Audiovox D1210 User manual

12” LCD TV/Monitor and DVD Player
D1210
Owner’s Manual

A. Introduction
Congratulation for selecting this multi-media system, which
features a 12” LCD TV/Monitor and DVD/MP3/CD Player. It
utilizes the latest state of the art electronics and is designed for
use in home, offices, hotels and vehicles. The unit is compact
so that you can take it with you anywhere and is designed for
easy installation. Please read all the instructions in this manual
to assure proper installation and best equipment performance.
B. Cautions and Warnings
1. Read Instructions — All the safety and operating instruc-
tions should be read before the product is operated.
2. Retain Instructions – The safety and operating instructions
should be retained for future reference.
3. Heed Warnings – All Warnings on the product and in the
operation instructions should be adhered to.
4. Follow Instructions – All Operating and user instructions
should be followed.
5. Cleaning – Unplug this product from the wall outlet before
cleaning. DO NOT use liquid cleaners or aerosol cleaners.
Use damp cloth for cleaning.
6. Attachments – DO NOT use attachments not recommended
by the product manufacturer they may cause hazards.
7. Mounting – DO NOT place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product.
Any mounting of this product should follow the manufacture’s
instructions, and should use a mounting accessory recom-
mended by the manufacturer.
8. Heat – The Product should be situated away from any
source, such as radiators, heat registers, stoves or other
products (including amplifiers) that produce heat.
2

9. Water – DO NOT use this product near water. For example,
avoid placing it near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool,
etc…
10. Cabinet Slots – NEVER push objects or any kind into the
unit through the cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a fire or
electric shock. NEVER spill liquid of any kind on the prod-
uct.
11. Ventilation – DO NOT block any ventilation openings.
Install in accordance with manufacturer’s instructions. Slots
and openings in the cabinet and the back and bottom are
provided for ventilation, and to ensure reliable operation of
the product and to protect it from overheating. These open-
ings must NOT be blocked or covered. There should be at
least 10cm of space from these openings. The openings
should never be blocked by placing the unit on a bed, rug or
other similar surface. This product should NOT be placed in
a built-in installation such as a bookcase unless proper
ventilation is provided.
12. Grounding or Polarization – This product may be
equipped with a polarized alternating current line plug (a
plug having one blade wider then the other). This plug will fit
the power outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the outlet, try re-
versing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. DO NOT defeat
the safety purpose of the polarized plug.
13. Power – Cord Protection – Power supply cords should
be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. Pay particu-
lar attention to cords at plugs, convenience receptacles, and
the point where they exit from the product.
3

14. Power Sources – This product should be operated only
from the type of power source indicated on the rear panel. If
you are not sure of the type of power supply to your home
consult your product dealer or local power company.
15. Lightning – For added protection for this product during a
lightning storm, or when it is left unattended and unused for
a long period of time, unplug it from the outlet and discon-
nect the antenna or cable system. This will prevent damage
to the product due to lightning and power-line surges.
16. Power Lines – An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touch-
ing such power lines or circuits as contact with them might
be fatal.
17. Overload – DO NOT overload wall outlets, extension cords
or integral convenience receptacles as this can result in a
risk of fire or electric shock.
18. Damages Requiring Service – Unplug this product from
the wall outlet and refer servicing to qualified service per-
sonnel under the following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally after following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in perfor-
mance – this indicates a need for service.
4

19. Replacement parts – When replacement parts are
required, be sure the service technician has used replace-
ment parts specified by the manufacturer or have the same
characteristics as the original part. UNAUTHORIZED
substitution may result in fire, electric shock or other haz-
ards.
20. Safety Check – Upon completion of any service or repair
to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
21. CAUTION – There is a danger of explosion if the battery is
incorrectly replaced. Replace only with the same or equiva-
lent type.
22. Important Information Regarding Use of Video Games,
Computer, Captions or other Fixed Image Displays.
The extended use of a fixed image program material can
cause permanent “Shadow Image” on the LCD Panel. The
Background image is viewable on normal programs in the
form of a stationary fixed image. This type of irreversible
LCD panel deterioration can be limited by observing the
following steps:
a. Reduce the brightness/contrast setting to a minimum
viewing level.
b. DO NOT display the fixed image for extended periods of
time.
c. Turn the power off when not in actual use.
23. Recycling – This product utilizes tin-lead solder, and
has a fluorescent lamp containing a small amount of mer-
cury. Disposal of these materials may be regulated in your
community due to environmental considerations. For dis-
posal or recycling information please contact your local
authorities, or the Electronics Industries Alliance: http://
www.eiae.org/
5

24. Safety Caution
The Lightning flash with the arrowhead symbol within an
equilateral triangle is intended to alert the user to the pres-
ence of uninsulated “DANGEROUS VOLTAGE” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk or electric shock to persons.
The Exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing instructions in the
literature accompanying the product).
25. Federal Communication Commission Information
(FCC)
This Equipment has been tested and found to comply with
the limits for a TV Broadcast Receiver, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. If this equipment
does cause or receive interference, which can be deter
mined by turning equipment off and on, the user is encour-
aged to try to correct the interference by one of the following
measures:
6

1. Reorient or relocate the TV antenna
2. Increase the separation between TV and other
equipment.
3. Connect TV into separate outlet from equipment.
4. Consult the dealer or an experienced radio/TV
technician for help
FCC Caution: Any changes or modifications not expressly ap-
proved by the party responsible for compliance could void the
user’s authority to operate this equipment
26. INSTALLATION
a. Receiver Location – Locate for comfortable viewing.
Avoid placing where sunlight or other bright light will fall
on the screen. Use of some types of florescent lighting
can reduce remote control transmitter range.
Adequate ventilation is essential to prevent internal com-
ponent failure. Keep away from areas of excessive heat.
To ensure optimum picture quality do not position mag-
netic equipment nearby.
b. Cable Equipment – The Video/Audio connection be-
tween components can be made with shielded video and
audio cable. For best performance, antenna cables
should utilize 75 Ohm coaxial shielded wire. Cables are
available from your dealer or electronic supply store.
Before you purchase any cables, be sure you know what
type of output and input connectors your various compo-
nents require. Also determine the length of cable you’ll
need.
c. Optimum Quality picture – Turn off florescent lamps
near the LCD and place in a location not exposed to
outdoor light.
7

27. DVD CAUTION: This unit employs a laser system. To
ensure the proper use of the unit, read this manual carefully
and keep it for future reference. To prevent direct exposure
to the laser radiation, do not open the cabinet. Invisible
laser radiation could be present when the cabinet is opened
or the interlocks are defeated. DO NOT stare into the laser
beams. Use of any controls, adjustments, or procedures
other than those specified herein may result in hazardous
radiation exposure!
a. Region Management Information – This Player is
designed to respond to the Region Management Informa-
tion recorded on DVDs, The region number of this player
is “1”. If the region number described on the DVD does
not correspond to the region number of this player, this
player cannot play this disc.
b. Dolby
Manufactured under license from Dolby Laboratories.
“Dolby” , “Pro Logic” and the double-D symbol are trade-
marks of Dolby Laboratories. Confidential Unpublished
Works © 1992-1997 Dolby Laboratories, Inc. All rights
reserved.
8

c. Macrovision
This product incorporates copyright protection technology
that is protected by method claims of certain U.S patents
and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized
by Macrovision Corporation. It is intended for home and
other limited viewing use only unless otherwise autho-
rized by Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
d. Note – Some DTS decoders which do not support DVD-
DTS interface may not work properly with the DVD/CD
Player.
e. Reference
1) Dolby Digital is a digital sound compression technique
developed by Dolby Laboratories, Inc. Supporting 5.1-
channel surround sound, as well as stereo (2 Channel)
sound, this technique enables a large quantity of sound
data to be efficiently recorded on a disc.
2) The Digital Theater System (DTS) is a 5.1-channel
surround sound system, which is widely used in movie
theaters around the world, It allows the bit rate to be
increased in order to provide good sound quality with-
out excessively compressing the data.
3) Linear PCM (LPCM) is a signal recording format used
in a CD. While a CD is recorded in 44.1 kHz/16 bit, a
DVD is recorded at 48 kHz/16 bit up to 96kHz/24 bit.
4) If you have a Dolby Pro Logic Surround decoder, you
will obtain the full benefit of Pro Logic from the same
DVD movies that provide fill 5.1-channel Dolby Digital
soundtracks, as well as from titles with the Dolby Digi-
tal mark
9

5) The digital audio output connector (optical) converts
electrical signals into optical signals (light) and trans-
fers them to an amplifier. These optical signals are
immune from electrical interference, and they also have
minimal effect on other equipment.
C. Contents
1. TV /DVD Combination Unit o w/Speakers
2. Coaxial Connector
3. Remote Control
4. AC to DC Adapter
5. Cig. Lighter Adapter
6. Wireless IR Headphones(2 pcs)
7. 3.5mm-RCA AV Cable
8. Storage Bag and Mounting Bag w/Mounting Straps
9. Owner’s Manual
D. Indoor Installation (Refer to Figure 1)
Swing up the rear metal stand and place the unit on a table or
other level surface. Plug one end of the AC to DC adapter into
the DC 12V input on the right side of the main unit, then plug the
other end into the 110V AC power receptacle.
Figure 1
Note: Detach the two speakers from the main unit, and only use
headphones or connect your Car Audio in the car.
10

D. Car Installation
On the seat back (Refer to Figure 2)
Figure 2
1. Take the unit and the mounting bag from the storage bag.
Slide the unit into the mounting bag, fasten the buckle and
tighten the straps and on the side of the bag.
2. Unfasten the velcro on the rear stand off flap on the rear of the
bag. Fold the rear stand off flap to form a triangle and attach
it’s end Velcro strap to the middle Velcro strap on the back of
the bag.
3. Take one of the supplied straps from the storage bag and
connect the latch to one of the top rings. Loop the strap
around the headrest. Attach the “S” hook to the other top ring
on the other side of the bag.
4. Take another strap and connect the latch to the lower ring on
the mounting bag. Attach the “S” hook to the same ring after
looping the strap around the rail located beneath the seat
track. Avoid moving parts in the seat mechanism. Repeat
this process for the other side. In some vehicles, it may be
necessary to attach the “S” connector to the rail directly, as it
may not be long enough to reach back to the ring.
5. Adjust all the straps tightly so that the bag is secure.
6. Plug one end of the cigarette lighter adapter into the DC 12V
input; then plug the other end into the cigarette lighter socket
on the dashboard. 11
Mounting
Bag
Top Rings
Lower Rings

Between two seats (Refer to Figure 3)
Figure 3
1. Take one of the supplied straps from the storage bag and
connect the latch to the top metal ring on the mounting bag.
Wrap the strap around the base of one the headrests. Attach
the “S” hook to the same top metal ring. Repeat this process
for the other side (Passenger Seat).
2. Take another strap and connect the latch to the lower metal
ring on the back of the bag. Attach the “S” hook to the same
ring after looping the strap around the rail located beneath
the seat track. Avoid moving parts of the seat mechanism.
Repeat this process for the other side. In some vehicles, it
may be necessary to attach the “S” connector to the rail
directly, as it may not be long enough to reach back to the
ring.
3. Adjust all the straps tightly so that the bag is secure.
4. Plug one end of the cigarette lighter adapter into the DC 12V
input; then plug the other end into the cigarette lighter socket.
12

1. DVD Previous
2. DVD Play
3. DVD Next
4. DVD Eject
5. DVD Stop
6. IR Headphone Sensor
7. TV Antenna Input
8. Headphone Input #1
9. AV Input
10. Power On/Off
11. DVD/TV/AV Switch
12. Picture Select
13. Volume Down
14. Volume Up
15. TV Channel Down
16. TV Auto Program
17. TV Channel Up
18. Surround Sound 3D
19. Headphone Input #2
20. DC 12V Input
21. DVD Video Output
22. DVD Left Audio Output
23. DVD Right Audio Output
24. External Speaker Input
Figure 4
13
E. Controls/Indicators/Connectors (Refer to Figure 4)

14
F. Remote Controls (Refer to Figure 5)
1. TV/DVD/AUX Select
2. DVD Number Control Select
3. Numbers 0-9
4. TV/CATV Select
5. Mute
6. Picture Select
7. Volume Up/Down (+/-)
8. DVD Eject Button
9. Up/Down-Left/Right/Enter
10. DVD Menu
11. DVD Display
12. DVD Stop
13. DVD Reverse
14. DVD Forward
15. DVD Audio Select
16. DVD Subtitle Select
17. Power On/Off
18. TV Number Control Select
19. TV Channel Auto Memory
20. TV Channel Skip Search
21. TV Channel Erase Write
22. Channel Up/Down (+/-)
23. DVD Power On/Off
24. DVD Setup
25. DVD Play
26. DVD Pause
27. DVD Next
28. DVD Previous
29. DVD Repeat
30. DVD Slow Play
Figure 5

15
G. DVD Player
1. Basic Operation
POWER
EJECT
PLAY
PAUSE
STOP
NEXT
PREVIOUS
FORWARD SCAN
REVERSE SCAN
SLOW
UP/DOWN/LEFT/RIGHT
ENTER
NUMBERS
MENU
SUBTITLE
AUDIO
DISPLAY
SETUP
Turn the unit ON or OFF
Eject and withdraw the disc
Resume play mode
Go into the standby mode
(1 time) Stops at the present playing
point / (2 times) Stops playing
Go to the next chapter, track or scene
during playback
Go back to the preceding chapter,
track or scene during playback
Scan forward at 2, 4, 6, or 8 times normal
speed
Scan backward at 2, 4, 6, or 8 times normal
speed
Play at 1/2, 1/4, or 1/8 times speed
For Navigating the Setup Menu
Execute item or setting
For entering a password
Display the root menu of the DISC
Select the subtitle language and turn it on/off
Select the audio language
Display information about the DISC
Display the setup menu

2. Menu
A DVD is divided into sections called title and chapter. When you
play a DVD, a root menu of the disc will appear on the screen of
your TV or Monitor. The contents of the menu vary from disc to
disc. Press MENU during playing to display the menu, and press
ENTER or PLAY to start playing. Some DVDs allow you to select
disc playback options using the DVD menu.
3. Display (The contents vary from disc to disc.)
1) Playing time and remaining time
a. During playback press DISPLAY to display the current title
number (1), the total number of titles (2), the current chapter
number (3), the total number of chapters (4), and the playing
time for the title (5). The heading will disappear automatically
in about 3 seconds.
b. Press DISPLAY again to display the remaining time for the
title. The heading will disappear automatically in about 3
seconds.
16

c. Press DISPLAY the 3rd time to display the elapsed time for
the chapter. The heading will disappear automatically in about
3 seconds.
d. Press DISPLAY the 4th time to display the remaining time for
the chapter. The heading will disappear automatically in about
3 seconds.
Press DISPLAY the 5th time to exit.
2) Subtitle
During play press SUBTITLE to select the subtitle language you
desire, with the current subtitle language number (1) and the
total number of subtitle languages (2) displayed. If there are
multiple languages press SUBTITLE again to select another sub-
title language. To turn subtitles off, press the subtitle button until
SUBTITLE OFF is displayed. The subtitle display will disappear
automatically if the SUBTITLE button isn’t pressed again for 3
seconds.
17

3) Audio
During playback, press AUDIO to select the audio language you
desire, with the current audio channel number (1) and the total
number of audio channels (2) displayed. Press AUDIO again to
select another audio language. The audio display will disappear
automatically if the AUDIO button isn’t pressed again for 3 sec-
onds.
4) Repeat
a. During playback, press REPEAT to repeatedly play the cur-
rent chapter.
18

b. During playback, press REPEAT again to repeatedly play the
current title.
c. During playback, press REPEAT a 3rd time to cancel the re-
peated playing and resume normal playback. The repeat dis-
play will disappear automatically if the REPEAT button isn’t
pressed again for 3 seconds.
4. Setup
Press SETUP to display the main page of the setup menu on the
screen. Press SETUP again to exit the SETUP menu and the unit
will resume playback or stop mode.
19

1) Select GENERAL SETUP using UP/DOWN and then press
ENTER to enter the general page.
a. Select TV DISPLAY using UP/DOWN, and then press RIGHT
to enter the submenu. Select the TV display mode on the
screen using UP/DOWN, and press ENTER to confirm the
setting. Press LEFT to return.
* NORMAL/PS: When the player is connected to a normal
TV, and a wide picture is shown on the full screen, with a
portion that may be cut off automatically.
* NORMAL/LB: When the player is connected to a normal TV,
and a wide picture is shown on the screen, with black strip at
both top and bottom of the screen.
* WIDE: When the player is connected to a wide screen TV, a
wide picture is shown on the full screen.
b. Select ANGLE MARK using UP/DOWN, and then press
RIGHT to enter the submenu. Choose to show an angle mark
on the screen using UP/DOWN and then press ENTER to
confirm the setting. Press LEFT to return.
20
