Autostart ASL-300 Quick start guide

V1.00 TL October 18, 2005
WIRING SCHEMATIC
WIRING SCHEMATIC
Keyless Entry And Alarm System
1- PURPLE ........... (+) Starter Input
2- PURPLE ............ (+) Starter Output
1- BLACK ......................................... GROUND (
-
)
2- RED ........................... +12V POWER INPUT (+)
3- GRAY....................... HOOD SWITCH INPUT (
-
)
4- YELLOW / BLACK .. PARKING LIGHTS INPUT
5- YELLOW............... PARKING LIGHTS OUTPUT
PUSH-BUTTON
VALET SWITCH
PLUG-IN L.E.D.
12- BLACK/PINK .................. ( - ) Zone 2 Disable Output
11- BLACK/GREEN .............. (
- ) Aux 3 Output
10- BLACK/BROWN ............. (
- ) Aux 2 Output
9- BLACK/BLUE ....... (
- ) Aux 1 Output
8- GRAY/RED ........................ (+) Pos. Door Trigger Input
7- GRAY/BLACK ................... (
- ) Neg. Door Trigger Input
6- WHITE/BLUE .................... (
- ) Horn Output
5- WHITE/RED ...................... (+) Siren Output
4- GRAY/GREEN .................. (
- ) Negative Trigger Input
3- GRAY/LIGHT BLUE ......... (
- ) Trunk Input
2- PURPLE ............................ N/A
1- PINK .................................. (+) Ignition Input
3- BROWN ............. (
- ) Lock
2- N/A ..................... (+) 12V for INV-200 Module
1- GREEN .............. (
- ) Unlock
1-WAY ANTENNA WIRE
2-WAY ANTENNA CABLE
*** Only available on 2-WAY System
SHOCK
SENSOR
