IrriGreen Irrigreen2 User manual

Irrigreen2® App Guide
IOS
Mobile App Video
Irrigreen.com/professionals-logged-in/
Password: goirrigreen!
IG2-APP-2.0.3 1
One Head per Zone … Simple.

Connect with IOS App
1. Start IG2 App
2. Click “Allow In Use Location” 3. Select “Allow While Using App”
2

Connecting with IOS App
4. Click “Add Controller”
5. Scan Barcode on Controller
3

Connecting with IOS App
6. App Will Start Connecting
7. Connected Screen
4

Connecting with IOS App
8. Dashboard Will Appear
App/Dashboard Menu appears
on bottom of screen
5
Wi-Fi
Connection
Status light
must be
Green.
Yellow is an
unstable
connection.
Red is no
connection,
move back
in range and
Click to
reconnect.

Connect System to Homeowner’s Wi-Fi for
for Online Monitoring
6
•Roll the system over to the property owner’s
2.4 GHz Wi-Fi network for internet access
•IrriGreen will update system software remotely
•IrriGreen will monitor system efficiency
•This typically improves Wi-Fi range for zone
mapping

Rollover to Home Wi-Fi. App will
automatically prompt user for rollover
Go to Dashboard
Click “More”
7
Follow Wizard, then
connect mobile device to
the home network
Click Wi-Fi
Settings

IOS System Settings
Go to System Setup Page
Click “More”
8
Click “System Setup”

IOS System Settings: Flow Sensor
System Setup Page
Click Flow Meter
9
Flow Meter Setup Page
Select Flo1 if Flow Sensor
wired to Flo1 in Controller

IOS System Settings: Master Valve/Pump
System Setup Page
Click Master Valve
10
Master Valve Setup Page
Select MV/P if system has a
Master valve or Pump

IOS System Settings: Rain/Soil Sensor
System Setup Page
Click Master Valve
11
Master Valve Setup Page
Select MV/P if system has a
Master valve or Pump
Rain/ Soil Sensor Setup Page
Select Sens1 if Rain/Soil
Moisture Sensor wired to
Sen1 in Controller

IOS Digital Zones are Pre-enabled
for each Installation at the Factory
A. Go to Setup Page
B. Click Digital Zone Button
to green On position
12
There are 16 (or 32)
Digital Zones
available, as two (or
four) separate
sequences of eight.
You may divide the
zones up between the
two separate
sequences of eight.
Example:
Seven Digital Zones
could be:
Digital Zones 1-7
OR
Digital Zones 1-4 and
Digital Zones 9-11
To enable Digital Sprinkler Zones
(if needed):

Sprinklers are Pre-numbered for each Zone
Sprinklers will run in that numerical order*
Locate sprinklers in the order you want them to run
13
Digital Sprinklers have Zone Numbers 1-16
assigned at the factory
Zone Number on Sprinkler box Zone Number on Sprinkler
*Head #1 runs first
Head #2 runs second
Head #3 runs third
Etc.

Connect up to Eight Sprinklers
per Controller Cable
Connect sprinklers with Sprinkler Cables and Cable Tees
Digital Zones 1-8:
Wire Controller Cable to “iG 1-8” and “Common”
Locate Sprinklers numbered 1-8 in the order you want them to run on the landscape
Digital Zones 9-16:
Wire second Server Cable to “iG 9-16” and “Common”
Locate Sprinklers numbered 9-16 in the order you want them to run on the landscape (after 1-8)
DO Install Cables in a trench or pull a parallel run of 1 inch pipe as conduit for Cables
DON’T pull IrriGreen Cables
DO loop excess Cable inside a valve box adjacent to the head, buried below turf
DON’T cut and splice IrriGreen Cables
DO branch out your Cables in different directions with Tees
Use a 6FT Plug-n-Play Cable Tee; use supplied End Plug to seal the last Sprinkler connector plug
DO add a second Controller Cable if branching off immediately from the Server
DO protect all Digital Sprinkler connections with small valve boxes, buried below turf

IOS Zone Mapping
Click Zones Select Digital Zone
15

IOS Zone Setup: First, Calibrate Digital Zones
Calibrate Every Digital Zone Before Mapping
Click Calibrate Button
Takes about 4 minutes
Head sprays varying distances
Start Mapping Zone Shape
Click Edit
16
Head will pop up
and spray ~15’ at
Position “0”
Click “Edit”
to program
Zone Shape

IOS Zone Startup: Map Digital Zones
Program/Map Sprinkler to Zone Shape
5. Click/Hold “Rotate Arrow” to turn
streams
437 Rotation settings, every 0.8o
Clockwise rotation only
6. Click “Up / Down” Arrows
to Set Distance
Distance (~6” increments)
Distances are approximate
7. Click “Save” to create Positions
System draws a straight line between
any two points/positions
17

Zone Map/Programming Rules
•Set map points to track about
6” from zone edges; water
will soak out to the edge
•Up to 50 map points are
allowed per zone
•“Best practice” is to use
minimal number of map
points to create zone shape,
then add points as needed to
optimize tracking
18
•When zone is started up, it
will spray at Rotation “0”
and 15 feet
•It will turn only when you
tap/hold “Rotate”
•The zone startup (Position
1) may be set to any
Rotation (0-437), but the
first Position distance must
be 10+ feet to fully pop up
and seat the riser

Digital Zone Map Point Table
Point 1 is the start up position, must be 10’+
Point 1 becomes the zone start up position
Position 1 may be any Rotation Position : 0-437
Position 1 must be 10+ feet so the head has
enough flow/pressure to fully “pop up” and
seat the riser seals.
After head is fully popped up, Positions may be
set as short as 5 feet.
Distances are
approximate
19
Current Distance & Rotation
values are continuously displayed
while mapping zones

IOS Back Up and Play Functions
Use “Play” to check your Zone Map
Click Reverse-Rotate Arrow
Streams will backup 15
degrees to redo Positions
Click Play Icon
System will quickly run
through the Zone Map
20
