Autronica AutroMaster ISEMS User manual

116-P-AMASTER-INSTCOMM/IGB, Rev.C, 2016-05-20, Autronica Fire And Security AS
Installation and Commissioning
Handbook
AutroMaster ISEMS - Integrated Safety and Emergency Management System

Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
COPYRIGHT ©
This publication, or parts thereof, may
not be reproduced in any form, by any
method, for any purpose.
Autronica Fire and Security AS and its
subsidiaries assume no responsibility
for any errors that may appear in the
publication, or for damages arising
from the information in it. No
information in this publication should
be regarded as a warranty made by
Autronica Fire and Security AS. The
information in this publication may be
updated without notice.
Product names mentioned in this
publication may be trademarks. They
are used only for identification.

Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Table of Contents
1. Introduction......................................................................1
1.1 About the Handbook..........................................................................1
1.2 About the Handbook..........................................................................2
1.3 The Reader........................................................................................2
1.4 Reference Documentation.................................................................2
2. About AutroMaster ISEMS ..............................................3
2.1 Overview............................................................................................3
2.2 AutroMaster Editions.........................................................................3
3. Installation........................................................................5
3.1 Preparing to Install the System..........................................................5
3.2 CentOS 4.6 Installation......................................................................6
3.2.1 Startup.....................................................................................6
3.2.2 Media Check ...........................................................................7
3.2.3 Welcome to CentOS 4.6.........................................................8
3.2.4 Select Installation Language...................................................8
3.2.5 Keyboard Configuration...........................................................9
3.2.6 Installation Type......................................................................9
3.2.7 Partitioning the Disk ................................................................10
3.2.8Adding a Swap Partition..........................................................11
3.2.9 Adding Linux Partitions............................................................12
3.2.10Completing the Partitioning of the Harddrive ..........................13
3.2.11Installing GRUB.......................................................................14
3.2.12Network...................................................................................14
3.2.13Firewall....................................................................................17
3.2.14Language Support...................................................................18
3.2.15Time Zone...............................................................................18
3.2.16Root Password........................................................................19
3.2.17Select the Software to be Installed..........................................19
3.2.18About to Install.........................................................................20
3.2.19CentOS Setup.........................................................................21
3.3 CentOS 5.11 Installation....................................................................28
3.3.1 Startup.....................................................................................28
3.3.2 Media Check ...........................................................................29
3.3.3 Welcome to CentOS 5.3.........................................................30
3.3.4 Select Installation Language...................................................30
3.3.5 Keyboard Configuration...........................................................31
3.3.6 Installation Type......................................................................32
3.3.7 Partitioning the Disk ................................................................32
3.3.8 Adding a Swap Partition..........................................................33
3.3.9 Adding Linux Partitions............................................................34
3.3.10Completing the Partitioning of the Harddrive ..........................35
3.3.11Installing GRUB.......................................................................36
3.3.12Network...................................................................................36
3.3.13Time Zone...............................................................................39
3.3.14Root Password........................................................................39
3.3.15Select the Software to be Installed..........................................40
3.3.16About to Install.........................................................................41
3.3.17Starting up Linux the Very First Time......................................42
3.3.18Firewall....................................................................................42

Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
3.3.19Security Enhanced Linux.........................................................43
3.3.20Kdump (Kernel Crash Dumping).............................................44
3.3.21Date and Time.........................................................................45
3.3.22Create User.............................................................................45
3.3.23Sound Card.............................................................................46
3.3.24Additional CDs.........................................................................47
3.3.25Logging in for the First Time ...................................................48
3.4 Installing AutroMaster ISEMS............................................................49
3.4.1 Installing AutroMaster ISEMS .................................................49
3.5 Upgrading an Existing AutroMaster System......................................50
4. AutroMaster ISEMS .........................................................51
4.1 Modifying the hosts-file......................................................................51
4.2 Registration of AutroMaster ISEMS...................................................52
4.3 Registration After Reconfiguration ....................................................53
5. Network Time Protocol....................................................54
5.1 Introduction........................................................................................54
5.2 Configuring an NTP-server................................................................54
5.3 Configuring an NTP-client .................................................................54
5.4 Giving AutroMaster Access to Devices .............................................55
6. Startup..............................................................................56
6.1 General..............................................................................................56
6.2 Printer Type.......................................................................................57
6.3 Alarm Printout....................................................................................58
6.4 Sound Output ....................................................................................59
6.5 Number of Input Modules Connected................................................60
6.6 Duty Control.......................................................................................61
6.7 Dimming of Computer Screen...........................................................62
6.8 Screen Resolution.............................................................................63
6.9 Shift to First Alarm Only.....................................................................64
6.10 Screensaver/Restore Screen ............................................................65
6.11 Adjust Clock in BS-100......................................................................66
6.12 Output Control...................................................................................67
6.13 Connected Units................................................................................68
6.14 Main Computer in Master / Slave Configuration................................69
6.15 BS-100 Addresses.............................................................................70
6.16 Saving Changes................................................................................71
7. Connections Between Fire Detection Systems
and AutroMaster ISEMS........................................................72
7.1 Connections Between AutroMaster and BS-100...............................72
7.2 Connections Between AutroMaster ISEMS and AutroSafe 3............73
7.3 Connections Between AutroMaster ISEMS and AutroSafe 4............74
7.4 Connections Between AutroMaster ISEMS and Autroprime.............74
7.5 Cable Specifications..........................................................................75
8. Assigning IP Addresses..................................................76
8.1 AutroMaster Connected to AutroSafe 3 ............................................76

Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
8.2 AutroMaster Connected to AutroSafe 4 ............................................77
8.3 AutroMaster Connected to Autroprime..............................................77
9. Other Configurations.......................................................78
9.1 Configuration of a Printer under CentOS 4.6 ....................................78
9.2 Configuration of a Printer under CentOS 5.3 ....................................82
9.3 Configuring Automatic Summer/Wintertime Adjustment...................87

Introduction
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 1
1. Introduction
1.1 About the Handbook
This handbook is intended to provide the necessary information for
basic configuration of the AutroMaster Integrated Safety and
Emergency Management System (AutroMaster ISEMS).
The majority of configuring is performed by using a normal editor.
Linux has a number of different editors that may be used, for example,
vi, emacs, gedit, kedit, kate, etc.
gedit is recommended and is to be used in graphic mode.
All editing is performed in Command line window. Security level 4
(Service) is required to gain access to Command line.
To open the pull-down menu, click Menu using the left mouse
button.
Select the desired submenu (Command line is selected in this
example) and then click the left mouse button (shaded black
above).

Introduction
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 2
1.2 About the Handbook
This handbook provides all necessary information for the installation
and commissioning of the AutroMaster Integrated Safety and
Emergency Management System (AutroMaster ISEMS).
1.3 The Reader
The handbook is intended to be used by personnel who are
responsible for the installation, commissioning and startup of the
communication with fire alarm panels, of type BS-100 or AutroSafe.
We assume that the reader has basic knowledge of the Linux
Operating System, plus BS-100 or AutroSafe.
1.4 Reference Documentation
The AutroMaster ISEMS documentation consists of the following
documents:
Document Name Part number File name
System Description
116-AMASTER-SYSTEM/XGB
amastersystem_xgb
Basic Configuration
Handbook
116-AMASTER-BASICCONF/EGB
amasterbasicconf_egb
Advanced Configuration
Handbook
116-AMASTER-ADVCONF/EGB
amasteradvconf_egb
Installation and
Commissioning Handbook
116-AMASTER-INSTCOMM/IGB
amasterinstcomm_igb
Operator’s Handbook
116-AMASTER-OPERATE/FGB
amasteroperate_fgb
Shortform User Guide
116-AMASTER-USERGUI/LGB
amasterusergui_lgb
AutroBrowser, Installation
116-AUTROBROWIN/DGB
autrobrowin_dgb
Datasheet:
AutroMaster ISEMS
116-AMASTER-ISEMS/CGB
amasterisems_cgb

About AutroMaster ISEMS
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 3
2. About AutroMaster ISEMS
2.1 Overview
AutroMaster ISEMS is an Integrated Safety and Emergency
Management System which can be used together with the AutroSafe
Interactive Fire Detection System or the BS-100 system.
The system can be connected to a large number of fire alarm panels
of different types (such as operator, control or repeater panels) via a
serial connection or an ethernet network.
AutroMaster ISEMS uses Linux as an operating system.
Platform
Operating system
Installation media
PC
CentOS 5.11
CD / DVD
2.2 AutroMaster Editions
AutroMaster ISEMS is the full AutroMaster edition, including all
functionality. In addition, there are three editions; one for the oil & gas
market, the maritime market, and the onshore market (see details in
the overview below).
Functions/Modules
Oil & Gas
Maritime
Onshore
ISEMS
Basic functionality
Fire management basic
functions (AutroSafe,
Autroprime 2.0.x or later,
and
BS-100 interface)
x
x
x
x
MultiSensor control
x
x
x
x
Report generator
x
x
x
x
Control and monitoring of
emergency lights/LLL
x
x
x
x
Extended functionality
AutroSafe IFG unit support
x
NA
NA
x
Dual Safety (AutroSafe 4.3
or later)
x
x
x
x
Touch screen support
x
x
x
x
Decision support
system/incident manager
x
Electronic plotting table
x
Training/simulation module
x
Event record and replay
module
x
Video module (live video
support CCTV)
x
x
Remote connect function
x
Message center module
x

About AutroMaster ISEMS
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 4
Interfaces
Hernis CCTV interface
x
System-S interface
x
NMEA interface
x
VDR output
x
x
Modbus interface
x
x
x
ESPA 4.4.4 interface
x
x
x
Gessler
x
Saia PLC
x
x

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 5
3. Installation
To install AutroMaster ISEMS on a PC make sure that you have the
following software.
Linux boot floppy and Linux CD based on CentOS installation CD
(alternatively DVD).
AutroMaster ISEMS distribution on CD’s.
3.1 Preparing to Install the System
AutroMaster ISEMS requires CentOS 5.6. It can either be downloaded
from the Internet or you can buy it from Autronica Fire & Security AS. If
you want to download a distribution, make sure that you download a
distribution in ISO format. The ISO format is one large file, which can
be loaded onto your CD burner program and the Linux DVD/CDs can
be burned.
Every Linux distribution contains complete software for network
communication, graphical user interface, a complete development
environment, and many different server softwares.
This chapter deals with 5.11.
Before the installation is carried out it is important to write down the
following key information about the PC:
Type of the graphical board installed and the available memory.
Type of mouse and where the mouse is connected.
Monitor information, including; type, resolution, horizontal and
vertical refresh frequencies. The standard resolution is 1280x1024,
therefore find the vertical frequency for this resolution in your
monitor manual.
Type of the network card, if the computer is to be connected to a
network or AutroSafe.
Make sure that all necessary CD’s (the Linux CD and AutroMaster CD)
and the information about the hardware are available.
Important! 

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 6
3.2 CentOS 4.6 Installation
Insert the CentOS setup CD-ROM and turn on the PC.
If the PC cannot start from a CD-ROM, the PC’s BIOS setup must be
changed so that the CD-ROM is defined as the first unit in the start-up.
3.2.1 Startup
When the PC is turned on, the following is shown:
Click Enter to continue.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 7
3.2.2 Media Check
If you are using the CentOS CD-ROM the very first time, we
recommend that a Media Check is performed in order to verify the
content of the CD-ROM.
If you are using the CentOS CD-ROM the very first time, click OK, if
not, click Skip.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 8
3.2.3 Welcome to CentOS 4.6
Click Next to continue.
3.2.4 Select Installation Language
The language selection allows you to define the language that is used
during the installation of the CentOS. The selected language is also
used in Linux fault messages etc. Note that this selection will not affect
other language-dependent settings, as for example the keyboard
configuration.
We recommend that English is selected. This handbook is based on
the English language setting.
Select English and click Next to continue.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 9
3.2.5 Keyboard Configuration
Select the layout type for the keyboard that is used for the system,
and click Next to contiunue.
3.2.6 Installation Type
Select custom installation, and click Next to continue.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 10
3.2.7 Partitioning the Disk
If the harddrive contains existing partitions, these have to be deleted.
A minimum of 200 GB harddisk is required.
It is recommended that the harddisk partitioned into five partitions, as
shown in the table below.
Partition Type
Size
Mounting point
Swap
4096 Mbytes
Ingen
Linux extended 3
20 GB
/
Linux extended 3
30 GB
/ home
Linux extended 3
20 GB
/ usr
Linux extended 3
Remaining space
/ var
Select Manually partition with Disk Druid, then click Next to
continue. (If the harddrive is new, it must be initialized.)
If a warning appears on the screen; ”Would you like to initialize this
drive, erasing ALL DATA?”, click Yes to continue.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 11
If the harddrive contains existing partitions, these have to be
deleted.
Select the partitions under the partition list, and click the Select
button.
Repeat this procedure until all existing partitions are deleted.
3.2.8 Adding a Swap Partition
Select New to define a new partition.
Select swap for the File System Type.
Select 4096 for the Size or at least twice the size of the PC’s
physical memory.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 12
3.2.9 Adding Linux Partitions
Click New to add a partition.
The screen dump below is a general example (does not
show the actual values).
Select EXT3 for File System Type.
Type / for the Mount Point.
Check off “Fixed size”
Type the size of the partition (20 000).
Click OK to continue.
Repeat this procedure for all partitions that are to be defined (note
that the partition /var must be defined as the last partition.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 13
3.2.10 Completing the Partitioning of the Harddrive
Ensure that the entire harddrive is allocated.
The screen dump below is a general example (does not
show the actual values).
If all free space is allocated, click Next to continue.
If you have not allocated all free space on the harddrive, delete the
partitions and repeat the procedure above.

Installation
Installation and Commissioning Handbook, AutroMaster ISEMS - Integrated Safety and Emergency Management System,
116-P-AMASTER-INSTCOMM/IGB, Rev. C, 2016-05-20, Autronica Fire and Security
Page 14
3.2.11 Installing GRUB
GRUB is the default startup program for Linux.
Make sure that the Boot loader is installed on the PC’s first
harddrive.
To continue, click Next.
3.2.12 Network
If the PC is to be connected to a network or communicate with
AutroSafe, the PC’s network card must be configured.
To change the network information, click Edit.
