AV TOOL AVT-6071 User manual

AVT-6071
Multi-Format Switcher
Instruction Manual

Table of Contents
1.0 Introduction 2
2.0 Specifications 4
3.0 Checking Package Contents 5
4.0 Connecting the Hardware 5
5.0 Operating The Unit 6
6.0 Troubleshooting 8
7.0 Limited Warranty 8
8.0 Regulatory Compliance 9
9.0 Contact Information 10

2
1.0 INTRODUCTION
Thanks for purchasing this product from the AV Toolbox Division of TV One. The
AVT-6071 Multi-Format Switcher allows selection of one of 10 input signals for
display on an HDMI monitor or projection system. The switcher’s output provides
a fully compliant V1.3 HDMI output from any HDMI, Component Video, Com-
posite Video, S-Video or PC Video input signal. PC Video inputs from VGA
through SXGA are supported as are Video signals from 480i (SDTV) through
1080p HDTV (including 12 bit deep color when operating at 1080p). The
Component only supports 1080i. The switcher will pass embedded audio in the
HDMI data-streams as well as switch discrete stereo audio associated with
analog video inputs. 150ms of audio delay is available to correct analog input lip
sync problems. This AVT-6071 Multi-Format Switcher is but one of our complete
range of video and audio products.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. TV One
cannot be held liable for the use of this hardware or any direct or indirect
consequential damages arising from its use. It is the responsibility of the user of
the hardware to check that it is suitable for his/her requirements and that it is
installed correctly. All rights reserved. No parts of this manual may be
reproduced or transmitted by any form or means electronic or mechanical,
including photocopying, recording or by any information storage or retrieval
system without the written consent of the publisher.
TV One reserves the right to revise any of its hardware and software following its
policy to modify and/or improve its products where necessary or desirable. This
statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The TV One logo, AV
Toolbox logo, TV One-task and CORIO are the registered Trademarks of TV
One. All other trademarks are the property of their respective holders.
1.2 Features
HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant
Deep Color video up to 12bit, 1080p@(24/60)Hz.
Analog/digital video/audio inputs and HDMI v1.3 output
Supports PC from VGA to SXGA and HDTV resolutions, 480i to 1080p
3D comb filter
3D noise reduction (DNR)
De-Interlacer allows conversion of 480i to 480p or 576i to 576p
Discrete stereo audio delay of 150ms for Analog Video Sources
IR remote control
RS-232 control

3
1.3 Getting the Best Results
There are many factors affecting the quality of results when switching HDMI type
signals. Some basic precautions will ensure the best possible performance from
your AVT-6071 Multi-Format Switcher.
Output display device – The quality of the output signal will depend
largely upon the type and quality of the HDMI display device used.
For instance, some video projectors just look better than others.
Distance between the switcher, the sources and the display – This
plays a major role in the final result. Long distances are possible, but
special measures should be taken in order to avoid cable losses.
These include using high quality cables. Line amplifiers may also be
necessary for the longest runs.
Input/Output connection cables – Low quality cables are susceptible
to interference. They degrade signal quality due to poor matching and
can cause elevated noise levels. Cables should be of the best quality.
Interference from nearby electrical devices – These can have an
adverse effect on signal quality. For example, an older computer
monitor often emits very high electromagnetic fields that can interfere
with the performance of video equipment in its proximity.

4
2.0 SPECIFICATIONS
Video Inputs 3x HDMI via Type A HDMI
2x CV via RCA
2x S-Video via 4-Pin Mini-DIN
2x YPbPr via 3x RCA each (1080i only)
1x PC via HD-15
Video Outputs 1x HDMI via Type A HDMI
Video Signal Processing 3D Comb Filtering, Digital Noise Reduction (DNR)
De-Interlacer Converts 480i to 480p and 576i to 576p
Signal Bandwidth 2.25Gbps (Single Link)
Maximum Resolutions PC:SXGA, HD:1080p (Component Input is 1080i only)
Output Format HDMI V1.3
Audio Inputs 3x HDMI Embedded Audio
2x RCA R/L (one for each CV/SV Input)
2x RCA R/L (one for each YPbPr Input)
1x 3.5mm Mini Stereo (for PC Audio)
Audio Signal Processing User Selectable - 150ms Audio Delay for Analog R+L
Local Control Via Front Panel
Remote Control Via IR Remote and RS-232
Weight 3lbs (1380g)
Dimensions–HxWxD 1.75”x11.0”x5.8” (44x280x147mm)
Power Source 100~240VAC to 5VDC Adapter

5
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain
the following items are contained in the shipping carton:
1x AVT-6071 Multi-Format Switcher
1x IR Remote Control
1x 100~240VAC to 5VDC Power Adapter
1x User Manual
1x Rack Mount Kit
Note: Please retain the original packing material should the need ever arise to
return the unit. If you find any items are missing, contact your reseller or TV One
immediately. Have the Model Number, Serial Number and Invoice available for
reference when you call.
4.0 CONNECTING THE HARDWARE
Connect the Video Sources to the inputs of the AVT-6071 switcher, connect its
output to an HDMI Compliant monitorand lastly connect the AC to DC Power
Adapter. The drawings below show the locations of the inputs, output, Front
Panel Controls, Power Switch and Power Connector.
4.1 Connecting the Inputs to the AVT-6071
Connect Composite Video, S-Video, Component Video, PC Video or HDMI Video
to the appropriate inputs. DVI Video input is also possible with the appropriate
DVI to HDMI adapter. Make certain that the cables aresecurely plugged into the
source device as well as the AVT-6071. Always use a high quality cable, as short
a length as possible, for best results. Note that you can use either Composite
Video or S-Video on each of the two dual purpose CV/SV inputs but you cannot
use both at the same time on a single input.

6
4.2 Connecting the AVT-6071 to a Display
Using a high quality HDMI cable, connect the output of the AVT-6071 to an HDMI
compliant display device. Use the shortest cable run possible.
4.3 Connecting Power to the AVT-6071
The AVT-6071 is shipped with a Power Adapter to convert 100~240VAC@50-
60Hz to 5VDC. Connect the DC Output Cable from the Power Adapter to the
back of the unit. Next, plug the Power Adapter into an active AC Receptacle.
You will be able to turn on the AVT-6071 via either the front panel power switch,
the power switch on the remote control or via RS-232 commands.
5.0 OPERATING THE AVT-6071
The AVT-6071 Multi-Format Switcher can be operated via the front panel
controls, Remote Infra-red control or via RS-232 commands. The Front Panel
controls are clearly labeled and allow Selection of Power On/Off, Input Selection,
Audio Delay On/Off (analog inputs only) and 480i to 480p or 576i to 576p De-
Interlacing*. LED displays indicate which input is active and there is an indicator
LED that shows when the unit is receiving power.
5.1 Operation of the AVT-6071 via Remote Control
* Some HDMI monitors and projectors will not display 480 or 576 interlaced
signals. If you encounter this problem, pressing the 480i–480p / 576i-576p button
will convert these signals from interlaced to progressive scan which the display
will accept. Note that this feature is not available using RS-232 Control Protocols.
Operation of the AVT-6071 is possible via an included
Infrared Remote Control. The unit can be turned on
and off, the inputs selected, audio delay invoked and
De-Interlacing activated simply by pressing the
appropriate button on the remote. For the signal inputs,
if there are more than one input selection possible for a
particular type of signal, input one (1) is on the left and
input 2 or 3 are positioned to the right of input 1.
Note: When you unpack the AVT-6071, you may have
to remove an insulator from the battery compartment of
the remote in order for the remote to receive power.
The battery compartment slides out from the bottom of
the unit.

7
5.2 AVT-6071 RS-232 OPERATION
The following table shows the types of signals present on the various pins of the
RS-232 connector.
System Remote Controller
Pin Definition Pin Definition
1
NC
1
NC
2
TxD
2
RxD
3
RxD
3
TxD
4
NC
4
NC
5
GND
5
GND
6
NC
6
NC
7
NC
7
NC
8
NC
8
NC
9
NC
9
NC
The AVT-6071’s RS-232 command structure is presented in the table below. It is
the user’s responsibility to program any connected device in such a manner that
successful communication occurs with the AVT-6071.
Command Code Response Description
S POWER 0 > POWER OFF POWER OFF
S POWER 1 > POWER ON POWER ON
S SOURCE 0 > SOURCE HDMI1 HDMI1 INPUT
S SOURCE 1 > SOURCE HDMI2 HDMI2 INPUT
S SOURCE 2 > SOURCE HDMI3 HDMI3 INPUT
S SOURCE 3 > SOURCE PC PC INPUT
S SOURCE 4 > SOURCE COMP1 COMPONENT1 INPUT
S SOURCE 5 > SOURCE COMP2 COMPONENT2 INPUT
S SOURCE 6 > SOURCE SV1 SV1 INPUT
S SOURCE 7 > SOURCE SV2 SV2 INPUT
S SOURCE 8 > SOURCE CV1 CV1 INPUT
S SOURCE 9 > SOURCE CV2 CV2 INPUT
S AUDIODELAY 0 > AUDIODELAY OFF OFF : NO DELAY
S AUDIODELAY 1 > AUDIODELAY ON ON : DELAY 150ms
S SD_ITOP 0 > 480i/576i TO 480p/576p OFF OFF : NO 480i/576i TO 480p/576p
S SD_ITOP 1 >480i/576i TO 480p/576p ON ON : 480i/576i TO 480p/576p
S RESET 1 > RESET ON RESET ACTION
R POWER > POWER ON~OFF SHOW POWER STATUS
R SOURCE > SOURCE HDMI~CV SHOW SOURCE STATUS
R AUDIODELAY > AUDIODELAY OFF~ON SHOW AUDIO DELAY STATUS
R FW_VER > FIRMWARE VERSION : Vx.xx SHOW FIRMWARE VERSION

8
6.0 TROUBLESHOOTING
In the event of problems, first make certain that the input and output cables are of
the highest possible quality and short as possible. Next, make certain that the
switcher is receiving power and try pressing the De-Interlace Button.
If these steps fail to clear the problem, remember that HDMI devices
communicate with one another so the source devices and destination device
must be fully HDMI capable. In addition, HDCP encryption requires additional
processing which also is dependent on the equipment you have connected to the
sources and destination device. If you experience problems using the AVT-6071
Multi-Format Switcher, you should attempt to determine what is wrong by
attaching each of the source devices – one at a time – directly to the destination
device using the same cables you are using with the expanded system if
possible. This is a way of determining if the problem is due to bad cables or a
problem with the other devices. If you are unable to obtain a signal using this
simplified path, suspect the cables, the source device(s) or the destination
device.
After trying the above suggestions should the problem still persist, contact your
dealer for additional suggestions before contacting TV One. Should the dealer’s
technical personnel be unable to assist you, contact TV One via our support
website: http://tvone.crmdesk.com. Create a technical support request on the
site and our support team will respond within a short period of time.
7.0 LIMITED WARRANTY
LIMITED WARRANTY – With the exceptions noted in the next paragraph, AV
Toolbox warrants the original purchaser that the equipment it manufactures or
sells will be free from defects in materials and workmanship for a period of one
year from the date of purchase. Should this product, in AV Toolbox’s opinion,
prove defective within this warranty period, AV Toolbox, at its option, will repair or
replace this product without charge. Any defective parts replaced become the
property of AV Toolbox. This warranty does not apply to those products which
have been damaged due to accident, unauthorized alterations, improper repair,
modifications, inadequate maintenance and care, or use in any manner for which
the product was not originally intended.
Items integrated into AV Toolbox products that are made by other manufacturers,
notably computer hard drives and liquid crystal display panels, are limited to the
term of the warranty offered by the respective manufacturers. Such specific
warranties are available upon request to AV Toolbox. If repairs are necessary
under this warranty policy, the original purchaser must obtain a Return
Authorization Number from AV Toolbox and return the product to a location
designated by AV Toolbox, freight prepaid. After repairs are complete, the
product will be returned, freight prepaid.

9
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is
in lieu of all other warranties for this product, expressed or implied, and is strictly
limited to one year from the date of purchase. AV Toolbox assumes no liability to
distributors, resellers or end-users or any third parties for any loss of use,
revenue or profit.
AV Toolbox makes no other representation of warranty as to fitness for the
purpose or merchantability or otherwise in respect of any of the products sold.
The liability of AV Toolbox with respect to any defective products will be limited to
the repair or replacement of such products. In no event shall AV Toolbox be
responsible or liable for any damage arising from the use of such defective
products whether such damages be direct, indirect, consequential or otherwise,
and whether such damages are incurred by the reseller, end-user or any third
party.
8.0 REGULATORY COMPLIANCE
The AVT-6071 has been tested for compliance with appropriate FCC and CE
rules and regulations. The Power Adaptor/Supplies have been tested for
compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or
Guidelines. These Products and Power Adapters are RoHS Compliant.
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not
covered by this manual, please contact TV One at the appropriate location.

10
AV Toolbox USA
2791 Circleport Drive
Erlanger, KY 41018
USA
Tel [phone]
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.com
AV Toolbox Europe
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[email protected]
www.avtoolbox.com
AV Toolbox Latin America
6991 NW 82nd Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
AV Toolbox Mercosur
Av. Diaz Velez 3965 #PB
(1200) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
AV Toolbox Asia
16F-4, No.75, Sec.1
Hsin Tai Wu Rd., Hsichih
Taipei Hsien 22101
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
AV Toolbox China
Room 1007, Golden Peach Building
No. 1900 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
End of Manual
