AutomationDirect ProSense LPM1 Series User manual

ProSense LPM1 Series Meter
Loop-powered 4 to 20mA process diplay unit
Operating
Instructions

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
2
71487579
1 Document Information ���������������������������������������������������������������3
1.1 Document function .......................................................................................3
1.2 Document conventions..................................................................................3
2 Basic Safety Instructions �������������������������������������������������������������5
2.1 Requirements for personnel ...........................................................................5
2.2 Designated use ..............................................................................................6
2.3 Workplace safety............................................................................................6
2.4 Operational safety..........................................................................................6
2.5 Product safety................................................................................................7
3 Scope of Delivery ������������������������������������������������������������������������7
4 Installation�����������������������������������������������������������������������������������7
4.1 Incoming acceptance, transport, storage .......................................................7
4.2 Installation conditions....................................................................................8
4.4 Post-installation check..................................................................................11
5 Wiring ����������������������������������������������������������������������������������������11
5.1 Quick wiring guide ......................................................................................12
5.2 Inserting the cable, field housing.................................................................14
5.3 Connecting to functional grounding ...........................................................15
5.4 Degree of protection ...................................................................................16
5.5 Post-connection check .................................................................................17
6 Operation ����������������������������������������������������������������������������������17
6.1 Operating functions.....................................................................................18
7 Commissioning��������������������������������������������������������������������������19
7.1 Post-installation check and switching on the device.....................................19
7.2 Operating matrix .........................................................................................19
8 Troubleshooting ������������������������������������������������������������������������22
8.1 Error limits as per NAMUR NE 43.................................................................22
8.2 Diagnostic messages....................................................................................22
9 Maintenance������������������������������������������������������������������������������23
10 Disposal �����������������������������������������������������������������������������������23
11 Mounting Kit ���������������������������������������������������������������������������23
12 Technical data��������������������������������������������������������������������������24
12.1 Input .........................................................................................................24
12.2 Power supply .............................................................................................24
12.3 Performance characteristics........................................................................24
12.4 Installation .................................................................................................25
12.5 Environment ..............................................................................................25
12.6 Mechanical construction............................................................................27

Operating Instructions - ProSense LPM1 Series Meter
3
LPM1 Series Meter Rev. 1
71487579
1 Document Information
1.1 Document function
These Operating Instructions contain all the information that is required in
various phases of the life cycle of the device: from incoming acceptance and
storage, to mounting, connection, operation and commissioning through
to troubleshooting, maintenance and disposal.
1.2 Document conventions
1.2.1 Safety symbols
Symbol Meaning
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
will result in serious or fatal injury.
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
can result in serious or fatal injury.
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation
can result in minor or medium injury.
NOTICE!
This symbol contains information on procedures and other facts which do not
result in personal injury.
Symbol Meaning
Direct current
A terminal to which DC voltage is applied or through which direct current flows.
Alternating current
A terminal to which alternating voltage is applied or through which alternating
current flows.
Direct current and alternating current
• A terminal to which alternating voltage or DC voltage is applied.
• A terminal through which alternating current or direct current flows.
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded
via a grounding system.
Protective ground connection
A terminal which must be connected to ground prior to establishing any other
connections.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
4
71487579
1.2.2 Electrical symbols
Symbol Meaning
Equipotential connection
A connection that has to be connected to the plant grounding system: This
may be a potential equalization line or a star grounding system depending on
national or company codes of practice.
ESD - Electrostatic discharge
Protect the terminals against electrostatic discharge. Failure to comply with
this instruction can result in the destruction of parts or malffunction of the
electronics.
1.2.3 Symbols for certain types of information
Symbol Meaning
Permitted
Indicates procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Indicates procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
Refers to the corresponding device documentation.
Reference to page
Refers to the corresponding page number.
Reference to graphic
,
…
,Series of steps
Result of a step
Help in the event of a problem
Visual inspection

Operating Instructions - ProSense LPM1 Series Meter
5
LPM1 Series Meter Rev. 1
71487579
1.2.4 Symbols for graphics
Symbol Meaning
1, 2, 3, ... Item numbers
,
…
,Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
Flow direction
Hazardous
Area
Hazardous area
Indicates a hazardous area.
Hazardous
Area
Safe area (non-hazardous area)
Indicates a non-hazardous area.
1.2.5 Symbols for tools
Symbol Meaning
Flat blade screwdriver
Allen key
Open-ended wrench
Torx screwdriver
2 Basic Safety Instructions
2.1 Requirements for personnel
The personnel for installation, commissioning, diagnostics and
maintenance must fulfill the following requirements:
• Trained, qualified specialists must have a relevant qualification for this
specific function and task
• Are authorized by the plant owner/operator
• Are familiar with federal/national regulations
• Before beginning work, the specialist staff must have read and understood
the instructions in the Operating Instructions and supplementary
documentation as well as in the certificates (depending on the
application)

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
6
71487579
• Following instructions and basic conditions
The operating personnel must fulfill the following requirements:
• Being instructed and authorized according to the requirements of the task
by the facility’s owner/operator
• Following the instructions in these Operating Instructions
2.2 Designated use
The process display unit displays analog process variables on its screen.
The device is powered via the 4 to 20 mA current loop and does not require
an additional power supply.
• The manufacturer accepts no liability for damages resulting from
incorrect use or use other than that designated. It is not permitted to
convert or modify the device in any way.
• Panel-mounted device (LPM1-A-PNL): The device is designed for
installation in a panel and must only be operated in an installed state.
• Field device (LPM1-A-ENC and LPM1-A-HAZ): The device is designed
for installation in the field.
• The device may only be operated under the permitted ambient
conditions
2.3 Workplace safety
For work on and with the device:
• Wear the required personal protective equipment according to federal/
national regulations.
2.4 Operational safety
Risk of injury!
• Operate the device in proper technical condition and fail-safe condition
only.
• The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to
unforeseeable dangers.

Operating Instructions - ProSense LPM1 Series Meter
7
LPM1 Series Meter Rev. 1
71487579
2.5 Product safety
This measuring device is designed in accordance with good engineering
practice to meet state-of-the-art safety requirements, has been tested, and
left the factory in a condition in which it is safe to operate.
It meets general safety standards and legal requirements. It also complies
with the EC directives listed in the device-specific EC Declaration of
Conformity. Confirmed by the affixing of the CE mark to the device.
The measuring devices have also been tested by UL or CSA. See “Technical
data” section.
3 Scope of Delivery
The scope of delivery of the device comprises:
• Panel mounted device (LPM1-A-PNL)
– Process display unit
– Operating Instructions
– Fastening fixtures
• Field mounted device (LPM1-A-ENC, LPM1-A-HAZ)
– Process display unit
– Operating Instructions
– CSA Control Drawing (LPM1-A-HAZ only)
4 Installation
4.1 Incoming acceptance, transport, storage
Compliance with the permitted environmental and storage conditions is
mandatory. Precise specifications for this are provided in the “Technical
data section”.
4.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Is the packaging or the content damaged?
• Is the delivery complete? Compare the scope of delivery against the
information on your order form.
4.1.2 Transport and storage
Please note the following:

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
8
71487579
• Pack the device so that it is protected against impact for storage and
transport. The original packaging provides optimum protection.
• The permitted storage temperature is –40 to +85 °C (–40 to +185 °F);
it is possible to store the device at borderline temperatures for a limited
period (48 hours maximum).
4.2 Installation conditions
At temperatures below –25 °C (–13 °F) the readability of the display
can no longer be guaranteed.
4.2.1 Display unit in the panel-mount housing
Permitted ambient temperature range –40 to 60 °C (–40 to 140 °F),
horizontal orientation. IP65 protection at front, IP20 at rear
See “Technical data” section.
4.2.2 Display unit in the field housing
Permitted ambient temperature range –40 to 60 °C (–40 to 140 °F). IP67
protection, NEMA 4x (aluminum housing).
See “Technical data” section.
4.3 Installation instructions
For the dimensions of the device, see “Technical data section”
4.3.1 Panel housing (LPM1-A-PNL)
1.
2.
Installation in a panel with a panel cutout 92x45 mm (3.62x1.77 in), max.
panel thickness 13 mm (0.51 in).
1. Insert the device into the panel cutout from the front.

Operating Instructions - ProSense LPM1 Series Meter
9
LPM1 Series Meter Rev. 1
71487579
2. Fit the mounting clips on the side of the housing and tighten the set screws.
Tightening screw torque: 0.4 to 0.6 Nm
4.3.2 Field housing (LPM1-A-ENC and LPM1-A-HAZ)
Pipe mounting (with optional LPM1-BKT mounting kit)
The device can be mounted on a pipe with a diameter of up to 50.8 mm (2 in)
with the mounting kit (sold separately).
Mounting plate for
pipe/wall mounting
5mm
4mm
1. 2.
3. 4.
TX20
1. Release the 4 housing screws.
2. Open the housing
3. Secure the mounting plate to the rear of the device with 4 screws supplied.
4. Guide the two gripper clamps through the mounting plate, fit them around
the pipe and tighten.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
10
71487579
Wall mounting (with optional LPM1-BKT mounting kit)
1.
2.
3.
1. Use the mounting plate as a stencil and make two 6mm (0.24 in) bore
holes, 82mm (3.23 in) apart. Secure the plate on the wall with 2 screws
(not supplied).
2. Open the housing.
3. Secure the display unit on the mounting plate with the 4 screws
supplied.
4. Close the cover and tighten the screws.
Without a mounting kit.
1. Open the housing.
2. Use the device as a stencil, four 6 mm (0.24 in) bore holes, 99 mm (3.9
in) apart on the horizontal plane, 66 mm (2.6 in) apart on the vertical
plane.
3. Secure the display unit on the wall with 4 screws.
4. Close the cover and tighten the housing screws.

Operating Instructions - ProSense LPM1 Series Meter
11
LPM1 Series Meter Rev. 1
71487579
4.4 Post-installation check
4.4.1 Display unit in the panel-mount housing
• Is the seal undamaged?
• Are the mounting clips securely fastened on the housing of the device?
• Are the set screws properly tightened?
• Is the device located in the center of the panel cutout?
4.4.2 Display unit in the field housing
• Is the seal undamaged?
• Is the housing firmly screwed to the mounting plate?
• Is the mounting bracket firmly secured on the wall/pipe?
• Are the housing screws firmly tightened?
5 Wiring
Danger! Electric voltage!
• The entire connection of the device must take place while the device is
de-energized.
Only certified devices may be connected in the hazardous area
• Observe corresponding notes and wiring diagrams in the CSA-control
drawing supplement to these Operating Instructions. If you have any
questions, please do not hesitate to contact AutomationDirect.com
1-800-633-0405.
SELV/Class 2 device
• The device may only be powered by a power unit with an energy-limited
circuit in accordance with IEC 61010-1: ‘SELV or Class 2 circuit’.
Device destroyed if current too high
• Do not operate the device at a voltage source without a current limiter.
Instead, operate the device only in the current loop with a transmitter.
Panel housing (LPM1-A-PNL): The terminals are located on the rear of
the housing.
Field housing (LPM1-A-ENC and LPM1-A-HAZ): The terminals are
located inside the housing. The device has two M16 cable entries. The
housing must be opened for wiring purposes.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
12
71487579
Operation of the spring terminals
1. When using rigid cables with a ferrule, just plug the cable into the
terminal. No tools required. With flexible wires the spring mechanism of
the terminal must be operated as shown in step 2.
2. In order to loosen the cable, push the spring mechanism in completely
using a screwdriver or other suitable tool and pull out the cable.
5.1 Quick wiring guide
Terminal Description
+ Positive connection, current measurement
- Negative connection, current measurement (without backlighting)
LED Negative connection, current measurement (with backlighting)
Auxiliary terminals (electrically connected internally)
Functional grounding:
• Panel-mounted device:
Terminal on the rear of the housing
• Field device:
Terminal in the housing

Operating Instructions - ProSense LPM1 Series Meter
13
LPM1 Series Meter Rev. 1
71487579
Connection without backlightingConnection with backlighting
Connection with transmitter power supply
and transmitter (sinking)
LED
- +
-
-
+
+
1
1 Transmitter power supply
+
+
1
-
-
LED
- +
Connection with transmitter power supply
and transmitter using the auxiliary terminal
(sinking)
-
-
+
+
1
LED
- +
+
+
1
-
-
LED
- +
Connection without transmitter power
supply directly in the 4 to 20 mA circuit
+
2
-
LED
- +
24to 20 mA current source
+
2
-
LED
- +
24to 20 mA current source
24to 20mA transmitter
LPM1
Meter
LPM1
Meter
LPM1
Meter
LPM1
Meter
LPM1
Meter
LPM1
Meter
2 2
2
2
1 Transmitter power supply
24to 20mA transmitter
1 Transmitter power supply
24to 20mA transmitter
1 Transmitter power supply
24to 20mA transmitter
Connection with transmitter power supply
and transmitter (sourcing)
LED
-
-
++
2
1 Transmitter power supply
24to 20mA transmitter
LPM1
Meter
1
+
+
2
-
-
LED
LPM1
Meter
1
1 Transmitter power supply
24to 20mA transmitter
- + -
+
Connection with transmitter power supply
and transmitter using the auxiliary terminal
(sourcing)
--
+
+
2
LED
-
+LPM1
Meter
1
1 Transmitter power supply
24to 20mA transmitter
+
+
2
-
-
LED
-
+
LPM1
Meter
1
1 Transmitter power supply
24to 20mA transmitter
Note: Always refer to the CSA control drawing (LPM1-A-HAZ-DWG) when installing a LPM1-A-HAZ in a hazardous location.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
14
71487579
5.2 Inserting the cable, field housing
TX20
2.
3. 4.
1.
M16 Cable Glands
LPM1-A-ENC sold separately
LPM1-A-HAZ included with meter
Inserting the cable, field housing, connection without transmitter power
supply (example)
1. Release the housing screws
2. Open the housing
3. Open the cable gland (M16 Cable Glands, LPM1-A-ENC sold
separately, LPM1-A-HAZ included with meter) and insert the cable
4. Connect the cable including functional grounding and close the cable
gland

Operating Instructions - ProSense LPM1 Series Meter
15
LPM1 Series Meter Rev. 1
71487579
5.3 Connecting to functional grounding
5.3.1 Panel-mounted device (LPM1-A-PNL)
For EMC reasons, the functional grounding should always be connected.
1
Functional grounding terminal (1) on panel-mounted LPM1-A-PNL
5.3.2 Field device (LPM1-A-ENC and LPM1-A-HAZ)
For EMC reasons, the functional grounding should always be connected.
When used in a hazardous area (LPM1-A-HAZ with CSA approval), the
connection is obligatory and the field housing must be grounded via a
grounding screw fitted on the outside of the housing.
TX20
Functional grounding terminal in field housing

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
16
71487579
TX20
Ground terminal on field housing
5.4 Degree of protection
5.4.1 Field housing (LPM1-A-ENC and LPM1-A-HAZ)
The devices meet all the requirements of IP67. It is absolutely essential to
comply with the following points to ensure this protection is guaranteed
after mounting or servicing the device:
• The housing seal must be clean and undamaged when inserted into the
groove. The seal must be cleaned, dried or replaced if necessary.
• The cables used for connection must be of the specified outside diameter
(e.g. M16 x 1.5, cable diameter 5 to 10 mm (0.2 to 0.39 in)).
• Mount the measuring device in such a way that the cable entries point
downwards.
• Fill unused cable entries with plugs.
• The housing cover and the cable entries must be firmly tightened.
5.4.2 Panel housing (LPM1-A-PNL)
The front of the device meets the requirements of IP65. It is absolutely
essential to comply with the following points to ensure this protection is
guaranteed after mounting or servicing the device:
• The seal between the front of the housing and the panel must be clean
and undamaged. The seal must be cleaned, dried or replaced if necessary.
• The set screws of the panel mounting clips must be firmly tightened.

Operating Instructions - ProSense LPM1 Series Meter
17
LPM1 Series Meter Rev. 1
71487579
5.5 Post-connection check
Device condition and specifications Notes
Are cables or the device damaged? Visual inspection
Electrical connection Notes
Does the supply current match the specifications on the nameplate? -
Are the cables, incl. functional grounding, connected correctly and strain-relieved? -
Field housing (LPM1-A-ENC and LPM1-A-HAZ): Are the cable glands securely closed? -
6 Operation
1
2
3
4
5
6
7
Display and operating elements of the process display unit
1. Symbol: operating menu disabled
2. Symbol: error
3. Symbol: warning
4. Operating keys “-”, “+”, “E”
5. 14-segment display for unit/TAG
6. Bar graph with indicators for under range and over range
7. 5-digit 7-segment display for measured value, digit height 17 mm (0.67 in)
The device is operated using three operating keys on the front of the
housing. The device setup can be disabled with a 4-digit user code. If
the setup is disabled, a padlock symbol appears on the display when an
operating parameter is selected.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
18
71487579
Enter key; calling up the operating menu, conrming the option/setting parameters in the
operating menu
Selecting and setting/changing values in the operating menu; pressing the '-' and '+' keys
simultaneously takes the user back up a menu level. The congured value is not saved.
6.1 Operating functions
The operating functions of the process display unit are divided into the
following menus. The individual parameters and settings are described in
the “Commissioning” section.
If the operating menu is disabled by means of a user code, the
individual menus and parameters can be displayed but not changed. To
change a parameter, the user code must be entered. As the display unit
can only display digits in the 7-segment display and not alphanumeric
characters, the procedure for number parameters is different to that for
text parameters.
If the operating position contains only numbers as parameters, the
operating position is displayed in the 14-segment display and the
configured parameter is displayed in the 7-segment display. To edit,
press the ‘E’-button followed by the user code.
If the operating position contains text parameters, only the operating
position is initially displayed in the 14-segment display. If the ‘E’
button is pressed again, the configured parameter is displayed in the
14-segment display. To edit, press the ‘+’ button followed by the user
code.
Setup
(SETUP)
Basic device settings
Diagnostics
(DIAG)
Device information, display of error messages
Expert
(EXPRT)
Expert settings for the device setup
The Expert menu is protected from editing by an access code (default 0000).

Operating Instructions - ProSense LPM1 Series Meter
19
LPM1 Series Meter Rev. 1
71487579
7 Commissioning
7.1 Post-installation check and switching on the device
Perform the final checks before commissioning the device:
• Checklist for “post-installation check”
• Checklist for “post-connection check”
The device starts after being connected to the 4 to 20 mA circuit. The
firmware version appears on the display during the start-up phase.
When the device is being commissioned for the first time, program the
setup in accordance with the descriptions in the Operating Instructions.
If you are commissioning a device that is already configured or preset, the
device immediately starts measuring the current as defined in the settings.
Remove the protective film from the display as this would otherwise
affect the readability of the display.
7.2 Operating matrix
Setup menu (SETUP)
Parameters Values visible at Description
DECIM 0 DEC
1 DEC
2 DEC
3 DEC
4 DEC
Number of decimal places for display
SC__4 Numerical value
–19 999 to 99 999
Default: 0.0
5-digit value (number of decimal places as congured
under DECIM) for scaling the measured value at 4 mA
Example: SC__4 = 0.0 displays 0.0 at 4 mA
measuring current
The unit selected under UNIT is used to display the
value.
SC_20 Numerical value
–19 999 to 99 999
Default: 100.0
5-digit value (number of decimal places as congured
under DECIM) for scaling the measured value at 20 mA
Example: SC_20 = 100.0 displays 100.0 at 20 mA
measuring current
The unit selected under UNIT is used to display the
value.
UNIT %
°C
°F
K
USER
Use this function to select the unit for displaying the
value. If "USER" is selected, a user-dened unit can be
entered in the TEXT parameter.
TEXT Customized text, 5-
digit
User-dened unit, only visible if the "USER" option has
been selected under UNIT.

Operating Instructions - ProSense LPM1 Series Meter
LPM1 Series Meter Rev. 1
20
71487579
Diagnostics menu (DIAG)
Parameters Values Description
AERR Read only The current diagnostic message appears on the display. If two or more
messages occur simultaneously, the message with the highest priority
is shown on the display.
LERR Read only The last diagnostic message with the highest priority appears on the
display.
FWVER Read only The rmware version appears on the display.
