Avalon Bay AB-Airfryer200SS User manual

http://www.avalon-bay.com Customer Care Number: 1-844-528-2566
Air Fryer Product Guide (AB-Airfryer200SS)

Avalon Bay Air Fryer Product Guide
2
http://www.avalon-bay.com
Introduction
Congratulations on your purchase of a new Avalon Bay Air Fryer. This “air” fryer provides an easy and
healthy way to prepare your favorite foods. Your Air Fryer uses hot rapid air circulation and a top grill to
cook your food in all directions, and the best part is that it doesn’t require any oil.
Before using your Air Fryer, please read this manual carefully. Incorrect
operation can result in serious damage or injury.
Need to Contact Us?
WEBSITE:
http://www.avalon-bay.com
SUPPORT EMAIL ADDRESS:
[email protected]
TELEPHONE NUMBER:
1-844-528-2566
Thank You for Choosing the Avalon Bay Air Fryer
Please read this manual thoroughly and follow all instructions and safety guidelines. With proper care
and maintenance, this appliance will provide you with many years of trouble-free use.
For future reference, we recommend you attach a copy of your sales receipt below and record the
following information, located on the manufacturer’s nameplate on the rear of the unit. You will need
this information if it becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase: ___________________________________________
Serial Number: ____________________________________________
Model Number: ____________________________________________

Avalon Bay Air Fryer Product Guide
3
http://www.avalon-bay.com
Contents
Introduction .................................................................................................................................................. 2
Need to Contact Us? ............................................................................................................................ 2
Contents........................................................................................................................................................ 3
Product Specifications.......................................................................................................................... 3
List of Main Parts ................................................................................................................................. 4
Important Safety Precautions ....................................................................................................................... 4
Getting To Know Your Avalon Bay Air Fryer ................................................................................................. 6
Before Your First Use............................................................................................................................ 6
Assembling your Air Fryer .................................................................................................................... 6
Operating your Air Fryer ...................................................................................................................... 7
Cooking Tips.................................................................................................................................................. 8
Preheating Your Air Fryer..................................................................................................................... 9
Reheating food..................................................................................................................................... 9
Baking a Cake?...................................................................................................................................... 9
Foods NOT to cook in your Air Fryer.................................................................................................... 9
Settings............................................................................................................................................... 10
Caring For Your Air Fryer............................................................................................................................. 11
Cleaning and Storage.......................................................................................................................... 11
Environmental Concerns .................................................................................................................... 11
Troubleshooting.......................................................................................................................................... 12
Limited manufacturer’s warranty ...............................................................................................................14
Warranty Terms ................................................................................................................................. 14
Product Specifications
TEMPERATURE CONTROL :
80 - 400°Fahrenheit
TIMER:
30-minutes
CAPACITY:
3.2 lbs.
FOOD BASKET:
Non-stick
DISHWASHER-SAFE PARTS:
Yes

Avalon Bay Air Fryer Product Guide
4
http://www.avalon-bay.com
List of Main Parts
1 - Pan
7 - Warming Light
2 - Basket
8 - Timer (0-30 min.)
3 - Basket release button
9 - Temperature Control (176-400°F)
4 - Basket handle
10 - Cooking Mode Selection
5 - Power button
11 - Air Inlet
6 - LCD Touch Screen
12 - Air Outlets
13 - Power Cord
Important Safety Precautions
CAUTION: Some Air Fryer parts, including outer surface, may get too hot to
touch. To prevent burns, refrain from touching the body of the Air Fryer
during operation, and wait until Air Fryer has cooled down to handle.
This Air Fryer is designed for household use only. It is not suitable for use in staff kitchens, farms,
motels, and other non-residential environments. The guarantee is invalid if the Air Fryer is used for
professional or semi-professional purposes, or if it is not used according to instructions.
Please read all instructions before using your Air Fryer and do not use the appliance for any purpose
other than what is described in this manual.
When using electrical appliances, basic safety precautions should always be followed.
Before Cooking
Ensure the appliance is placed on a flat, even, and stable surface.
Check if the voltage indicated on the appliance fits the local main voltage.
Do not use the appliance if the plug, main cord, or other parts have been damaged.
Do not plug in the appliance to an earthed wall socket. Always make sure that the plug is
properly inserted into an electrical socket.
Do not connect the appliance to an external timer switch.
Do not place the appliance on or near combustible materials such as tablecloths or curtains.

Avalon Bay Air Fryer Product Guide
5
http://www.avalon-bay.com
Do not place the appliance against a wall or against another appliance. Leave at least 4 inches of
free space on the back and sides and 4 inches free space above the appliance.
Do not place anything on top of the appliance.
Keep the appliance and the power cord out of the reach of children.
Do not use an unauthorized repairman to replace or fix a damaged main cord.
While Cooking
Keep all food in the basket to keep it from coming into contact with the heating element.
Do not cover the air inlet or the air outlet while the unit is on.
Do not fill the pan with oil. Oil is a fire hazard.
Do not touch the inside of the appliance while it is on.
Do not leave the appliance unattended while it is cooking. While it is cooking, hot steam is
released through the air outlet. Keep your hands and face at a safe distance away from the air
outlet.
Always be careful when removing the cooking pan. Hot steam and air may be
released when you remove it from the Air Fryer.
Keep the main cord away from hot surfaces.
Any surfaces below or beneath underneath the Air Fryer may become hot
during use (Figure 2).
Immediately unplug the appliance if you see dark smoke coming out of the
Air Fryer. Wait for the smoke to stop before you remove the pan from the
appliance.
Automatic Switch-Off
Your Air Fryer has a built-in timer. The appliance will automatically shut off when the timer count
reaches zero. You can also manually switch off the Air Fryer by pressing the power button, which will
shut down the appliance after 25 seconds.
Special Cord Set Instructions
A short power supply cord is provided with your Air Fryer to reduce the risk of tripping or entanglement.
Using a longer detachable power supply cord or extension cord is not recommended for use with the Air
Fryer.
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric
shock, this plug is intended to fit into a polarized outlet in only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to
modify the plug in any way. Improper use of the plug can result in electrical shock. If the power cord is
damaged, please contact customer service.

Avalon Bay Air Fryer Product Guide
6
http://www.avalon-bay.com
Electromagnetic Fields (EMF)
The appliance complies with all scientific standards regarding Electromagnetic fields (EMF). If used
properly, there is no evidence it will not cause any harm.
Getting To Know Your Avalon Bay Air Fryer
Your Avalon Bay Air Fryer uses a unique combination of fast circulating air and an electrical heating
element that allows you to fry an assortment of delicious foods quickly, easily, and with less fat. You can
prepare a variety of foods in your Air Fryer including French fries, chicken, vegetables, and even cakes.
Any snacks that can be cooked in an oven can also be easily cooked in your Air Fryer.
Before Your First Use
1. Remove all packaging materials, stickers or labels from your Air Fryer. Be sure all the parts (see
List of Main Parts on page 4) have been included before discarding any packaging materials. You
may want to keep the box and packing materials for use at a later date.
2. Clean the basket and pan using hot water, mild soap, and a non-abrasive sponge. The basket
and pan are also dishwasher safe.
3. Wipe the inside and outside of the appliance with a cloth. Never immerse the appliance in
water; do not let water inside the Air Fryer or it may damage its electrical and heating
components.
Assembling your Air Fryer
Since your Air Fryer uses hot air, do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance or it will disrupt airflow.
1. Place your Air Fryer on a clean, flat surface. Do not place the
appliance on a NON heat-resistant surface.
2. Put the basket in the pan (Figure 3).
3. Plug the cord into a standard electrical outlet. You are now ready to
begin hot air frying.

Avalon Bay Air Fryer Product Guide
7
http://www.avalon-bay.com
Operating your Air Fryer
Once your Air Fryer is assembled properly, you are ready to
begin frying.
1. Carefully pull the pan out of the Air Fryer and place your
food in the basket (Figure 4).
2. Slide the pan back into your Air Fryer. Never use the pan
without the basket (Figure 5).
3. Do not touch the pan during or immediately after use.
The pan will be very hot. Only hold the pan by the handle.
4. Select your cooking mode for your food (Figure 6). There are seven modes:
French fries, chicken, steak, shrimp, meat, fish, and cake. To select one, press
the “M” button to cycle through each mode. Once you’ve selected the right
one, press “Start” to begin cooking.
The heating and fan lights blink while the unit is cooking
To change modes during the cooking process, press “M” to select a new
option.
5. To adjust the time manually, press the + or –buttons above or below the timer icon. Press the
buttons once to increase or decrease the time by one minute, or hold them down for rapid
adjustment. See Settings to determine the appropriate cooking time.
During cooking, the time will count down to zero from your pre-set cooking time.
6. To adjust the temperature manually, press the + or –buttons above or below the temperature
icon on the control panel. Press the buttons once to increase or decrease the temperature by
5°F, or hold them down for rapid adjustment. Once the appropriate temperature has been
selected (see Settings), press “Start.”
During the hot air frying process, the heat indicator light will occasionally turn off and
on. This lets you know when the heating element has been switched on or off to
maintain the cooking temperature.

Avalon Bay Air Fryer Product Guide
8
http://www.avalon-bay.com
Any excess oil from the food will be collected in the bottom of the
pan.
7. Some foods require you to shake the pan halfway through cooking (Figure 8).
Pull the pan out of the appliance by the handle and shake it. Then slide the
pan back into your Air Fryer (Figure 7).
Do not press the button on the handle during shaking (Figure 8).
To reduce weight while shaking, you can remove the basket from the pan and
shake it by itself. To do so, place the pan on a heat-resistant surface, such as a
trivet, and press the release button on the handle (Figure 9).
As a reminder, set the set the timer for half the cooking time. When the timer
bell rings, shake the food. Don’t forget to re-set the timer for the remaining
cook time once you’ve put the basket back in the Air Fryer.
8. When the timer bell chimes 5 times, the Air Fryer is done cooking. Pull out the
pan and place it on a heat-resistant surface. The fan will shut off
automatically 20 seconds after the timer reaches zero.
9. Check your food to see if it is ready. If not, slide the pan back into the Air
Fryer and set the timer for a few extra minutes.
10. To remove small foods (e.g. fries), press the basket release button and lift the
basket out of the pan (Figure 10).
Note: Don’t turn the pan over, otherwise the oil in the bottom of the pan will
drip into your food.
The pan and the food will be hot after cooking. Depending on the type of food you were frying,
there may be some steam coming off the pan as well.
11. Empty the basket into a bowl or plate (Figure 11). Use tongs to remove large
or fragile food from the basket. Once the basket is empty, the Air Fryer is
ready to cook again.
Once you’re done cooking, clean the Air Fryer thoroughly, so it will be ready
for the next time you need to use it.
Cooking Tips
You can use your Avalon Bay Air Fryer to cook many of the foods you love. This includes any meat you
usually broil, grill, or bake (like chicken or beef). You can also cook most frozen foods in your Air Fryer
too (and you don’t need to defrost them first).

Avalon Bay Air Fryer Product Guide
9
http://www.avalon-bay.com
Keep these tips in mind when cooking:
Smaller items usually require slightly shorter cooking times than larger items (e.g., smaller fries
will cook faster than larger fries).
Shaking smaller items halfway through cooking enhances the end result and can help prevent
unevenly fried food. Because the Rapid Air technology reheats the air inside the appliance
instantly, pulling the pan briefly out of the Air Fryer while it is cooking barely disturbs the
process.
A larger amount of food only requires a slightly longer cooking time, a smaller amount of food
only requires a slightly shorter cooking time.
Use pre-made dough to prepare filled snacks quickly and easily. Pre-made dough also requires a
shorter preparation time than homemade dough. We suggest placing a baking tin or oven dish
right in your fryer basket if to fry fragile food or filled food.
If you want crispy potatoes, cover them with a small amount of oil and cook them for a few
extra minutes.
Preheating Your Air Fryer
You can preheat your Air Fryer without any food inside.
1. Set the air fryer to the required cooking temperature, set the timer for three minutes, and then
press “Start.”
2. Once the timer goes off, fill your Air Fryer basket with food.
3. Set the timer to the required preparation time and press “Start.”
Reheating food
You can also use your Air Fryer to reheat food. Just set the temperature to 300°F and allow up to 10
minutes for your food to reheat.
Baking a Cake?
Baking a cake in your Air Fryer is easy. Just place a cake pan or oven dish directly in your Air Fryer
basket. See Settings for more information.
Foods NOT to cook in your Air Fryer
Do not prepare extremely greasy food such as sausages or bacon in your Air Fryer. Also avoid vegetables
that you usually cook or steam, such as carrots, broccoli and beans.

Avalon Bay Air Fryer Product Guide
10
http://www.avalon-bay.com
Settings
Use the frying times in this chart as a guide. You may need to adjust these times to suit different
quantities or thickness of food, and to suit your own taste.
Min-max
amount
(ounces)
Time
(min)
Temp (F)
Shake
Extra information
Potatoes & Fries
Thin frozen fries
10-25
9-16
400
Shake
Thick frozen fries
10-25
11-20
400
Shake
Home-made fries
(thin sticks)
10-30
16-10
400
Shake
Add ½ tbsp. of oil
Home-made potato
wedges
10-30
18-22
370
Shake
Add ½ tbsp. of oil
Home-made potato
cubes
10-25
12-18
370
Shake
Add ½ tbsp. of oil
Rosti
9
15-18
400
Shake
Potato gratin
17
15-18
400
Shake
Meat & Poultry
Steak
3.5-17
8-12
370
Pork chops
3.5-17
10-14
370
Hamburger
3.5-17
7-14
370
Sausage roll
3.5-17
13-15
400
Drumsticks
3.5-17
18-22
370
Chicken breast
3.5-17
10-15
370
Snacks
Spring rolls
3.5-14
8-10
400
Shake
Use oven-ready
Frozen chicken nuggets
3.5-17
6-10
400
Shake
Use oven-ready
Frozen fish fingers
3.5-14
6-10
400
Use oven-ready
Frozen bread crumbled
cheese snacks
3.5-14
8-10
370
Use oven-ready
Stuffed vegetables
3.5-14
10
330
Baking
Cake
10.5
20-25
330
Use cake pan
Quiche
14
20-22
370
Use cake pan/
oven dish
Muffins
10.5
15-18
400
Sweet snacks
14
20
330
Use cake pan/
oven dish

Avalon Bay Air Fryer Product Guide
11
http://www.avalon-bay.com
Caring For Your Air Fryer
Cleaning and Storage
You should thoroughly clean your Air Fryer after every use.
To preserve the non-stick coating, do not use metal kitchen utensils or abrasive cleaning
materials to clean the pan, basket, or the inside of the Air Fryer.
1. Before cleaning, unplug your Air Fryer and wait for it to cool down (about 30 minutes).
Removing the pan will help cool down your Air Fryer a little faster.
2. Wipe the outside of your Air Fryer with a damp cloth. Never use an abrasive cleaner or harsh
pad.
3. Clean the pan and basket using hot water, mild soap, and a non-abrasive sponge (the pan and
basket are also dishwasher-safe). If necessary, use a degreasing liquid to remove any remaining
dirt.
NOTE: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water
and a mild liquid soap. Put the basket in the pan and soak for about 10 minutes.
4. Clean the inside of the appliance using hot water and a non-abrasive sponge.
5. Clean the heating element with a cleaning brush to remove any food residue.
6. Push the cord into the cord storage compartment. Fix the cord by inserting it into the cord fixing
slot.
WARNING: Never immerse the base of the Air Fryer in water or other
liquid or it may damage the multi electrical and heating components. TO
prevent electric shocks or short-circuits, do not let any liquid enter the
Air Fryer.
Environmental Concerns
Do not throw your Air Fry away with the normal household waste when it is worn
out. Dispose of it at an official collection point for recycling. By doing this, you
help protect the environment (see Figure 12).

Avalon Bay Air Fryer Product Guide
12
http://www.avalon-bay.com
Troubleshooting
My Air fryer doesn’t turn on
Problem
Possible cause
Solution
Fryer does not work
Air Fryer is not plugged in.
Put the cord into a standard electrical
outlet.
The timer has not been set
Set the timer to the required time and
press “Start.”
The pan doesn’t slide into my Air fryer
Problem
Possible cause
Solution
Pan does not slide into
the appliance properly
There is too much food in the
basket.
Do not fill the basket beyond the MAX
indicator.
The basket was not placed in
the pan correctly.
Push the basket down into the pan
until it clicks.
White smoke is coming out of my Air Fryer
Problem
Possible cause
Solution
White smoke comes
out of the appliance
The food being cooked is too
greasy.
When frying greasy food, a large
amount of oil will leak into the pan.
The oil produces white smoke & the
pan may heat up more than usual. This
will not affect the appliance or the end
result.
The pan contains greasy
residue from a previous use.
White smoke is caused by grease
heating up in the pan. Make sure you
clean the pan properly after each use.
My food isn’t cooking correctly
Problem
Possible cause
Solution
Food is undercooked
There is too much food in the
basket.
Put smaller batches of food in the
basket. Smaller batches fry more
evenly.
The cooking temperature too
low.
Set the temperature to the required
temperature setting.
Food is fried unevenly
Certain types of food require
shaking halfway through the
preparation time.
Food that lies on top of or across each
other (e.g., fries) need to be shaken
halfway through the preparation time.
See Settings for preparation
information.

Avalon Bay Air Fryer Product Guide
13
http://www.avalon-bay.com
Problem
Possible cause
Solution
Fried snacks are not
crispy
You used a type of snack meant
to be prepared in a traditional
deep fryer.
Use oven snacks or lightly brush some
oil onto the snacks for a crispier result.
Fresh fries are fried
unevenly
You did not use the right type
of potato.
Use fresh potatoes and make sure that
they stay firm during frying.
You did not rinse the potato
sticks properly before frying
them.
Rinse the potato sticks again to remove
starch from the outside of the sticks.
Fresh fries are not
crispy
The crispiness of the fries
depends on the amount of oil
and water in the fries.
Make sure you dry the potato sticks
properly before you add the oil.
Cut the potato sticks smaller.
Add slightly more oil.

Avalon Bay Air Fryer Product Guide
14
http://www.avalon-bay.com
Limited manufacturer’s warranty
This appliance is covered by a limited manufacturer’s warranty. For one year from the original date of
purchase, the manufacturer will repair or replace any parts of this appliance that prove to be defective
in materials and workmanship, provided the appliance has been used under normal operating
conditions as intended by the manufacturer.
Warranty Terms
During the first year, any components of this appliance found to be defective due to materials or
workmanship will be repaired or replaced, at the manufacturer’s discretion, and at no charge to the
original purchaser. The purchaser will be responsible for any removal or transportation costs.
Exclusions
The warranty will not apply if damage is caused by any of the following:
Power failure
Damage in transit or when moving the appliance
Improper power supply such as low voltage, defective household wiring, or inadequate fuses
Accident, alteration, misuse, or abuse of the appliance such as using non-approved accessories,
inadequate air circulation in the room or abnormal operating conditions (extreme
temperatures)
Use in commercial or industrial applications
Fire, water damage, theft, war, riot, hostility, or acts of God such as hurricanes, floods, etc.
Use of force or damage caused by external influences
Partially or completely dismantled appliances
Obtaining service
When making a warranty claim, please have the original bill of purchase with purchase date available.
Once confirmed that your appliance is eligible for warranty service, all repairs will be performed by an
Avalon Bay authorized repair facility. The purchaser will be responsible for any removal or
transportation costs. Replacement parts and/or units will be new, re-manufactured, or refurbished and
are subject to the manufacturer’s discretion. Do not use an unauthorized person to replace or fix a
damaged main cord.
For technical support and warranty service, please email [e-mail].
