AV TOOL AVT-6544 User manual

Instruction Manual
AVT-6544
4x4 HDMI Matrix Switcher

Table of Contents
1.0
Introduction
2
2.0
Specifications
3
3.0
Package Contents
4
4.0
Connecting the Hardware
4
5.0
Operating The Unit
5
6.0
Troubleshooting
6
7.0
Limited Warranty
7
8.0
Regulatory Compliance
7
9.0
Contact Information
8

2
1.0 INTRODUCTION
Thanks for purchasing this AVT-6544 4x4 HDMI Matrix Switcher from the AV Toolbox
division of TV One. The AVT-6544 provides the capability to assign any of four HDMI
inputs to any of the four HDMI outputs. The AVT-6544 senses when a valid HDMI
connection has been made to either the input or output. All inputs and outputs are HDMI
V1.3 compliant and the device can be controlled via an Infrared remote device or by use
of dedicated front panel push buttons. AV Toolbox offers a wide range of video, audio
and multimedia products.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. AV Toolbox
cannot be held liable for the use of this hardware or any direct or indirect consequential
damages arising from its use. It is the responsibility of the user of the hardware to check
that it is suitable for his/her requirements and that it is installed correctly. All rights
reserved. No parts of this manual may be reproduced or transmitted by any form or
means electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the publisher.
AV Toolbox reserves the right to revise any of its hardware and software following its
policy to modify and/or improve its products where necessary or desirable. This
statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The AV Toolbox logo is a
trademarks of AV Toolbox. All other trademarks are the property of their respective
holders.
1.2 Features
The AVT-6544 4x4 HDMI Matrix Switcher has many features that enable it to perform in
a superior manner. Among those features you will find:
V1.3 HDMI Compliant
HDCP Compliant
Large Variety of Bitrates and Signal Formats
Supports DTS-HD Master Audio, Dolby True-HD and SACD Embedded Audio
Manual or IR Remote Control
“Hot Plug” Automatic HDMI Signal Detection

3
2.0 SPECIFICATIONS
Signal Inputs
Signal Type
V1.3 HDMI
Connector Type
4x Type A HDMI
Signal Outputs
Signal Type
V1.3 HDMI
Connector Type
4x Type A HDMI
Supported Video Formats
24 Bit
RGB/YCbCr 4:4:4
30/36 Bit
RGB/YCbCr 4:4:4 (Deep Color)
24/30/36 Bit
RGB/YCbCr 4:2:2
Supported Audio Formats
Embedded Audio
DTS-HD Master Audio, Dolby True-HD, DD+,
DTS, DD, SACD
I/O Control
Manual
Via Front Panel Buttons
Remote
Via IR Remote
Mechanical
Dimensions (H-W-D)
48x380x220mm (1.9”x15”x8.6”)
Weight (Net)
1.16kg (2.54lbs)
Environmental
Operating Temperature
+10° to +50° C (+50° to +122° F)
Operating Humidity
0% to 50%, Non-condensing
Storage Temperature
0° to +70° C (+32° to +158° F)
Storage Humidity
0% to 80%, Non-condensing
Warranty
Limited Warranty
1 Year Parts and Labor
PowerRequirement
External Power Supply
9VDC@3A
Regulatory Approvals
Amplifier Units
FCC, CE, RoHS
Power Supplies
UL, CUL, CE, PSE, GS, RoHS
Accessories Included
1x Power Adapter
US, UK or Euro
1x Infrared Control
1x Operations Manual
Product Item Numbers
AVT-6544
4x4 HDMI Matrix Switcher

4
3.0 CHECKINGPACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain the
following items are contained in the shipping carton:
1x AVT-6544 Matrix Switcher
1x Power Adapter with 9VDCOutput
1x IR Remote Control
1x User Manual
Note: Please retain the original packingmaterial should the need ever arise to return the unit. If
you find any items are missing,contactyour reseller or AVToolbox immediately.Have the
Model Number,Serial Numberand Invoiceavailable for reference when you call.
4.0 CONNECTINGTHE HARDWARE
The AVT-6544 has a single LED that indicates when power has been applied, an
Infrared remote control sensor located behind a square translucent window next to the
power on/off button, four sets of four buttons that allow signal selection for the four
outputs and signal selection indicator LEDs. The rear panel has the power connection,
four input connections and four output connections and an RJ-45 connector that is not
currently used on this product. Please take a moment to familiarize yourself with the
location of the various signal selection buttons, the input and output connectors and the
power input connector.
Note that you have four groups of outputs, each of which allows four possible input
selections. This technology is called a 4x4 matrix switcher because all four inputs and
all four outputs can be controlled independently without having an effect on one
another.
Note: Make certain you connect only the suppliedpower adaptor to the device as
serious damage can result by usingimproper voltages.

5
5.0 OPERATING THE UNIT
5.1 Connectthe Unit as follows:
1. Turn off power to each HDMI source device and to all HDMI destination devices
(such as Monitors).
2. Connect the output of each source device to the AVT-6544 4x4 Matrix switcher’s
inputs using high quality HDMI cables.
3. Connect the input of the destination devices to the output connectors of the AVT-
6544 using high quality HDMI cables.
4. Turn on power to the destination Devices.
5. Plug the DC Connector from the 9VDC Power Adapter provided into the
Amplifier.
6. Plug the Power Adapter into an AC Outlet and turn on the AVT-6544.
7. Turn on power to the source Devices.
Note: The AVT-6544uses Output 1 as the primary EDID source for all Inputs. If there is
no display connected to Output 1 the AVT-6544 will use a built in “compatibility” EDID.
When you press the power button, the red Power LED will illuminate on the AVT-6544 if
the unit is receiving 9 volts DC. The LEDsabove each of the selection buttons will
illuminate with a white light if there are valid HDMI signals present. If you have these
indications on the front panel of the AVT-6544, it means the switcher is ready for you to
make your routing selections.
5.2 Making Signal Routing Selections
The purpose of a matrix switcher is to allow the user to route input signals to different
destinations independent of one another.
The device is called a matrix because you can send one of four signals to a single
destination; send four different source signals to four different destinations or any
combination thereof.
For instance, you might wish to send the HDMI signal present on input number one to
all four destinations. By pressing the input select for HDMI source number one for all
four of the outputs, all four destinations will receive the HDMI source present on input
number one.
By the same token, you could select input source number one for output number one
and then select HDMI source two as the input signal on output two. Whatever is
connected to the switcher’s output number one would then receive the HDMI source
present on the switcher’s input number one but the device connected to switcher output
number two would receive the HDMI signal present on the switcher’s input number two.

6
Using this same approach, any of the four HDMI inputs can be sent to any of the four
outputs present on the AVT-6544.
When you make a selection as explained above, the white LED above the appropriate
input button for each output group will turn green. This means you can tell at a glance
which input each of the four outputs is receiving at the moment. By noting which of the
input LEDs is white, you can also tell if pressing the input button will result is sending
that input’s HDMI signal to the output for the desired output.
Note that once the AVT-6544 is receiving power, you can change the input cables to
different HDMI sources and the AVT-6544 will recognize that you have plugged in a
new HDMI source and light the white LED above the appropriate input (if there is a valid
HDMI signal present). This is called “Hot Plug” sensing and if the LED is white, you can
select the HDMI source is a valid HDMI format even though you didnot power down the
unit and the sources to reinitialize the unit.
5.3 Using the Infrared Remote Control
6.0 TROUBLESHOOTING
A problem with the AVT-6544 4x4 HDMI Matrix Switcher is rare. Most of the time,
problems are caused by the use of low grade cable, too long of a cable run, bad
connectors on the cable or occasionally by damaged cables. Bad grounds or use of
different AC power sources for the AVT-6544, Signal Source and/or Display Device(s)
may also cause problems due to ground loops. If the unit should free –something that
can happen to any electronic device due to momentary voltage surges or a millisecond
loss of power, power down all sources, destination devices and the AVT-6544 and re-
power them using the procedure described in section 5.1.
After trying the above suggestions should the problem still persist, contact your dealer
for additional suggestions before contacting AV Toolbox. Should the dealer’s technical
personnel be unable to assist you, contact AV Toolbox via the TV One support website:
http://tvone.crmdesk.com. Create a technical support request on the site and our
support team will respond within a short period oftime.
The Infrared Remote Control is organized using the
same logic as the front panel control buttons. Each
output has four dedicated input selection buttons. By
pressing an input section button, you can cause the
desired HDMI source to appear on the desired output.
Pressing the button on the top left causes the AVT-
6544 to enter the standby state and pressing the
button at the top right causes a reset command to be
generated.

7
7.0 LIMITED WARRANTY
LIMITED WARRANTY –AV Toolbox warrants the original purchaser that the equipment
it manufactures will be free from defects in materials and workmanship for a period of
one year from the date of purchase. Should this product, in AV Toolbox’s opinion,
prove defective within this warranty period, AV Toolbox, at its option, will repair or
replace this product without charge. Any defective parts replaced become the property
of AV Toolbox. This warranty does not apply to those products which have been
damaged due to accident, unauthorized alterations, improper repair, modifications,
inadequate maintenance and care, or use in any manner for which the product was not
originally intended.
If repairs are necessary under this warranty policy, the original purchaser must obtain a
Return Authorization Number from AV Toolbox and return the product to a location
designated by AV Toolbox, freight prepaid. After repairs are complete, the product will
be returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in lieu of
all other warranties for this product, expressed or implied, and is strictly limited to one
year from the date of purchase. AV Toolbox assumes no liability to distributors, dealers
or end-users for any loss of use, revenue or profit.
AV Toolbox makes no other representation of warranty as to fitness for the purpose or
merchantability or otherwise in respect of any of the products sold. The liability of AV
Toolbox with respect to any defective products will be limited to the repair or
replacement of such products. In no event shall AV Toolbox be responsible or liable for
any damage arising from the use of such defective products whether such damages be
direct, indirect, consequential or otherwise, and whether such damages are incurred by
the reseller, end-user or any third party.
8.0 REGULATORY COMPLIANCE
The AVT-6544 4x4 HDMI Matrix Switcher has been tested for compliance with
appropriate FCC and CE rules and regulations. The Power Adaptor/Supplies have been
tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations
and/or Guidelines. These Products and Power Adapters are RoHS Compliant.

8
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not covered
by this manual, please contact AV Toolbox at the appropriate location.
AV Toolbox
A division of TVOne
2791 Circleport Drive
Erlanger, KY 41018
USA
Tel [phone]
Fax [phone]
[e-mail]
www.avtoolbox.com
AV Toolbox
A division of TV One Ltd
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[e-mail]
www.avtoolbox.co.uk
AV ToolboxLatin America
A division of TV One L.A.
6991 NW 82 Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax [phone]
[e-mail]
www.avtoolboxla.com
TV One Mercosur
Av. DiazVelez 3965 #PB
(1200) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[e-mail]
www.tvonela.com
TV One Asia
16F-4, NO.75, Sec. 1
Xintai 5th Rd., Xizhi Dist.
New Taipei City 22101
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[e-mail]
www.tvoneasia.com
TV One China
Rm. 1007, Golden Peach Bldg.
No. 1900 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax [phone]
Email: [e-mail]
www.tvonechina.com
[End of Manual]
