Autostart AS-1727 Quick start guide

1- BLACK ........................ GROUND ( - )
2- PURPLE........................... TACH (AC)
3- GREY ................. HOOD SWITCH (
- )
4- ORANGE ........ BRAKE SWITCH (+)
5- YELLOW ....... PARKING LIGHTS (+)
GREEN ............ 5
th
RELAY
PURPLE............. STARTER
ORANGE...ACCESSORIES
(Heater Blower Motor)
YELLOW ........... IGNITION
RED ............+12V (Battery)
RED ..............12V (Battery)
PUSH-BUTTON
VALET SWITCH
(Optional on
certain models)
Warning: Use pliers when removing the
L.E.D. connector, do not pull out the cord
as you could tear off the wires from the
connector, leaving the latter inside the
module.
30 A Fuse
30 A Fuse
INV-200 Connector
Jumpers for second outputs
(Starter, Ignition, Accessories)
Data Port (Optional)
15 A Fuse
85
87
(Solenoid Side)
86
30
STARTER WIRE
(Key Side)
IGNITION (+)
N/A
Start Kill Output (-)
87A
STARTER WIRE
Optional Starter Kill Relay
V1.00 TL October 9, 2005
WIRING SCHEMATIC
WIRING SCHEMATIC
Starter 2 Jumper
Ignition 2 Jumper
Accessories 2 Jumper
INV-200 CONNECTOR
(Door Lock pulse
inverter)
REAR VIEW OF MODULE
Data Port (Optional)
Optional
programming
port
Optional
programming
port
12- YELLOW .......................... ( - ) AUX 5 - RIGHT Sliding door output
11- GREY ............................... (
- ) AUX 4 - LEFT Sliding door output
10- WHITE .............................. (
- ) GROUND out when running
9- PURPLE ............................ (
- ) EXT. TRIGGER
8- ORANGE ........................... (
- ) AUX 2 output
7- WHITE/ORANGE ............... (
- ) Starter kill output
6- BLUE/WHITE ..................... (
- ) Priority door output
5- WHITE/GREEN .................. (
- ) DISARM
4- WHITE/BROWN ................. (
- ) ARM
3- GREEN .............................. (
- ) UNLOCK
2- BROWN ............................. (
- ) LOCK
1- BLUE ................................. (
- ) AUX 3 output (TRUNK)
(Optional on certain models)
+2 VOLT L.E.D.
1. BLUE/WHITE ... (-) HORN Output
2. YELLOW .......... (-) PARKING LIGHTS
OOOOO
OO
L.E.D PLUG-IN
CONNECTOR
Programming
Assistance Button
(Hood Switch
Interrupt)
L.E.D.
(Optional)
TACH Threshold: HIGH
TACH Threshold: NORMAL
SIDE VIEW OF MODULE
2. (-) PARKING LIGHTS
1. (-) HORN Output
