnot available then
secure the relay's metal mounting tab to an under dash metal brace with a #8 self tapping
sheet metal screw. Wire the relay as per the diagram found later in this manual.

128-8804b
5 of 16
Page5
WIRING THE SYSTEM
Large 8 Pin Power Connector:
Red/White (5 Amp) & Red Fused (15 Amp) Wires : + 12 VDC Constant Battery Source
This wire controls the sensitivity of the voltage sensing circuit, which detects the turning on of an interior
lightwhen a dooris opened.Itwill alsodetectthe switchingonof parkingorheadlamps andinmany cases
willtriggerthealarm when a thermostatically controlled electronic radiatorcoolingfanswitches on.
When installing this system into vehicles with electronic "after fans " it is recommended you disable the
voltagesensecircuit.
In voltage sensing applications, the closer to the battery that the red wire is connected, the less sensitive
thevoltagesense circuitrywillbe. Movingthisconnection point tothefuse panelwillincrease the sensitiv-
ity,andconnecting to thecourtesylamp fuse inthevehicle will provide maximumsensitivityof the voltage
sense circuit. Be certain to set selectable feature # 7 to 1 chirp, Voltage Sense On.
When hardwiring the control module to pin switches at all entry points, the voltage sense circuit must be
disabled.
Orange Wire: 300 mAGround Output WhenArmed
This wire is provided to control the starter cut relay. Connect the orange wire to terminal 86 of the relay.
Connect relay terminal 85 to an ignition wire in the vehicle that is live when the key is in the on and crank
positionsand offwhenthe keyis intheoff position. (Thisiswhere theyellow wirefromthe alarmshould be
connected).
Cutthe lowcurrent startersolenoidwireinthevehicle,andconnectone sideof thecut wiretorelayterminal
87A. Connect the other side of the cut wire to relay terminal 30.
Note: This is a normally closed starter cut arrangement and when power is removed from the security
system,thestarter disablefeaturewill not operate,allowing the vehicletostart.Audiovoxdoesnot
recommend usingthe Orangewire tointerrupt anythingbut thestarting circuit ofthevehicle.
Green w/ White trace Wire: Entry Illumination Ground Output
Thiswireprovidesa30secondgroundoutput(300mAMax)whenevertheremoteisusedtodisarmthealarmorto
unlock the doors and provides a continuous pulsed output whenever the alarm is triggered. This wire should be
connectedtoanexternalrelay andwired tothevehiclesinteriorentrylightingwhenevertheoptionalInteriorIllumina-
tioncircuit isdesired. SeeWiring Diagramfor details.
Dark Blue Wire: Delayed300mA Pulsed Output /Channel3
ThedarkbluewirepulsestogroundviaanindependentRFchannelfromthekeychaintransmitter.Thisisatransis-
torized,lowcurrentoutput,andshouldonlybeusedtodriveanexternalrelaycoil.
CAUTION: Connectingthe dark bluewireto thehighcurrent switched outputoftrunk releasecircuits,and some
remotestarttriggerinputs,willdamagethecontrolmodule. Inthesecases,connectthedarkbluewire
to terminal 86 of anAutomotive 30AMP relay, terminal 85 to +12 Volts, and wire the remaining relay
contactstoperformtheselectedfunctionofchannel3.
White w/ Black Trace Wire: Positive Output to Siren
Routethiswirethrougharubbergrommetinthefirewall,andtothesirenlocation.Connectthewhite/blackwiretothe
positivewireofthesiren.Securetheblackgroundwireofthesirentochassisground.

128-8804b
6 of 16
Page6
Black Wire: Chassis Ground
Connectthiswire to a solid,metalpart of the vehicle’schassis.Do not confuse thiswirewiththe thin black antenna
wirethatexitsthecontrolmoduleindependently.
White Wire: + 12 VDC Pulsed Parking Light Output (15Amp Max)
This wire is provided to flash the vehicle’s parking lights. Connect the white wire to the positive side of one of the
vehicle’sparkinglights.
WiringThe11AccessoryInput/Output Connector:
Dark Green w/ Black Trace Wire: Latching Output / Channel 4
Thegreenw/blacktracewirelatchestogroundviaanindependentRFchannelfromthekeychaintransmitter.Thisis
atransistorized,lowcurrent( 300mA)output,and shouldonlybeusedtodriveanexternalrelaycoil.
This wire provides an immediate ground signal and stays at ground for as long as the button(s) on the keychain
transmitterremainspressed.
CAUTION! Connecting the dark green w/ black trace wire to the high current switched output of trunk
release circuits will damage the control module.
Connectthedarkgreenw/blacktracewiretoterminal86oftheAS9256relay(oranequivalent30Ampautomotive
relay),andwiretheremainingrelaycontactstoperformtheselectedfunctionofchannel4.
Dark Blue w/Black Trace Wire:AlternateChannel 3 Output(Dbl. Push Required)
Thiswireiscontrolledfromthetransmitterbuttonprogrammedtothereceiver'schannel3. Bydoublepressingthisthe
transmitterbutton,thisoutputwillbecomeactivefor1second. Thisisatransistorized,low current(300mA)output,
designedtoprovideanoutputonlywhenthetransmitterisintentionallyoperated,suchasisthecasewithremotestart
addonmodules. If you require more than300mAdrive from this output, youmust drivean external relay coil, and
arrangetherelayscontactstopreformthespecifiedfunction.
Note: Pressingthetransmitterbutton,thenimmediatelypressingandholdingitwillcausethisoutputtobeactiveas
longas the transmitterbutton is depressed.
Black w/ White Trace Wire: 300 mAHorn Output
The black w/ white trace wire is provided to beep the vehicle’s horn. This is a transistorized low current output, and
shouldonlybeconnectedtothelowcurrentgroundoutputfromthevehicle’shornswitch.
Ifthe vehicleuses a+12VDChornswitch,thenconnecttheblackw/whitetrace wireto terminal86 oftheAS 9256
relay(oranequivalent30Ampautomotiverelay),andconnectrelayterminal85toafused+12VDCbatterysource.
Connect relay terminal 87 to the vehicle’s horn switch output, and connect relay terminal 30 to a fused + 12 VDC
batterysource.
Orange w/ White Trace Wire: 300 mAGround Output When Disarmed - N. O. Starter Disable
( Optional Relay Required ).
Thiswireisprovidedtocontrolthestartercutrelay.Connecttheorangew/whitewiretoterminal86oftherelay.Connect
relayterminal85toanignitionwireinthevehiclethatislivewhenthekeyisintheonandcrankpositions,andoffwhen
thekey isinthe offposition. (Thisis wherethe yellowwirefrom thealarm shouldbeconnected ).
Cut the low current starter solenoid wire in the vehicle, and connect one side of the cut wire to relay terminal 87.
Connectthe othersideofthecutwiretorelayterminal 30.
Note: Thisisanormallyopenedstartercutarrangement,andwhenpowerisremovedfromthesecuritysystem,the
starter disable feature will remain operational, and the vehicle will not start.Audiovox does not recommend
usingtheOrangew/Whitetracewire tointerruptanythingbutthe startingcircuitofthevehicle.

128-8804b
7 of 16
Page7
Dark Green Wire: ( - ) Instant Trigger Zone
Thisis aninstanton groundtrigger wire.Itmust beconnected totheoptional previouslyinstalledhoodand
trunk pin switches when used.
Brown Wire: - Door Trigger
If the vehicle’s courtesy light switches have a ( - ) ground output when the door is opened (GM and most
Imports), you must connect this wire to the negative output from one of the door switches.
WARNING: Donot usethebrown wireifthe vehiclehas+ 12voltoutput typedoor switches. (SeePurple
Wire). Notefor vehicleswithinterior delaylightingsee programmingunder titleCompleting
TheInstallation".
Purple Wire: + Door Trigger
If the vehicle’s door courtesy light switches have a + 12 volt output when the door is opened (most Fords
and some Imports), you must connect this wire to the positive output from one of the door switches.
WARNING: Donot use thepurple wire ifthe vehicle hasgroundoutput typedoorswitches. ( seeBrown
Wire). Notefor vehicles withinteriordelay lighting seeprogrammingunder title "Complet-
ingThe Installation".
Yellow Wire: + 12 VDC Ignition Source
Connect this wire to a source that is live when the key is in the on and crank positions. Be sure that this
source is off when the key is in the off position.
White w/ Blue Trace Wire: Low Current (-) Ground Headlight Output
The White w/ Blue Trace wire is provided to operate the optional headlamp illumination feature of the
system. This is a low current (300mA) output and must be connected to an external relay to control the
high current switching circuit of the vehicle's headlamps. To use this option, Connect the White /w Blue
Trace wire to terminal # 86 of a P&B VF45F11 relay or equivalent. ConnectTerminals #85 and # 30 to a
fused + 12 Volts source with a current capability equal to or in excess of the factory headlamp fuse.
Connect terminal # 87 of the relay to the switched + 12 volt wire feeding the vehicle's headlamp circuit.
NOTE: For groundswitchedheadlamp circuits, Connect theWhite/w Blue Trace wiretoterminal # 86
of a P&B VF45F11 relay or equivalent. Connect Terminal #85 to a fused + 12 Volts source.
Connectterminal #30to acleanchassis ground. Connectterminal #87to theground switched
headlampcontrolwire inthevehicle.
Light Green Wire: (-) Instant Trigger Zone 1
This is a instant on ground trigger input intended for the connection of optional triggering devices. The
ground trigger output wire of motion detectors, microwave detectors, or glass break detectors, can be
connectedtothisLightGreen trigger input wire.
Light Blue/Green Wire: Delayed 300 mA Pulsed Output / Channel 5
Thelightblue/green wire pulses togroundvia an independentRFchannel from the keychaintransmitter.
This is a transistorized, low current output, and should only be used to drive an external relay coil.

128-8804b
8 of 16
Page8
WARNING: Connectingthelight blue/green to thehighcurrent switched output oftrunkrelease
circuits, some remote start trigger inputs, will damage the control module.
Connectthe lightblue/greento terminal86of a30Aautomotive relay,connectterminal 85
to a + 12 volt source, and wire the remaining relay contacts to perform the selected
functionofchannel 5.
2 Pin White Connector: DASH MOUNTED LED.
Route the single blue wire in the 2 pin white connector from the receiver to the control module, and plug it
into the mating white connector on the side of the module.
2 Pin Blue Connector: PUSHBUTTON VALETSWITCH
Routethesingle gray wireinthetwo pin blueconnectorfrom the receivertothecontrol module andplugit
into the mating connector on the side of the module.
4 Pin White Connector: SHOCK SENSOR PART#1122591
Routethe red,black,blue,andgreen wiresin the4pinwhiteconnector fromthe shocksensortothecontrol
module,andplug one endintothe shock sensor, and theotherend into the matingwhiteconnector on the
sideofthemodule.
Red, Green, & Red / Black 3 Pin White Connector: Door Lock Outputs PART # 1122906
TheRed andGreenwires willprovideeither apulsed groundoutputto thefactory doorlockcontrol relay,or
a pulsed + 12 volt output to the factory door lock control relay. In either case, the maximum current draw
throughtheseoutputs must not exceed300mA. The Red w/Blacktracewire will provide apulsedground
only,and willonly providean outputwhentheunlockbutton ofthe transmitteris pressedasecondtimeafter
a first unlock command was issued. This is used for second step unlock or all doors unlock in a two step
circuit. In this arrangement, Red, or Green is used to control the drivers door unlock relay, and the Red/
Black will be used to control unlock of all other doors.
3 Wire Ground Switched Single Step Door Locks
Inthis application, thered wire providesagroundpulse duringarming,or thepulsed ground lock output.
Connectthered wiretothe wire thatprovidesa low currentground signal fromthefactory door lockswitch
to the factory door unlock control relay.
Thegreen wire provides a groundpulse during disarming,orthe pulsed ground unlock output.Connect
thegreen wireto thewire thatprovides alow currentground signalfrom thefactory doorunlockswitchtothe
factorydoorunlock control relay.
Red/Black Not Used.
3 Wire Ground Switched 2 Step Door Locks
Inthisapplication,the red wire provides a ground pulseduringarmingor locking, connect the redwireto
thewirethat provides alowcurrent ground signal fromthefactory door lockswitchto the factory doorlock
controlrelay.
The green wire provides the first ground pulse during disarming or unlocking, connect this wire to the
drivers door unlock relaythatrequiresa low current ground signal tounlockonlythe drivers door.
Ifthe vehicledoes nothave aseparatedriversdoorrelay,onewillhavetobeadded. Locatethedrivers door
unlock motor wire and cut it at a convenient location to allow wiring of an optional relay.

128-8804b
9 of 16
Page9
Connect the door side of the cut wire to terminal 30 of the optional relay added.
Connect the vehicle side of the cut wire to terminal 87a of the optional relay added.
Connect the green wire of the 3 pin harness to terminal 86 of the optional relay added.
Connect terminal 85 of the optional relay added to a fused constant + 12 volt source.
Mostvehicles doorlock/unlockmotor legsrest atground,and switch+12voltstothe doorlock/unlockmotor
legs for operation, if this is the case in the vehicle you are working on, connect the remaining terminal, 87,
to a fused + 12 volt source.
Inthe rareinstancethat thevehicle doorlock/unlockmotor legsrestat +12 voltsandswitches groundto the
door lock/unlock motors, connect he remaining terminal, 87, to chassis ground.
The Red/Black wire provides a pulse ground output when the unlock button of the transmitter is pressed a
secondtimeafter disarming.
Connectthe Red/Blackwire tothe wirethat providesa lowcurrent groundsignal fromthe factorydoorunlock
switch to the factory door lock control relay.
3 Wire Positive Switched Door Locks
In this application, the red wire provides a positive pulse during disarming or unlocking, connect the red
wiretothe wire that providesalow current positivesignalfromthe factory doorunlockswitch to the factory
doorunlockcontrol relay.
The green wire provides a positive pulse during arming or locking, connect the green wire to the wire that
providesalow currentpositivesignal from thefactorydoor lock switchto the factorydoorlock control relay.
3 Wire Positive Switched 2 Step Door Locks
The green wire provides a positive pulse during arming or locking, connect the green wire to the wire that
providesalow currentpositivesignal from thefactorydoor lock switchto the factorydoorlock control relay.
Thered wire provides apositivepulse duringdisarmingor unlocking, connectthiswire tothe drivers door
unlock relaythatrequiresalow current positive signal to unlock only thedriversdoor.
Ifthe vehicledoesnot havea separatedriversdoorrelay,onewill havetobeadded. Locatethe driversdoor
unlock motor wire and cut it at a convenient location to allow wiring of an optional relay.
Connect the door side of the cut wire to terminal 30 of the optional relay added.
Connect the vehicle side of the cut wire to terminal 87a of the optional relay added.
Connect the red wire of the 3 pin harness to terminal 86 of the optional relay added.
Connectterminal85of the optional relay added tochassisground.
Mostvehicles doorlock/unlockmotor legsrest atground,and switch+12voltstothe doorlock/unlockmotor
legs for operation, if this is the case in the vehicle you are working on, connect the remaining terminal, 87,
to a fused + 12 volt source.
Inthe rareinstancethat thevehicle doorlock/unlockmotor legsrestat +12 voltsandswitches groundto the
door lock/unlock motors, connect he remaining terminal, 87, to chassis ground.
The Red/Black wire provides a pulse ground output when the unlock button of the transmitter is pressed a
second time after disarming. Because the vehicle you are working on requires a positive pulse from the
factorydoorlock switchtothe factorydoorlock control relay, you willhaveto addarelay toinvertthe output
polarity of this wire.
Connect the Red/Black wire to terminal 86 of the optional added relay.
Connect terminal 85 & 87 to a fuse + 12 volt source.
Connect terminal 30 to the low current door unlock wire from the factory door switch to the door unlock
controlrelay.

128-8804b
10 of 16
Page10
Resistive Circuits, As Well As 4 Wire Polarity Reversal and
5 Wire Alternating 12 Volt Door Lock Control Circuits
These applications require the use of additional components which may include relays, fixed resistors, or
forconvenience, theAS9159aDoorLockInterface. RefertotheAUDIOVOXDoorLock WiringSupplement
and or theAudiovox fax back service for information on your particular vehicle for properly connecting to
these types of circuits.
4 Pin Upgrade Telematic Module:
Red = + 5 Volts
Black =Ground
White =DataTX
Yellow =Data RX
Connect the 4 pin harness found in the Telematic one way module kit to the mating port on the telematic
module and the other side to the connector on the alarm or keyless entry module.
NOTE: If using the TWO WAYTelematic module, only Ground, TX, and RX are used on this port, the
+ 12volt supply for the two way module must be sourced separately or the unit will not operate.
COMPLETINGTHE INSTALLATION
NOTE: This unit has the ability to learn the dome light delay time, up to 60 seconds. If the vehicle has
delay interior lights, and you wish to avoid three chirp, defect zone, indication normally
associated with this type of interior light, we suggest you learn the interior light delay.
TO LEARN THE DOME LIGHT ENTRYDELAY START WITHALL DOORS CLOSED:
(1) Use the transmitter to Lock / Unlock / Lock / Unlock / Lock / Unlock / Lock, the system.
The LED turns on solid to confirm the system entered the learn mode.
(2) Immediately open and close the door of the vehicle to initiate the dome delay.
Theunitwill monitorthedoor triggerinputPositive, (Purple),andNegative, (Brown)whenactive.
When the dome light turns off, the unit will add 2 seconds then exit the learn mode.
(3) The LED will begin flashing theArmed indication indicating the unit has exited the learn mode
andisarmed.
Adjusting the Shock Sensor:
If used, the sensitivity of the pre - detect circuit is automatically set 30% less sensitive than the full trigger
circuit.
Usinga smallscrewdriver, gentlyturn theadjustmentscrew fullycounterclockwise. (DONOTover turnthis
screw. Maximum rotation for this adjustment is 270°). Close the hood and trunk lids, and arm the alarm.
Wait6seconds fortheaccessories trigger zonetostabilize, thenfirmlystrike the rearbumperwith theside
ofaclosed fist considering theamountof force required tobreaka window.
WARNING ! Never perform this test on the vehicle’s glass, as you may break the window.
Turn the adjustment screw clockwise (increasing sensitivity) about ¼ turn and re-test.
Repeat this procedureuntil thealarmsounds. Ultimately, one firmstriketo therearbumper
will cause the alarm to emit pre-detect warning tones.
CAUTION: Setting the sensitivity too high can cause false alarms due to noise vibrations from passing
trucksandheavyequipment.Todecreasesensitivity,turntheadjustment screwcounter
clockwise.

128-8804b
11 of 16
Page11
4 PIN IN VEHICLE DATABUS PORT (DBI Port) (ConnectorPort)
The 4 pin port located on the side of this module is for proprietaryAudiovox data bus interface modules.
These modules are used to access a variety of features in the vehicle which can be as simple as door
triggerinputs, to morecomplex door locksoutputs, or transponderinterfaces for remotestarting. DO NOT
connectanythingto thisportother than theAudiovox DBImodulesor damage totheRemote Startmodule
willoccur. Allinstallationinstructions for theDBImodules will bepackagedwith the individualcomponent
along with the proper 4 pin wiring harness requires to access the data transmit and receive as well as the
propervoltage levelsfor theinterface.
Wire Dressing:
Always wrap the alarm wires in convoluted tubing, or with a spiral wrap of electrical tape. Secure these
looms along the routing using cable ties. This will ensure that the alarm wires are not damaged by falling
ontohotor sharp movingsurfacesin the vehicle.
Operation:
Take a few moments to check off the appropriate option boxes in the owner’s manual and to fully explain
the operation of the system to your customer.

128-8804b
12 of 16
Page12
The transmitters are pre-programmed from the factory. If you find you need to program new or additional
transmittersfollowthe instructions below.
PROGRAMMINGBANK1 (TRANSMITTERS):
1) Turn the ignition key to the on position.
2)Pressand release thevalet/programmingswitch 3 times (SirenChirps).
3 Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or
siren.
4)Turnthe ignition switchoff.
The above action programs the Lock, Unlock, Start/Trunk, and Option 1 buttons of the system. For addi-
tionalchannelprogramming see the ownersguidefound within the literaturebagpackaged with thiskit.
PROGRAMMING BANK 2 (ALARMFEATURES):
You can enter bank 2 from bank 1 by turning the ignition key off then on from step 4 of Bank 1.
(Siren Short then Long Chirp), or You can also go right to bank 2 by:
1) Turn the ignition key to the on position.
2)Pressand release thevalet/programmingswitch 3 times (SirenChirps).
3)Turnthe ignition keyoffthen on. (SirenShortThen long Chirp)
4) Press the pushbutton switch once to advance to feature 1, twice to advance to feature 2, etc,,,then use
the lock button of the transmitter to select the feature setting.
Example to set passive arming:
1) Turn the ignition key to the on position.
2)Pressand release thevalet/programmingswitch 3 times (SirenChirps).
3)Turnthe ignition keyoffthen on. (SirenShortThen long Chirp)
4) Press the pushbutton switch six times to advance to features 6, Pass/ActArm, then use the lock button
of the transmitter to select two chirps "PassiveArm".
5)Toexit theprogrammingmode, turntheignition keyoff. Theprogram modeisautomatically exitedwhen
there is no activity on the pushbutton switch or the transmitter lock button.

128-8804b
13 of 16
Page13
SELECTABLEFEATURES
Theselectablefeatures of this unitcanbe set manually asexplainedon the previous page,orwith the RF featureprogrammer describedinthe guidepackaged withheprogrammer. Factory default settings are indicated by BOLD text.
Note : The method of manual override can either be selected to operate from the valet switch or operate by custom code. Custom Code programming is found
in the owners guide
Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual. Note: Keyless Entry Models with no horn output will Flash the Parking Lights instead of chirp where chirp is indicated. Also, No data will be indicated if a feature is not available for a particular model. The unit will enter the feature but no selection will be available. RF Programmable Feature Bank 1 Is For Transmitter Programming See Transmitter Programming Guide. RF Programmable Features Bank 2 Is Alarm Selectable Features: Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps 5 Chirps 6 Chirps 1st DoorL/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L Dbl L, 1 Sec UL DblL, DblUL 1 Sl/350mS ul 2nd Accy Lock Auto Lock On Auto Lock Off 3rd Accy. UL Auto UL Dr. Auto ULAll Auto UL Off 4th Headlights OnArm OnDisarm On Both Off 5th Passive Locks Passive Active 6th Pass/Act Arm Passive Arm Active Arm 7th Siren/Horn Siren/Horn Siren Only Horn Only 8th Horn Chirp 10mS 16mS 30mS 40mS 50mS 9th O/R Method Custom Code Valet 10th 2 Step U/L On Off 11th Chp Del Tx On Off 12th Volts/HdWire Voltage Sense Hardwire 13th Trigger Circuits Not Available 14thL/UL Poll Not Available 15th Aux Ch 5 Sel Pulse Push & Hold 10 Sec 20 Sec Latch On/Off Hold 3/S ForO/P 16th Aux Ch 6 Sel Not Available 17th Aux Ch 7 Sel Not Available 18th Trigger Delay Not Available When using the RF programmer, enter the program mode as follows: Turn the ignition on Press and release valet switch 3 times turn ignition off then on Press and hold valet switch for 5 seconds Siren chirps 2 times indicating access to RF feature program mode.

128-8804b
14 of 16
Page14
For technical support go to www.prestigecarsecurity.com or call 1 800 225 6074.
© 2013 Audiovox Electronics Corp., Hauppauge, N.Y. 11788 128-8804b

128-8804b
15 of 16
Page15
NOTES

128-8804b
16 of 16
Page16
NOTES
