Aurora Design FMR-2.8 Operating instructions

Aurora Design
FMR-2.8
User Installation and
Operation Manual
Your radio Configuration:
☐!Tone Control - Original
☐!Tone Control - External control
☐!Tone Control - Using tone switch and volume control
☐!Balance Control - Original
☐!Balance Control - External control
☐!Balance Control - Virtual
☐!Fader Control - Original
☐!Fader Control - External control
☐!Fader Control - Virtual
☐!AM/FM switching - Original
☐!AM/FM switching - Power cycling
☐!DAB/DAB+ switching (optional) - Switch
☐!DAB/DAB+ switching (optional) - Power cycling
☐!Aux Input selection - Tune to left side of dial
☐!Aux Input selection - Signal sensing (VOX)
☐!Aux Input selection - Power cycling
☐!Aux input selection - External switch
☐!American channels
☐!Worldwide channels
☐!Japanese channels
☐!LED - Not Installed
☐!RGB LED - AM/red FM/yellow Aux/green BT/blue USB/magenta
☐!Bi-color LED - AM/red FM/yellow Aux/green BT-USB/orange
☐!Tube Emulation Mode
☐!Automatic Volume Control
☐!Power - 12V negative ground, fused @ 12.5A max
☐!Power - 12V positive ground, fused @ 8A max
☐!Power - 6V negative ground, fused @ 12.5A max
☐!Power - 6V positive ground, fused @ 8A max
☐!Original Power lead
☐!Red wire in cable harness
☐!Original Dial lamp lead
☐!Orange Dial lamp wire in cable harness
☐!Dial lamp comes on with radio
!! 2

Congratulations on your new FMR-2.8 converted radio. With the FMR-2.8
installed in your radio you will experience unrivaled performance, features and
reliability all while retaining the radios original appearance.
Note: Your radio was custom configured to your specifications. All wiring and
options listed in this manual may or may not be present on your radio.
Please consult the Configuration and Notes sections of this manual for more
information. Contact your dealer with any questions about installation or
operation of your radio.
Installation:
Before starting installation you should remove one of the battery cables. Your
radio came with a short 12 pin wiring harness. This harness will be used to
connect the radio to your vehicle. The pinout is as follows:
!Color!Signal!Color!Signal
!Red!Ignition!Black!Ground
!Blue!Switched Bat Out!Orange!Dial Lamp
!White!Left Front+!White/Black!Left Front-
!Grey!Right Front+!Grey/Black!Right Front-
!Green!Left Rear+!Green/Black!Left Rear-
!Violet!Right Rear+!Violet/Black!Right Rear-
The Red wire should be connected to an Ignition switched circuit that is fused as
shown in the Configuration section of this manual. It should not be connected to a
continuous battery circuit. The Black wire can be attached to a convenient point on
the dashboard. The Orange wire should connect to the original dash lamp circuit.
The Blue wire is a switched power output that can be used for power antennas,
external amplifiers, etc. Do not connect the Blue wire to battery!
The remaining wires are for the speakers. To achieve such high power levels,
the FMR-2.8 uses a bridged amplifier design where neither speaker lead is
ground. Speakers with one side already grounded as used in some original
applications must not be used. The FMR-2.8 performs best with speakers of 4
ohm impedance, a SPL rating of at least 90 dB and a power rating of at least
50W. The FMR-2.8 can also drive two 2 ohm speakers if four speakers are not
possible in the vehicle. DO NOT connect four 2 ohm speakers. The FMR-2.8 can
drive 1, 2, 3 or 4 speakers as follows:
For a 1 speaker installation the speaker can be connected to any one of the four
outputs. The FMR-2.8 will detect that only one speaker is attached and enable
mono mode while disabling the balance and fader controls.
For 2 speaker installation, the speakers can be attached in one of three ways as
follows:
1) If the two speakers are attached to either the front left/right pair or the rear
left/right pair the FMR-2.8 will enable stereo mode and the balance control.
2) If one speaker is attached to the left or right front output and the other
speaker is attached to the same channel (left or right) rear output, the
FMR-2.8 will enable mono mode and the fader control.
3) If one speaker is attached to the left or right front output and the other
speaker is attached to the opposite channel (right or left) rear output, the
FMR-2.8 will enable stereo mode and the fader control.
For a 3 speaker installation, connect two speakers to the rear outputs and one
speaker to the Left Front+ and Right Front- terminals.
For a 4 speaker installation all the speaker outputs will be used and the
FMR-2.8 will enable stereo, balance and fader controls.
Note: When attaching a speaker output to an external amplifier, a 150 ohm 1
watt resistor needs to be connected across the output to tell the FMR-2.8 an
external amplifier is attached to that output.
Note: Do not use bass blocking capacitors on speakers.
All unused wires should be taped up so they can’t short out. The radio can now
be mounted back into the vehicle and connected to the new wiring harness.
Reattach the battery cable. Installation is now complete.
Operation:
Your converted radio will operate as before but with new performance and
features.
LED: If your radio has a front panel status LED installed, it will display the
current operating mode for AM, FM, Bluetooth, USB, Auxiliary and Errors.
The color of the LED for each mode will be as shown in the Configuration
section of this manual.
Mode Select: Mode selection (AM, FM, Aux) varies depending on your radio
configuration. In the following description, power cycling refers to quickly
switching the radio off and back on. Each time this is done the radio will
change to the next mode. The radio will always return to the last mode selected
when first turned on.
If your radio has an AM/FM band switch, it will work as normal, otherwise
AM/FM selection is done by power cycling.
The Auxiliary Input is selected by either tuning to the low end of the dial,
automatically when a signal is sensed (VOX), or power switch cycling. Refer
to the Configuration section for information on how your radio was configured.
Balance/Fader: If your radio has balance/fader controls they will operate as
before. If your radio does not have balance/fader controls, the FMR-2.8 enables
virtual controls. Note, a “plink” sound will be heard as the virtual control
passes through the center position to aid in adjustment.
Virtual Balance: Quickly twist the tone control back and forth twice to the
left. The tone control temporarily becomes the balance control. The Voice
Assist HD will announce the function to verify you have entered the virtual
balance control. You may adjust the balance for as long as you wish. When
finished, the FMR-2.8 waits a few seconds and then announces that the
setting was accepted. This setting is retained until it the next time it is
changed.
Virtual Fader: Quickly twist the tone control back and forth twice to the
right. The tone control temporarily becomes the fader control. The Voi ce
Assist HD will announce the function to verify you have entered the virtual
fader control. You may adjust the fader for as long as you wish. When
finished, the FMR-2.8 waits a few seconds and then announces that the
setting was accepted. This setting is retained until the next time it is changed.
!3!4

Loudness/EQ: Loudness contouring or a three band equalizer with adjustable
loudness/subwoofer can be selected. Normally, enabling loudness (default) is all
that is required for the best overall performance. The full EQ mode can be used
to adjust the radio to the exact speakers/vehicle environment. To make
adjustments to the radio’s equalizer settings, quickly twist the tone control back
and forth three times to the left to enter the EQ On mode. Next, quickly twist the
tone control once to the left or right to enter the EQ Adjust mode. Each time this
action is performed while the radio is still announcing the current setting, the
radio will move to the previous or next setting as follows:
↔Treble ↔Mid ↔Bass ↔Loudness ↔Subwoofer ↔Crossover ↔
You may adjust the setting for as long as desired. Wh e n f i n i s h e d , t h e F M R - 2 . 8 w a i t s
a few seconds and then announces that the setting was accepted. Note that a “plink”
sound will be heard as the setting passes through the center point to aid in
adjustment. To readjust the setting, or make another setting, quickly twist the tone
control once to the left or right again. After 30 seconds of inactivity, the radio will
lock the EQ settings and an announcement will be heard. To reenter the EQ Adjust
mode, quickly twist the tone control back and forth three times to the left as before.
All EQ settings will be retained even if the EQ mode is turned off and back on.
Tone Switch: If your radio has a tone switch rather than a tone control it may have
been configured to select between volume and tone functions on the main volume
control. In one position of the tone switch, the volume control will function as
normal. In the other position of the tone switch it will function as the tone control
with full compatibility with the virtual controls as described above.
When you switch from volume to tone, the FMR-2.8 will hold the volume steady
until you return to the volume position of the tone switch. Since it is possible the
volume control could now be set to a very high volume depending on where it was
left after making adjustments to the tone and virtual controls, the Vo i ce A ss i st H D
will alert you of this condition, and the volume control will need to be lowered to at
least the previous level before it will start operating normally again. Also if the tone
switch is set to the tone position when the radio is first turned on, the volume will
be at a safe, preset level so that it will not damage the speakers.
Tuning: Your radio will tune as before including pushbuttons and automatic
Signal Seeking operation. Pushbuttons can be set for an AM or FM station
(radio must be in correct band mode for button).
Seek/Scan (motorized tuners): Signal Seeking radios like the Wonderbar®,
Town & Country and ElectroTouch will operate as before including sensitivity
(Town/Country) controls. A Scan feature is also provided by quickly pressing
the Seek button twice. The Voice Assist HD will announce that the radio is
scanning. The radio will scan to the next station, pause and then continue to the
next station until the Seek button is pressed again. The front panel status LED
will slowly pulsate while in the Scan mode.
Scan (standard tuners): On manually tuned radios, quickly twist the tuning
control twice to the right. The Voic e As s is t H D will announce that the radio is
scanning and the front panel status LED will slowly pulsate. The radio will scan
to the next station, pause, and then continue. (the dial pointer will not move while
scanning) You can cancel a scan by pushing a tuner preset, turning the tuning
knob to the left or switching the radio off. When a desired station is found, turn
the tuning knob to the right. The status LED will pulsate faster for 5 seconds. If
nothing is done, the station will be held until the tuning is changed or the radio is
turned off. If the actual position of the station is desired, turn the tuning knob
within the 5 seconds. If you are turning in the direction towards where the station
is located on the dial, the radio will mute and then unmute when the station
position is found. You can then mark this station by setting a preset.
Status/Signal Strength: The Voice Assist HD can announce the status of the
radio at any time. By twisting the volume control three times to the right, Voice
Assist HD will announce the radio station when in radio mode such as “FM
101.3”, or the current input in other modes such as “Bluetooth Streaming”.
If the action is performed again while the radio is speaking, it will enter the
Signal Strength mode. This mode will announce the signal strength of the radio
signal. This can be used to diagnose reception problems. When finished,
perform the action again or change modes on the radio.
Line Out: Optional Line Out jacks may have been added to your radio if
requested. The five outputs (front/rear pair and subwoofer) can be attached to
an outboard amplifier. These outputs are post pre-amp and are affected by the
controls on the radio.
Troubleshooting:
Low Power: If the voltage to the radio drops to low for normal operation, the
front panel LED will alternate between green and red and no audio will be
heard until this situation is corrected.
No Sound: Make sure the radio is getting power. Check all fuses and wiring.
Make sure speakers are properly connected and in good working order.
Weak/Noisy Reception: Make sure the antenna is connected to the radio and
in good working order. The cable for the antenna can become damaged. Check
for continuity between the center pin of the connector and the antenna mast.
Also check for shorts between the center pin and the outer shield.
The FMR-2.8 uses sophisticated noise blankers to reduce or eliminate most
engine/generator noise. If engine or generator noise is still present, investigate
the cause of this noise, i.e. spark plugs and wires, generator/alternator
suppression condensers etc.
PowerOnDiagnostics: Each time the radio is powered on it uses a
sophisticated method to check the speaker outputs for problems. If a problem is
found, the specific speaker channel is disabled and the error is reported by the
Voice Assist HD such as “left rear speaker ground short”. The front panel LED
(if installed) will also flash red.
Overheating: If the FMR-2.8 ever overheats in operation the Voice Assist HD
will announce it and the front panel LED (if installed) will also flash red. No
damage will occur to the radio and it may start to lower the output power to
bring the temperature back down. This should never occur in normal operation.
Version: Twisting the volume control four times to the left will announce the
version number of the FMR and any attached options.
Options:
If your radio was equipped with the BTU-2.6, BT-2.6 or USB-2.5 option
cards, the radio will automatically mute the radio and switch to the option card
when required. Please refer to the appropriate User Manual that came with the
option card for complete information.
!5!6

Specifications*:
FM Receiver:
Frequency Range:!87.5-108MHz (Worldwide except Japan)
!76.0-90.0MHz (Japan)
Channel Spacing:!200kHz (America’s)
!100kHz (all other regions)
Sensitivity:** !5.0dBµV @ 26dB SNR
De-emphasis:!75µS (America’s)
!50µS (all other regions)
SNR:** !60dB typ
Image Rejection:** !60dB typ
Audio Separation:** !40dB typ
Audio Response:** !30Hz-15kHz -3dB
AM Receiver:
Frequency Range:!530-1710 (America’s)
!531-1611 (all other regions)
Channel Spacing:!10kHz (America’s)
!9kHz (all other regions)
Sensitivity:** !30dBµV @ 26dB SNR
SNR:** !56dB typ
Image Rejection:** !55dB typ
Audio Output:
Speaker Impedance:!2-32Ω
Output Power:!4 X 45W into 4Ω@ 14.4V max (EIAJ)
!2 X 75W into 2Ω@ 14.4V max (EIAJ)
!4 X 22W into 4Ω@ 14.4V 1% THD
!2 X 40W into 2Ω@ 14.4V 1% THD
Auxiliary Input:
Input Level:!-10dBV nominal level
!0dBV max without clipping
Input Impedance:!~5KΩ
Withstand Voltage:!+/- 24V max
Auxiliary Outputs:
Output Level:!0dBV nominal level into 5KΩ
Frequency Response:!10Hz-20kHz -1dB into 5KΩ
Notes:
Dealer Name:
Date:
Job #:
*Subject to change without notice **Characterized by component manufacturer
Aurora Design LLC. ©2013-20 Rev 2.8.0 10/20
www.tech-retro.com
!7!8
