AUSTRALIAN MADE CLEO User manual

CLEO
400Wh Portable Solar Generator
User Manual

Contents
Foreword..................................................................................3
Safety warning.........................................................................3
Storage and maintenance........................................................3
1. Packed Items ......................................................................4
2. Function Introduction...........................................................5
3. Charging Instructions...........................................................6
4. Operational instructions.......................................................7
5. Technical specification .....................................................10
6. Trouble shooting................................................................11
7. Frequently Asked Questions and Answers (FAQ)…………12

01
Foreword
Safety warning
1. Please read all the safety warnings before use and keep the manual. Warranty
does not cover damage caused by failure to follow instructions.
2. Please note the warning labels and operate accordingly.
3. Avoid exposing the product to rain or using the product in a humidenvironment.
4. Do not install the product near heat sources, such as electric furnace andheaters.
5. Place and store the product in a well-ventilated place.
6. Wipe the product clean with a dry cloth.
7. In case of fire, use dry powder fire extinguishers for this product. Do not use waterfire
extinguisher, which may cause electric shock.
8. Please do not alter or disassemble this product.
Storage and maintenance
1. Operating and storage environment may influence product life and the reliabilityof
performance. Thus, remember to:
(1) Place the product in a dry and well- ventilated area with mild temperature
(suitable temperature:0℃ -45℃, suitable relative humidity 10% ~ 90%)
(2) Place the product in a safe area where it will not be shaken or fall.
(3) Keep the product away from corrosive and combustible material.
2. The product will turn off itself when the battery voltage is very low, If this happens,
you need to charge the battery within 2-3months.
3. If you are not going to use it for a long time, please charge it fully before storage and
then charge it at least once every month. Store the product in a dryenvironment.
Please fully charge the product before storage and charge it at least once every 3 months.
03

Please read this manual before use and follow its guidance. Keep this manual for future
reference
1. Packed Items
Before opening the parcel, please check if the parcel is damaged. If the product is
damaged during delivery or if any items went missing upon arrival, please contact our
Customer service to get it resolved. You should receive the following items:
No.
Item
Quantity
1
Cleo Portable Solar Generator
1
2
AC adaptor (including AC charging cable)
1
3
Cigarette lighter cable( cigarette port to DC7909 connector male)
1
4
MC4 cable (MC4 connector to DC 7909 connector male )
1
5
User manual
1
6
Warranty card
1
Note:
1. If the product malfunctions, error codes will be displayed on screen.
2. When the product is powered on, but not in use, the product would switch off by itself
after 60seconds of inactivity.
3. When the product is powered on and the AC/DC output is turned on, the backlight
would turn off by itself after a period of inactivity. To turn on the backlight again, press
any button. 04
3
2
5
1
4
6

5
1
2
3
6
7
4
8
9
10
11
12
13
2. Function Introduction
1. Main power button
2. DC powerbutton
3. AC power button
4. DC12V car ignitor outputport
5. Handle bar
6. LCD screen
7. DC 12V 5521 output port
LCD Screen
8. Type-C PD output port
9. USB output port
10. LED light button
11. LED light
12. Charging port
13. AC output port
1. Charging power 4. ACON/OFF
2. DC ON/OFF 5. AC output power
3. DC output power 6. Battery capacity indicator
05

LCD Battery Display:
The battery icon indicates the battery level of this product. The battery level is displayed
in 5 segments. When the battery is being charged, the icon will start flashing. When the
battery is fully charged, the icon would stop flashing and all 5 segments will be filled.
！
Note: If the product malfunctions, error codes would be displayed on screen.
3. Charging Instructions
！
Note: Please charge the product to 100% capacity before using.
While charging the product, the battery capacity display icon on the LCD screen will
start flashing and will be stop once the battery is fully charged.
How to charge this product?
Solar Panel to charge the product
(1)Chose a suitable solar panel (recommended DC14~40V/120W)
(2) Keep the solar panel under direct sunlight and facing the sun
(3) Take the MC4 cable and connect the solar panel to theproduct.
(4)When the product is fully charged by the Sun, it will stop charging automatically.
Please take out the charging cable, and turn off the product.
！
Note: Please make sure the cable connection is correct and stable, or it will result in
overheating and short circuits.
！
Note: Please charge the product under 0~45℃temperature.
！
Note: During charging, it is normal for the product to get a little hot.
！
Note: The charging time is different under different sunlight intensity.
！
Note: Make sure that the positive and negative poles of solar panels are connected
correctly. Refer to the following connection chart.
Solar panel PV+
Connecting cable PV+
Solar panel PV-
Connecting cable PV-
06

AC charger to charge the product
！
Note: Always use the standard AC charger that comes with the product.
(1) Insert one end of the adapter into the wall outlet and insert the other end into the input
port of the product.
(2) Please unplug the charger after charging is completed. (It takes about 5-6hrs tofully
recharge the product if using a 90W AC adapter charger)
！
Note: It is normal for this product to get a little hot during charging.
！Note: Make sure that the wiring is connected properly, otherwise the contact
terminals may melt or ignite at high temperatures.
Car charger to charge the product
(1) Connect the product to the cigarette lighter socket in the car with the cigarette lighter
cable provided in the package.
(2) Charge the product after starting the car.
！Note: Make sure that the wiring is connected properly, otherwise the contact
terminals may melt or ignite at hightemperatures.
！
Note: The product will be fully charged with a 24V car battery, but only partially
charged with a 12V car battery.
4. Operational instructions
Operation guidance
Attention:
1. The operating environment should meet the requirements specified in this manual.
2. Make sure that the air inlet/outlet is not blocked.
3. Please power off the product if you are not going to use it.
4. Please fully charge the product if you are going to keep it idle for a longperiod.
07

How to use the product?
Turn on/off the product
1. Turn on the product: Press and hold the master power button about 2 seconds to
turn on the product. The LED indicator light and the display screen will lightup.
2. Turn off the product: Press and hold the master power button about 2 seconds to
turn off the product. The display screen and the LED indicator light would turnoff.
AC/DC output
Note: Check to make sure the product is turned on. Otherwise, you cannot turn on the
AC/ DC output.
1. Turn on AC/DC output: Press and hold the AC/DC power button to turn on the product.
The corresponding LED indicator light would light up and the display screen would
show “AC ON/DC ON”.
2. Turn off AC/DC output: Press and hold theAC/DC power button to turn off the product.
The LED indicator light would turn off and the display screen would show “AC OFF/
DC OFF”.
Connectible devices
USB output port: Smartphone, MP3 player, digital camera, electronic reader, tablet
computer, etc.
Type-C PD output port: Smart phones, tablets, etc.
DC 12V 5521 output port: Mainly used for LED lighting.
DC12V Cigarette Lighter output port: Vehicle Refrigerator and Other 12V
equipment.
AC output port: Notebook computer, camera, display devices and other AC power
supply working equipment.
！
Note: DC output is suitable for most products in the market. Some products with
instantaneous high current may trigger over-current protection.
！
Note: Please make sure that the connected electrical products can work properly
before using this product.
！
Note: AC output uses electrical products with rated power below 300W.
！
Note: Some electrical products which require instantaneous high current, rated
power below 300W may not be used (e.g. air conditioning, motors etc.).
！
Note: The output will stop automatically if overload protection is triggered.
！Note: If the output stops repeatedly, please stop using the product
immediately and contact the local maintenance or service team.
！Note: There might be some RF noise in the broadcast or video player or TV
appliances which are connected to this product.
08

load power
consumption(W)
20smartphones
2 hours
10Watt load
20W LED lamp
20 hours
20Watt load
75W LCD TV
5.3 hours
75Watt load
Estimation of backup time
400Wh÷ =
！
Note: The above data is for reference only. The backup time varies with the power
of different loads and appliances.
Intelligent Cooling Control
Cooling fan will start working automatically when the following conditions are met:
1. The load of inverter exceeds 200w.
2. The load of 5v-USB output port exceeds 10w.
3. The load of Type C-PD output port exceeds 30w
4. The load of 12V cigarette lighter socket exceeds 50w.
5. The charging power of attached appliances exceeds 100W.
The generator intelligence system will adjust the PV input or AC output
power based on the temperature of the outer case temperature, to keep the outer case at a
touchable temperature.
Note: Do not use the machine when the cooling tan is broken.
09
200W electric
stewing pot
2 hours.
200Watt load
90W refrigerator
4.4 hours
90W load
80W electric tool
5 hours
80Watt load
Hours used
(approx.)

5. Technical specification
Output
AC output
Rated voltage
100-120Vac
220-240Vac
Rated power
300 W
Peak power
450W
Overload
capability
300W≤load<450W@120S;
450W≤load@1s;
Frequency
50/60Hz(adjustable)
DC12V output
(cigarette
lighter)
Rated voltage
12Vdc (12-14V workable)
Rated current
10A①
DC12V output
(5521)
Rated voltage
9.6-12.6Vdc ②
Rated current
3A
USB output
QC
BC1.2,Apple,Samsung
Rated voltage
5V
Rated current
3A
Type-C output
QC
PD2.0 (45W)
Rated output
5V3A, 9V3A ,12V3A ,15V3A , 20V2.25A
LED torch
While the power button is on, press the LED light button repeatedly. The
order of LED light will be: fullbrightness-half brightness-SOS- Off
Solar PV Input ③
Input voltage
14-40 Vdc
Input power
120W MAX
Battery
Rated capacity
416Wh
Rated voltage
11.1 Vdc
Battery cell type
Li-ion
Voltage range
9.6-12.6Vdc
General
Protection level
IP21
Working environment condition
Relative humidity: 10%-90%
Temperature: 0-45℃
Size
300*159*219mm
Net weight
6.2 kg
！
Note:
①② May cause input low-voltage protection of some equipment if the voltage is low.
③ Solar panel charge type: MPPT
10

6. Trouble shooting
If the product cannot charge or power appliances, please check the following:
1. Make sure the power button is turned on.
2. Make sure the AC and DC power buttons are on, viz. the LED on the right ofthe
button is green.
3. Check the battery capacity - if it’s lower than 10%, please recharge the productas
soon as possible.
4. Make sure the load power connected is not exceeding the load limit of thisproduct.
Each port has a limit for the connected power load.
If the product still does not work, then please contact our after sale service center.
Error
code
Cause
Protection Condition
Recovery condition
E01
Over Temperature
Protection
Heat sink Temp≥75℃
Auto Recover when the
temp≤70℃
E02
Low temperature protection
<-8℃
＞-2℃,self-recovery
E04
Battery Over temperature
>68℃
<58℃ ,self-recovery
E05
Battery low temperature
<-8℃
>-2 ℃ ,self-recovery
E06
Battery charge over
temperature
>48℃
<38℃ ,self-recovery
E07
Battery charge low
temperature
<0℃
>5℃ ,self-recovery
E09
Total voltage too low
<9.6V
>10.5℃ recover charging.
E18
PV input over voltage
>45V
<40V self-recovery
E25
DC 12V output over voltage
Battery voltage >13V
Recover by pressing any
button
E26
DC12V-1output over loaded
Load power >140W
E27
DC12V-1 output over current
output current >11A or
short-circuit
E28
DC12V-1 input over current
Current >-1A
E29
DC12V-2 output over loaded
Load power >75W
E30
DC12V-2 output over current
Output current > 6A or
short-circuit
E31
DC12V-2 input over current
Current >-1A
E34
System overloaded, DC
output stop
Total power>380W at
3mins

E36
Inverter output overloaded
Power>300W at 2mins or
power >450W
Recover by pressing any
button
E37
Inverter output overcurrent
AC output short-circuit
E38
System overloaded, AC
output stop
Total power>380W at
3mins
7. Frequently Asked Questions and Answers (FAQ)
●How to check the state of charge?
The battery icon display on the LCD display shows the battery level and charge status.
●How to use the product to charge other electronic devices?
(1) Check the user manual or search for information online to learn aboutthe
charging parameters of the electronic devices you wish to connect.
(2) Check the power of each output port. For example, the maximum rated output power
of the AC output port is 300W. This means that if the power of the connected electronic
device exceeds 300W for a long time, the inverter will turn off theoutput.
●What is the depth of discharge (DOD)?
To prolong the battery life, the product has a DOD setting to 90%, which means that only
90% of the battery capacity can be discharged, and retain 10% to avoid damage to the
battery dueto excessive discharge.
●Can it charge and discharge simultaneously?
Yes, but it is not recommended to charge and discharge at the same time in order to
protect the battery life.
●Can it be charged by using 2 solar panels in series?
Yes, just make sure the total open circuit voltage (VOC) of the solar panels are less than
40V. Otherwise it may trigger the charging overvoltage protection or cause damage.
●How to extend the using time of CPAP?
Recommend to turn off its humidifier, heater, and set a lower pressure.
●50Hz/60Hz frequency switching (factory setting: 60 Hz).
Step 1: Press the power button to turn the product on, then press the DC and AC
buttons at the same time. The LCD will illuminate and display the current frequency (50Hz
or 60Hz). Release the button and continue to the next step.
Step 2: Press and hold the DC button or AC button to select 50Hz and 60Hz. The
frequency displayed on the LCD will change accordingly.
Step 3: After selecting the desired frequency, press the DC button and AC button at
the same time to complete the setting. Step 1 can be repeated to check the current
frequency.
Step 4: Reboot to use with new frequency.
●Can the AC output power a refrigerator or air conditioner?
Workable for low power refrigerators. The starting power of refrigerators and air
conditioners are generally 5~7 times more than the rated power, which easily triggers AC
overload.
●Can two power stations be used in parallel?
No.
12
