AutomationDirect ProSense DPM2 Series User manual

ProSenSe DPM2 SerieS
Digital Panel Meter for ProceSS,
teMPerature anD reSiStance inPut
SignalS
Models:
DPM2-AT-HL, DPM2-AT-2R-HL
DPM2L-AT-HL, DPM2L-AT-2R-HL
uSer Manual
Scan or click the QR code for a series of Configuration and Programming
videos for the ProSense DPM Series Panel Meters
DPM2 Series
DPM2L Series

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
2
UL
CUS
R
In this Chapter...
General Information......................................................................................................4
Package Contents.........................................................................................................4
Recycling Instructions...................................................................................................4
General Safety Considerations ......................................................................................4
Symbols Identification ..................................................................................................4
Maintenance ................................................................................................................5
Technical Support.........................................................................................................5
Agency Approvals.........................................................................................................5
Description.....................................................................................................................5
Features........................................................................................................................6
Dimensions and Mounting............................................................................................6
Installation....................................................................................................................7
Wiring Terminals............................................................................................................7
Wiring Examples ............................................................................................................9
Process Input Signal Wiring Diagrams (V).....................................................................9
Process Input Signal Wiring Diagrams (mA)................................................................10
Potentiometer Input Wiring Diagram (Ω)...................................................................10
Pt100 and Pt1000 Sensor Input Wiring Diagrams ......................................................11
Thermocouple J, K, T and N Input Wiring Diagram....................................................11
Resistance Input Wiring Diagram (Ω).........................................................................11
Relay Output Wiring...................................................................................................11
Display and Key Pad ....................................................................................................12
Configuration...............................................................................................................13
Input Configuration....................................................................................................13
Process .......................................................................................................................14
Temperature...............................................................................................................14
Display Offset.............................................................................................................14
Potentiometer ............................................................................................................15
Resistance...................................................................................................................15
Display Configuration..................................................................................................15
Display Scaling ...........................................................................................................16
Process Input..............................................................................................................17

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
3
Temperature Input .....................................................................................................18
Potentiometer Input...................................................................................................18
Resistance Input .........................................................................................................19
Relay Setpoint Configuration......................................................................................20
Additional Functions....................................................................................................22
MAX/MIN and RESET Functions .................................................................................22
Direct Access to Setpoints Value.................................................................................22
Return to Factory Configuration .................................................................................23
Configuration Lock-Out...............................................................................................23
Technical Specifications...............................................................................................26
Instrumentation Configuration Notes ........................................................................28

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
4
General Information
Package Contents
• DPM2 Series Process digital panel meter
• Quick start guide
• Mounting panel accessories (a sealing gasket and 2 fixing clips)
• Wiring accessories (plug-in terminal block connectors and 2 key tools for wire insertion)
• 4 adhesive engineering unit label sheets
Recycling Instructions
This electronic instrument is covered by the 2002/96/CE European Directive so, it is properly
marked with the crossed-out wheeled bin symbol that makes reference to the selective collection
for electrical and electronic equipment which indicates that at the end of its lifetime, the final
user cannot dispose of it as unsorted municipal waste.
In order to protect the environment and in agreement with the European legislation regarding
waste of electrical and electronic equipment from products put on the market after August 13,
2005, the user can give it back, without any cost, to the place where it was acquired to proceed
to its controlled treatment and recycling.
General Safety Considerations
All instructions and guidelines for the installation and manipulation that are present in this
manual must be considered to ensure personal safety and to prevent damage to either the
instrument or any equipment connected to it.
Safety of any equipment incorporated to this instrument is the responsibility of the system
installer.
If this electronic indicator is used in a manner not specified by the manufacturer in this manual,
the protection provided by the instrument may be impaired.
Symbols Identification
Warning: Potential risk of danger.
Read complete instructions when this symbol appears in order to know the potential risk and
know how to avoid it.
Warning: Risk of electric shock.
Instrument protected by double isolation or reinforced isolation.

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
5
Maintenance
To ensure instrument accuracy, it is recommended to check its performance according to the
technical specifications listed in this manual.
For front cover cleaning, just wipe with a damp cloth and neutral soap product. DO NOT USE
SOLVENTS!
Technical Support
We strive to make our manuals the best in the industry. We rely on your feedback to let us
know if we are reaching our goal. If you cannot find the solution to your particular application,
or, if for any reason you need technical assistance, please call us at:
1-800-633-0405
Our technical support group will work with you to answer your questions. They are available
Monday through Friday from 9:00 A.M. to 6:00 P.M. Eastern Time. We also encourage you
to visit our web site where you can find technical and non-technical information about our
products and our company.
www.AutomationDirect.com
Agency Approvals
Description
The ProSense DPM2 series offers a simple, low cost digital display of analog process signals,
temperature in either Fahrenheit or Celsius from RTD or Thermocouple temperature sensors,
or potentiometer inputs. The 4-digit 14mm character height red LED display is easily scaled
into any engineering units from -9999 to 9999 with a selectable decimal point location. The
DPM2L offers a larger 20mm character height scaled from -1999 to 9999. Two point direct
or reverse acting linear scaling values can be entered manually or by introducing actual sensed
process values in Teach mode. Temperature inputs are pre-configured for fixed temperature
ranges based on the type of temperature sensor and can be displayed with 1 or 0.1 degree
of resolution. One model includes two SPDT relay outputs that can be set to activate on
an increasing or decreasing input signal with hysteresis or time delay operation. The meter
is powered from an external wide range AC or DC power supply and provides 24VDC for
external sensor excitation. The 1/8 DIN housing is easy to install in a panel and the meter
face has an IP65 rating. Configuration parameters can be totally or selectively locked out to
prevent unauthorized or accidental changes to the meter’s operation. Additionally, the DPM2
meters include memory and reset of minimum and maximum display values. ProSense digital
panel meters are backed by a 3 year warranty.

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
6
Features
• 96 x 48mm 1/8 DIN
• Simple menu driven pushbutton configuration
• 14mm 4 digit (-9999 to 9999) or 20mm (-1999 to 9999) red LED display
• Selectable decimal point
• Process (±10V, ±200V and ±20mA)
• Temperature (RTD: Pt100, Pt1000, TC: J, K, T, N, Resolution: 1°F, 0.1°F, 1°C, 0.1°C)
• Potentiometer (100Ωto 100kΩ)
• Resistance (999.9Ω, 9999Ωand 50kΩ)
• AC or DC powered
• Sensor excitation voltage 24V
• Optional (2) Form C SPDT relays
N.O. or N.C. operation
Activation on increasing or decreasing input signal
Hysteresis or time delay operation
• Display scaling or process teaching modes
• Configuration for direct or reverse acting linear processes
• Minimum and maximum value memory
• Total or selective configuration lock out
• 3 year warranty
Dimensions and Mounting
(2) Fixing clips
Sealing gasket
DPM2 Meter
Panel mounting surface

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
7
Installation
To install the instrument, prepare a 92mm x 45mm
panel cut-out and slide the unit inwards making sure
to place the sealing gasket between the front side panel
and the front bezel.
While holding the unit in place, put the fixing clips on both sides of the case and slide them
through the guide tracks until they reach the panel at the rear side.
Press slightly to fasten the clips to the latching slots on the case and get the unit fully assembled
and close fitted to achieve a good seal.
To remove the instrument from the panel, pull the rear fixing clips latching tabs outwards until
they are disengaged, then slide the fixing clips back over the case.
Wiring Terminals
CN3
1 2
CN2
1 2 3 4 56 7
CN1
CN4
1
2
3
4
5
6
Output relay terminals
(DPM2-AT-2R-HL only)
Terminals
Connector CN1 CN2 CN3 & CN4
Wire cross section 0.08 to 2.5mm² (28 to
12 AWG)
0.08 to 1.5mm² (28 to
14 AWG)
0.08 to 2.5mm² (28 to
12 AWG)
Strip length 8 to 9mm 6 to 7mm 8 to 9mm
Manufacturer Wago 231-202/026-000 Wago 734-107 Wago 231-303/026-000
Cage clamp
connection
Insertion tool or
screwdriver with 0.5 mm
x 3.0 mm blade
Insertion tool or
screwdriver with 0.3 mm
x 1.8 mm blade
Insertion tool or
screwdriver with 0.5 mm
x 3.0 mm blade
Installation
Dimensions 96 x 48 x 83.1mm (1/8 DIN)
Panel Cutout 92 x 45mm
(Max. panel thickness 10mm)
Case Material Polycarbonate UL 94 V-0

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
8
CN2
1Common / RTD B / -TC / Pot. Term. 1
2RTD A / +TC / 10kΩ res. / Pot. center
350kΩ res. / Pot. Term. 2
4RTD B Pt100
5+20mA
6Excitation +24V
7 +10/200VDC
Polarity insensitive for
DC power
CN1
AC Supply DC Supply
1 Line 1 VDC
2 Neutral 2 VDC
CN3 (Relay 1)
1NO1
2CM1
3 NC1
CN4 (Relay 2)
4NO2
5CM2
6NC2
NO: Normally open contact
CM: Common
NC: Normally closed contact
(DPM2-AT-2R-HL and
DPM2L-AT-2R-HL only)
CN2 Terminals CN1, CN3, CN4 Terminals
Insertion Tool (included with meter)
Insert wires into the proper terminal
while using the insertion tool to
open the clip inside the connector.
Release the insertion tool to fix wire
to the terminal.
Insertion Tool (included with meter)
Insert wires into the proper terminal
while using the insertion tool to
open the clip inside the connector.
Release the insertion tool to fix wire
to the terminal.
Warning Isolation:
1500Vrms for 1 minute to signal terminals (CN2) and power terminals (CN1).
2500Vrms for 1 minute to signal terminals (CN2) and relays terminals (CN3 or CN4).
2500Vrms for 1 minute to power terminals (CN1) and relays terminals (CN3 or CN4).
Refer to the instructions in this manual to preserve safety protections.
WARNING: If this instrument is not installed and used in accordance with these
instructions, the protection provided by it against hazards may be impaired.
To meet the requirements of EN 61010-1 standard, where the unit is permanently connected to
main supply, it is obligatory to install a circuit breaking device easily reachable by the operator
and clearly marked as the disconnecting device.
To guarantee electromagnetic compatibility, the following guidelines should be kept in mind:
• Power supply wires should be separately routed from signal wires and never run in the same conduit.
• Use shielded cable for signal wiring.
• Cables section should be ≥0.25 mm².
Before connecting signal wires, signal type and input range should be verified to be within the
right limits. Do not connect simultaneously more than one input signal to the meter.

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
9
Wiring Examples
Process Input Signal Wiring Diagrams (V)
4 WIRE CONNECTION WITH EXTERNAL EXCITATION 4 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
DPM2 TRANSDUCER
EXC.
1 7
COM.
+V
+OUT -OUT -EXC.+EXC.
0-10V
0-200V
+-
DPM2 TRANSDUCER
1 7
COM.
+V
+OUT -OUT -EXC. +EXC.
0-10V
0-200V
6
+EXC.
3 WIRE CONNECTION WITH EXTERNAL EXCITATION 3 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
DPM2 TRANSDUCER
EXC.
1 7
COM.
+V
+EXC.
0-10V
0-200V
+-
DPM2 TRANSDUCER
1 7
COM.
+V
+EXC.
0-10V
0-200V
6
+EXC.
+OUT -OUT
+OUT -OUT

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
10
Process Input Signal Wiring Diagrams (mA)
4 WIRE CONNECTION WITH EXTERNAL EXCITATION 4 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
3 WIRE CONNECTION WITH EXTERNAL EXCITATION 3 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
2 WIRE CONNECTION WITH EXTERNAL EXCITATION 2 WIRE CONNECTION WITH EXCITATION SUPPLIED BY THE DPM2
DPM2 TRANSDUCER
1
COM.
+mA
+OUT -OUT -EXC. +EXC.
0-20mA
4-20mA
5
EXC.
+-
DPM2 TRANSDUCER
1
COM.
+mA
+OUT -OUT +EXC.
0-20mA
4-20mA
5
EXC.
+-
DPM2 TRANSDUCER
1
COM.
+mA
+OUT +EXC.
4-20mA
5
EXC.
+-
DPM2 TRANSDUCER
1
COM.
+mA
+OUT -OUT -EXC. +EXC.
0-20mA
4-20mA
5 6
+EXC.
DPM2 TRANSDUCER
1
COM.
+mA
+OUT -OUT +EXC.
0-20mA
4-20mA
5 6
+EXC.
DPM2 TRANSDUCER
+mA
+OUT +EXC.
4-20mA
5 6
+EXC.
Potentiometer Input Wiring Diagram (Ω)
DPM2 POTENTIOMETER
1
TERM.2 TERM.1
2
CENTER
(WIPER)
3
TERM.2
TERM.1
CENTER (WIPER)
NOTE:
Do not perform measurements with potentiometer subjected to external voltage, since it may
interfere in the measurement, alter the reading and even cause serious damages on this unit.

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
11
Pt100 and Pt1000 Sensor Input Wiring Diagrams
DPM2 Pt100 SENSOR
1 2 4
RTD B Pt100
RTD B
RTD A
DPM2 Pt1000 SENSOR
1 2
RTD B
RTD A
Thermocouple J, K, T and N Input Wiring Diagram
DPM2
1 2
+TC
-TC
+ -
J,K,T,N
Resistance Input Wiring Diagram (Ω)
DPM2
1 3
50kΩ
COM.
50kΩ MAX. DPM2
1 2
10kΩ
COM.
10kΩ MAX.
Note: Do not perform measurements with resistance subjected to external voltage, since it
may interfere in the measurement, alter the reading and even cause serious damages to this
unit.
Relay Output Wiring
RELAY 2 RELAY 1
4
5
6
1
2
3
NO
CM
NC
NO
CM
NC
8A/250V MAX.
Important: To guarantee electrical safety according to EN 61010-1 a protective 8A/250V
external fuse must be installed.

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
12
Display and Key Pad
Pro mode is when configuration menu is entered to program the indicator. RUN is the
normal mode in which display shows the reading according to configuration and input signal
value.
1 2
1
2
4
5 6 7 8
9
UP SHIFT DATA
ENTER
3
Programming Panel
#Description Run Mode Programming Mode
14 digit display Red Shows value according to
configuration. Shows steps and data during configuration.
2Minus sign Illuminates for negative
readings. Illuminates for negative values.
3Key Pad --- ---
4Setpoint 1 LED Illuminates when setpoint
1 turns active. Illuminates when setpoint 1 turns active.
5UP key No application Shows setpoint value. Increases value of active
digit.
6SHIFT key
Displays maximum and
minimum stored values.
After 3s of pressing, sets
maximum and/or minimum
memorized value to
current display value.
Shifts active digit to the next right digit.
7DATA/ENTER key Changes to PRO mode.
Validates selected data and parameters.
Moves one step forward in configuration menu.
Changes to RUN mode.
8Setpoint 2 LED Illuminates when Setpoint
2 turns active. Illuminates when Setpoint 2 turns active.
9Free space for
units label --- ---

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
13
Configuration
When the power is applied to the meter, a display test begins automatically to check the
function of LED’s and digits. Once this test is finished the display shows the internal software
version and then the unit goes to RUN mode.
Configuration follows a structure composed of a number of menus and submenus. By pressing
ENTER key, display shows “Pro”, pressing again allows access to the main menu level which
includes the menus for input configuration (InP), display configuration (dSP) and relay
setpoints configuration (SEtP) if relays are present in the meter.
If configuration has been totally locked-out, when pressing ENTER key to get into main menu,
display shows “dAtA” instead of “Pro”. This indicates that it is only possible to see programmed
information and that it is not allowed to modify any parameter from the entire configuration. In
this visualization mode, the meter automatically switches back to RUN mode after 15 seconds
since last key press.

MAIN MENU


  
ENTER:Vertical displacement / Validates data.
UP:Increases active digit value.
SHIFT:Horizontal displacement / Changes active digit.
Once inside each menu, all configuration parameters are sequentially shown and they can then
be introduced or edited by pressing ENTER key. Numeric values must be entered digit by digit,
by first selecting the digit using the SHIFT key and then changing its value with the UP key.
When the desired display value is reached, press the ENTER key to validate the data and move
forward to next configuration step.
Data entered or changed during configuration are stored in device memory only when
configuration routine belonging to the respective submenu is completed, not before. On last
routine step and after having pressed ENTER key, display indicates “StorE” and the unit goes
back again to RUN mode.
Input Configuration
The first menu corresponds to input configuration. This, in turn, consists of four submenus, one
for each input type: process (ProC), temperature (tEMP), potentiometer (Pot) and resistance
(rES).

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
14


  
Process
The parameters to be configured in input process
submenu are:
Input Type:
V: ±10V or ±200V
A: ±20mA
Temperature
The parameters to be configured in input
temperature submenu are:
Sensor Type:
tC: Thermocouple J(1), K(2), T(3) or N(4)
Pt1: Pt100 sensor
Pt2: Pt1000 sensor
Display Resolution:
Select from degree or tenths of degree resolution in
Celsius or Fahrenheit.
Display Offset
-9.9 to +9.9 display counts if a tenths of degree resolution is selected
-99 to +99 display counts if a degree resolution is selected
Usually it will not be necessary to introduce any offset value, except in cases
where a known difference between temperature measured by the sensor and real
temperature should be compensated.
º .º º .º


 
 
 
.

 
 

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
15
Potentiometer
No additional configuration is needed for this input type (direct validation).
Resistance
The only parameter to be configured in input resistance
submenu is:
RESISTANCE RANGE:
999.9 to 999.9Ω(1kΩ) Range
9999 to 9999Ω(10kΩ) Range
50.00 to 50.00kΩ(50kΩ) Range
Display Configuration
The second menu corresponds to display configuration consisting of submenus according to
previously programmed input type.
THROUGH FRONTAL KEYS CONFIGURATION “SCAL”
Input and display values are configured manually through the
three keys of the instrument. This method is suitable when
signal values supplied by the transducer at each extreme point of
the process are known.
REAL INPUT SIGNAL CONFIGURATION “tEAC”
Input values are entered by introducing actual process values.
The input signal device must be connected to the meter at
the CN2 input connector and operational. Display values are
configured manually through the three keys, as in the previous
case. This method is suitable when signal values at each point are
unknown but, it is possible to drive the process to the conditions
defined by these extreme points.
WEIGHTED AVERAGE FILTER “FiLt”
Sets low-pass filter cutoff frequency (Fc) which allows the meter to smooth out undesirable
display reading fluctuations.
 
         
 

.  .

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
16
Display Scaling
Display scaling is necessary when adapting display reading to a particular engineering unit.
Display range can be configured between -9999 and 9999 for the DPM2 or -1999 to 9999
for the DPM2L.
Display scaling is a linear process that consists in introducing two input values, referred as
Input 1 and Input 2, and their respective display values, referred as Display 1 and Display 2.
On the basis of this proportional relationship internal software calculates display value that
would correspond to a given input value. Decimal point position is selectable and completes the
engineering units indication configuration.
It is possible to scale display in an direct acting (increasing) or reverse acting (decreasing)
proportional mode depending on whether the second display value (DISP.2) is greater or less
than the first (DISP.1). In an increasing mode, display value increases proportionally to the
input value whereas in a decreasing mode, display value decreases.
Direct acting (increasing)
proportional mode Reverse acting (decreasing)
proportional mode
DISPLAY 2
DISPLAY 1
DISPLAY 1
DISPLAY 2
INPUT 1 INPUT 2 INPUT 1 INPUT 2
IMPORTANT IN “tEAC” MODE:
To ensure the best accuracy, both points 1 and 2 should represent extreme process limits.
The figure below shows an example for a 10 bar pressure sensor with a 4-20mA output signal.
Decimal point is situated between second and third digit of the display.
(10.00)
DISP.2
(00.00)
DISP.1
(04.00)
INP.1
(20.00)
INP.2

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
17
Process Input
In “SCAL” method, all values must be manually introduced through the
three frontal keys whereas in “tEAC” method, input signal value must be
present at the conector at each point that is intended to be configured.
FIRST POINT INPUT AND DISPLAY VALUE:
InP1: Input value indication.
000: Value entered in counts within available model display range.
dSP1: Display value indication.
0000: Value entered in counts within display range.
DECIMAL POINT:
00.00: Setting of decimal point position. (Decimal point can be located in
any position, and will be the same for Display 1 and Display 2. This
position remains fixed for all configuration steps and also for RUN
mode).
SECOND POINT INPUT AND DISPLAY VALUE:
InP2: Input value indication.
0000: Value entered in counts within display range.
dSP2: Display value indication.
0000: Value entered in counts within display range.
WEIGHTED AVERAGE FILTER:
FiLt: 0 to 9 selectable for low pass
filter cut-off frequency.
Value Fc (Hz) Value Fc (Hz)
0 -- 5 2.2
1 7.3 6 1.6
2 5.1 7 1.1
3 3.8 8 0.5
4 2.9 9 0.2
 

   
 
 

  

.
 

  


DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
18
Temperature Input
When programmed input type is temperature, thermocouple or Pt100 or Pt1000
sensor, the only parameter to configure is the filter and its configuration is done in the
same way as described for process input.
Display scaling is not available for this input type, the unit then will assume a fixed
calibrated range depending on sensor type and previously configured units resolution
Potentiometer Input
When programmed input type is potentiometer, “tEAC” is the only method available to
perform display scaling.
In this case, it must be assured first that potentiometer is connected properly and
that it is not subjected to any external voltage.
After pressing ENTER key, the instrument analyzes connected potentiometer to
internally determine both maximum and minimum resistive values. Once this
calculation have finished, display shows “dSP1”.
FIRST POINT DISPLAY VALUE:
dSP1: Display value indication.
0000: Value entered in counts within display range.
(potentiometer wiper must correspond to process first point).
DECIMAL POINT:
00.00: Setting of decimal point position. (Decimal point can be located in
any position, and will be the same for Display 1 and Display 2. This
position remains fixed for all configuration steps and also for RUN
mode).
SECOND POINT DISPLAY VALUE:
dSP2: Display value indication.
0000: Value entered in counts within display range.
(potentiometer wiper must correspond to process second point).
WEIGHTED AVERAGE FILTER:
FiLt: 0 to 9 selectable for low pass
filter cut-off frequency.
FiLt
0
 

 
  

.
  

Value Fc (Hz) Value Fc (Hz)
0 -- 5 2.2
1 7.3 6 1.6
2 5.1 7 1.1
3 3.8 8 0.5
4 2.9 9 0.2

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
19
Resistance Input
When programmed input type is resistance, the display can be manually scaled by selecting
(uSEr) or the display can be scaled to fixed calibrated ranges (CAL) depending on the resistance
range previously configured.
Display scaling is possible through frontal keys (“SCAL”)
and through real input signal (“tEAC”) as described for
process input. If the fixed calibrated range option “CAL” is
selected, the programming routine goes directly to the filter
configuration (“FiLt”) with no option to return to scaling
configuration.
Filter configuration is done in the same way as described for
process input.
       
     

DPM2 Process User Manual, 1st Edition
User Manual - DPM2 Series Process Panel Meters
20
Relay Setpoint Configuration
The third menu “SEtP” only appears for the DPM2 with relay outputs.
RELAY OUTPUT OPTION
Programming steps are equal for both relays on each “SEt1” and
“SEt2” submenus. The parameters to be configured are the following:
SETPOINT VALUE:
00.00: Value entered in counts within display range. (The decimal
point position is previously defined in display configuration
menu).
ACTIVATING MODE:
Hi: High level relay activation.
Lo: Low level relay activation.
In HI mode, relay output activates when display value goes above
setpoint level, whereas in LO mode, relay output activates when
display value falls below setpoint level.
RESTING CONTACTS STATE:
NO: Normally open contact.
NC: Normally closed contact.
  
     
.
  
 
