MODEL SU-101
SUB-WOOFER SPEAKER SYSTEM
WITH
DUAL SATELLITE TWEETERS
OO
OO
OWNER'S MANUWNER'S MANU
WNER'S MANUWNER'S MANU
WNER'S MANUALAL
ALAL
AL
ANDAND
ANDAND
AND
INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATION GUIDETION GUIDE
TION GUIDETION GUIDE
TION GUIDE

INTRODUCTION
Congratulations on your purchase of the Rampage High Performance vehicle Sub-woofer System. High
quality Bass reproduction, coupled with dual tweeters, allows your car's audio system perform to its full
potential.
TOLL-FREE ASSISTANCE
The installation and connections are so simple we doubt you’ll need our help, but if you do, we’re here to
help you. Just call our toll-free assistance line at 1-800-645-4994 during the days/hours shown.
EASTERN
8:30AM - 7PM
9AM - 5PM
7:30AM - 6PM
8AM - 4PM
CENTRAL
6:30AM - 5PM
7AM - 3PM
MOUNTAIN
PACIFIC
5:30AM - 4PM
6AM - 2PM
MON. - FRI.
SATURDAY
DAY TIME ZONE
2
INDEX
Introduction and Contents Page 2
Packing List Page 3
Major Components Page 3
InstallationParts Page 3
Placing the System Page 4
InstallationSub-woofer Page 5
Enclosure
SatelliteTweeterConfiguration Page 6
Wiring Instructions Page 7
SU-101 Speaker System Page 8
Interconnection Wiring Diagram
Use of Controls Page 9
Troubleshooting Page 10
Specifications Page 10
Warranty Page 11

PACKING LIST
Installation of your SU-101 is easy and everything you need is included in this package. Open it up, lay out
the parts and you are ready to get started.
3
INSTALLATION PARTS
Socket-Head
Machine Screw
M6 x 12 mm
4 pcs
Pan-Head
Machine Screw
M5 x 10 mm
4 pcs
Hex-Head Tapping Screw
(with Captive Washer)
5mm x 25 mm 8 pcs
Tweeter Mtg
U-Channel
Bracket
2 pcs
2 pcs Tweeter Mtg
Bracket
Tweeter Mtg
Retaining
Plate
2 pcs
2 pcs
Enclosure Cable
Assembly (High
Level In/Out)
Enclosure Mtg
Bracket 4 pcs
1 pc
2 pcs
HighInput/Output
Extension Cable
Assys (4 M Each)
Ground Wire
(Black, 1.3 M)
Remote Wire
(Blue, 3.0 M)
12 Vdc B+ Wire
(Yellow, 4.0 M)
Hex Allen-Head
Driver (2.5mm
and 5mm)
1 pc
1 pc
1 pc
M5 Flat Washer4 pcs
MAJOR COMPONENTS
Sub-woofer Enclosure Assembly Tweeters (2)
SAFETY
LANYARD
TWEETER SWIVEL
BRACKET
TWEETER
SPEAKER
BRACKET MTG
SCREWS

4
REAR CARGO AREA MOUNTING (VANS, SUVs AND HATCHBACKS)
Placing the System
1. Mount the subwoofer enclosure in either the Rear Cargo Area (for Vans, SUVs and Hatchbacks) or in the trunk
(forsedans).
2. Mount the tweeters on the vehicle interior, high up for maximum sound and facing forward for optimum usage.
Important Installation Warnings
1. NEVER attempt to install this system in the area above the vehicle fuel tank. Drilling mounting holes could pierce
the fuel tank.
2. ALWAYS check under the area you select for installation, for wires or other obstructions.
3. ALWAYS make sure that you mount the subwoofer so the control panel is accessible to facilitate adjustments.
4. NEVER try to extend the length of the cables supplied with your system. The High Level Input/Output cable from
the speaker enclosure and the four RCA jacked extension cables are 15 feet long. DO NOT exceed this length in
yourinstallation.
5. CAREFULLY plan the routing of your wires from the rear deck area to the dashboard and/or satellite tweeters,
keeping in mind the length of the available cables.
6. CHECK to make sure your chosen installation place does not interfere with the removal of your spare tire.
7. REMEMBER that failure to properly install the subwoofer enclosure may affect sound quality.
Follow the installation instructions for best results.
TRUNK MOUNTING (SEDANS)
SATELLITE TWEETER
MOUNTING
MOUNT ON FLOOR OF DECK
(HORIZONTAL)
SATELLITE TWEETER
MOUNTING MOUNT ON FLOOR OF DECK
(HORIZONTAL)
SATELLITE TWEETER
MOUNTING
MOUNT ON FLOOR OF
TRUNK(HORIZONTAL)

5
INSTALLATION
SUB-WOOFER ENCLOSURE
The SU-101 sub-woofer enclosure is designed for horizontal (flat) mounting. It must never be mounted upside-down
or on either of it's sides. The most convenient area for enclosure installation is within the trunk of cars, such as sedans,
or on the rear cargo area of vans and SUVs. It is also possible to mount the unit behind the front seat area of utility and
pick-up trucks if space allows.
The following procedure outlines the basic installation criteria for the enclosure.
1. On a flat surface, place the enclosure upside down and determine the position of each of the four mounting
brackets; each should be positioned in from each corner approximately 2 inches.
2. Attach each bracket using four of the 5mm x 25 self-tapping screws supplied.
NOTE: Make sure to orient each bracket so the tab contacts the side of the unit. This will prevent the bracket from
shifting during vehicle movement, sudden stops, etc.
3. Secure the enclosure to the surface (trunk or deck ) of the vehicle in the desired position. If desired, a mounting platform
of 3/4" plywood or other material could be used to compensate for uneven surfaces within the vehicle; the enclosure
could then be mounted to this surface.
4. Center the enclosure either on the vehicle surface or on the mounting platform and secure the unit using the remaining
four 5mm x 25 self-tappingscrews through the bracket holes.
5. Proceed to the wiring diagram on page 8 of this manual.
ENCLO-
SURE
BOTTOM
2 inches 5mm x 25 SELF-
TAPPING SCREW
ENCLOSURE
MOUNTING
BRACKET
MOUNTING PLAT-
FORM (3/4" PLYWOOD
OR OTHER MATERIAL)
ATTACHED TO
VEHICLE
5mm x 25 SELF-TAPPING
SCREW

6
SATELLITETWEETERSCONFIGURATION:
Normally, the satellite tweeter each is supplied with the bracket
andlanyardwireattachedas shown in the drawingtotheright.Ifthe
speaker is not assembled as shown, assemble the swivel bracket
and lanyard to the speaker as illustrated. The bracket, lanyard and
screws are packed with each speaker.
SATELLITETWEETERS
The two satellite tweeters supplied with the system are intended
formounting inside thevehicle interior; theycan be mounted
severaldifferentways.
1. Mounting the Speaker to the Rear Wall:
The satellite tweeter can be mounted to the interior rear wall
oneachside of thevehicle,aftof the rear window. Suggested
locations are the clothes hangar clip and/or the assist
handle. To accomplish this, proceed as follows:
a. Attach one end of a stepped metal bracket to each
speaker bracket as shown using an M5 x 10 mm screw.
b. Loosen the assist handle or clothes hangar clip at the
desired mounting location.
c. Attach the other end of the stepped bracket to the de-
sired mounting location using the existing factory hard-
ware. The speaker lanyard should be securely attached
to the other available factory hole locations using the
existing factory hardware.
d. Orient the speaker (facing front) as desired and tighten
the speaker bracket setscrew to maintain this position.
2. Mounting the Speaker over the Rear Molding:
Thesatellite tweeter can be mounted over the edge of the
molding that runs along the interior rear wall on each side of
the vehicle. To accomplish this, proceed as follows:
a. Attach a U-channel bracket to each speaker bracket
using an M5 x 10 mm screw; the screw can be
tightenedby extending thescrewdriver through thelarge
access hole in the U-channel bracket as shown.
b. SliptheU-channel bracket overthetopedge of themold-
ing; then slide the retaining plate in front of the molding
surface. Secure each assembly in place by threading
two M6 x 12 mm screws through the U-channel bracket
into the indents of the retaining plate, clamping the
retainingplate securely against themoldingsurface. The
speaker lanyard should be securely attachedto the
other available factory hole locations using the existing
factoryhardware.
c. Orient the speaker as desired and tighten the speaker
bracket setscrew to maintain this position.
U-CHANNEL
BRACKET
M5 X 10
PAN HEAD
SCREW
M6 X 12 SOC
HD SCREW
LANYARD
RETAINING
PLATE
WINDOW
MOLDING
CLAMP
BRACKET
(REF)
EXISTING MOUNT
LOCATION IN VEHICLE
5 X 10mm
SCREW STEPPED
MOUNTING
BRACKET
SPEAKER
BRACKET
(REF)
LANYARD
SPEAKER
BRACKET
WINDOW
MOLDING
SPEAKER
BRACKET
HEX ALLEN
WRENCH BRACKET
SETSCREW
TO CLOTHES
HANGAR CLIP OR
ASSIST HANDLE
EXISTING
VEHICLE
HARDWARE
SATELLITETWEETERCONFIGURATION
SPEAKERBRACKET
LANYARD
BRACKET
MOUNTING
SCREWS
SATELLITE
TWEETER

WIRING INSTRUCTIONS
ThepowerconnectionsfortheSU-101enclosurearemadeviaascrew-tightenedterminalblock.Simplyloosenthescrew
fully insert the wire or spade lug under the respective terminal screw, then tighten the screw to secure the lug.
1. Power Connection
The battery terminal (B+) must be connected directly to the positive terminal of the vehicle battery to provide an
adequatevoltagesourceandminimizenoise.Connectingthebatteryterminalleadtoanyotherpoint(suchasthefuse
block) will not power-up the SU-101. Use only the Yellow wire supplied for this purpose. Connect this lead to the
battery terminal after all other wiring is completed.
2. Ground Connection
The ground terminal (GND) terminal connection is also critical for correct operation of the SU-101. Use only the
supplied Black wire with spade lugs for this purpose, and connect it between the ground terminal (GND) of the
enclosureandametalpartofthevehicleclosetothemountinglocation.Thiswireshouldbeasshortaspossible
andanypaintorrustatthegroundingpointshouldbescrapedawaytoprovideacleanmetalsurfacetowhichthe
end of the ground wire can be screwed or bolted.
3. Remote Turn-On Connection
TheSU-101isturnedonbyapplying+12voltstotheremoteturn-onterminal(REM).ThesuppliedBluewirewith
spadelugs should beattached betweenthis terminal andthe "Auto-Antenna" leadfrom the carstereo whichwill
provide+12volts only when thecarstereois turned on. Ifthecarstereo does not provideanAuto-Antennalead,
the remote turn-on lead may be wired to an "Accessory" or "Radio" terminal in the car's fuse block. This will turn
the amplifier on and off with the ignition key, regardless of whether the car stereo is on or off.
4. Speaker Connections
Wirethesatellitespeakerstothe"SpeakerOutput"terminalsaspertheOutputWiringDiagramusingthesupplied
input/output extension cable assemblies. When mating the wiring to the speakers, pay careful attention to the
polarityofthespeakerleads,and make certaintheycorrespondtothepolarityofthecorrespondingterminalson
the highlevel input/output 10-pin adapter harness. DO NOT ground any speaker leads to the chassis of the
vehicle.
5. Input Connections
Thesub-wooferenclosurefeaturesbothhighandlow-levelinputcapability. Useeitherthelow-levelorhigh-level
inputs,notboth.Iflow-leveloutputsareprovidedfromthe car stereo, it isrecommendedthatthelow-levelinputs
beusedforlowest distortion andbestperformance.Usegood quality shielded audiocableswithRCA plugs (not
supplied)at both ends to connectthe stereo tothe sub-woofer enclosure Land R low-levelinput jacks; keepthe
cable lengths to a minimum to avoid noise.
Ifthecarstereodoesnotprovidelow-leveloutputs,thesub-woofer maybeconnectedviathespeaker(high-level)
outputs from the stereo. Wire the speaker leads from the car stereo to the supplied 10-pin adapter harness
using the supplied RCA tip-jack cable assemblies as shown in the diagram (shielded cable is not required
forthisapplication),andplugtheharnessconnectorintothematingHigh-LevelInputconnectorontheenclosure.
Carefully mate and insulate all wire connections.
CAUTION: Use either the low-level or the high-level inputs on the enclosure. DO NOT use both input levels at
the same time.
7

8
SU-101 SPEAKER SYSTEM INTERCONNECTION WIRING DIAGRAM
BLUE (REMOTE POWER ON ENABLE)
BLACK (VEHICLE GROUND)
YELLOW (+ 12 VOLTS)
RIGHT CHANNEL
SATELLITE
TWEETER
LEFT CHANNEL
SATELLITE
TWEETER
CHASSIS (VEHICLE)
GROUND
RIGHT
REAR
RIGHT
FRONT
LEFT
REAR
LEFT
FRONT
SU-101 SUB-WOOFER
ENCLOSURE
10-PIN
RECEPTACLE
EXISTING SCREW OR BOLT
CLEAN PAINT, RUST, DIRT OR
GREASE FROM AREA FOR GOOD
CONNECTION
CONNECT THIS
WIRE LAST
USE # 10 GAUGE
GROUND METAL
SECTION OF VEHICLE
CHASSIS
GROUND
LOW-LEVEL
RCA OUTPUTS
GROUND (BLACK)
RED
TO FRONT
SPEAKERS
(WHEN USED)
BLACK
( - )
RED
( + ) BLACK
( - )
RED
( + )
10-PIN
CONNECTOR
12 VOLT VEHICLE
BATTERY
BLACK ( - )
RED ( + )
BLACK ( - )
RED ( + )
EXISTING VEHICLE
REAR SPEAKERS
LEFT REAR
SPEAKER RIGHT REAR
SPEAKER
IMPORTANT
USE EITHER HIGH LEVEL OR
LOW LEVEL INPUT NOT BOTH
RCA TYPE
SHIELDED
CABLES

9
USE OF CONTROLS
1 1
1 1
1 ON LED INDICATOR
This indicator lights green when the system is powered up
and operating normally.
2 2
2 2
2 FAIL LED INDICATOR
This indicator lights red when a system failure occurs
activating the overvoltage protection circuit.
3 3
3 3
3 PHASE SELECT SWITCH
This slide switch is used to change the phase of the
reproduced sound output from the SU-101 Speakers to
match the phase of the audio receiver system.
44
44
4RCA INPUT - R CONNECTOR
This connector accepts the right channel low level output
RCAconnector(LINEOUT)fromthevehicleradioreceiver.
5 5
5 5
5 RCA INPUT - L CONNECTOR
This connector accepts the left channel low level output
RCAconnector(LINEOUT)fromthevehicleradioreceiver.
66
66
6HIGH LEVEL INPUT/OUTPUT CONNECTOR
This 10-pin connector provides audio (speaker) connec-
tionsbetweenthesub-wooferenclosure,thesatellitetweet-
ers and existing audio receiver system.
7 7
7 7
7 FUSE - 15A
This fuse provides surge/overvoltage protection for the
SU-101 speaker system.
12 34 5 6
7
8
9
1011
12
13
88
88
8B+ TERMINAL
Connect+12Vdcvehiclepowertothisterminalusingthe
Yellow wire supplied (4 meters long).
99
99
9 GND TERMINAL
Connectthisterminaltovehiclechassisgroundusingthe
Black wire supplied (1.3 meters long).
blbl
blbl
bl REMOTE (REM) TERMINAL
Connecttheremoteoutputfromthecaraudiosystemto
this terminal using the Blue wire supplied (3 meters
long).
bm bm
bm bm
bm L/R LEVEL CONTROL
This control varies the audio output level to the
satellite tweeters between MIN and MAX.
bn bn
bn bn
bn SWF FREQ CONTROL
This control adjusts the sub-woofer low-pass-filter
cutoff frequency between 36 Hz and 220 Hz.
bn bn
bn bn
bn SWF LEVEL CONTROL
This control varies the audio output level to the sub-
woofer enclosure between MIN and MAX.

TROUBLESHOOTING
An error made in operation or during installation of this product may be mistaken for a system malfunction. Please
perform the checks described below before contacting your dealer or service facility.
10
Specifications:
Speaker Section:
Woofer (1) 8" Cone Type
Tweeter (2) 3" Satellite Speaker
Impedance 4 Ohms
Power Amplifier Section:
Inputs Low-Level RCA Jack and High Level Speaker Inputs
Maximum Output 360 Watts
Nominal Output 55 Watts (150 Hz, 0.1% THD)
Input Level Adjustment Range 0.2 - 4.0 V Low Level
0.4 - 8.0 V High Level
Harmonic Distortion < 0.03 % (at 100 Hz)
Low-Pass Filter Cut-Off Frequency 36 - 220 Hz (Variable), 18 dB/Octave
Satellite Tweeter Frequency Range 2 kHz - 20 kHz
Subwoofer Frequency Range 30 Hz - 300 kHz
System Section:
Input Power Requirements 12 Vdc Car Battery (Negative Ground)
Power Supply Voltage (min/max) 10.5/16 Vdc
Current Drain 13 Amps at Rated Output
1.5 mA Remote Input
Dimensions
Main Unit 420 mm x 249 mm x 249 mm
(16 2" W x 9f" H x 9f" D)
Satellite Tweeter 76 mm x 76 mm x 102 mm
(3.0 " W x 3.0" H x 4.0" D)
Weight
Main Unit 9 kg (19 lbs, 13 oz)
Satellite Tweeter 0.4 kg (0.85 lb, 0.58 oz)
WARNING: High-powered car audio systems may produce sound pressure levels that exceed the thresh-
old at which hearing loss may result. They may also impair a driver’s ability to hear traffic sounds
or emergency vehicles. Use common sense and practice safe listening habits when listening to
your audio system.
Remedy
Symptom
No power
Sub-woofer audio out-
put distorted
Satellite tweeter audio
output too low
Sub-woofer audio
output too low
Possible Cause
Check fuses in vehicle fuse box and SU-101 sys-
tem. Replace as necessary with fuse of same type
and rating as original. If fuse blows again, consult
with service facility.
Check all wiring and correct as necessary.
Checkallwiringandcorrectasnecessary.Consult
with service facility.
Checksatellitetweeterwiring.Consultwithservice
facility.
Check wiring between sub-woofer enclosure and
existingaudiosystem.Consultwithservicefacility.
Blown fuse
Incorrect connection
UsePHASEswitchtoadjustthephase
relationshipbetweencaraudiosystem
and sub-woofer system.
UseL/RLEVELcontrolonenclosureto
adjust tweeter audio output to desired
level.
UseSWFLEVELcontrolonenclosure
to adjust sub-woofer audio output to
desired level.

11
© 2003 Audiovox Electronics Corp., Hauppauge, NY 11788 Printed in China
128-6692
AUDIOVOXCORPORATION(theCompany)warrantstotheoriginalretailpurchaserofthisproductthatshould
thisproductoranypartthereof,undernormaluseandconditions,beprovendefectiveinmaterialorworkmanship
within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with new or
reconditionedproduct(attheCompany'soption)withoutchargeforpartsandrepairlabor.
ToobtainrepairorreplacementwithinthetermsofthisWarranty,theproductistobedeliveredwithproofofwarranty
coverage(e.g.dated billofsale),specificationofdefect(s),transportationprepaid,tothewarrantycenteratthe
addressshownbelow.
ThisWarrantydoesnotextendtotheeliminationofcarstaticormotornoise,tocorrectionofantennaproblems,
to costs incurred for installation, removal, or reinstallation of the product, or damage to tapes, compact discs,
speakers, accessories, or vehicle electrical systems.
ThisWarrantydoesnotapplytoanyproductorpartthereofwhich,intheopinionoftheCompany,hassuffered
orbeendamagedthroughalteration,improperinstallation,mishandling,misuse,neglect,accident,orbyremoval
ordefacementofthefactory serial number/bar code label(s). THEEXTENTOFTHECOMPANY'SLIABILITY
UNDERTHISWARRANTYISLIMITEDTOTHEREPAIRORREPLACEMENTPROVIDEDABOVEAND,INNO
EVENT,SHALLTHECOMPANY'SLIABILITYEXCEEDTHEPURCHASEPRICEPAIDBYPURCHASERFOR
THEPRODUCT.
ThisWarrantyisinlieuofallotherexpresswarrantiesorliabilities. ANYIMPLIEDWARRANTIES,INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS
WRITTENWARRANTY. ANYACTIONFORBREACHOFANYWARRANTYHEREUNDERINCLUDINGANY
IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30 MONTHS
FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESSORIMPLIED,WHATSOEVER. NopersonorrepresentativeisauthorizedtoassumefortheCompany
any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of
incidentalorconsequentialdamagesotheabovelimitationsorexclusionsmaynotapplytoyou. ThisWarranty
gives you specific legal rights and you may also have other rights which vary from state to state.
90 DAY LIMITED WARRANTY
U.S.A. : AUDIOVOX CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788 " 1-800-645-4994
CANADA: CALL1-800-645-4994 FOR LOCATION OFWARRANTY STATIONSERVINGYOUR AREA
FormNo.128-5047A
