Avalon Bay 100B User manual

http://www.avalon-bay.com Customer Care Number: 1-844-528-2566
Food Sealer
(100B)

Avalon Bay Food Sealer Product Guide
2
http://www.avalon-bay.com
Introduction
Thank you for buying this top quality food sealer.
Before using your food sealer, please read this manual carefully.
Incorrect operation can result in serious damage or injury.
Need to Contact Us?
WEBSITE:
http://www.avalon-bay.com
SUPPORT EMAIL ADDRESS:
[email protected]
TELEPHONE NUMBER:
1-844-528-2566
Thank You for Choosing the Avalon Bay Food Sealer
Please read this manual thoroughly and follow all instructions and safety guidelines. With proper
care and maintenance, this appliance will provide you with many years of trouble-free use.
For future reference, we recommend you attach a copy of your sales receipt below and record the
following information, located on the manufacturer’s nameplate on the rear of the unit. You will
need this information if it becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase:
Serial Number:
Model Number:

Avalon Bay Food Sealer Product Guide
3
http://www.avalon-bay.com
Contents
Introduction .................................................................................................................................................. 2
Need to Contact Us? ........................................................................................................................ 2
Product Specifications................................................................................................................................... 3
Important Safety Precautions ....................................................................................................................... 4
Key Features of Your New Food Sealer......................................................................................................... 5
Main Parts of Your New Food Sealer ............................................................................................................ 6
How to Make Custom Sized Bags.................................................................................................................. 8
How to Vacuum Seal with the Vacuum Bags ................................................................................................ 9
How to Use the Seal Button........................................................................................................................ 10
Care and Cleaning ....................................................................................................................................... 11
Troubleshooting.......................................................................................................................................... 12
Service Instructions..................................................................................................................................... 14
Limited Manufacturer’s Warranty .............................................................................................................. 15
Warranty Terms ............................................................................................................................. 15
Product Specifications
VOLTAGE:
110V
WATTAGE:
140W
DIMENSIONS:
10” x 6” x 2”
VACUUM DEGREE:
-0.4 ~ 0.60 bar

Avalon Bay Food Sealer Product Guide
4
http://www.avalon-bay.com
Important Safety Precautions
Read and fully understand all instructions and warnings prior to using
this machine. Your safety is most important!
Danger
•Read the instructions carefully.
•Do not allow the appliance to be used as a toy.
•This appliance should not be operated by children.
•Do not operate the appliance with a damaged power cord or plug.
•Do not use the appliance on a wet or hot surface, or near a heat source.
•Always use the appliance on a level surface.
•Do not immerse any part of the appliance, power cord, or plug into water or other liquid.
•To disconnect, unplug the power cord from the electrical outlet. Do not disconnect by pulling
on the cord. Always unplug the appliance before cleaning and when not in use.
•Do not operate the appliance if it malfunctions or is in any way damaged. If the cord or the
machine is damaged, please return it to our service department for proper service, replacement,
or repair.
•Close supervision is required when this product is used near children.
•This appliance is not for commercial use. If sealing more than 20 bags continuously, wait at least
25 minutes before resuming use of your appliance.
•Keep the upper lid of the appliance unlocked when not use.
This appliance is for HOUSEHOLD USE ONLY.
Do not attempt to service this product. Service should be performed
by an authorized service representative.
Caution
A short power supply cord is provided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord. Extension cords are not prohibited from being used when care is exercised
in their use. When an extension cord is used, the marked electrical rating of the extension cord shall be
no less than the marked electrical rating of the appliance. The longer cord shall be arranged so that it
does not drape over the counter top or table top where it is capable of being tripped over, snagged, or
pulled on unintentionally, especially by children.

Avalon Bay Food Sealer Product Guide
5
http://www.avalon-bay.com
Key Features of Your New Food Sealer
•Most compact design ever.
•Wide sealing line prevents air leakage and keeps high vacuum degree for a longer time.
•Press the left and right side of lid at the same time to vacuum.
•Press the button in the middle to release/open the lid after vacuuming and sealing.
•Pre-seal the vacuum bag any time when vacuuming.
•Sealing width: MAX 8 inches.

Avalon Bay Food Sealer Product Guide
6
http://www.avalon-bay.com
Main Parts of Your New Food Sealer

Avalon Bay Food Sealer Product Guide
7
http://www.avalon-bay.com
A
LID
Press the left and right side at the same time to vacuum and seal.
B
RELEASE BUTTON
When vacuuming and sealing are done, press this button to release and open lid, then bag
can be taken out.
C
SEAL BUTTON
Is used when pre-sealing is needed. When is vacuuming delicate foods, or foods with liquid,
press this button with your thumb while pressing the lid, to stop vacuuming and seal the bag
immediately.
D
INDICATOR LIGHT
1. When the machine is vacuuming, the blue indicator light is on.
2. When the machine is sealing, the blue indicator light blinks.
E
SEALING BAR
Do not tear the high temperature resistant tape away.
F
SEALING FOAM RING
Make sure the open end of bag is inside this area when vacuuming.
G
CIRCUIT SWITCH
When the lid touches this switch, the machine starts to vacuum. Please do not touch this
switch when the lid is open.
H
SEALING FOAM
I
SEALING SILICONE
J
POWER CORD STORAGE

Avalon Bay Food Sealer Product Guide
8
http://www.avalon-bay.com
How to Make Custom Sized Bags
•Pull enough bag material to hold the item to be vacuum packaged, plus two inches (2”). With a
pair of scissors or sharp knife, cut desired bag length from bag roll. Make sure to cut in a
straight line. Plug in power cord.
•Open lid. Place one end of cut bag onto sealing bar. Please make sure this end is not on or
inside the sealing foam ring area.
•Close lid by pressing down on both sides. Now keep pressing until the light goes off, or you can
use your left thumb to press the “SEAL” button to make an instant sealing.
•The machine is sealing the bag when the blue indicator light blinks.
•Once completed, the indicator light will turn off. Stop applying manual pressure, and press the
“RELEASE” button to open the lid. The custom sized bag is now ready for vacuum sealing.
CAUTION: Make sure you give the appliance time to cool down. Wait
at least 20 seconds between seals. Under very heavy usage, appliance
will shut off automatically to prevent overheating. If it does, wait 25
minutes to allow appliance to cool off.

Avalon Bay Food Sealer Product Guide
9
http://www.avalon-bay.com
How to Vacuum Seal with the Vacuum Bags
•Place the item(s) to be sealed into the pre-cut or custom sized bag. Leave at least two inches
(2”) between the contents and the top of the bag to allow for bag contraction.
•Open lid and place the open end of the bag down into the vacuum chamber.
•Close lid by pressing down on both sides. Keep pressing both sides of the lid to vacuum and
seal.
•Once the indicator light has turned off, press the “RELEASE” button to open lid and take out the
bag with food well packed.

Avalon Bay Food Sealer Product Guide
10
http://www.avalon-bay.com
How to Use the Seal Button
This button is used when vacuum packing delicate food, or food with liquid, or in any other cases that
pre-sealing is needed. While the machine is vacuuming the bag, press this button with your left thumb
while your hands are still pressing both sides of lid. Then the machine stops vacuumizing and starts
sealing, at this time, the blue indicator light blinks. When the light goes off, take your hands off the lid
and the pre-sealing is done.

Avalon Bay Food Sealer Product Guide
11
http://www.avalon-bay.com
Care and Cleaning
•Always unplug the unit before cleaning.
•Do not immerse in water.
•Do not use abrasives to clean the unit.
•Wipe the outer surface with a soft, damp cloth and soap.
•To clean the inside of the unit, wipe away any food or liquid with a paper towel.
•Dry all parts thoroughly before you plug in and operate the unit again.
•Vacuum chamber may trap liquids that were drawn from the bag; use a mild dishwashing soap
and a warm, damp cloth to wipe away any left behind liquid from the vacuum chamber. Dry
thoroughly.
•Keep the upper lid of the appliance unlocked when not in use.

Avalon Bay Food Sealer Product Guide
12
http://www.avalon-bay.com
Troubleshooting
Nothing happens when I press both sides of the lid to vacuum
Problem
Possible cause/Solution
Food sealer does not work
•Make sure the power cord is correctly plugged into the
electrical outlet.
•Make sure the power cord is not damaged in any way.
•Make sure the electrical outlet is operative by plugging in
another appliance. If it’s not, please check the circuit breakers
or fuses in your home.
•Make sure the bag is positioned correctly down in the sealing
foam chamber.
•Wait 25 minutes to allow appliance to cool off, and then try
using again.
Air is not vacuumed from the bag
Problem
Possible cause/Solution
Air is not vacuumed from the
bag
•Check that there are no gaps, folds, wrinkles, or holes in the
pre-sealed bags.
•Check for loose, worn or cracked UPPER and LOWER sealing
gaskets.
•Foods with high liquid contents may prevent the bag from
sealing properly. Cut bag open and wipe top inside of bag and
reseal.
•Make sure you have placed the bag in the proper place. When
making a bag from a roll, make sure end of cut piece is on the
sealing bar.
Bag melts
Problem
Possible cause/Solution
Bag melts
•The sealing strip may have been too hot during the sealing
process. Allow the unit to cool for 20 seconds between uses.
If the bag continues to melt, allow unit to cool with the lid in
the upright position for 25 minutes before using.

Avalon Bay Food Sealer Product Guide
13
http://www.avalon-bay.com
Air has seeped back into the vacuumed bag
Problem
Possible cause/Solution
Air has seeped back into the
vacuumed bag
•Check the seal of the bag. There may be a hole or wrinkle that
is allowing air to re-enter the bag. Carefully cut the bag open
and reseal it, or use an entirely new bag.
•Make sure there is no moisture or liquid from the food
present within the bag seal. You may need to cut open the
bag and reseal it, or use an entirely new bag. Partially freeze
foods with excess liquids, prior to vacuum sealing.
•Make sure there are no food items with sharp edges that may
have punctured the bag. If you find a puncture holes, seal the
item in an entirely new bag.
•Make sure no liquids were drawn to the sealing strip area.
•Check for loose, worn, or cracked UPPER and LOWER sealing
gaskets.
•Moisture of foods with high liquid content will prevent the bag
from sealing properly. Cut bag open and wipe top inside of
bag and reseal.
Bag will not seal
Problem
Possible cause/Solution
Bag will not seal
•Check that there are not any gaps folds, wrinkles, or holes in
pre-sealed edges.
•Moisture of foods with high liquid content will prevent the bag
from sealing properly. Cut bag open and wipe top inside of
bag and reseal.
•Make sure you have placed the bag in the proper place. When
making a bag from a roll, make sure the end of the cut piece is
on the sealing strip.
•Make sure you have given the appliance time to cool down.
Wait 20 seconds between seals.

Avalon Bay Food Sealer Product Guide
14
http://www.avalon-bay.com
Service Instructions
•Do NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so
will void the warranty.
•If you have any questions or comments regarding the unit’s operation, or believe any repair is
necessary, please contact our after-sales department.

Avalon Bay Food Sealer Product Guide
15
http://www.avalon-bay.com
Limited Manufacturer’s Warranty
This appliance is covered by a limited manufacturer’s warranty. For one year from the original date of
purchase, the manufacturer will repair or replace any parts of this appliance that prove to be defective
in materials and workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms
During the first year, any components of this appliance found to be defective due to materials or
workmanship will be repaired or replaced at the manufacturer’s discretion, and at no charge to the
original purchaser. The purchaser will be responsible for any removal or transportation costs.
Exclusions
The warranty will not apply if damage is caused by any of the following:
•Power failure
•Damage in transit or when moving the appliance
•Improper power supply, such as low voltage, defective household wiring, or inadequate fuses
•Accident, alteration, misuse, or abuse of the appliance, such as using non-approved accessories,
inadequate air circulation in the room or abnormal operating conditions (extreme
temperatures)
•Use in commercial or industrial applications
•Fire, water, damage, theft, war, riot, hostility, or acts of God, such as hurricanes, floods, etc.
•Use of force or damage caused by external influences
•Partially or completely dismantled appliances
Obtaining Service
When making a warranty claim, please have the original bill of purchase with purchase date available.
Once confirmed that your appliance is eligible for warranty service, all repairs will be performed by an
Avalon Bay authorized repair facility. The purchaser will be responsible for any removal or
transportation costs. Replacement parts and/or units will be new, re-manufactured, or refurbished and
are subject to the manufacturer’s discretion. Do not use an unauthorized person to replace or fix a
damaged main cord.
For technical support and warranty service, please email [e-mail].
