Autostart AS-6265i SH Quick start guide

V5.0 TL - October 3, 2006
Programming
Assistance Button
(Hood Switch
Interrupt)
TACH Threshold: HIGH
TACH Threshold: NORMAL
SIDE VIEW OF MODULE
Data Port (Optional)
1- BLACK ........................ GROUND ( - )
2- PURPLE........................... TACH (AC)
3- GREY ................. HOOD SWITCH (
- )
4- ORANGE ........ BRAKE SWITCH (+)
5- YELLOW ....... PARKING LIGHTS (+)
GREEN ............ 5
th
RELAY
PURPLE............. STARTER
ORANGE...ACCESSORIES
(Heater Blower Motor)
YELLOW ........... IGNITION
RED ............+12V (Battery)
RED ..............12V (Battery)
PUSH-BUTTON
VALET SWITCH
(Optional on
certain models)
INV-200 Connector
Jumpers for second outputs
(Starter, Ignition, Accessories)
15 A Fuse
30 A Fuse
30 A Fuse
REAR VIEW OF MODULE
WIRING SCHEMATIC
WIRING SCHEMATIC
85
87
(Solenoid Side)
86
30
STARTER WIRE
(Key Side)
IGNITION (+)
N/A
Start Kill Output (-)
87A
STARTER WIRE
Optional Starter Kill Relay
Optional
programming
port
Optional
programming
port
Starter 2 Jumper
Ignition 2 Jumper
Accessories 2 Jumper
INV-200 CONNECTOR
(Door Lock pulse
inverter)
Data Port (Optional)
RS-232 Port (ADS)
N/A
RS232 Port
(ADS)
2. WHITE/PURPLE ........ (-) HORN output
3. BLACK/GREEN ......... (-) AUX2 output
1. GRAY/LIGHT BLUE ... (-)N/A
Shock Sensor
Shock Sensor
4. BLACK/BROWN ........ (-) N/A
5. YELLOW .................... (-) PARKING LIGHTS input
2. WHITE/PURPLE ..... (-) HORN output
3. BLACK/GRENN ...... (-) AUX2 output
1. GREY/BLUE ............ (-) N/A
4. BLACK/BROWN ..... (-) N/A
5. YELLOW ................. (-) PARKING LIGHTS
12- YELLOW .......................... (+) Glow plug input
11- GREY ............................... (
- ) Negative Door input
10- WHITE .............................. (
- ) GROUND out when running
9- PURPLE ............................ (+) Siren output
8- ORANGE ........................... (-) Hand Brake Input
7- WHITE/ORANGE ............... (
- ) Starter kill output
6- BLUE/WHITE ..................... (+) Positive Door input
5- WHITE/GREEN .................. (
- ) DISARM
4- WHITE/BROWN ................. (
- ) REARM
3- GREEN .............................. (
- ) UNLOCK
2- BROWN ............................. (
- ) LOCK
1- BLUE ................................. (
- ) TRUNK output
