Avalue Technology ECM-TGU-B1 User manual

Part No. E2047395404R
ECM-TGU-B1
11th Gen Intel® Tiger Lake U 3.5”Micro Module
User’s Manual
1st Ed –26 December 2022

ECM-TGU-B1 User’s Manual
2 ECM-TGU-B1 User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2022 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

User’s Manual
ECM-TGU-B1 User’s Manual
3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose
failure to perform can be reasonably expected to cause the failure of the life
support device or system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

ECM-TGU-B1 User’s Manual
4 ECM-TGU-B1 User’s Manual
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example,
CPU type and speed, Avalue’s products model name, hardware & BIOS
revision number, other hardware and software used, etc.) Note anything
abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material
authorization) number from your dealer. This allows us to process your good
return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the
purchase date is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it
prepaid to your dealer.

User’s Manual
ECM-TGU-B1 User’s Manual
5
Content
1. Getting Started............................................................................................................8
1.1 Safety Precautions....................................................................................................8
1.2 Packing List...............................................................................................................8
1.3 Document Amendment History .................................................................................9
1.4 Manual Objectives...................................................................................................10
1.5 System Specifications.............................................................................................11
1.6 Architecture Overview—Block Diagram..................................................................15
2. Hardware Configuration...........................................................................................16
2.1 Product Overview....................................................................................................17
2.2 Jumper and Connector List.....................................................................................18
2.3 Setting Jumpers & Connectors ...............................................................................20
2.3.1 Serial port 1/2 pin9 signal select (JRI1/2) ...................................................................................... 20
2.3.2 Clear CMOS (JRTC1) .................................................................................................................... 20
2.3.3 AT/ATX Input power select (JAT1)................................................................................................. 21
2.3.4 LCD inverter connector (JBKL1) .................................................................................................... 21
2.3.5 Serial port 1 connector (JCOM1) ................................................................................................... 22
2.3.6 Serial port 2 connector (JCOM2) ................................................................................................... 22
2.3.7 Serial port 3-6 connector (JCOM3_6) ............................................................................................ 23
2.3.8 CPU fan connector (JCPU_FAN1)................................................................................................. 24
2.3.9 General purpose I/O connector (JDIO1)........................................................................................ 24
2.3.10 SATA Power connector (JSATA_PWR1) .................................................................................. 25
2.3.11 Power connector (PWR1).......................................................................................................... 25
2.3.12 LVDS connector (JLVDS1)........................................................................................................ 26
2.3.13 USB2.0 connector (JUSB56)..................................................................................................... 27
2.3.14 USB2.0 connector (JUSB78)..................................................................................................... 27
2.3.15 Battery connector (JBAT1)......................................................................................................... 28
2.3.16 LPC connector (JLPC1)............................................................................................................. 28
2.3.17 Front Panel connector (JFP1).................................................................................................... 29
2.3.18 PC Buzzer connector (JBZ1)..................................................................................................... 29
2.3.19 AMP connector (JAMP1) ........................................................................................................... 30
2.3.20 BIOS SPI connector (JBIOS_EC1)............................................................................................ 30
2.3.21 Audio connector (JAUDIO1) ...................................................................................................... 31
2.3.21.1 Signal Description –Audio connector (JAUDIO1)................................................................. 31
2.3.22 SIM card slot (J_N_SIM1).......................................................................................................... 32
2.3.23 EDP connector (EDP1).............................................................................................................. 33

ECM-TGU-B1 User’s Manual
6 ECM-TGU-B1 User’s Manual
3.BIOS Setup....................................................................................................................34
3.1 Introduction .............................................................................................................35
3.2 Starting Setup .........................................................................................................35
3.3 Using Setup ............................................................................................................36
3.4 Getting Help............................................................................................................37
3.5 In Case of Problems................................................................................................37
3.6 BIOS setup..............................................................................................................38
3.6.1 Main Menu...................................................................................................................................... 38
3.6.1.1 System Language.................................................................................................................. 39
3.6.1.2 System Date.......................................................................................................................... 39
3.6.1.3 System Time.......................................................................................................................... 39
3.6.2 Advanced Menu ............................................................................................................................. 39
3.6.2.1 Connectivity Configuration..................................................................................................... 40
3.6.2.2 CPU Configuration................................................................................................................. 41
3.6.2.3 Power & Performance ........................................................................................................... 42
3.6.2.3.1 CPU –Power Management Control...................................................................................... 42
3.6.2.4 PCH-FW Configuration.......................................................................................................... 43
3.6.2.4.1 Firmware Update Configuration............................................................................................. 43
3.6.2.5 Trusted Computing................................................................................................................ 44
3.6.2.6 APCI Settings ........................................................................................................................ 44
3.6.2.7 Super IO Configuration.......................................................................................................... 45
3.6.2.7.1 Serial Port 1 Configuration .................................................................................................... 46
3.6.2.7.2 Serial Port 2 Configuration .................................................................................................... 46
3.6.2.7.3 Serial Port 3 Configuration .................................................................................................... 47
3.6.2.7.4 Serial Port 4 Configuration .................................................................................................... 47
3.6.2.7.5 Serial Port 5 Configuration .................................................................................................... 48
3.6.2.7.6 Serial Port 6 Configuration .................................................................................................... 48
3.6.2.8 HW Monitor............................................................................................................................ 49
3.6.2.9 S5 RTC Wake Settings.......................................................................................................... 49
3.6.2.10 Serial Port Console Redirection ............................................................................................ 50
3.6.2.10.1 Legacy Console Redirection Settings ................................................................................... 51
3.6.2.11 USB Configuration................................................................................................................. 51
3.6.2.12 Network Stack Configuration................................................................................................. 52
3.6.2.13 NVMe Configuration .............................................................................................................. 53
3.6.3 Chipset.......................................................................................................................................... 53
3.6.3.1 System Agent (SA) Configuration.......................................................................................... 54
3.6.3.1.1 Memory Configuration ........................................................................................................... 54
3.6.3.1.2 Graphics Configuration.......................................................................................................... 55
3.6.3.1.3 VMD setup menu................................................................................................................... 55
3.6.3.2 PCH-IO Configuration............................................................................................................ 56

User’s Manual
ECM-TGU-B1 User’s Manual
7
3.6.3.2.1 PCI Express Configuration .................................................................................................... 56
3.6.3.2.2 SATA And RST Configuration ............................................................................................... 62
3.6.3.2.3 HD Audio Configuration......................................................................................................... 62
3.6.3.3 Board & Panel Configuration................................................................................................. 63
3.6.3.3.1 SHOW DMI INFO .................................................................................................................. 64
3.6.4 Security......................................................................................................................................... 65
3.6.4.1 Secure Boot........................................................................................................................... 66
3.6.4.1.1 Key Management..................................................................................................................... 67
3.6.5 Boot .............................................................................................................................................. 67
3.6.6 Save and exit................................................................................................................................ 68
3.6.6.1 Save Changes and Reset...................................................................................................... 69
3.6.6.2 Discard Changes and Reset.................................................................................................. 69
3.6.6.3 Restore Defaults.................................................................................................................... 69
3.6.6.4 Launch EFI Shell from filesystem device .............................................................................. 69
4. Drivers Installation.......................................................................................................70
4.1 Install Chipset Driver...............................................................................................71
4.2 Install VGA Driver....................................................................................................72
4.3 Install ME Driver......................................................................................................73
4.4 Install LAN Driver....................................................................................................74
4.5 Install Audio Driver..................................................................................................75
5. Mechanical Drawing ....................................................................................................76

ECM-TGU-B1 User’s Manual
8 ECM-TGU-B1 User’s Manual
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x 3.5” ECM-TGU-B1 Micro Module
1 x Serial ATA cable (7-pin, standard) 1 x Wire SATA power cable
(15-pin, 4P/2.0mm) 1 x Flat Cable 9P(M)-PHD (10P/2.0mm)
1 x CPU Heatsink set
1 x M.2 Module bracket set

User’s Manual
ECM-TGU-B1 User’s Manual
9
1.3 Document Amendment History
Revision
Date
By
Comment
1st
December 2022
Avalue
Initial Release

ECM-TGU-B1 User’s Manual
10 ECM-TGU-B1 User’s Manual
1.4 Manual Objectives
This manual describes in details Avalue Technology ECM-TGU-B1 Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to set up
ECM-TGU-B1 or change the standard configurations. Whilst all the necessary information
is available in this manual we would recommend that unless you are confident, you contact
your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors regarding this manual and want to inform us
of these, please contact our Customer Service department with the relevant details.

User’s Manual
ECM-TGU-B1 User’s Manual
11
1.5 System Specifications
System
CPU
Onboard Tiger Lake U Gen 11th Intel® Core™ SoC i7/i5/i3 & Celeron®BGA
Processor
Intel® Core™ i7-1185G7E, i7-1185GRE (up to 4.4GHz, quad-core, 12M Cache,
TDP: 28/15/12W)*
Intel® Core™ i5-1145G7E, i5-1145GRE (up to 4.1GHz, quad-core, 8M Cache,
TDP: 28/15/12W)*
Intel® Core™ i3-1115G4E, i3-1115GRE (up to 3.9GHz, dual-core, 6M Cache, TDP:
28/15/12W)*
Intel® Celeron® 6305E (up to 1.8GHz, dual-core, 4M Cache, TDP: 15W)
BIOS
AMI uEFI BIOS, 256Mbit SPI Flash ROM
I/O Chip
iTE IT8528E
System Memory
One 260-pin DDR4 3200MHz SO-DIMM socket, supports up to 32GB Max (non
ECC only.)
Watchdog Timer
H/W Reset, 1sec. –65535sec./min.1sec. or 1min. step
H/W Status
Monitor
CPU temperature monitoring
Voltages monitoring
CPU fan speed control
TPM
Onboard NuvoTon NPCT754AADYX support TPM 2.0
iAMT
Core i SKU CPU support iAMT
Celeron SKU CPU no support iAMT
Expansion Slot
M.2
1 x M.2 Key M support 2260/2242 (with 1 x PCI-e Gen4 x4 signal), standard
package with 60 to 42 bracket + screw set
1 x M.2 Key B 3042/2242 (with PCIe x1, SATA and USB2.0 signal, with 1 x SIM
card slot) standard package with 52 to 42 bracket + screw set. Support 4G, no 5G
(no USB3 signal).
1 x M.2 Key E 2230 support WiFi module (1 x PCI-e x 1 & USB 2.0 Signal)
Storage
M.2
1 x M.2 Key M support 2260/2242 (with 1 x PCI-e Gen4 x4 signal), standard
package with 60 to 42 bracket + screw set
1 x M.2 Key B 3042/2242 (with PCIe x1, SATA and USB2.0 signal, with 1 x SIM
card slot) standard package with 52 to 42 bracket + screw set
SATA
1 x SATA III
Edge I/O
LAN
3 x Intel® I226LM/I226IT 2.5 Gigabit Ethernet(I226IT for Extend Temperature SKU)

ECM-TGU-B1 User’s Manual
12 ECM-TGU-B1 User’s Manual
USB 3.1
4 x USB 3.2 Gen 2 x1
DP
2x DP++
Audio
Support Audio Line-out & Mic-in by 2 in 1 Jack
LED Indicator
Power LED /HDD LED at IO
Onboard I/O
COM
COM 1 & COM2:
- COM 1 & COM2 support RS232/422/485 connector, with / +5V & +12V Supported
and RS422/485 by BIOS setting
- 2 x 2 x 5 pin, pitch 2.00mm connector support RS-232/422/485 connector, Pin 9
with / +5V & +12V Supported
- 2 x 2 x 3 pin, pitch 2.00mm connector, for RI/+5V/+12V Supported
COM3 to 6:
- 1 x 2 x 20 pin, pitch 2.00mm connector for COM3~6: support RS-232 connector
USB 2.0
2 x 2 x 5 pin, pitch 2.00mm connector (or pin header) for 4 USB 2.0
GPIO
1 x 2 x 6 pin, pitch 2.00mm connector for GPIO: 8 bits & +3.3S Level
SATA Power
1 x SATA Power, pitch 2.54mm connector
CPU/System
FAN
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
Buzzer
1 x Buzzer header_1 x 1 x 2pin 2.0mm Wafer connector for Buzzer
Front Panel
1 x 2 x 5 pin, pitch 2.00mm connector for front panel
RTC Battery
1 x 2 Pin Pitch 1.25mm horizontal type battery connector (CR2032X Battery)
AT/ATX Selector
1 x 1 x 3 pin pitch 2.00mm connector for AT/ATX jumper
Clear CMOS
1 x 1 x 3 pin pitch 2.00mm connector
LVDS
1 x 2 x 20 pin, pitch 1.25mm connector for LVDS
LCD Inverter
1 x 1 x 5 pin, pitch 2.00mm Wafer connector for LCD inverter backlight (5V/12V)
eDP
1 x 1 x 40 pin, pitch 0.5mm IPEX connector for eDP
LPC
1 x 2 x 5 pin, pitch 1.27mm connector for LPC debug
BIOS SPI
1 x 2 x 5 pin, pitch 1.27mm connector for BIOS SPI
Audio
1 x 2 x 6 pin, pitch 2.00mm connector
Support Audio Line-out & Mic-in & Line-in
DC-Input
Default: 1 x 2 x 2 pin, pitch 4.20mm connector for power input connector
Amp Connector
1 x 4 pin, pitch wafer 2.00mm connector for 3W x 2 Speaker
Display
Graphic Chipset
Intel® Tiger Lake UP3 SoC Processor integrated Gen12 graphics
Spec. &
Resolution
DP1+DP2 (DP1.4): Max: 7680 x 4320@60 Hz. Note: This resolution is actual test
result, Intel spec:
2 x DP++ 1.4 : 4096 x 2304@60 Hz
1 x LVDS: 1920 x 1080 Dual channel 18/24-bits LVDS (Chrontel CH7511B eDP to
LVDS)

User’s Manual
ECM-TGU-B1 User’s Manual
13
1 x eDP 4096 x 2304@60 Hz
Multiple Display
Four Display
2 x DP++, 1 x 2CH LVDS, 1 x eDP
Audio
Audio Codec
Realtek ALC888S Audio Codec (co-lay ALC897)
Amplifier
ALC105 2W4Ω per channel Amplifier
Ethernet
LAN Chip
3 x Intel® I226LM/I226IT 2.5 Gigabit Ethernet (I226IT for Extend Temperature
SKU)
LAN Spec.
3 x 10/100/1000/2.5 Base-Tx GbE compatible
Mechanical &
Environmental
Power
Requirement
DC in +12V ~ +24V
ACPI
Single power ATX Support S0,S3, S4, S5
ACPI 5.0 Compliant
Power Mode
AT / ATX mode Switchable Through Jumper, default AT
Operating Temp.
Intel® Standard Temperature CPU SKU support: 0~60°C (32~140°F) with 0.5m/s
air flow
Intel® Extend Temperature CPU SKU Support: -20~60°C (-4~140°F) with 0.5m/s
air flow
Storage Temp.
-40°C ~ +75°C
Operating
Humidity
40°C @ 95% Relative Humidity, Non-condensing
Size (L x W)
5.7" x 4" (146mm x 101mm)
(Please consult product engineers for the production feasibility if the size is larger
than 410x360mm or smaller than 80x70mm)
Weight
0.40kg
Vibration Test
Package Vibration Test
Reference IEC60068-2-64 Testing procedures
Test Fh: Vibration broadband random Test
1. PSD: 0.026G²/Hz, 2.16 Grms
2. Non-operation mode
3. Test Frequency: 5-500Hz
4. Test Axis: X,Y and Z axis
5. 30 min. per each axis
6. IEC 60068-2-64 Test:Fh
Random Vibration Operation

ECM-TGU-B1 User’s Manual
14 ECM-TGU-B1 User’s Manual
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration broadband random Test
1. PSD: 0.00454G²/Hz, 1.5 Grms
2. Operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
Random Vibration Non Operation
Reference IEC60068-2-64 Testing procedures
Test Fh : Vibration broadband random Test
1. PSD: 0.01818G²/Hz, 3.0 Grms
2. Non Operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
Drop Test
Packing Drop
Reference ISTA 2A, Method : IEC-60068-2-32 Test: Ed
Drop Test
1 One corner , three edges, six faces
2 ISTA 2A, IEC-60068-2-32 Test:Ed
OS Information
Win10 64bit, Linux
Note: Specifications are subject to change without notice.
User condition suggestion:
1. RealTek ALC888S-VD2-GR IC specification Operating Temp Range 0℃~+70℃.
2. It is required for 8K resolution by using 2 x DP simultaneously. Limitation: Black screen
will be shown if close LVDS function in BIOS when using 2 x DP, with debug card code: Ad.
User needs to connect one DP to OS, then connect the second DP.
3. When remove device M.2 KeyE (Intel® Wireless-AC 9560) from ECM-TGU-B1
motherboard, OS Device Manager will still show this on device item with exclamation mark
「! 」(Code 10). It has to power off DC-In and reboot. (With system product, please
request dedicated AE for OEM BIOS to enable, or customer can Enable from BIOS menu)
4. N_SIM1 and J_N_SIM1 can’t be using at the same time, user can choose either one.

User’s Manual
ECM-TGU-B1 User’s Manual
15
1.6 Architecture Overview—Block Diagram
The following block diagram shows the architecture and main components of ECM-TGU-B1

ECM-TGU-B1 User’s Manual
16 ECM-TGU-B1 User’s Manual
2. Hardware
Configuration

User’s Manual
ECM-TGU-B1 User’s Manual
17
2.1 Product Overview

ECM-TGU-B1 User’s Manual
18 ECM-TGU-B1 User’s Manual
2.2 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JRI1/2
Serial port 1/2 pin9 signal select
3 x 2 header, pitch 2.00mm
JAT1
AT/ATX Input power select
3 x 1 header, pitch 2.00mm
JRTC1
Clear CMOS
3 x 1 header, pitch 2.00mm
Connectors
Label
Function
Note
JBKL1
LCD inverter backlight connector
5 x 1 wafer, pitch 2.00mm
Matching Connector: JST PHR-5
JCPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54mm
JCOM1
Serial Port 1 connector
5 x 2 header, pitch 2.00mm
JCOM2
Serial Port 2 connector
5 x 2 header, pitch 2.00mm

User’s Manual
ECM-TGU-B1 User’s Manual
19
JCOM3_6
Serial Port 3-6 connector
20 x 2 header, pitch 2.00mm
JDIO1
General purpose I/O connector
6 x 2 wafer, pitch 2.00mm
NGFF_M_1
M.2 KEY-M 2260/2242 connector
NGFF_E_1
M.2 KEY-E 2230 connector
NGFF_B_1
M.2 KEY-B 3042/2242 connector
LED1
HDD/Power LED indicator
JLVDS1
LVDS connector
DIN 40-pin wafer, pitch 1.25mm
Matching Connector: Hirose
DF13-40DS-1.25C
JFP1
Front Panel connector
5 x 2 header, pitch 2.00mm
USB12/34
4 x USB3.2 connector
JUSB56
USB2.0 connector
5 x 2 header, pitch 2.00mm
JUSB78
USB2.0 connector
5 x 2 header, pitch 2.00mm
JBZ1
PC Buzzer connector
2 x 1 wafer, pitch 2.00mm
LAN1/23
RJ-45 Ethernet 1/2/3
JBAT1
Battery connector
2 x 1 wafer, pitch 1.25mm
JLPC1
LPC connector
5 x 2 header, pitch 1.27mm
PWR1
Power connector
2 x 2 wafer, pitch 4.20mm
JBIOS_EC1
BIOS SPI connector
5 x 2 header, pitch 1.27mm
JSATA_PWR1
SATA Power connector
4 x 1 wafer, pitch 2.00mm
SATA1
Serial ATA connector
DP1/2
2 x DP connector
SO_DIMM1
DDR4 SODIMM socket
AUD1
Line-out & Mic-in audio jack
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00mm
N_SIM1
SIM card slot
J_N_SIM1
SIM card slot
10 x 1 FPC, pitch 0.50 mm
JAMP1
Amp Connector
4 x 1 wafer, pitch 2.00mm
EDP1
EDP connector
40 x 1 wafer, pitch 0.50mm

ECM-TGU-B1 User’s Manual
20 ECM-TGU-B1 User’s Manual
2.3 Setting Jumpers & Connectors
2.3.1 Serial port 1/2 pin9 signal select (JRI1/2)
* Default
Ring*
+5V
+12V
2.3.2 Clear CMOS (JRTC1)
* Default
Normal*
Clear CMOS
JRI2
JRI1
