Aurora ShredSafe AU1250XB User manual

AU1250XB
Model No.
Modelo No.
1-800-327-8508
USA Only • Los Estados Unidos Solomente
1-310-793-5650
International • Internacional
Email: [email protected]
For more information, please visit us at:
www.auroracorp.com
Shredder User Manual
Please read these operating instructions before using the unit.
Antes de operar esta unida, por favor lea todas las instrucciones.
Manual del usuario de la trituradora
™

3ENGLISH
WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!
Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the paper entry slot.
Do not spray or keep any
aerosol products in or around the
shredder.
Keep loose clothing or jewelry
away from the paper entry slot.
Avoid getting hair near the
paper entry slot.
•AlwaysturntheshredderoffandunplugthepowercordfromtheACoutletwhen
notinuse,beforecleaningit,movingit,oremptyingthewastebasket.
•RISKOFFIRE.Neveruseanypetroleumbasedorflammableoilsorlubricants in or
around the machine as some oils can combust causing serious injury.
•NEVER dispose of flammable chemicals or materials that have come into contact with flammable
chemicals (for example, nail polish, acetone and gasoline) in the shredder basket.
•Nevershredlargepaperclips,windoworinsulatedenvelopes,continuousforms,
newsprint,boundpages(inexample:notepads,checkbooks,magazines,etc...),
transparencies,laminateddocuments,cardboard,anyitemswithadhesives,hard
materialsorplastic(exceptCreditCards).
•A socket-outlet should be near the equipment and be easily accessible.
•Never let the wastebasket become full. This will lead to shredded material being pulled back up into
the shredder and cause jams.
•Never place the shredder near water or any heat source.
•Do not use the shredder if the power cord is damaged in any way.
•Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturers warranty.
•Never try to clean or clear the shredder blade.
•Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.

4ENGLISH
INSTALLATION
PaperShredder
OperatingInstructions
Installation
Operation
Maintenance
Troubleshooting
Service Center
Limited Warranty
*ONEFOLDEDSHEETOFPAPEREQUATESTO2SHEETSOFPAPER
Heavier paper, humidity or other than rated voltage may reduce shredding capacity.
Sheet Capacity
Paper Shred Size
Paper Entry Width
Credit Card Capacity
Duty Cycle
Voltage
12 Sheets of 20 lb. bond paper*
3/16 in. x 2 5/32 in. pieces
0.5 cm x 5.5 cm pieces
8.7 in / 220 mm
1 at a time
5 min. on / 30 min. off
120V~60Hz / 3.0 A
1. Make sure the basket door is securely closed shut. This shredder features a safety power cut off and
will not operate if door is open. Shredders with pull-out wastebaskets feature a safety power cut off
upon bin removal. The supplied wastebasket activates this switch, which allows the shredder to be
operable.
2. Attach 4 caster wheels to the bottom of the shredder body.
3. A socket-outlet should be near the equipment and be easily accessible.
4. Connect the power cord to any standard 120 volt AC outlet.
Crosscut shredders have very sharp exposed blades on the underside.
Use care when mounting the shredder on the wastebasket.
!Caution:
Remove the shredder from the box.
1Carefully lift and remove shredder head
and casters from the shredder body.
2
CONTINUED NEXT PAGE
INSTALLATION

5ENGLISH
INSTALLATION
3
4 5
Attach 4 caster wheels to the bottom of the shredder body.
Gently place the shredder head onto the
shredder body.
Make sure the shredder head is correctly
mounted.
PUSH
DOWN
PUSH
DOWN
CORRECT FIT

6ENGLISH
OPERATION
ControlSwitch
Using the switch located on the unit, select one of the following settings by sliding the switch either left
or right. (FIGURE 1)
I AUTO/ON:
This setting allows the shredder to be automatically started by insert-
ing paper into the feed slot. Always feed the paper in as straight
as possible. When the paper has passed through, the shredder will
automatically stop.
READY:The green LED light indicates the shredder in “On” and
ready for use.
O OFF:
This setting turns off all features of the shredder. For safety reasons,
we recommend that you leave the shredder in the “Off” position
whenever the shredder is unattended or not in use.
R REV(REVERSE):
In the unlikely event of a paper jam, the reverse setting can be used
to help clear the cutters of paper that did not pass through. Never
attempt to clear a jam by using the reverse function until you have
emptied the wastebasket.



CONTINUED NEXT PAGE
FIGURE1

7ENGLISH
CONTINUED NEXT PAGE
OPERATION
Paper/CreditCardEntry:
ShredSafe™ technology is an added safety feature incorporated in this particular
model. It is a new technology where the shredder is able to detect forced entry and
automatically cuts the power off, preventing further shredding.
To begin shredding, locate the control switch on the unit and select the “Auto” mode. The Green LED
light indicates the shredder is “On” and ready to use. Press the designated “PUSH OPEN” area on the
handle of the cover to open and expose the paper feed slot (FIGURE 2). Thecoverwillclickinto
apresetpositionwherethe“SHREDDERSTATUS”linemustalignwiththe“READY”
setting.
READY:
TheshredderiscurrentlyonSTANDBYandreadytooperatewhenpaperisinserted.
With the feed slot now exposed, you can shred sheets of paper or 1 credit card per pass.
DISABLED:
The safety feature has been activated. All power to the SHREDDER
IS CURRENTLY SHUT OFF AND WILL NOT OPERATE until the cover
is returned to the “READY” setting. The cover has been opened
beyond the safe position (FIGURE 3).
AFTERUSE:
When shredding is completed, you can press the designated
“PUSH CLOSE” area on the cover to tilt shut the paper feed slot
(FIGURE 4). It is recommended to have the paper feed slot closed
when shredder is not in use to prevent any objects from accidentally
getting into the feed slot.
FIGURE2
FIGURE3
FIGURE4

8ENGLISH
NOTE:
•Always turn off and unplug the shredder when not in use.
•This shredder will shred staples and small paper clips. It is recommended that you remove paper
clips whenever possible to extend the lifespan of your shredder.
•Only shred credit cards by feeding them vertically into the middle of the entry, releasing when shred
ding begins. Never feed more than one credit card at a time.
OPERATION
•PowerOn:
The Green LED light indicates the shredder is “On” and ready to operate when paper is inserted.
•Overheat:
The Red LED light indicates the shredder has shred continuously beyond the maximum running time
and overheating, the unit will automatically shut off. If this happens, switch the shredder Off for 30
minutes or longer before resuming normal operation.
•BinFull:
When the "Basket is Full", the RED light will indicate it needs to be emptied. While lit, the shredder
will be inoperable until the wastebasket is cleared.
•Overload:
The Red LED light indicates when too much paper is inserted. Use the "Reverse" mode to back up
and reduce number of sheets.
•DoorOpen:
The Red LED light indicates the shredder basket is not pushed in properly. Shredders with pull-out
wastebaskets feature a safety power cut off upon bin removal. Make sure the pull-out wastebasket is
properly set back into place and the green “Power On” indicator is lit.
LEDStatusIndicators:
Dooropen/Overload/Binfull/Overheat/PowerOn

9ENGLISH
OPERATION MAINTENANCE
Shredder
Oil
DONOTUSE
AEROSOLPRODUCTS!
!Caution:
FIGURE5
Warning:Failuretoproperlymaintainyourshredderwillvoidthewarranty.
Oil the shredder blades every month with basic vegetable, cooking oil or shredder oil. Follow oiling
procedure below (FIGURE 5). It helps to keep the shredder blades operating well over many years of
use.
Oilingprocedure:
1. Turn off shredder.
2. Apply shredder oil across paper entry.
3. Turn shredder in reverse mode for 3~5 seconds.
Note:ShredderoilisNOTincluded.
• Donotsprayorkeepanyaerosolproducts
inoraroundshredder.
• DONOTUSECANNEDAIRONSHREDDER.
CLEANING:
• ALWAYS UNPLUG THE SHREDDER BEFORE CLEANING!
• Only clean the shredder by carefully wiping the unit with a dry soft cloth or towel.
• Do not clean or immerse shredder in water. Having the unit wet may result in damage or malfunction to
the electrical components. If the shredder happens to get wet, be sure to completely dry the unit immedi-
ately with a cloth or towel.
• Never use anything flammable to clean the shredder. This may result in serious injury or damage to the product.

10 ENGLISH
TROUBLESHOOTING
If there is a problem with your shredder, check below for the symptoms and steps to resolve. If you
continue to have problems, contact customer support at our Service Center 1-800-327-8508. DO
NOT ATTEMPT TO REPAIR BY OPENING THE SHREDDER HEAD. This will completely void the
product warranty.
Theshredderdoesnotworkatall.
1)Make sure the unit is pluggedin and that the outlet is in good working order.
2) Overheatingwithextendeduse: In the event that the shredder has shred continuously
beyond the maximum running time and overheated, the unit will automatically shut off. If this hap-
pens, switchtheshredderOfffor30minutes or longer before resuming normal operation.
3) Shredders with pull-out wastebaskets feature a safety power cut off upon bin removal. Shredder will
not function unless the pull-out wastebasket is pushed in all the way and properly set back into place.
4) BesureNOTtoopenthecoverbeyondthepresetposition, otherwise the ShredSafe™
feature will be activated and the shredder will be inoperable. The “SHREDDER STATUS” indication line
must align with the “READY” setting.
5) If using a plastic bag to line the wastebasket, please remove it. This may cause the shredder not to
operate properly.
6) The activation sensor of the shredder is located near the center of the feed slot. Be sure to feed
directly into the center area to activate the machine (especially applies to smaller pieces of paper
or credit cards).
Theshredderrunsin“Rev(Reverse)”modebutnotin“Auto(On)”mode.
1) While in “Auto” mode, the motor will not start running until paper is inserted into the feed slot. Set
the unit to “Auto” and insert paper to shred. The sensor that activates the shredder in Auto mode
is located directly in the center of the slot. If the paper you are inserting is narrow, it may not be
activating the optical sensor. It is also possible that the feed slot has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blockage.
CONTINUED NEXT PAGE
Coverovertilt
Disabledposition
Readyposition
TROUBLESHOOTING

11ENGLISH
TROUBLESHOOTING
Howtoclearapaperjamintheshredder.
1) Switch the shredder over into Reverse (REV) mode. While in Reverse, the shredder will back up and
loosen the jammed paper. If required, you may need to tug and remove several sheets to effectively
clear the machine. When jammed paper is loosened or removed, switch back to the Auto-On mode
to continue shredding. Repeat steps if needed.
2) With stubborn situations where the reverse function does not help, you may loosen the jammed
paper with shredder oil (cooking oil is acceptable, nothing aerosol). Start by drizzling oil into the
feed slot where the paper is jammed. Let it soak for about 30 minutes to completely saturate. Return
the shredder back to Auto-On mode. Ifrequired,anindexcardorarigidsheetofcard-
stock(oldgreetingcardorfoldedfilefolder)canbefedintotheshreddertohelp
pushthejammedpaperthrough.
Theshredderisconstantlyrunningwhilein“Auto(On)”mode.
1) It is possible that the activation sensor, which starts the shredder, has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blocking the activation sensor and feed entry.
2) The activation sensor is being triggered by dust, debris, or oil. A cotton swab may be
used to clean the sensor. DO NOT USE CANNED AIR. The activation sensor of the shredder is
located around the center of the feed entry.
Powerswitchinautoposition
Usethickpaperstockorgreetingcard
topushthejamthrough
