Audipack PCL-M350 User manual

PCL-M350 PCL-X350
ML-350 XL-350
Manual
•Mounting instructions
•Montagevoorschrift
•Instructions de montage
•Montage anleitung
Version 5.0

©Audipack

©Audipack

©Audipack

©Audipack

©Audipack

Model B (mm)
XL-350 480
PCL-X350 480
ML-350 320
PCL-M350 320 B
©Audipack

Model B (mm)
XL-350 515
PCL-X350 515
ML-350 355
PCL-X350 355
B
©Audipack

Model B (mm)
XL-350 >500
PCL-X350 >500
ML-350 >340
PCL-M350 >340
B
©Audipack

©Audipack

ML-350 and XL-350 only
©Audipack

S= store function, hold & pres with 1 ,2,3 or 4 for
storing the position
Arrowup = Up direction for finding the build-in height
position.
Arrow down = Down direction for finding the projection
position.
1= Preset / programmed position build-in position
(closed). Use this contact for external permanent
control with contact relay.
2= Preset / programmed position of presentation
position.
Use this contact for external permanent control with
contact relay.
3 & 4 can be used as additional positions (only through
RS232)
S= Common, use in combination with contacts
1 -4.
Keyboard RS232 connection
(RJ45)
Control connector
(loop + 1 + 2)
Fuse 24 VDC in
NEW RS232 control for PCL lift systems
Connecting the Mirror-Kit.
For first use, the lift can be used to control the travel and
build-in height. Use the arrows to do so.
For external control use at least 0,5-0,75 mm wires for long
distances up to 15 meters in combination with a relay per
each direction / position.
Use the extra booklet for RS232 instructions.
©Audipack
PCL-M350 and PCL-X350 only
12.1

©Audipack
Optional IR remote IR-12 part. No. 260211. ML-350 & XL-350 only
Optional RF remote RF-12 part. No. 260213. ML-350 & XL-350 only

©Audipack
ML-350 and XL-350 only

1.
Remove 2 screws
Verwijder 2 schroeven
Entfernen Sie den 2
Schrauben
2.
Slide out motor board
Schuif de motorprint eruit
Ziehen Sie den Motorplatine aus
3.
Insert remote PCB
Steek de remote print in de houder
Stecken Sie den Fernbediening im Platine
Remote control PCL-M350 and PCL-X350 only
©Audipack
18.
Optional IR remote IR-12 part. No. 260214. PCL-M350 & PCL-X350
Optional RF remote RF-12 part. No. 260213. PCL-M350 & PCL -X350 only
Insert remote PCB in main board
Stecken Sie den Empfanger in den haubt PCB
Steek de remote print in de hoofdprint

©Audipack
