Aurora AU1645XA User manual

AU1645XA
Model No. Please read these operating instructions before using the unit.
1-800-327-8508
USA Only
1-310-793-5650
International
Email: [email protected]
For more information, please visit us at:
www.auroracorp.com
Shredder User Manual

3ENGLISH
WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!
•AlwaysturntheshredderoffandunplugthepowercordfromtheACoutletwhen
notinuse,beforecleaning,moving,oremptyingthewastebasket.
•RISKOFFIRE.Neveruseanypetroleumbasedorflammableoilsorlubricants in or
around the machine as some oils can combust causing serious injury.
•NEVER dispose of flammable chemicals or materials that have come into contact with flammable
chemicals (for example, nail polish, acetone and gasoline) in the shredder basket.
•Nevershredmetalcreditcards,largepaperclips,windoworinsulatedenvelopes,
continuousforms,newsprint,boundpages(forexample:notepads,checkbooks,
magazines,etc...),transparencies,laminateddocuments,cardboard,anyitemswith
adhesives,hardmaterialsorplastic(exceptplasticCreditCardsandCDs).
•DonotholdCD/DVDwithfingerthroughthecenterringwhilefeedingintotheshredder.
Seriousinjurymayoccur.
•A socket-outlet should be near the equipment and be easily accessible.
•Never let the wastebasket become full. This will lead to shredded material being pulled back up into
the shredder and cause jams.
•Never place the shredder near water or any heat source.
•Do not use the shredder if the power cord is damaged in any way.
•Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades
and/or electricity and will void the manufacturer's warranty.
•Never try to clean or clear the shredder blade.
•Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.
Read instructions before use.
Avoid touching the document
feed opening with hands.
Product is not intended for use by
children (product is not a toy).
Do not insert foreign objects into
the paper entry slot.
Do not spray or keep any
aerosol products in or around the
shredder.
Keep loose clothing or jewelry
away from the paper entry slot.
Avoid getting hair near the
paper entry slot.
Keep away from moving parts.
Sharp blade edges!
Do not touch!

4ENGLISH
INSTALLATION
PaperShredder
OperatingInstructions
Installation
Operation
Maintenance
Troubleshooting
Service Center
Limited Warranty
*ONEFOLDEDSHEETOFPAPEREQUATESTO2SHEETSOFPAPER
Heavier paper, humidity or other than rated voltage may reduce shredding capacity.
Sheet Capacity
Paper Shred Size
Paper Entry Width
CD/Credit Card Capacity
Duty Cycle
Voltage
16 Sheets of 20 lb. bond paper*
5/32 in. x 1 7/32 in. pieces
0.4 cm x 3.1cm pieces
8.7 in / 220 mm
1 at a time
30 min. on / 45 min. off
120V~60Hz / 4.0 A
1. Make sure the basket door is securely closed shut. This shredder features a safety power cut off and
will not operate if door is open. Shredders with pull-out wastebaskets feature a safety power cut off
upon bin removal. The supplied wastebasket activates this switch, which allows the shredder to be
operable.
2. Attach all 4 caster wheels to the bottom of the wastebasket. (FIGURE 1)
3. A socket-outlet should be near the equipment and be easily accessible.
4. Connect the power cord to any standard 120 volt AC outlet.
Crosscut shredders have very sharp exposed blades on the underside. Do not touch. Unplug the
shredder before clearing paper jams.
Use care when mounting the shredder on the wastebasket.
FIGURE1
PUSH
DOWN
PUSH
DOWN
!Caution:
CORRECT FIT
OPERATION

5ENGLISH
OPERATION
CONTINUED NEXT PAGE
ControlSwitch
Using the switch located on the unit, select one of the following
settings by sliding the switch either left or right. (FIGURE 2)
Auto/On:This setting allows the shredder to be automatically started by inserting paper
into the feed slot. Always feed the paper in as straight as possible. When the paper has
passed through, the shredder will automatically stop.
Off:This setting turns off all features of the shredder. For safety reasons, we recommend that you
leave the shredder in the OFF position whenever the shredder is unattended or not in use.
Reverse:In the unlikely event of a paper jam, the reverse setting can be used to help clear
the cutters of paper that did not pass through. Never attempt to clear a jam by using the
reverse function until you have emptied the wastebasket.
Forward(JamRemover):The forward setting can also be used to help clear the cutters in
the event of a paper jam. This allows to manually activate the shredder into cutting mode.
FIGURE2




I

6ENGLISH
CONTINUED NEXT PAGE
OPERATION
Paper/CreditCard/CDsEntry:
Make sure you do not exceed sheet
count per pass (16 sheets max).
Insert paper as straight as pos-
sible into feed slot and release.
Insert one credit card at a time into
the middle of the feed slot.
•PowerOn:
The Green LED light indicates the shredder is “On” and ready to operate when paper is inserted.
•Overheat:
The Red LED light indicates the shredder has shred continuously beyond the maximum running time
and overheating, the unit will automatically shut off. If this happens, switch the shredder Off for 45
minutes or longer before resuming normal operation.
•Overload:
The Red LED light indicates when too much paper is inserted. Use the "Reverse" mode to back up
and reduce number of sheets.
LEDStatusIndicators:
Binfull/Dooropen/Overload/Overheat/PowerOn
FeaturesaCD/DVDdestroyer:
Do not hold CD/DVD with finger through the center ring while feed-
ing into the shredder. Serious injury may occur.
Never feed more than one credit card or CD/DVD at a time.
1) Hold the CD/DVD by the edge and feed one at a time, releasing
when shredding begins.
2) Shredder will stop when the entire disc has been destroyed.

7ENGLISH
OPERATION
NOTE:
•Always turn off and unplug the shredder when not in use.
•This shredder will shred staples and small paper clips. It is recommended that you remove paper clips
whenever possible to extend the lifespan of your shredder.
•Only shred credit cards by feeding them vertically into the middle of the entry, releasing when
shredding begins. Never feed more than one credit card at a time.
•Overfeeding the shredder: Shredding beyond the specified sheet capacity can result in extensive
damage to the shredder. Overfeeding will strain the machine and quickly wear and break the cutting
blades and internal components.
•Overheating with extended use: In the event that the shredder has shred continuously beyond the
maximum running time and overheating, the unit will automatically shut off. If this happens, switch
the shredder off for 45 minutes or longer before resuming normal operation.
•DoorOpen:
The Red LED light indicates the shredder basket is not pushed in properly. Shredders with pull-out
wastebaskets feature a safety power cut off upon bin removal. Make sure the pull-out wastebasket is
properly set back into place and the green “Power On” indicator is lit.
•BinFull:
When the "Basket is Full", the RED light will indicate it needs to be emptied. While lit, the shredder
will be inoperable until the wastebasket is cleared.

8ENGLISH
MAINTENANCE
Warning:Failuretoproperlymaintainyourshredderwillvoidthewarranty.
Oil the shredder blades every month with basic vegetable, cooking oil or shredder oil. Follow oiling
procedure below (FIGURE 3). It helps to keep the shredder blades operating well over many years of
use.
Oilingprocedure:
1. Turn off shredder.
2. Apply shredder oil across paper entry.
3. Turn shredder in reverse mode for 3~5 seconds.
Note:lubricatingoilisNOTincluded.
• Donotsprayorkeepanyaerosolproducts
inoraroundshredder.
• DONOTUSECANNEDAIRONSHREDDER.
CLEANING:
• ALWAYS UNPLUG THE SHREDDER BEFORE CLEANING!
• Only clean the shredder by carefully wiping the unit with a dry soft cloth or towel.
• Do not clean or immerse shredder in water. Having the unit wet may result in damage or malfunction to
the electrical components. If the shredder happens to get wet, be sure to completely dry the unit immedi-
ately with a cloth or towel.
• Never use anything flammable to clean the shredder. This may result in serious injury or damage to the product.
FIGURE3
Shredder
Oil
DONOTUSE
AEROSOLPRODUCTS!
!Caution:

9ENGLISH
TROUBLESHOOTING
If there is a problem with your shredder, check below for the symptoms and steps to resolve. If you
continue to have problems, contact customer support at our Service Center 1-800-327-8508. DO
NOT ATTEMPT TO REPAIR BY OPENING THE SHREDDER HEAD. This will completely void the
product warranty.
Theshredderdoesnotworkatall.
1)Make sure the unit is pluggedin and that the outlet is in good working order.
2) Overheatingwithextendeduse: In the event that the shredder has shred continuously
beyond the maximum running time and overheated, the unit will automatically shut off. If this hap-
pens, switchtheshredderOfffor45minutes or longer before resuming normal operation.
3) Shredders with pull-out wastebaskets feature a safety power cut off upon bin removal. Shredder will
not function unless the pull-out wastebasket is pushed in all the way and properly set back into place.
4) If using a plastic bag to line the wastebasket, please remove it. This may cause the shredder not to
operate properly.
5) The activation sensor of the shredder is located near the center of the feed slot. Be sure to feed
directly into the center area to activate the machine (especially applies to smaller pieces of paper
or credit cards).
Theshredderrunsin“Rev(Reverse)”modebutnotin“Auto(On)”mode.
While in “Auto” mode, the motor will not start running until paper is inserted into the feed slot. Set
the unit to “Auto” and insert paper to shred. The sensor that activates the shredder in Auto mode
is located directly in the center of the slot. If the paper you are inserting is narrow, it may not be
activating the optical sensor. It is also possible that the feed slot has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blockage.
Howtoclearapaperjamintheshredder.
1) Switch the shredder over into Reverse (REV) mode. While in Reverse, the shredder will back up and
loosen the jammed paper. If required, you may need to tug and remove several sheets to effectively
clear the machine. When jammed paper is loosened or removed, switch back to the Auto-On mode
to continue shredding. Repeat steps if needed.
2) With stubborn situations where the reverse function does not help, you may loosen the jammed
paper with shredder oil (cooking oil is acceptable, nothing aerosol). Start by drizzling oil into the
feed slot where the paper is jammed. Let it soak for about 30 minutes to completely saturate. Return
the shredder back to Auto-On mode. Ifrequired,anindexcardorarigidsheetofcard
CONTINUED NEXT PAGE

10 ENGLISH
TROUBLESHOOTING
stock(oldgreetingcardorfoldedfilefolder)canbefedintotheshreddertohelp
pushthejammedpaperthrough.
Theshredderisconstantlyrunningwhilein“Auto(On)”mode.
1) It is possible that the activation sensor, which starts the shredder, has become blocked with paper.
Insert an index card or any rigid sheet of cardstock (old greeting card or folded file folder), directly
in the center of the feed slot, while applying force to help push the jammed paper through. This will
usually clear any paper blocking the activation sensor and feed entry.
2) The activation sensor is being triggered by dust, debris, or oil. A cotton swab may be
used to clean the sensor. DO NOT USE CANNED AIR. The activation sensor of the shredder is
located around the center of the feed entry.
Powerswitchinautoposition
Usethickpaperstockorgreetingcard
topushthejamthrough
