Audiovox 82-168-00030 User manual

Identifying the Parts
1. Function Scroller
2. Hold
3. DC IN jack
4. Strap Holder
5. AV IN jack
6. Earphone jack
7. USB port
8. SD/MMC CARD slot
P ersonal V ideo R ecorder
PERSONAL MEDIA CENTER QUICK GUIDE
Charging the Battery
You must charge the battery before using the PVR.
1. Insert the Battery
2. Connect the Power Adapter
Close the battery cover. Connect one end of the AC Adapter to the
DC IN jack of the PVR, the other end to a wall outlet. The red LED
will light during battery charging. Charge the battery for at least 3
hours before using for the Þrst time.
9. Battery Cover
10. Mode button
11. Speaker
12. Record/Vol
button
13. Microphone
14. Power button
15. Menu/Stop
button
16. Play/Pause/
OK button
“Open the battery cover” “Insert the battery in ac-
cordance with the +/- sign
shown on the battery sticker”
Software Installation
1. Insert the Installation CD into CD-ROM.
2. Follow the on-screen instructions to complete
the software installation.
Synchronizing Files between PC
and PVR
1. Power on the PVR and then connect to PC.
2. Upload Þles to PVR via Multimedia Converter program.
Inserting SD/MMC Card for Memory
Expansion
The PVR has built-in internal memory, but you may insert additional
memory card to expand the storage capacity.
“Insert the card as shown
above”
“Push it until a “click“ is heard”
Attaching the Strap
To protect the PVR from falling by accident, it is recommended to
wind the attach around your wrist while holding the PVR.
To attach the strap to the PVR:
82-168-00030
Icons and Indicators on the LCD Display
Photo Player Mode With Card
Video Player Mode Card Lock
Voice Player Mode Battery Full
MP3 Player Mode Battery Low
AV Recorder Mode Out of Battery
Slide Show Mode Recording
Calendar Mode Volume
Game Mode / Low Quality Video/Voice
Record ;
High Quality Video/Voice
Record
Repeat A-B Alarm Clock
Repeat One Search
Repeat All Time
Repeat Normal Video Record Clock
“Insert the thin end of the strap
into the strap holder”
“Pass the other end of the
strap through the loop of thin
cord and pull tight”
Setting Date and Time
Use the MODE button to enter the Calendar mode and then
press the MENU button to select . A date and time adjust-
ment screen will appear. Use the scroller to set up the correct data
and then save the new settings.
Turning on the PVR
Press and hold the the power button for 2 seconds to turn on the
PVR.
Note: You have to either install the battery or connect the power adapter Þrst
*The PVR front panel design is subject to change without further notice.

A
B
C
F
E
D
I
H
G
OSD Menu
The OSD menu contains 9 categories. Each of them provides
individual functions.
Photo Player
To play photos, you have to enter
Photo Player category. In this
category you can review photos,
record voice clip, add special effects
to photos.
Video Player
In this category you can review
videos.
Voice Player
In this category you can listen to
WAV music, record audio clip,
choose a sound track for alarm
sound, add sound effects.
MP3 Player
In this category you can listen to
MP3 music, choose a song for
alarm sound, add sound effects.
AV Recorder
In this category you can record your
favorite TV show directly with PVR or
even set the timer record.
Slide Show
In this category you can review pho-
tos as a slide show.
Calendar
This PVR can be a long life electric
calendar. It’s built-in clock can be a
convenient replacement when you
forget your watch.
Game
There are 2 games available on the
PVR. They are Puzzle and Tic-Tac-
Toe.
Setup Menu
In the Setup Menu you can change
the factory default setting and format
the data stored in the external
memory card/internal memory.
Product Function Digital Photo Player, Digital Video Player,
Digital Video Recorder, Digital Voice Play-
er, Digital Voice Recorder, MP3 Player,
USB Portable Disk, SD/MMC Card Reader
Display 2.5” TFT LCD
Microphone Built-in
Speaker Built-in
TV System NTSC/PAL
DPS Support Yes
Audio Effects POP/Jazz/Classic/Bass/Rock
Interface USB/AV IN/Earphone/DC-IN
Memory Card Slot SD/MMC
Internal Memory Built-in 32MB
File Format ASF(video)/JPEG(photo)/MP3/WAV(audio)
Power Rechargeable Li-ion Battery x1 ;
Power Adapter
Mass Storage Windows 98SE/2000/Me/XP ; Mac OS 9.X
and 10.1 above
Dimensions 3.7(L) x 3.0 (W) x .78 (H) inches
Weight
SpeciÞcations
128-7115
.25lbs without battery
