Autopot 4Pot XL Instruction Manual

[email protected] I www.autopot.co.uk I [phone] [email protected] I www.autopot.co.uk I [phone]
Your 4Pot XL system
set-up guidelines
Ensuring that the AQUAvalve floods
and drains correctly
Care and maintenance
Making sure your AQUAvalve floods and
drains correctly is simply achieved and
only takes a few seconds.
Hold the AQUAvalve at eye level so that
you can see the silicon fitted to the top float
resting on the hole below it.
The silicon must create a tight seal when
touching the hole.
If it looks like it is not sitting parallel on the
hole below, simply lift the top float and
apply pressure to one side of the silicon,
drop the float and hold at eye level again.
Repeat the procedure if necessary.
At the end of your growing season, clean
the AQUAvalve using warm soapy water.
Using an old tooth brush will help.
The AQUAvalve is easily disassembled.
The top float will slide all the way across
and the bottom float is unclipped from its
pivoting position. The circular discs fitted to
the top float can also be removed by using
pliers to grip the raised point.
At this point is it advisable to remove the
silicones to avoid them being lost.
It is also handy to have a paper clip or
pipe cleaner to hand so that you can push
it through the AQUAvalve nozzle, this will
remove any lime scale build up that may
have occurred during the growing season.
Blowing through the AQUAvalve nozzle will
also help to remove any build up. Do not
under any circumstances use a drill & drill
bit to clear the AQUAvalve nozzle.
This will potentially damage the
AQUAvalve beyond repair.
Simple care
guidelines
11
2
2
3
4
Ensure the silicon is sitting parallel on
the hole below it. Hold at eye level
to check the position is correct
plants
Allow your
to
establish
before turning your
system
on
.
4
Layout 2
Layout 1

4Pot XL system
setup instructions
Using your front instruction sheet, repeat the module set up instructions for the number of trays.
If you require any guidance email - [email protected]
Advice
Allow your plants to establish for 7-10 days before turning system on
[email protected] I www.autopot.co.uk I [phone]
Plan views
and options
Suggested layouts
• 1x47ltrtankandlid
• 4x1PotXLtrayandlid
• 4x25ltrpot
• 4xAQUAvalve
• 1x6mmtophatgrommet
• 1x6mmgolffilter
• 2x6mmin-linetap
• 2x6mmcrossconnector
• 4x6mmteeconnector
• 4metresof6mmpipe
• 4xXLrootcontroldisc
4Pot XL system contents 1Pot XL dimensions
Advice
47 ltr
tank
375mm
300mm
615mm
• Potupyourplants,waterthrough,thenallowyourplantstoestablishinthepotsforaperiodof7to10days
before turning your system on. This will encourage a stronger and healthier root system.
• Alwaysraiseyourtanktoaminimumof150mmabovethehighestAQUAvalveandre-fillthetankwhen
thereisapproximatelya1/3ofthesolutionleft-NEVERALLOWTHETANKTORUNEMPTY.
• Forbestresults,werecommendmineralfertilisers.Donotuseorganicfertilisers,astheyhaveatendencyto
block small pipe work.
• Clean all substrate from the bottom and sides of the pots before placing in each tray.
This will ensure your system is clean from the start.
• Always use free draining substrates, for example: soil/perlite, coco/perlite, soil/clay pebbles,
coco/claypebbles,rockwool/claypebbles.
1
7 8 8
2
Place circular
root control disc
gold face down
in the pot.
5
Position tray so it is
level.
Push 6mm top hat grommet
into tank, then push 6mm
pipe through grommet.
Inside the tank push
6mm filter into 6mm pipe.
3Remove collar.
Push 6mm pipe through
collar and attach to
AQUAvalve nozzle.
Rescrew collar - DON’T
overturn... when you feel
it grip STOP.
Connect AQUAvalve
so ‘half moon’ is on T
section in the tray.
4
Fill pot with medium
and pot up plants.
Water through pot
and allow to drain
outside the tray.
Place pot in the
tray, make sure it is
CLEAN!
Place lid over valve
onto tray.
Cut 6mm/16mm pipe
to appropriate length
Connect your 6mm pipe
to the relevant fitting
6
380mm
285mm
25 ltr
pot
330mm
372mm
275mm
6mm pipe
6mm top hat grommet
6mm cross connector
6mm tee connector
6mm golf filter
AQUAvalve
6mm inline tap
Layout 1
Layout 2
47 ltr
Tank
47 ltr
Tank
6mm pipe
6mm top hat grommet
6mm cross connector
6mm tee connector
6mm golf filter
AQUAvalve
6mm inline tap
Layout 1
Layout 2
47 ltr
Tank
47 ltr
Tank
