Avalon Bay AB-Airfryer230B User manual

http://www.avalon-bay.com Customer Care Number: 1-844-528-2566
Air Fryer Product Guide (AB-Airfryer230B)

Avalon Bay Air Fryer Product Guide
2
http://www.avalon-bay.com
Introduction
This Air Fryer is used for cooking food, such as meat, fish, side dishes, and vegetables. This Air Fryer is
not designed for commercial use or operation in a company. This Air Fryer may only be used for private
purposes, as any other use is not as intended. Furthermore, the Air Fryer may not be used outdoors, or
in tropical climates. This Air Fryer meets all relevant norms and standards in relation to CE conformity.
In the event of any modification to the Air Fryer that was not approved by the manufacturer,
compliance with these standards is no longer guaranteed. The manufacturer does not accept any
liability for any resulting damage or faults in such cases.
Please observe the regulations and laws in the country of use.
Before using your Air Fryer, please read this manual carefully. Incorrect
operation can result in serious damage or injury.
Need to Contact Us?
WEBSITE:
http://www.avalon-bay.com
SUPPORT EMAIL ADDRESS:
[email protected]
TELEPHONE NUMBER:
1-844-528-2566
Thank You for Choosing the Avalon Bay Air Fryer
Please read this manual thoroughly and follow all instructions and safety guidelines. With proper care
and maintenance, this appliance will provide you with many years of trouble-free use.
For future reference, we recommend you attach a copy of your sales receipt below and record the
following information, located on the manufacturer’s nameplate on the rear of the unit. You will need
this information if it becomes necessary to contact the manufacturer for service inquiries.
Date of Purchase:
Serial Number:
Model Number:

Avalon Bay Air Fryer Product Guide
3
http://www.avalon-bay.com
Contents
Introduction .................................................................................................................................................. 2
Need to Contact Us? ........................................................................................................................ 2
General Description ...................................................................................................................................... 4
Important Safety Precautions ....................................................................................................................... 5
Getting to Know Your Avalon Bay Air Fryer.................................................................................................. 7
Prior to Use ...................................................................................................................................... 7
First Use ........................................................................................................................................... 7
Using the Appliance ......................................................................................................................... 7
Settings ....................................................................................................................................................... 10
Automatic Programming................................................................................................................ 10
Cooking Tips................................................................................................................................... 10
Caring For Your Air Fryer............................................................................................................................. 13
Maintenance .................................................................................................................................. 13
Cleaning ......................................................................................................................................... 13
Storage........................................................................................................................................... 14
Environmental and Disposal Information...................................................................................... 14
Troubleshooting.......................................................................................................................................... 15
Limited Manufacturer’s Warranty .............................................................................................................. 17
Warranty Terms ............................................................................................................................. 17
Product Specifications
MODEL:
AB-Airfryer230B
POWER SUPPLY:
120v ~60hZ
POWER CONSUMPTION:
1400W
TEMPERATURE RANGE:
160oto 400oF (+/- 15oF)
TIMER FUNCTION:
Up to 60 minutes
BASKET VOLUME:
Up to 3.7 quarts
cETL Certified:
Yes
Non-Stick:
Yes
Dishwasher-Safe:
Yes

Avalon Bay Air Fryer Product Guide
4
http://www.avalon-bay.com
General Description
Supplied Items
•AB-Airfryer230B
•These operating instructions, which have a fold-out cover. The Air Fryer is illustrated with
numbers below. The numbers indicate the following:
1. Carrying handle
2. Display (including touch operation)
3. Basket
4 Pan
5. Release button (including cover)
6. Handle
7. Ventilation slots (bottom)
8. Ventilation slots (rear)
Display
9. Temperature
10. Automatic programs
11. “Increase temperature”
12 “Reduce temperature”
13. “On/standby”
14. Fan
15. Heating
16. “Start/pause”
17. Timer
18. “Program selection”
19. “Reduce minutes”
20. “Increase minutes”

Avalon Bay Air Fryer Product Guide
5
http://www.avalon-bay.com
Important Safety Precautions
Before using the Air Fryer for the first time, read the following instructions and pay attention to all
warnings, even if you are familiar with handling electronic devices. Store these operating instructions in
a safe place for future reference. If you sell the Air Fryer, or pass it on, always include these instructions.
They are an integral part of the product.
Symbols Used and Their Meaning
WARNING! This symbol indicates important information for safe
operation of the Air Fryer and the safety of the user.
DANGER! This symbol warns about injuries or burns associated with hot
surfaces of the Air Fryer.
This symbol indicates other important information on the topic.
Warning
•The Air Fryer is not intended to be operated with an external time switch, or a separate remote
control system. Never leave the Air Fryer unattended when it is switched on. It poses a fire
hazard!
•This Air Fryer can be used by children ages eight and older, and by persons with reduced
physical, sensory or mental abilities, or lack of experience and knowledge, if they are supervised
or have been instructed on the safe use of the device and understand the resulting risks.
Children must not play with the Air Fryer. Cleaning and user maintenance must not be carried
out by children without supervision. Always keep plastic packaging away from children. It poses
a suffocation risk.
•If smoke is produced, or there are any unusual sounds or smells, switch off the Air Fryer
immediately and remove the main plug from the socket. In these cases, the Air Fryer should not
be used until it has been inspected by authorized service personnel. Never inhale smoke from a
potential device fire. If you have inhaled smoke, consult a doctor. The inhalation of smoke can
be harmful.
•Never touch the main cable and the Air Fryer with wet hands because there is a risk of an
electric shock!
•The Air Fryer must not be covered, to avoid overheating. Covering it poses a fire hazard!
•Always place the Air Fryer on a flat, heat-resistant surface and not in the vicinity of heat sources
and flammable materials, liquids, or gases. Leave at least 19.7 inches clearance all around the

Avalon Bay Air Fryer Product Guide
6
http://www.avalon-bay.com
Air Fryer to prevent contact with flammable and combustible materials, because there is a risk
of fire!
•The Air Fryer must not be damaged, in order to prevent hazards.
•Ensure that no fire sources (i.e., burning candles) are placed on or near the Air Fryer. It poses a
fire hazard!
•Do not leave the Air Fryer unattended when it is operating. Always switch off the Air Fryer
when it is not in use and remove the main plug from the socket. Put away the Air Fryer only
when it has completely cooled down. It poses a fire hazard!
•Remove the main plug from the socket to disconnect the Air Fryer completely from the power
supply.
•The Air Fryer must never be exposed to any direct heat sources (i.e., heaters), or direct sunlight,
or bright artificial light. Also, avoid contact with dripping water and splashes and corrosive
liquids. Do not use their Air Fryer near water. In particular, the Air Fryer should never be
submerged in liquid. Do not place any items filled with liquid (i.e., vases or drinks) on the Air
Fryer. Also, ensure that the Air Fryer is never subjected to excessive shocks and vibrations.
Furthermore, no foreign objects may penetrate the device, otherwise the Air Fryer could be
damaged.
CAUTION: FIRE HAZARD! Never us the Air Fryer in the vicinity of
flammable materials, such as curtains, drapes, etc.
Main Cable
•Always handle the main cable by the main plug and do not pull on the cable itself.
•Do not place the Air Fryer, furniture, or any other heavy objects on the main cable and ensure
that it is not kinked.
•Never tie a knot in the main cable and do not tie cables together. Ensure that the main cable is
placed so that no one can tip over it and it does not cause an obstruction.
•Make sure that the main cable does not touch any hot surfaces of the Air Fryer.
•Do not use adapter plugs or extension cables that do not comply with applicable safety
standards, and do not make any alterations to the main cable! If the main cable is damaged, it
must be replaced by the manufacturer, or its customer service representative, or a similarly
qualified person to prevent any safety hazards.

Avalon Bay Air Fryer Product Guide
7
http://www.avalon-bay.com
Getting to Know Your Avalon Bay Air Fryer
Prior to Use
Take the Air Fryer out of the packaging and remove the packaging material completely. Check the Air
Fryer for signs of damage. The Air Fryer must not be used if it is damaged. Prior to its initial use, clean
the Air Fryer, as described in the section “CLEANING.”
First Use
Place the Air Fryer on a flat, heat-resistant surface. If the surface is
sensitive, place a heat-resistant board under the Air Fryer.
There is a risk of burns! The temperature of the accessible surfaces may
be very high when the device is operating. Hot steam continues to
escape from the ventilation slots during operation. Hot steam may also
escape when you open the air fryer. To remove the food, just touch the
handle and do not touch the pan, basket, or the inside of the Air Fryer.
The accessible surfaces of the Air Fryer can become very hot. Use
potholders or oven gloves to prevent burns. There is a risk of injury.
The food to be fried may be placed only in the basket. The basket may
be filled up the “MAX” marking at most.
CAUTION: FIRE HAZARD! The pan and the basket must never be filled
with oil.
Using the Appliance
To cook food in the Air Fryer, proceed as follows:
•Remove the pan and the basket by lifting them from the Air Fryer by the handle.
•Place the food in the basket.
•Insert the pan and basket into the Air Fryer.
•Insert the main plug into a socket that is always easily accessible. A beep sounds twice.
•Press “OVEN/STANDBY” to switch on the Air Fryer. Each touch operation is confirmed by a
beep.

Avalon Bay Air Fryer Product Guide
8
http://www.avalon-bay.com
•The temperature is at 360oF. Set the desired temperature in steps of 5oF by pressing “INCREASE
TEMPERATURE”, or “REDUCE TEMPERATURE”. To start the progress of numbers, you can keep
the button “INCREASE TEMPERATURE”, “REDUCED TEMPERATURE”pressed.
•The timer is set for fifteen minutes. Set the desired time by pressing “REDUCE MINUTES” or
“INCREASE MINUTES”. To start the quick progress of numbers, you can keep the button
“REDUCE MINUTES” or “INCREASE MINUTES” pressed.
•Press “START/PAUSE” to start the heating process. The timer indicates the remaining minutes.
The symbols fan and heating are displayed in animated form in operating mode. If the set
temperature has been reached, the heating symbol lights up continuously. You can pause the
heating process by pressing “START/PAUSE” and restart it by pressing the button again.
•The Air Fryer switches off automatically upon expiry of the time indicated by the timer and a
beep sounds several times.
•Remove your food by lifting up the pan by the handle.
There is a risk of burns! Do not touch the pan, basket, or the inside of
the Air Fryer directly.
•Place the pan on a flat, heat-resistant surface.
•Slide the cover to one side, and then press the “RELEASE” button to detach the basket from the
pan. Now place the food in a bowl or on a plate.
•The Air Fryer switches automatically to standby mode after a short time. You can also set the
Air Fryer to standby mode by pressing “ON/STANDBY”.
•Clean the Air Fryer as described in section “CLEANING”.
Some food should be shaken halfway through the cooking time to ensure that it is
cooked evenly. To do so, lift the pan and basket by the handle from the Air Fryer and
shake the food. Re-insert the pan and basket into the Air Fryer. The Air Fryer switches
itself off automatically when you remove the pan and basket. Once the pan and basket
are correctly re-inserted, the Air Fryer switches itself on again automatically until the
timer expires.
If you are cooking food that should be shaken halfway through the cooking time, you
can also set the timer to half the cooking time. Thus, a beep sounds when you need to
shake the food. After shaking the food, set the timer to the remaining cooking time to
complete the full cooking time.
You can also preheat the Air Fryer without food. If the food is not fully cooked after the
specified cooking time, re-insert the pan and basket correctly into the Air Fryer. Set the
timer to a few extra minutes.
Place the food in a bowl, or on a plate, if you have already detached the pan from the
basket. Otherwise, the excess oil that has collected in the pan will be poured over the

Avalon Bay Air Fryer Product Guide
9
http://www.avalon-bay.com
food.
You can also keep your ingredients warm by setting a low temperature (i.e., 180oF).

Avalon Bay Air Fryer Product Guide
10
http://www.avalon-bay.com
Settings
Automatic Programming
You can also use the Air Fryer with an automatic program. The temperature and the timer are already
pre-programmed in the automatic programs. Proceed as follows to start an automatic program:
•Press “ON/STANDBY” to switch on the Air Fryer.
•By repeatedly pressing “PROGRAM SELECTION”, you can go from one automatic program to
another. The following automatic program can be selected:
•Press “START/PAUSE” to start the heating process with the selected automatic program. The
timer indicates the remaining minutes. The symbols fan and heating are displayed in animated
form in operating mode. You can pause the heating process by pressing “START/PAUSE” and
restart it by pressing the button again.
•The Air Fryer switches off automatically upon completion of the automatic program and a beep
sounds.
Cooking Tips
•Do not overfill the basket with food, for better cooking results. The basket may be filled up to
the “MAX” marking at most.
•To avoid an excessively long cooking time, your food should not be too thick.
