Audiovox WIDTV1 User manual

WIRELESS
LIVE LOCAL TV
ON THE GO
WIDTV1
Mobile TV
Receiver
User’s Guide
128-9242 WIDTV1 User's Guide 08 15 2013.indd 1 8/15/2013 5:33:03 PM

FCC Caution:
"Changes or modications not expressly approved by the part responsible for compliance
could void the user's authority to operate the equipment."
FCC Statements:
"is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) is device
must accept any interference received, including interference that may cause undesired
operation"
“is equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. ese limits are designed to provide
reasonable protection against harmful interference in a residential installation.
is equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help."
128-9242 WIDTV1 User's Guide 08 15 2013.indd 2 8/15/2013 5:33:03 PM

Table of Contents
Introduction................................................................................... 2
Package Contents......................................................................... 3
System Requirements ................................................................. 4
Safety Instructions ....................................................................... 5
Installation Instructions .............................................................. 6
Troubleshooting .......................................................................... 8
Warranty......................................................................................... 10
Notes ............................................................................................... 12
Table of Contents
1
128-9242 WIDTV1 User's Guide 08 15 2013.indd 3 8/15/2013 5:33:04 PM

2
Introduction
Introduction
Thank you for purchasing the Audiovox WIDTV1 Mobile TV Receiver.
The WIDTV1 is an ecient, user-friendly accessory for viewing live
free-to-air TV content on Android® and Apple® devices, and is compatible with
ATSC-M/H digital TV transmissions. The WIDTV1 creates its own private WiFi
networkforusebythemobiledeviceandthereisnoneedtosearchforaninternet
connection or use cellular data airtime. Download the free SianoTV application
from the App Store or Google Play®, watch TV and enjoy.
To ensure the best performance, please read this manual carefully.
Highlights
• View live TV (ATSC-M/H broadcasts) on your Android® and
Apple® smartphone or tablet
• Pause, rewind, and record programs while viewing
• Access to detailed programming information (Electronic Programing
Guide - EPG)
• Equipped with internal battery for over 4 hours of viewing time
128-9242 WIDTV1 User's Guide 08 15 2013.indd 4 8/15/2013 5:33:04 PM

3
Package Contents
1. WIDTV1 Mobile TV Receiver
2. Telescopic Antenna
3. User’s Guide
4. Micro USB Cable
1
3
4
2
Package Contents
128-9242 WIDTV1 User's Guide 08 15 2013.indd 5 8/15/2013 5:33:05 PM

4
Supports the following Apple® devices: iPad2®, New iPad®, iPad Mini®,
iPhone 4S®, iPhone 5®, and iPod 5® with iOS 5.1.X or newer.
Designed for use with advanced Android® devices using Android® 4.0.3 or
newer, such as Samsung® Galaxy S2/S3, Note/Note2, Google® Nexus 7,
Asus® TF300, HTC® One and others (WIDTV1 was tested with a select list of
manufacturers and models only).
System Requirements
System Requirements
Trademark Notice:
Andriod® / Nexus® / Google Play® and Google® are all trademarks of Google® Inc. All rights
reserved. Google ®and the Google® Logo are registered trademarks of Google® Inc. in the U.S. and
other countries.
Asus® is a registered trademark of ASUSTeK Computer in the U.S. and/or other countries.
HTC® is a registered trademark of HTC® Corporation. All Rights Reserved. HTC®, the HTC® logo,
HTC® Innovation, ExtUSB, and HTC® Care are trademarks and/or service marks of HTC® Corporation.
iPad®/ iPad 2®/ iPad Mini®/ iPhone®/ iPhone 4S®/ iPhone 5®/ iPod® are all trademarks of Apple®
Computer, Inc., registered in the U.S. and other countries.
SAMSUNG® is a trademarks of Samsung® Group, Samsung® Electronics in the United States or other
countries.
Wi-Fi® is a registered trademark of the Wireless Fidelity Alliance, Inc.
128-9242 WIDTV1 User's Guide 08 15 2013.indd 6 8/15/2013 5:33:05 PM

5
Safety Instructions
Safety Instructions
• Read this entire User’s Guide to ensure proper usage.
• Keep this User’s Guide handy for future reference.
• Do not use the WIDTV1 while driving, cycling, or operating any moving
vehicle or apparatus. This is dangerous and may result in a trac violation
and may be illegal in some areas.
• Keep the WIDTV1 away from all liquids and liquid-prone locations such as
sinks, bathtubs, rain, and other sources of moisture. Moisture can cause
electric shock as with any electronic device.
• Clean the WIDTV1 with a soft lint-free cloth.
• Do not allow children under the age of 6 to use the WIDTV1 unsupervised.
• Never force any connector into the WIDTV1 USB and antenna ports.
Ensure that your connectors are the identical shape and size before you
connect.
• Do not disassemble, crush, short-circuit or incinerate the WIDTV1 battery,
as it may cause re, injury, burns or other hazards.
128-9242 WIDTV1 User's Guide 08 15 2013.indd 7 8/15/2013 5:33:05 PM

6
Installation Instructions
Installation Instructions
1. Charge the WIDTV1 fully before initial operation.
• PlugthesuppliedUSBchargingcableintoaUSBport.
• InserttheMicroUSBchargingcableconnectorintotheWIDTV1and
the red “Charge” LED will illuminate.
• WhentheWIDTV1isfullycharged,thered“Charge”LEDwillturnOFF.
NOTE: While the WIDTV1 is in use, the blue “Power” LED will turn o
10 minutes before the battery is depleted.
2. Download and install the free SianoTV application from the App Store or
Google Play®.
3. Turn the WIDTV1 ON by sliding the ON/OFF switch to the ON position.
The blue “Power” LED will illuminate.
4. Release the telescopic antenna from its docked position and swivel it to an
upright position.
5. Extend the telescopic antenna and place the WIDTV1 in a suitable location
close to a window or outdoors where it will not be subjected to moisture
or excessive heat.
128-9242 WIDTV1 User's Guide 08 15 2013.indd 8 8/15/2013 5:33:05 PM

7
Installation Instructions
Installation Instructions
6. Set up the WiFi connectivity on your mobile device’s settings/connectivity
manager.
• Use your mobile device at a maximum of 7 meters distance from the
WIDTV1
• Go to the Network Manager on your mobile phone or tablet and search
for the “Audiovox Mobile TV xxxxxx” network. NOTE: The “xxxxxx”
notation in the network name represents the last six digits of the
WIDTV1 MAC address.
• Enter the password – “audvx” (all lowercase).
7. Activate the “SianoTV” application.
8. For initial use only, channels must be scanned;
go to:
SianoTV --> Select Settings --> Choose your location--> Scan Channels.
9. Once the channel scan is complete, press DONE .
10.Select “Live TV”, press and watch TV channels. To switch from one channel
to another, swipe ngertips over the screen either right or left.
128-9242 WIDTV1 User's Guide 08 15 2013.indd 9 8/15/2013 5:33:05 PM

8
Troubleshooting
Troubleshooting
Cannot connect to WIDTV1’s WiFi
• Turn OFF the WIDTV1 and then turn it ON again
• Go to the network manager in your phone or tablet and search for the “WIDTV1”
network
• Verify that the correct password was entered
• Make sure that the mobile device is not in ight/airplane mode
Poor Image Quality
• Try to improve the antenna location (near a window if possible)
• Scan for available stations with strong signals again
Application is stuck or is not working
• a.)ClosetheSianoTVapplication
b.) Turn the WIDTV1 OFF
c.) Turn the WIDTV1 ON and reconnect to the WiFi network
d.) Open the SianoTV application again
NOTE: Channels must be scanned again:
SianoTV --> Select Settings --> Choose your location--> Scan Channels
Scan did not locate a TV channel
• Try to improve the antenna location (near a window if possible)
• For up-to-date information on what stations may be available in your area, please
visit www.dyle.tv/coverage map .
128-9242 WIDTV1 User's Guide 08 15 2013.indd 10 8/15/2013 5:33:06 PM

9
Troubleshooting
Troubleshooting
“no signal” message appears
• Try to improve the antenna location (near a window if possible)
• For up-to-date information on what stations may be available in your area,
please visit www.dyle.tv/coverage map .
Application does not recognize the device
• Close the application, turn the WIDTV1 OFF and back ON , reconnect to the
WiFi and open the application again
While using WIDTV1, TV reception suddenly stops
• Make sure that the blue LED is ON
• If it is not on, this means that the battery is either empty or has only 10 more
minutes of operation; charge the battery until the red charging LED turns
OFF.
NOTES:
a.) Reception inside buildings may be sub-optimal; it is recommended that
the WIDTV1 is placed near a window.
b.) Applicationmayaskfora“FirmwareUpgrade”.Ifasked,acceptrequest. WIDTV1
will reboot and when complete. NOTE: Channels must be scanned again:
SianoTV --> Select Settings --> Choose your location--> Scan Channels.
c.) Using more than one device with WIDTV1? It is recommend selecting
“Forget” WIDTV1 network on previous device’s WiFi manager before
connecting WIDTV1 to another device.
128-9242 WIDTV1 User's Guide 08 15 2013.indd 11 8/15/2013 5:33:06 PM

10
AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to the original retail purchaser
of this product that should under normal use and conditions, be proven defective in material or
workmanship within 12 months from the date of original purchase, such defect(s) will be repaired
or replaced with new or reconditioned product (at the Company’s option) without charge for parts
and repair labor.
To obtain repair or replacement within the terms of thisWarranty, the product is to be delivered with
proof of warranty coverage (e.g. dated bill of sale), specication of defect(s), transportation prepaid,
to an approved warranty station or the Company at the address shown below.
This Warranty does not extend to the elimination of externally generated static or noise, to costs
incurred for installation, removal or reinstallation of the product, or to damage to speakers,
accessories or electrical systems.
ThisWarranty does not apply to any product in the opinion of the Company that has been damaged
through alteration, improper installation, mishandling, misuse, neglect, accident, or by removal or
defacement of the factory serial number/bar code label(s).THE EXTENT OFTHE COMPANY’S LIABILITY
UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN
NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
12 MONTH LIMITED WARRANTY
Warranty
128-9242 WIDTV1 User's Guide 08 15 2013.indd 12 8/15/2013 5:33:07 PM

11
Warranty: 128-7351
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION
OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER MUST
BE BROUGHT WITHIN 24 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS
OR ANY OTHER WARRANTY. No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or
limitation of incidental or consequential damage so the above limitations or exclusions may not
apply to you. This Warranty gives you specic legal rights and you may also have other rights which
vary from state to state.
AUDIOVOX ELECTRONICS CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788
www.audiovoxproducts.com
Warranty
128-9242 WIDTV1 User's Guide 08 15 2013.indd 13 8/15/2013 5:33:07 PM

12
Notes
Notes
128-9242 WIDTV1 User's Guide 08 15 2013.indd 14 8/15/2013 5:33:07 PM

128-9242 WIDTV1 User's Guide 08 15 2013.indd 15 8/15/2013 5:33:07 PM

128-9242
www.audiovoxproducts.com
© 2013 AUDIOVOX,150 Marcus Blvd. Hauppauge, NY 11788
128-9242 WIDTV1 User's Guide 08 15 2013.indd 16 8/15/2013 5:33:09 PM
