AUSTRALIAN MONITOR ACM1202P User manual

120W + 120W
Dual Channel Power Amplifier
ACM1202P
Description
The ACM1202P is a dual channel 120W + 120W power amplifier designed to deliver continu-
ous full range performance in a compact and reliable package. The ACM1202P is two inde-
pendent amplifiers in the one chassis making it the perfect choice for multi-zone or multi-chan-
nel applications.
Inputs and Outputs
The ACM1202P provides dual balanced XLR inputs (male and female) per channel. These two
inputs are wired in parallel enabling a line level “split” to be taken from the second input of
each channel.
100/70 volt line and 4/8 ohm outputs are available via the rear panel barrier strip.
Controls and Metering
A recessed input attenuation control for each channel is included on the rear panel. These pots
are accessible using a screwdriver.
The ACM1202P features a signal-present LED per channel and power-on LED.
Protection
The ACM1202P features ”slow start“ and dual AC and DC fuse protection. Also featured is
automatic speaker protection. The ACM1202P includes generous heat sinking for reliable
operation in even the most extreme conditions.
Australian Monitor Installation Series amplifiers feature a protection network that provides
greater stability and performance. Our amplifiers are recognised
worldwide for their reliability and this is due to the extensive levels of
current limiting which protect the amplifiers from both overload and
overdrive conditions.

Power Output 120 Watts per channel
Maximum Load 80 Ohms on 100 Volt line setting
Frequency Response 50Hz - 15kHz (± 3dB)
Total Harmonic Distortion 0.5% at 1kHz (1 Watt - full power)
Signal To Noise Ratio -80dB at 100V; -80dB at 8 Ohms; -80dB at 4 Ohms
Input Sensitivity 0.5 Volt RMS - 100 Volt line
Input Impedance 10K Ohms
Input Connection Active balanced input with male and female
3 pin XLR input/output sockets per channel.
Outputs 100/70 Volt line and 4/8 Ohm via rear panel barrier strip. Line out to feed
additional amplifiers from one of the paralleled XLR input sockets
Controls Front panel power switch; Recessed rear panel input attenuator (per channel)
Metering/Indicators Signal-present LED per channel
Power Source 240V - 50Hz or 110V - 60Hz (special), 3 pin IEC connector
Power Consumption 400 Watts (maximum)
Protection Fuses for overload and short circuit protection, High temperature trip (disconnects
load at 120ºC), DC Output Sensing (disconnects load if DC is present)
Dimensions/Weight 88mm H x 483mm W x 315mm D (Chassis dimensions only). 15kg
Rack Mounting Standard
Engineered and Distributed By AUDIO TELEX COMMUNICATIONS PTY LTD (ABN 78 001 345 482), 149 Beaconsfield Street, Silverwater, Sydney, NSW, 2128 Australia
NSW Tel: [phone] Fax: [phone] VIC Tel: [phone] Fax: [phone] QLD Tel: [phone] Fax: [phone] WA Tel: [phone] Fax: [phone]
TAS Tel: [phone] Fax: [phone] SA Tel: [phone] Fax: [phone] Export Enquiries: [email protected] Website: www.australianmonitor.com.au
ARCHITECTURAL AND ENGINEERING SPECIFICATIONS
The power amplifier shall be a dual channel model capable of delivering 120 watts RMS per channel
into 100/70 volt line and 4/8 ohm loads. The unit shall feature a signal-present LED per channel.
Speaker connection shall be via a rear panel barrier strip. The amplifier shall have two balanced XLR
inputs per channel, one of which can be used to feed additional power amplifiers.
The unit shall also include fuse protection for overload and short circuit conditions. The unit shall also
feature generous heatsinking for reliable operation in extreme conditions.
The unit shall be of high quality suitable for continuous, reliable performance. It shall have a frequency
response of no less than 50Hz - 15kHz (±3dB). Distortion shall not exceed 0.5% at 1kHz. The signal to
noise ratio shall be -80dB (on 100V setting) or better. The power amplifier shall be packaged in a
rugged 2 rack unit metal chassis suitable for desk or rack mounting.
The amplifier shall be an Australian Monitor Installation Series model ACM1202P.
