AutomationDirect CTT Series User manual

3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860
Digital Counter/Timer/Tachometer
CTT Series
The CTT series is an extremely versatile multi-function device that is easily configured for operation as a digital counter, timer,
combination timer + counter, or tachometer. Both voltage and non-voltage inputs are accepted from a wide variety of sensor types
with NPN, PNP, or dry contact outputs. The first output on the CTT is a single-pole, single-throw relay and NPN transistor
that operate concurrently. The second CTT output can be ordered as either a single-pole, double throw relay or NPN transistor.
Parameters are easily set using the externally accessible DIP switches or the lockable keypad. The double-line, 6-digit, two-color
LCD display shows the counter, timer, or tachometer present values, setting values and menu parameters during set-up. Additional
individual indicators are provided for inputs, outputs and functions. The standard 1/16 DIN size, included panel mounting clip
and gasket make panel mounting a snap. The CTT is available in 120-240VAC and 24VDC powered models.
For additional product information, please download the complete product manual which can be found at:
www.AutomationDirect.com
Description: MODE
CTT
AUTOMATIONDIRECT
.com
RST2
RST1
K/P2
K/P1
OUT2
OUT1
LOCK RESET
Quick Start Guide
Box Contents and Unpacking Instructions
After receiving the CTT Counter/Timer/Tach, please check for the following:
• Make sure that the package includes the CTT Counter/Timer/Tachometer, the
mounting bracket and hardware, and the Quick Start Guide.
• Inspect the unit to insure it was not damaged during shipment.
• Make sure that the part number indicated on the label corresponds with the
part number of your order.
• If anything is missing or damaged, immediately call the AutomationDirect returns
department @ 1-800-633-0405.
• For additional product information, please download the complete product manual
which can be found at: www.AutomationDirect.com
~ WARNING ~
Thank you for purchasing automation equipment from Automationdirect.com™, doing business as AutomationDirect. We want your new automation
equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and any other relevant publications) before installing
or operating the equipment.
To minimize the risk of potential safety problems, you should follow all applicable local and national codes that regulate the installation and operation of
your equipment. These codes vary from area to area and usually change with time. It is your responsibility to determine which codes should be followed,
and to verify that the equipment, installation, and operation is in compliance with the latest revision of these codes.
At a minimum, you should follow all applicable sections of the National Fire Code, National Electrical Code, and the codes of the National Electrical
Manufacturer’s Association (NEMA). There may be local regulatory or government offices that can also help determine which codes and standards are
necessary for safe installation and operation.
Equipment damage or serious injury to personnel can result from the failure to follow all applicable codes and standards. We do not guarantee the prod-
ucts described in this publication are suitable for your particular application, nor do we assume any responsibility for your product design, installation, or
operation.
Our products are not fault-tolerant and are not designed, manufactured or intended for use or resale as on-line control equipment in hazardous environ-
ments requiring fail-safe performance, such as in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control, direct
life support machines, or weapons systems, in which the failure of the product could lead directly to death, personal injury, or severe physical or environ-
mental damage (“High Risk Activities”). AutomationDirect specifically disclaims any expressed or implied warranty of fitness for High Risk Activities.
For additional warranty and safety information, see the Terms and Conditions section of our catalog. If you have any questions concerning the installation
or operation of this equipment, or if you need additional information, please call us at 770-844-4200.
This publication is based on information that was available at the time it was printed. At AutomationDirect we constantly strive to improve our products
and services, so we reserve the right to make changes to the products and/or publications at any time without notice and without any obligation. This
publication may also discuss features that may not be available in certain revisions of the product.
Trademarks
This publication may contain references to products produced and/or offered by other companies. The product and company names may be trademarked
and are the sole property of their respective owners. AutomationDirect disclaims any proprietary interest in the marks and names of others.
Copyright 2011-2012, Automationdirect.com™ Incorporated
All Rights Reserved
No part of this manual shall be copied, reproduced, or transmitted in any way without the prior, written consent of Automationdirect.com™ Incorporated.
AutomationDirect retains the exclusive rights to all information included in this document.
CTT- AN- D24
D24: 24VDC powered
A120: 100-240VAC powere
d
AN: NPN output 2
1C: SPDT relay output 2
Counter/Timer/Tachometer
Model Number Explanation
Input Specification
Agency Approvals
Country of Origin
Label Information
General Specifications
MODE
45.00
[1.77]
45.00
[1.77]
65.00
[2.56]
60.00
[2.36]
1
6
11
2
7
12
3
8
13
4
9
14
5
10
15
44.80
[1.76]
44.80
[1.76]
6.35
[0.25]
44.80
[1.76]
CTT
AUTOMATIONDIRECT
.com
RST2
RST1
K/P2
K/P1
OUT2
OUT1
LOCK RESET
44.80
[1.76]
79.35
[3.12]
6.35
[0.25]
47.85
[1.88]
47.85
[1.88]
79.35
[3.12]
Dimensions [mm] inch
0V CP1
CP2/
GATE
+12V RST1
RST2/
START
0V CP1
CP2/
GATE
+12V RST1
RST2/
START
N.O.
COM
LOAD +V0V
N.C.
N.O. COM
CTT-1C-D24
OUT
2
21.6 to
26.4 VDC
Load
21.6 to
26.4 VDC
OUT
1
OUT
2
CTT-AN-D24
N.O.
COM0V
LOAD
OUT
1
0V
LOAD
0V CP1
CP2/
GATE
+12V RST1
RST2/
START
0V CP1
CP2/
GATE
+12V RST1
RST2/
START
N.O.
COM
LOAD +V0V
CTT-1C-A120
OUT
2
AC100 to 240V
50/60Hz
Load
AC100 to 240V
50/60Hz
OUT
1
OUT
2
CTT-AN-A120
N.O.
COM0V
LOAD
OUT
1
0V
LOAD
N.O. COM
POWER SOURCE
12VDC @ 100mA
POWER SOURCE
12VDC @ 100mA
POWER SOURCE
12VDC @ 100mA
POWER SOURCE
12VDC @ 100mA
N.C.
109
321
1514
876
131211
54
10
9
321
15
14
876
13
1211
54
10
9
1514
876
131211
54
10
9
321
15
14
876
131211
54
321
+
-+
-
S
S
Terminal Layout
Reset 2 indicator
Reset 1 indicator
Key protect 2 indicator
Output 2 indicator
Key protect 1 indicator
Output 1 indicator
Special function indicator
Lock key
Reset key
Mode and number shift key
PV(Present Value) display
SV(Set Value) display
Timer function indicator
Counter function indicator
Tachometer function indicator
Up/Down key
CTT
A UTOMATION D IRECT
.com
LCD Display and Indicators
RST 1/2 Light on when reset signal is detected BATCH “Batch Counting Mode” in Counter
K/P 1/2 Light on when key-protected mode is enabled SET 1 2 SV1, SV2 display
OUT 1/2 Light on when output is executing TAC Light on in Tachometer function
H M S Hour, minute, second, unit of timer, displayed in Timer function CNT Light on in Counter function
TOTAL “Total Counting Mode” in Counter function TMR Light on in Timer function
Key Operation
, . Increase and decrease SV or change paramter settings
´Left move 1 digit of the selected digit. The indicator of the selected digit will flash.
ÄSave the set parameters or switch among functions.
LOCK
Prevent settings from being changed. Key-protected mode still works after power cycle. Press LOCK to enter key-protected mode. In non-key-protected status, press
LOCK to enter Lock 1, press LOCK again to enter Lock 2. Press Äand ´at the same time to disable key-protected mode. LoC1 (Lock 1) disables the functions
of all keys. LoC2 (Lock 2) allows users to change SV and functions of RESET remain. LOCK only functions in non-key-protected status.
RESET Clear and reset PV.
Modes: Operation Mode and Configuration Mode
Operation When the power is on, the timer/counter/tachometer is in the operation mode. Press ,. to change SV, or ´to select to change digit. The indicator of the se-
lected digit will flash. After the change is made, press Äto save the setting. If SV or paramters are not changed, press Äonce to switch between SET1 and SET2.
Configuration Press Äin operation mode for more than 3 seconds to enter configuration mode. Press Äonce to switch among parameters. To return to operation mode, press
Äfor more than 3 seconds.
Display, Indicators and Keys
Counter Functions Counter Input Modes Counter Output Modes
1-Stage Up Select from eleven (11) different
output modes (F, N, C, R, K, P,
Q, A, S, T, D)
2-Stage Down
Batch Up / Command Down
Total Up/ Down
Dual Quadrature
Addition
Subtraction
Timer Functions (Up or Down)
Signal On Delay 1 Repeat Cycle
Signal On Delay 2 Repeat Cycle Hold
Signal Off Delay Repeat Cycle 2
Signal On Signal Cumulate
Power On Delay Signal Twin On-Start
Power On Delay Hold Signal Twin Off-Start
Timer + Counter
Timer Functions
(Up or Down) Counter Input Modes Counter Output Modes
Signal On Delay 1 Up Select from eight (8) different out-
put modes (F, N, C, R, K, P, Q, A)
Signal On Delay 2 Down
Signal Off Delay
Signal On
Power On Delay
Power On Delay Hold
Repeat Cycle
Repeat Cycle Hold
Tachometer Output Modes
Select from four (4) different output modes
2Lo/1Lo
2Lo/1Hi
2Hi/1Lo
2Hi/1Hi
Digital Counter / Timer / Tachometer General Specifications
Input Power Requirements 100 to 240 VAC 50/60 Hz 24 VDC
Operation Voltage Range 85 to 264 VAC 21.6 to 26.4 VDC
Power Consumption Less than 10VA
Power Source 12VDC w10%, 100mA
Display Double-line, 6-digit LCD display (SV = 8mm, PV = 6mm)
Input Signal NPN ON impedance 1K ohm max. ON residual voltage: 2V max.
PNP 4.5 to 30VDC, low level: 0 to 2VDC
Output 1 Relay: SPST max. 250VAC, 5A (resistive load), 4A (inductive load); Transistor: NPN open collector. When 100mA @
30VDC, residual voltage = 1.5VDC max
Output 2 CTT-1C-xxx Relay: SPDT max. 250VAC, 5A (resistive load), 4A (inductive load)
CTT-AN-xxx Transistor: NPN open collector. When 100mA @ 30VDC, residual voltage = 1.5VDC max
Output Switching Time 2 milliseconds max
Dielectric Strength 2000VAC 50/60Hz for 1 minute
Vibration Resistance Without damage: 10 ~ 55Hz, amplitude = 0.75mm, 3 axes for 2 hours
Shock Resistance Without damage: drop 4 times, 300m/s² 3 edges, 6 surfaces and 1 corner
Ambient Temperature +32°F to +122°F (0°C to +50°C)
Storage Temperature -4°F to +149°F (-20°C to +65°C)
Altitude 2000m or less
IP Rating IP 66 (with proper enclosure installation)
Case Materials Case = ABS Plastic, Lens = Polycarbonate
Ambient Humidity 35% to 85% RH (non-condensing)
Memory Backup upon Power Failure EEPROM writing up to 100,000 times; Memory duration: 10 years
Terminals Conforming Wiring 0.25-1.65mm² (24 to 16 AWG)
Permitted Torque 0.5Nm (0.369 ft/lbs)
Agency Approvals UL508 listed (E311366), cULus, CE marked
P.1
CTT-AN-D24
MADE IN CHINA
Model Number

P.2
Counter Example:
1-Stage Counting (Sta6e1)
Counting Up (UP)
Using the counter feature of the CTT to count the total number of pieces in a box to signal a conveyor to advance to the
next station.
Counting Input
Output 1
Reset
Count
Input Mode
Counting Up (UP)
With the input signal OFF at input CP2, each leading edge of the input signal at CP1 will increment the count present
value PV by 1.
Output Mode
Mode F (F)
When the count present value PV counts up to the count setting value SV both outputs 1 and 2 will turn ON.
The count PV will continue to increment with each input signal. The leading edge of “a reset” input signal at RST1 will
turn OFF both outputs, reset the count PV to 0, and prohibit an input signal from incrementing the count PV. The trailing
edge of the “reset” signal at RST1 enables counting to begin.
Keypad set up of the parameters in the Counter for 1-Stage Counting:
Select functions: There are 4 modes in CTA, (left to right) timer, counter, tachometer and timer + counter.
–FunC Cont taCh –mixtime
Select counter functions: 1-stage counting, 2-stage counting, batch counting, total counting, dual counting.
Ä
CntFun sta6e1 sta6e2 batCh total dual
C–inPt ––UP down ud–a ud–b ud–C
Select input modes: counting up, counting down, command counting up/down, individual counting up/down,
quadrature input.
C–otmd FnC rkp
qastd
Select output modes: CTA offer 11 output modes, among which mode S, T and D are only valid with input modes
Ud_A, Ud_b and Ud_C.
Select counting speed: Maximum 10Kcps; others 5K, 1K, 200, 30 and 1cps.
C–Sped –10k ––5k ––1k –200 ––30
t–out1
Pulse width of output 1: The default output time is 0.02 second. When the parameter is set to 0.00 second, the
output status will continue.
–––1
–002 –000
t–out2
Pulse width of output 2: This paramter is adjustable according to different output modes selected. If the output mode is C,
the default output time will be 0.02 second, When the parameter is set to 0.00 second, the output status will continue.
–002 –000
–point
Set up the position of decimal point: 0 (no decimal point), 1 (one digit after decimal point), 2 (two digits after decimal
point), 3 (three digits after decimal point).
012 3
psCale 1000
Set up pre-scale value: 1.000 (default 1:1) Range: 0.001 to 99.999
–pwers
Save the data while switching off the power: When SAVE is selected, the PV will be saved; when CLEAR is selected,
the PV will not be saved.
Clear save
–rtsr
Set up minimum width of reset signal: Default = 20ms; 1ms is also selectable
––20 –––1
inptlC
Select input signal types: NPN and PNP
–npn –pnp
Back to Top
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Ä
or or or or
or or
or
or
or
or
or
or or
or
or
or
or
or
or or or
or
or or
or or or
or
or
or
or or
or
or or
or oror or
or
or or
oror
or or
To enter the page for parameter setting of the counter, press Äfor the main menu for more than 3 seconds. After the setup
is completed, press Äfor more than 3 seconds under any of the parameter page you are in and return to the main menu.
Timer Example:
A basic Timer used to control a clamp time of a compression model press.When the operator signals the
mold is loaded with material by pressing the start button the hydraulic cylinder closes the press to make a
limit switch which starts the CTT timing. Upon completion of the timer cycle Output 1 is turned on and the
press is opened by the hydraulic cylinder.
Signal On Delay 1 (Sond1)
With power applied to the CTT, the leading edge of an input signal at START will begin the
timing period setting value SV (timing up or down based on parameter (t modE). At
the end of the timing period both outputs will turn ON momentarily for the time set in the output pulse
width parameter (tout1) or will be maintained ON if the output pulse width parameter (tout1) is set
to 0.00. The trailing edge of the “start” signal has no effect on the outputs or timing period. The leading
edge of an “reset” input signal at RST1 will turn OFF the outputs and reset the timing period.
The “reset” signal minimum pulse width is set by reset pulse width parameter
( rtSr ) or DIP Switch 8. The leading edge of an “pause” signal at GATE will pause the
timing period after it has been started. The timing period will continue after the trailing edge of the
external switch “pause” (Gate) signal. When power is removed, both outputs will turn OFF and the
timing period will be reset.
Output 1
Reset
O
ut
p
ut 1
R
ese
t
Limit
Switch
Starts
Timer
To enter the page for parameter setting of the timer, press Äin the main menu for more than 3 seconds. After the
setup is complete, press Äfor more than 3 seconds under any of the parameter page you are in and return to the
main menu.
–funC
time Cont taCH –mix
Ä
t–mode –up down
Ä
t–otmd sond1 sond2 soffd –son
Ä
pond
t–out1 –002 –000
Ä
pond
h
–rCy rCyh rCy2 sConsto
nstoff
Select funtions: There are 4 modes in CTT, (left to right) timer, counter, tachometer and timer + counter.
Select timer mode: timing up and timing down
t–unit s–001 s–01 –s–1 ms–001
Ä
ms–01m–01
–m–1 hms–1 hm–1–h–1
Select output modes: There are 12 output modes in the timer. The user can choose the mode that best
meets the demand.
Select display unit: the min. unit 10ms to the max. unit hour are selectable. Refer to table below.
Select pulse width of output 1: The default output time is 0.02 second. When the parameter is set to 0.00
second, the output status will continue.
–rtsr––20 –––1
Ä
Select min. width of reset signal: The defaul value is 20ms; can be set to 1ms.
inptlC –npn –pnp
Ä
Select input signal types: NPN and PNP.
Back to To p
or
or or
or
or or
or
or or or
or or
or
or
or
or
or or or or
or or or or
oror
or
ororor
or or or or
Keypad set up of the parameters in the Timer:
Tachometer Example:
Using PSCALE to convert pulses into engineering units
The PSCALE feature of the CTT is very useful in converting the pulsed signal from an encoder or sensor into some
usable unit of measurement.
For example if one was to connect a proximity switch to the CTT to monitor the speed of a motor using a sensing gear
there is a simple calculation to convert the pulses from the sensor to Motor RPMs.
Using this formula you can calculate a PSCALE value to change a pulse signal into RPMs. First obtain the pulses per
revolution (ppr) or number of teeth on the sensing gear for example in the illustration below there are 38 teeth on the
gear or 38 ppr. If the gear is coupled directly to the motor this is all that is required to perform the calculation.
PSCALE = 60/ppr or 60/38
PSCALE = 1.579
With the PSCALE set to 1.579 for every 38 input cycles the CTT will display a value of 1.
Select functions: There are 4 modes in CTT, (left to right) timer, counter, tachometer and timer + counter.
–FunC Cont taCh –mixtime
Select rotation speed: Maximum 10Kcps; others 5K, 1K, 200, 30 and 1cps.
Ä
C–Sped –10k ––5k ––1k –200 ––30
–point
Set up the position of decimal point: 0 (no decimal point), 1 (one digit after decimal point), 2 (two digits after decimal
point), 3 (three digits after decimal point).
012 3
psCale
Set up pre-scale value: 1.000 (default 1:1) Range: 0.001 to 99.999
St–taC
Set up the delay time after switching on the power: 0.0 (default). The tachometer will start to run when the set delay
time is due after the power is switched on. Setup range: 0.1 to 99.9 seconds
––00
St–Av6
Set up average value of the input filter: The average value is for making the present value detected by the tachometer
more stable.
The setup range is 0 to 3 (1 = 2 data, 2 = 4 data, 3 = 8 data). For example, if you select “3”, the system will
average the 8 present values from the tachometer to make the present value displayed on the screen more stable.
–rtsr
Set up minimum width of reset signal: Default = 20ms; 1ms is also selectable.
––20 –––1
Select output modes: There are 4 output modes, 2Lo1Lo, 2Lo1Hi, 2Hi1Lo, and 2Hi1Hi, For example, when you select
2Hi1Lo, and assume the first set value is 100 (2Hi) and the second 50 (1Lo), the output value of the tachometer will be
below 100 (2Hi) and above 50 (1Lo) and CTT will not perform an output. If the set value exceeds the range, CTT will
perform an output.
taotmd 2Lo1Lo 2Lo1Hi 2Hi1Lo 2Hi1Hi
–––1
1000
012 3
InptlC –npn –pnp
Back to Top
Select input signal types: NPN and PNP.
or
or
or
or
or
or or
or or or
or or
or
or
or or or or or
or or
ororor
or
or
or or
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Ä
Data Sheet: CTT-CTT
Copyright 2017, Automationdirect.com Incorporated/All Rights Reserved Worldwide
Additional Help and Support
• For additional technical support and questions, call our Technical Support team @ 1-800-633-
0405 or 770-844-4200
• For additional product information, please download the complete product manual which can be
found at: www.AutomationDirect.com
Keypad set up of the parameters in the Tachometer:
For a full set of Demo and Set Up videos for the CTT units please
scan the QR code or follow the link below.
https://www.automationdirect.com/videos/
home?t=link&cat1=60
