Avalue Technology EPC-BSW User manual

Part No. E2017CAH0A0R
EPC-BSW
Fanless Intel® Celeron® SoC Tiny Box PC
Quick Reference Guide
1st Ed –03 February 2016
Copyright Notice
Copyright 2016 Avalue Technology Inc., ALL RIGHTS RESERVED.

EPC-BSW
2EPC-BSW Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
EPC-BSW Quick Reference Guide
3
Content
1. Getting Started............................................................................................................4
1.1 Safety Precautions ................................................................................................4
1.2 Packing List...........................................................................................................4
1.3 System Specifications ...........................................................................................5
1.4 System Overview...................................................................................................7
1.4.1 Front View................................................................................................................................ 7
1.4.2 Rear View................................................................................................................................ 7
1.5 System Dimensions...............................................................................................9
1.5.1 Front & Top View ......................................................................................................................... 9
2. Hardware Configuration...........................................................................................10
2.1 EPC-BSW connector mapping ............................................................................11
2.1.1 Serial Port 1 connector (COM1)................................................................................................. 11
2.1.2 Serial Port 2/3/4/5 connector (COM2/3/4/5) .............................................................................. 11
2.2 AUX-032 User’s Guide ........................................................................................12
2.2.1 Jumper and Connector Layout................................................................................................... 12
2.2.2 Jumper and Connector List........................................................................................................ 12
2.2.3 Setting Jumper and Connector.................................................................................................. 13
2.3 Installing Hard Disk & Memory (EPC-BSW)........................................................14

EPC-BSW
4EPC-BSW Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x EPC-BSW Fanless Intel® Celeron® SoC Tiny Box PC
1 x DVD-ROM contains the followings:
—QRG in PDF file
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
—Chipset drivers and utilities
Other major components include the followings:
—Screw kit
—Adapter
—Power Cord
—Stand

Quick Reference Guide
EPC-BSW Quick Reference Guide
5
1.3 System Specifications
System
Mother Board
ECM-BSW
CPU
Optional : Intel® Pentium® N3700 4-Core 1.6GHz Processor (up to
2.4GHz)
Default : Intel® Celeron® N3150 4-Core 1.6GHz Processor (up to
2.08GHz)
BIOS
Insyde BIOS, 64 Mbit SPI Flash ROM
System Chipset
Braswell SoC Integrated
I/O Chipset
Nuvoton NPCE388N
System Memory
One 204-pin SODIMM Socket Up to 8GB DDR3L 1600 SDRAM
(If 1333 MHz DIMM is installed, it will run at 1066 MHz)
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec and 1sec. or 1min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage with Auto Throttling Control
Storage
Solid State Drive
1 x 2.5” Drive Bay(7mm HDD Restricted), 1 x mSATA
External I/O
COM Port
1 x RS-232/422/485(Factory option), 4 x RS-232
USB Port
6 x USB (4 x USB3.0; 2 x USB 2.0)
Video Port
1 X HDMI
Audio Port
1 x Mic-In, 1 x Line-Out, 1 x Line-In
LAN Port
2 x RJ45
Switch
1 x Power on/off membrane w/ LED
Indicator Light
1 x Power on/off LED on the rear side
1 x Storage LED on the rear side
Antenna
1 x Knockouts for antenna mounting
Expansion Slots
1 x Full-Size Mini PCI Express Mini Card with mSATA supported
1 x Half-size Mini PCIe
Display
Chipset
Braswell SoC integrated Graphics
Resolution
HDMI Mode: 1920 x 1080 @ 60Hz
Audio
HD Codec
Realtek ALC233 HD Audio Supports
Audio Interface
Mic-in, Line-in, Line-out
Ethernet
Chipset
2 x RealTek RTL8119 Gigabit Ethernet Controller

EPC-BSW
6EPC-BSW Quick Reference Guide
Ethernet Interface
10/100/1000 Base-Tx Compatible
Mechanical
Power Type
+12 ~ 26Vdc (Lockable DC Jack)
ACPI
Single Power ATX Support S0, S3, S4, S5
ACPI 5.0 Compliant
Power Mode
AT/ATX (ATX is the default setting)
Operating
Temperature
0 ~ 50°C (32 ~ 122°F) (w/CF & SSD), Ambient w/Air Flow
0 ~ 40°C (32 ~ 104°F) (w/HDD), Ambient w/Air Flow
Storage
Temperature
-40 ~ 75°C (-40 ~ 167°F)
Relative Humidity
0% ~ 90% Relative Humidity, Non-condensing
Vibration
Protection
With CF/SSD: 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis
Shock Protection
With CF/SSD: 10G, IEC 60068-2-27, Half Sine,11ms
Certification
CE, FCC Class A
Dimension (W x H x
D)
178mm x 142mm x 50mm
Weight
1.2kgs
Color
Black
Fanless
YES
Reliability
IP Rating
IP 30
Note: Specifications are subject to change without notice.

Quick Reference Guide
EPC-BSW Quick Reference Guide
7
1.4 System Overview
1.4.1 Front View
Connectors
Label
Function
Note
POWER
Power on button
COM2/3/4/5
Serial port 2/3/4/5 connector
D-sub 9-pin, male
1.4.2 Rear View
Connectors
Label
Function
Note
COM1
Serial port 1 connector
D-sub 9-pin, male
Note：COM1 support RS422/485
by BIOS setting (Factory option)
HDD
HDD indicator
PWR
System power indicator
LAN
RJ-45 Ethernet x 2
USB2.0
USB 2.0 connector x 2
LED
POWER

EPC-BSW
8EPC-BSW Quick Reference Guide
USB3.0
USB 3.0 connector x 4
HDMI
HDMI connector
DC-IN
DC Power-in connector
MIC IN
Mic-in audio jack
LINE IN
Line-in audio jack
LINE OUT
Line-out audio jack

Quick Reference Guide
EPC-BSW Quick Reference Guide
9
1.5 System Dimensions
1.5.1 Front & Top View
(Unit: mm)

EPC-BSW
10 EPC-BSW Quick Reference Guide
2.Hardware
Configuration
For advanced information, please refer to:
1- ECM-BSW User’s Manual
2- AUX-032 included in this manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
EPC-BSW Quick Reference Guide
11
2.1 EPC-BSW connector mapping
2.1.1 Serial Port 1 connector (COM1)
RS-232
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
RS-422/485(D-sub 9pin Male)
Signal
PIN
TX-
1
TX+
2
RX+
3
RX-
4
GND
5
2.1.2 Serial Port 2/3/4/5 connector (COM2/3/4/5)
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
RS-232
RS-422/485

EPC-BSW
12 EPC-BSW Quick Reference Guide
2.2 AUX-032 User’s Guide
2.2.1 Jumper and Connector Layout
2.2.2 Jumper and Connector List
Connectors
Label
Function
Note
CN1/2
USB connector
CN4
Line out connector
Phone Jack
CN5
Line in connector
Phone Jack
CN6
Mic in connector
Phone Jack
JAUDIO
Audio connector
6 x 2 header, pitch 2.0mm
JP1
2.54mm USB connector
5 x 2 header, pitch 2.54mm
JP2
2.54mm USB connector
5 x 2 header, pitch 2.54mm
JP4
2.0mm USB connector
5 x 2 header, pitch 2.0mm
JP5
2.0mm USB connector
5 x 2 header, pitch 2.0mm
JP7
TV / Audio connector
8 x 2 header, pitch 2.54mm

Quick Reference Guide
EPC-BSW Quick Reference Guide
13
2.2.3 Setting Jumper and Connector
Audio Connector (JAUDIO)
2.54mm USB Connector (JP1)
Signal
PIN
PIN
Signal
OUTR
1
2
OUTL
GND
3
4
GND
INR1
5
6
INL1
MICIN1
7
8
AREF
FRONT-JD1
9
10
LINE1-JD1
MIC1-JD1
11
12
GND
Signal
PIN
PIN
Signal
+5V
1
2
GND
D1-
3
4
GND
D1+
5
6
D2+
GND
7
8
D2-
GND
9
10
+5V
Note: Wrong USB cable configuration with your USB
devices might damage your USB devices.
2.54mm USB Connector (JP2)
TV / Audio Connector (JP7)
Signal
PIN
PIN
Signal
+5V
1
2
GND
D3-
3
4
GND
D3+
5
6
D4+
GND
7
8
D4-
GND
9
10
+5V
Signal
PIN
PIN
Signal
Mic In
1
2
Mic Bais
GND
3
4
GND
Line out L
5
6
Line out R
SPK L
7
8
SPK R
Line in L
9
10
Line in R
GND
11
12
NC
TVGND
13
14
NC
TVGND
15
16
COMP
2.0mm USB Connector (JP4)
2.0mm USB Connector (JP5)
Signal
PIN
PIN
Signal
+5V
1
2
GND
D3-
3
4
GND
D3+
5
6
D4+
GND
7
8
D4-
GND
9
10
+5V
Signal
PIN
PIN
Signal
+5V
1
2
GND
D1-
3
4
GND
D1+
5
6
D2+
GND
7
8
D2-
GND
9
10
+5V

EPC-BSW
14 EPC-BSW Quick Reference Guide
2.3 Installing Hard Disk & Memory (EPC-BSW)
Step1. For HDD installation, please remove 8 screws to detach top cover, HDD enclosure from board &
system assembly.
Step2. Fix HDD using the 4 screws in the Accessory Kit.
Step3. Properly install the memory module and press until properly seated.
Step4. Re-assemble your system back through previous steps to complete the installation.
