Autopilot APBC1000 User manual

APBC1000
USER MANUAL
ANALOG TO DIGITAL CONVERSION MODULE

APBC1000 - USER MANUAL
OVERVIEW
Autopilot has designed an intermediary box that will take the analog 0-10V signal input from
commercial environmental controllers and will convert into the digital RS-485 Phantom brand lighng
signal. The APBC1000 signal converter allows Phantom brand lighng products to adjust the light
intensity based on what readings the quantum sensor is communicang back to the commercial
environmental controller (greenhouse producon facility). Alternately, if the grow is relying solely on
arcial lighng, the signal converter can operate without the quantum sensor, allowing the grower to
manually control lighng intensity (indoor producon facility).
PACKAGE CONTENTS
1 – Autopilot converter module
4 – 15’ RJ-RJ cable
1 – 120-240v power adaptor
4 – RJ splier
2 – 0-10v terminal connector
POWER ADAPTER SPECIFICATIONS
Main Voltage: 120-240V
Operang Voltage Range: 110-265V
Max Input Power: 2 was
Input Power Frequency: 50/60Hz
COMPATIBLE PHANTOM BALLAST PRODUCTS
* Applicable to Phantom models with USB data interface only.
1000W (40 and 50 series) DE HPS
750W (50 series) DE HPS
315W Dual CMH
315W CMH
2

OPERATING INSTRUCTIONS
Signal
Voltage <6V ≥6V ≥7V ≥8V ≥9V ≥10V
Phantom
1000W Standby 60%
(600W)
75%
(750W)
80%
(825W)
100%
(1000W)
115%
(1150W)
Phantom
750W Standby 53%
(400W)
66%
(500W)
80%
(600W)
100%
(750W)
115%
(825W)
315W
Dual Standby 60%
(378W)
80%
(536W)
100%
(630W)
105%
(660W)
315W Standby 60%
(189W)
85%
(268W)
100%
(315W)
105%
(330W)
Includes two 0-10v (-/+) terminal block connectors.
Each 0-10v (-/+) input will control two digital RS-485 outputs.
3

Hydrofarm.com
LIMITED WARRANTY
Hydrofarm warrants the APBC1000 to be free from defects in materials and workmanship. The
warranty term is for 1 year beginning on the date of purchase. Misuse, abuse, or failure to follow
instrucons is not covered under this warranty. Hydrofarm’s warranty liability extends only to the
replacement cost of the product. Hydrofarm will not be liable for any consequenal, indirect, or
incidental damages of any kind, including lost revenues, lost prots, or other losses in connecon
with the product. Some states do not allow limitaon on how long an implied warranty lasts or the
exclusion of incidental or consequenal damages, so the above limitaons or exclusions may not apply
to you. Hydrofarm will, at our discreon, repair or replace the APBC1000 covered under this warranty
if it is returned to the original place of purchase. To request warranty service, please return the
APBC1000, with original sales receipt and original packaging, to your place of purchase. The purchase
date is based on your original sales receipt.
APBC1000 Instrucons -October 10, 2018 11:04 AM
WARRANTY
Like us on Facebook, follow us on Twier,
and check out Hydrofarmtv on YouTube and Instagram!
