Autoadapt Carolift 40 User manual

7
1. PRESENTATION
Carolift 40 is a wheelchair hoist with a lift capacity of 40 kg, designed for installation in vehicles.
The hoist has an articulated arm that folds towards both sides. This feature enables the wheelchair to

narrow rear door openings or behind wide bumpers.
The rotating movement is made manually

use, be easily removed from its base and placed elsewhere.

EMC Direktive 95/54/EC (Electronic disturbances)
Machine Direktiv 2006/42/EC (Risk for injuries, lift capacity, m.m.)
ECE regulations R-17 (Crash test)



procedure has ended and when not in use.
2. SAFETY REGULATIONS
The contents of these instructions must be read and understood before the product is
taken into use. Keep the instructions easily accessible for further reference.
If Carolift is altered, rebuilt or used for other purposes than intended, Autoadapt AB
denies any liability.
Installation and repair of Carolift must, for safety reasons and for warranty conditions,
be made by Autoadapt AB or by a workshop authorized by Autoadapt AB.
Make sure the lift belt is not twisted when retracted on the reel.

8
3. HOW TO USE CAROLIFT 40
Erecting and folding the hoist
2. To fold the hoist press the catch at the base.
Grab hold of the hoist arm to prevent it from falling


It can also be placed leaning on the loaded wheelchair.
1. To erect the hoist just pull it up until it is locked in an
upright position.
Remove the hoist
1. If the hoist is not needed it can easily be removed by
just lifting it out from its holder on the base.
2.
please refer to ” Erecting and folding the hoist”
above.

9
Loading the wheelchair
1. Erect the hoist and rotate it outwards. Place the
wheelchair in a suitable position for hoisting it up.
Carolift 40 can pick it up either from the pavement by
the side of the vehicle or from behind.
The illustration shows
a view from above.
This is how the hoist
is moved to provide
the best possible
loading.
2. Drive down the lift belt by pressing the toggle switch
on top of the lift arm.
Hook the wheelchair to the lifting device.
Wheelchair
Luggage
compart-
ment
3. Press the toggle switch to lift the wheelchair until it
has reached slightly above the vehicle theshold.
4. Rotate the hoist towards the luggage compartment
and fold the hoist arm inwards to let the wheelchair
pass through the rear door opening.
5. Lower the wheelchair in a suitable position in the
vehicle.

Fold down the hoist on top of the wheelchair according
to the instructions ”Erecting and folding the hoist”
Toggle switch:
Drive down the lift belt
Toggle switch:
Drive up the lift belt
Unloading the wheelchair
1. Erect the hoist and make sure that the lift belt is
hooked to the wheelchair.
Lift up the wheelchair, by pressing the toggle switch,
until it can pass freely over the threshold.
2. Turn the hoist arm outwards and guide the wheel-
chair past the rear door opening to a suitable position
for lowering.
Lower the wheelchair to the ground by pressing the
toggle switch. Unhook it.

to the instructions: ”Erecting and folding the hoist”.

10
4. MAINTENANCE
4.1 Check-up
If the lift belt is showing signs of tear and wear it
must be replaced by a new.
4.2 Fuse
The hoist has a 10 A fuse that is placed either on
the cable by the plug to the electricity socket or on
the cable just before the connection to the vehicle
battery.
4.3 Lift belt
The lift band shall be replaced every four years.
4.4 Cleaning
Use a vacuum cleaner with a thin nozzle to clean
the hoist base and its cavities.
Use a moist towel to clean from dirt etc.
Symptom Cause Measure
The hoist is not
activeted when
toggle switch is
pressed.
5. TROUBLE SHOOTER
6. TECHNICAL DATA
7. SPARE PARTS
a) The lift belt has been jammed and caused
the fuse to blow.
b) End position is reached.
c) The electricity plug is not connected (applies
for installations via the compartment socket).
d) Vehicle battery is discharged
e) A short circuit has caused the fuse to blow.
Remove the motor and rewind the lift belt
evenly. Replace the fuse.
Activate in reversed direction.
Plug the cable in the socket.
Charge the vehicle battery.
Contact the autorized workshop.
The hoist is working
unusually slow.
Vehicle battery is discharged. Charge the vehicle battery.
In case of an emergency: Try to start
the motor and let the motor run while
unloading the wheelchair.
Lift cacapcity:
Weight (not including the mounting base):
Voltage:
Power consumption at maximum load:
40 kg
11 kg
12 Volt
5 A
The Carolift has a CE-poster where the serial
number is stated.
Please write down this number!
The number is needed when ordering spare parts.
Serial No: ____________________

Art. no: 420157, ed 2
