Avalue Technology LX800 User manual

Part No. E20173711A6R
EPC Series
VIA Eden V4/ Intel® Core™Duo/ Intel® Atom™/
AMD Geode™ LX 800 Tiny Box PC
Quick Reference Guide
7th Ed –17 March 2011
Copyright Notice
Copyright 2011 Avalue Technology Inc., ALL RIGHTS RESERVED.

EPC-Series
2 EPC Series Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
EPC Series Quick Reference Guide
3
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.
Headquarters and Branch
Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Chung Ho City, Taipei,
Taiwan
Tel:[phone]
Fax: [phone]
Information:[e-mail]
Service: [e-mail]
Avalue Technology Inc.
9 Timber Lane, Marlboro, NJ 07746-1443
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Service: [e-mail]
BCM Advanced Research
Avalue Europe
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: sales.e[email protected].tw
Service: service.[email protected].tw
Avalue China
Avalue Japan
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: sales.chi[email protected].cn
Service: [e-mail]
Avalue Technology Inc.
2F keduka-Bldg, 2-27-3 Taito,
Taito-Ku, Tokyo 110-0016 Japan
Tel: [phone]
Fax: [phone]
Information: sales.japa[email protected].tw
Service: [e-mail]

EPC-Series
4 EPC Series Quick Reference Guide
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.

Quick Reference Guide
EPC Series Quick Reference Guide
5
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x EPC-3711 VIA Eden Tiny Box PC (with ECM-3711-E10 inside) or
1 x EPC-CX700M VIA Eden Tiny Box PC (with ECM-CX700 inside)or
1 x EPC-945 Intel® Tiny Box PC (with ECM-945GME inside ) or
1x EPC-AT270 Inte® l Tiny Box PC (with ECM-945GSE inside)
1 x EPC-LX800W AMD Geode™ LX 800 Tiny Box PC (with ECM-LX800W)
1 x Quick Reference Guide
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
Other major components include the followings:
—1 x PS/2 keyboard and mouse Y cable (6-pin, Mini-DIN)
—1 x SATA cable
—1 x AC to DC adapter
—1 x Protective Cover

EPC-Series
6 EPC Series Quick Reference Guide
1.3 System Specifications
Model
EPC-3711
EPC-CX700
CPU
Onboard VIA Eden V4 1 GHz
Onboard VIA Eden V4 500 MHz
BIOS
Award 512 KB Flash BIOS
System Chipset
VIA CN700/VT8251
VIA CX700M
I/O Chipset
VIA VT1211
System Memory
One 200-pin SODIMM supports up to 1 GB DDR2 400/533 SDRAM
SSD
One CompactFlash Type I/II socket with ejector
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system and CPU temperature, voltage,
Auto throttling control when CPU overheats
Display
VIA ProSavage CN700 integrated
2D/3D graphics engine
VIA CX700M with integrated 2D and
3D Graphics engine
Audio
VIA VT1616 supports 5.1 CH Audio
Realtek ALC883 supports 5.1 CH
Audio and 7.1 CH with SPDIF
Ethernet
Dual Realtek RTL8111B 1000Base-T
Fast Ethernet controllers
Dual Realtek RTL8101L
System Indicators
2 LED indicators show the power and HDD
COM Port
1 x RS-232, 1 x RS232/422/485, Setting by BIOS
Ethernet Port
2 x RJ-45
VGA / LCD Port
1 x DB-15
Audio Port
Mic-in, Line-in, Line-out
USB Port
3 x USB 2.0
3 x USB 2.0
Mouse & KB
1 x PS/2 mini DIN
Power Input
100 ~ 240 Vac / 50 ~ 60 Hz
Power Output
+5 Vdc / 8 A (40W)
Operating Temperature
0~40°C (32~104°F)
Storage Temperature
-20 to +75°C (-4~167°F)
Relative Humidity
5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H)
7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight
2.65 lbs (1.2 Kgs)

Quick Reference Guide
EPC Series Quick Reference Guide
7
Model
EPC-945
EPC-AT270
CPU
Supports 65nm Intel® µFC-PGA
478/µFC-BGA 479 Core™Duo/Core™
Duo/Celeron® M CPU
Onboard Intel® Atom™N270 1.6GHz
CPU
BIOS
Award 4 MBit Flash BIOS
Award 8 MBit Flash BIOS
System Chipset
Intel® 945GME / ICH7-M
Intel® 945GSE/ICH7-M
I/O Chipset
Winbond W83627HF-AW
ITE 8712F
System Memory
One 200-pin SODIMM supports up to 2
GB DDR2 400/533/667 SDRAM
One 200-pin SODIMM supports up to 2
GB DDR2 400/533 SDRAM
SSD
One CompactFlash Type I/II socket
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Display
Intel® 945GME Integrated GMA 950
graphic
Intel® 945GSE Integrated
Audio
Realtek ALC883 supports 7.1-CH Audio
Realtek ALC655 supports 5.1-CH
Audio
Ethernet
Dual Realtek RTL8111C PCI-E Gigabit
Ethernet, supports wake on LAN
(RTL8111B for Rev. A1)
Dual Marvell 88E8053 Gigabit Ethternet,
supports Wake on LAN
System Indicators
2 LED indicators show the power and HDD
Drive Bay
Mounting kit for one 2.5”HDD(hidden)
Expansion Interface
-------
1 x Mini PCIe
Serial Port
1 x RS-232
1x RS-232, 1xRS232/422/485
Ethernet Port
2 x RJ-45
WiFi
Optional (USB Module)
DVI
------
1 x DVI (Optional)
VGA / LCD Port
1 x DB-15
Audio Port
Mic-in, Line-in, Line-out
USB Port
3 x USB 2.0
5 x USB 2.0
Mouse & KB
1 x PS/2 mini DIN
1 x PS/2 mini DIN (Optional)
Power Input
100 ~ 240 Vac / 50 ~ 60 Hz
Power Output
+12 V
Operating
Temperature
0~40°C (32~104°F)
Storage Temperature
-20 to +75°C (-4~167°F)
Relative Humidity
5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H)
7.0" x 5.6" x 2.0" (178 x 142 x 50 mm)
7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight
2.7 lbs (1.2 Kgs)
Mounting
VESA Compliance

EPC-Series
8 EPC Series Quick Reference Guide
Model
EPC-LX800W
CPU
Onboard AMD Geode™ LX 800 @ 500MHz CPU
BIOS
Award 4 MBit Flash BIOS
System Chipset
AMD Geode™ LX 800/ CS5536
I/O Chipset
NuvoTon W83627DHG
System Memory
One 200-pin SODIMM supports up to 1 GB DDR 333/400 SDRAM
SSD
One CompactFlash Type I/II socket
Watchdog Timer
Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Display
AMD Geode LX800 with Integrated Graphics Engine
Audio
Realtek ALC203 supports 2-CH Audio
Ethernet
Dual Realtek RTL8101L 10/100 Rthernet
System Indicators
2 LED indicators show the power and HDD
Drive Bay
Mounting kit for one 2.5” HDD(hidden)
Expansion Interface
N/A
Serial Port
2x RS-232
Ethernet Port
2 x RJ-45
WiFi
Optional (USB Module)
VGA
1 x DB-15
Audio Port
Line-out
USB Port
3 x USB 2.0
Mouse & KB
1 x PS/2 mini DIN
Power Input
100 ~ 240 Vac / 50 ~ 60 Hz
Power Output
+5V
Operating Temperature
-40 ~ 75°C (-40~167°F)
Storage Temperature
-20 to +75°C (-4~167°F)
Relative Humidity
5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H)
7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)
Weight
2.7 lbs (1.2 Kgs)
Mounting
VESA Compliance

Quick Reference Guide
EPC Series Quick Reference Guide
9
1.4 System Overview
1.4.1 Front View
Connectors
Label
Function
Note
POWER
Power on button
LED
System power indicator
USB
USB 2.0 connector
1.4.2 Rear View
EPC-3711/EPC-CX700

EPC-Series
10 EPC Series Quick Reference Guide
EPC-AT270
EPC-945
EPC-LX800W

Quick Reference Guide
EPC Series Quick Reference Guide
11
Connectors
Label
Function
Note
COM
Serial port
DB-9 male connector
CF
CF Type I/II Socket with Ejector
DC-IN
DC Power-in connector
DVI
DVI connector (EPC-AT270 only)
HDD
HDD indicator
K/B
Keyboard and PS/2 mouse connector
6-pin mini DIN
LAN1&2
2 x 10/100Base-Tx Ethernet connector
RJ-45
LINE IN
Line-in audio jack
LINE OUT
Line-out audio jack
MIC IN
Mic-in audio jack
PWR
System power indicator
RESET
Reset button
USB
2 x USB 2.0 connector
VGA
CRT connector
DB-15 female connector

EPC-Series
12 EPC Series Quick Reference Guide
1.5 System Dimensions
1.5.1 Top /Front& Rear
EPC-3711/EPC-CX700/EPC-AT270/ EPC-LX800W
EPC-945
(Unit: mm)

Quick Reference Guide
EPC Series Quick Reference Guide
13
1.5.2 Bottom
EPC-3711 / EPC-CX700/EPC-AT270/ EPC-LX800W
EPC-945
(Unit: mm)

EPC-Series
14 EPC Series Quick Reference Guide
2.Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
Please refer to ECM-3711,ECM-CX700,ECM-945GME,or ECM-945GSE or
ECM-LX800W Quick Installation Guide or User’s Manual for advanced
information.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
EPC Series Quick Reference Guide
15
2.2 Installing Hard Disk & Memory
Step 1. Unfasten 8 screws from two sides, 4
screws of COM and VGA From the
rear side as displayed above then
remove the chassis cover.
Step 4. Insert the DDR SODIMM into the
memory socket.
Step 2. Turn over the system and take off the
front/rear chassis, then unlock 4
screws of the bottom.
Step 5. Place back the bottom cover with 4
screws locked and assemble the
front/rear chassis into one piece.
Step 3. Reverse the bottom cover and fasten
3 screws with HDD as above.
Step 6. Fasten 4 screws back as the
original.

EPC-Series
16 EPC Series Quick Reference Guide
