1. Introduction
1.1 About the Handbook
This document provides information on how to connect detectors and
other loop units to the Interactive Fire Detection Systems Autroprime
and AutroSafe.
Note that some loop units can be connected to AutroSafe only (the
indication “AutroSafe only” is written in the beginning of these
chapters).
For more detailed information on loop units, refer to the datasheet for
each specific unit.
1.2 The Reader
This handbook is intended for technical personnel.

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 4
2. Connections to Detectors
2.1 Connecting Detectors
PRESSH ERETRYKK HER
KNUS GLASSET
BREAK GLASS
Loop
Driver
Module
Detector I/O Unit Manual Call Point
BN- 320
BRANNALARM
Tilpasningsenhet
FIRE ALARM
Interfac e unit
Nr.
No.
BN- 320
BRANNALARM
Tilpasningsenhet
FIRE ALARM
Interfaceunit
Nr.
No.
Input
Output
2.2 LED Connection on Detector
+
-
BU-46
Input
Output
1 - IN
2 - OUT
3 + COMMON
4 - LED
LED
Varistor SIOV-S07K25

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 5
2.3 Connection of Branch-off
If necessary, a branch-off can be connected to a detection loop if the
existing cable layout requires this, but this is not recommended, as the
safety will be reduced.
To ensure a correct addressing of the detectors on a branch-off when
configuring the system, there can not be more than one branch-off per
detector. For safety reasons, the number of detectors on each branch-
off must be kept to a minimum, as the detectors on a branch-off will
not operate in case of a break or shortcircuit on the branch-off. The
absolute maximum number of detectors on a branch-off (or an open
loop) is 32.
Accepted NOT Accepted!
Loop Loop
Branch-off Branch-off
Branch-off
Input
Output
+
-
+-
1 - IN
2 - OUT
3 + COMMON
4 - LED
Main Loop
Branch-off
Next detector on
branch-off
NOTE:
Always connect a
branch-off to terminal
2 (-) and 3 (+).

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 6
2.4 Detector Head / Base Alignment
Alignment
LED
LED
2.5 Detector Label
AUTRONICA
FI RE & SECURITY
INSPECTIONSERTIFICATE
REF AFS-
OPTI CAL DETECTORBHH320
ID
ID
EN54/7 CE
001 1998 239 0001
0842
001 1998 239 0001
Location for
tagname sticker

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 7
2.6 Detector Locking Mechanism
2.6.1 Detector Base
In the detector base a small locking nub will keep the springloaded
tongue in an open position to prevent the detector head from being
locked. If the locking nub is removed before mounting with a pair of
cutting nippers or similar, the detector head will enter a locked
position.
I
Detector base with locking nub
2.6.2 Detector head
The new springloaded tongue (figure 3) on the detector head will lock
the head in a correct position if the locking nub has been removed
before mounting.
Detector head with springloaded tongue
Springloaded tongue
Locking nub

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 8
2.6.3 Removing a locked detector head
• To remove a locked detector head, use a suitable tool
(for example a paper clip or similar) to push the
springloaded tongue in, and simply turn the detector
head counter-clockwise.
Use this hole to
access and release
the locking
mechanism.

Connections to Detectors
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 9
2.7 Detector Dust Covers
Autronica detectors are supplied with a dust cover. To avoid possible
contamination of the detector chamber during installation, these
should remain in place on the detector until commissioning is started.
IMPORTANT:
LEAVE DETECTOR DUST
COVERS ON UNTIL
COMMISSIONING IS
STARTED

Connections to Other Loop Units
