Autowel NICE-80DP User manual

I.G.B.T. INVERTER
PLASMA Cutting M/C
NICE - 80DP
NICE - 100DP
NICE - 130DP
Autowel Co., Ltd.
User
Manual

-1-
Guarantee Certificate◀▶
* The warranty of products shall confirm to the specification set forth in
the article 2 "configuration and specifications" for 14 months from the date
on Bill of Lading.
* The extent of seller's liability under this warranty shall be limited to the
repair or replacement as herein provided of any defective parts thereof.
* The warranty does not extend to following occasion:
- subjected to mis-use, neglect, accident or abuse
- improperly repaired, installed, transported, altered or modified
- used in violation of instructions furnished by user's manual
Warranty Card.
*Note:
1. The "Guarantee Certificate" shall practically be effected with seller's
signature after fill in blank of Warranty Card.
2. Users has to pay attention to the subjects set forth Article 3
"installation" when installing the main power units and accessories.
3. Autowel has no liability of accessories, which are consumable and not
to manufactured by Autowel
Model NICE - DP 1. warranty period is 14 months from
the date on Bill of Lading.
2. Except for the express limited
warranties set forth in this
guarantee certificate, Autowel
has no other liability.
Certified by Autowel CO., Ltd.
Serial no.
manufacture
date 년월200
shipdate 년월일200
seller's name Autowel Co., Ltd.
client name
company
person

-2-
CONTENTS◀▶
1. PRODUCT INTRODUCTION
2. CONFIGURATION AND SPECIFICATION
3. INSTALLATION
4. OPERATION AND HANDLING
5. SAFETY INTRODUCTION
6. MAINTENANCE AND INSPECTION
7. TROUBLE SHOOTING
Before using welding machine, users have to read the
all contents described by manual to have better quality
of weld, and to reduce maintenance works.

-3-
1. Product introduction
Autowel NICE-80(100, 130)DP PLASMA Cutting M/C is controlled by
I.G.B.T inverter, and cutting metal plate by Plasma Arc via current(A)
with compressed air. The use rate with the low input power and high
output is maximized.
2. Configuration and Specification
1) Configuration
Type
Item NICE-80(100, 130)DP
POWER SOURCE 80A 100A 130A 1
TORCH (SET) P-80 8M
EARTH CABLE 14SQ 3M
Nozzle 1.5mm 1.8mm 1
Electrode P-80 1
Shield Cap P-80 1
Guide Ring P-80 1

-4-
2) Standard specification
Type
Name NICE-80DP NICE-100DP NICE-130DP
Input Voltage
AC 220V 1P, 3P AC 220V/380V BOTH
1P, 3P
220V/380V BOTH
Input Power 9,6KW 11.2KW 18.2KW
Frequency 50/60Hz
Max. output
current
1P 3P 1P 3P 1P 3P
60A 70A 80A 100A 110A 130A
optimal cutting 8mm 12mm 15mm 18mm 20mm 25mm
max. cutting 12mm 16mm 18mm 22mm 25mm 30mm
Open circuit
voltage 280V 300V 320V
Load Voltage 120V 130V 140V
Air pressure 4Kgf/cm2 5Kgf/cm2 6Kgf/cm2
사 용 율 40%
Dimension
(WXDXH) 260x430x430 290x550x500 290x550x500
Weight 28Kg 32Kg 35Kg

-5-
3. Installation
* Installation Diagram
NFB
Ground
P-80 Torch
Fig.1 Total Installation Diagram
NO Description NO Description
1 MAIN NFB(3Ø 50A, more) 5 Ground (3rd level Ground)
2 Input 5.5SQ and more 6 Torch (P-80) 8M
3 Air Hose inner dia 8mm 7 Earth WCT-14SQ, more
4 Compressor 3HP, more

-6-
Fig.2RearPanel

-7-
4. Operation and handling
4-1. Front panel and name
4-2. Function and explanation
1) Cutting Current : Output current adjustment when cutting base metal.
2) Power Lamp : It turns on when the power on/off switch is on.
3) Cutting Lamp : It turns on during cutting process.
4) Warning Lamp : It turns on when occurring error of air and temperature
error of air : not work when air pressure is lower than 2Kgf/cm2.
error of temperature : stop operation when Temperature is over 85 .℃
Restart cutting process when warning lamp is off a certain
period latter.
5) Power switch : Power on/off of cutting machine.

-8-
6) Pilot switch : ON- Arc beam is coming out from torch nozzle when
cutting the base metal as per non-contact.
OFF- use it at low current when cutting the base metal as
per contact.
7) Self hold switch : ON- Cutting start when press torch switch, and
after torch switch release, cutting is continuously on
process, and stop(off) cutting when press torch
switch again.
OFF- Cutting is on when press torch switch.
8) Control Fuse : for security fuse(3A) of control unit.
9) Torch Connector : it connect to torch switch.
10) Pilot terminal : It connect with torch, and to generate Arc Beam at torch.
11) Air connector : it connect to torch main cable(incl. Air hose).
12) Earth terminal : it connect to base metal, which is to be cut.
13) Air Check : Air flow check function for 100DP/130DP model.
5. Safety Instruction
1) Input power : Each cutter has to install NFB. Cable 5.5SQ and more for
1Ph. 220V and 3Ph 380V for 80DP, Cable 8.0SQ and more for 100DP, and
14SQ and more for 130DP.
2) Components of torch should be changed after power off.
3) Apply class 3 grounding.
4) Pay attention of respiratory and burns taking mask and safety product, and
especially fire prevention from fume gas and inflammables.
5) Arc beam makes a certain damage of eyes and skin during cutting
process. Therefore safety cloths and welding mask should be used.

-9-
6. Maintenance and Inspection
7. Trouble shooting
Check Items POINT Description Period
Output Fasten connector Fasten enough 2 months
Inner Part Dust opening cover, and
blow out dry air. 1-3months
Air Unit water of inner
open coke of unit,
and drain water and
dry it.
everyday
Electrode and
Nozzle Wear & tear enlarged nozzle hole
and before using
Main body Input power
after checking input
power source, and
connect it
before using
and move to
other place
NO Phenomenon Reason Remedy
1No reaction when
power on
out of main switch Replace
open input cable Replace
2
FAN is running,
but no work when
press torch switch
out of switch Replace
warning lamp brink Air press, temp. cfm
Warning lamp on Over load, A/S need
3
only air come out,
and not cutting
base metal.
out of Torch Replace
Hi-press. PCB out A/S need
outofoutputdiode A/Sneed
electrode nozzle wear Replace
4
Hi-volt is working,
but pilot is not
coming out
out of torch insulator Replace
out of transistor
A/S need
open resistance
opennpilot cable
out of PCB
nozzle electrode short Replace
