Avalue Technology LPC-0833 User manual

Part No. E2017L833A0R
LPC-0833
8” Multi-functional Touch Panel Computer
Quick Reference Guide
1st Ed –28 December 2022
Copyright Notice
Copyright 2022 Avalue Technology Inc., ALL RIGHTS RESERVED.

LPC-0833
2 LPC-0833 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
LPC-0833 Quick Reference Guide
3
Content
1. Getting Started ........................................................................................................6
1.1 Safety Precautions....................................................................................................6
1.2 Packing List...............................................................................................................6
1.3 System Specifications...............................................................................................7
1.4 System Overview....................................................................................................10
1.4.1 Right View.............................................................................................................................. 10
1.4.2 Bottom View........................................................................................................................... 10
1.5 System Dimensions ................................................................................................11
2. Hardware Configuration .......................................................................................12
2.1 LPC-0833 connector mapping ................................................................................13
2.1.1 Serial port 1 connector (COM1)............................................................................................. 13
2.1.2 Serial port 2 connector (COM2)............................................................................................. 14
2.2 Installing Memory.....................................................................................................15
2.2 ECM-APL-B1 Overview...........................................................................................17
2.3 ECM-APL-B1 Jumper and Connector List...............................................................18
2.4 ECM-APL-B1 Jumpers & Connectors settings........................................................20
2.4.1 AT/ ATX Input power select (JAT1)....................................................................................... 20
2.4.2 Serial port 1 pin9 signal select (JRI1).................................................................................... 20
2.4.3 Clear CMOS (JBAT1)............................................................................................................ 21
2.4.4 LCD backlight brightness adjustment (JBKL_SEL1)............................................................. 21
2.4.5LCD Inverter connector (JBKL1) ........................................................................................... 22
2.4.6 CPU fan connector (CPU_FAN1).......................................................................................... 22
2.4.7 Serial port 2/3/4/5/6 connector (JCOM2/3/4/5/6)................................................................... 23
2.4.8 General purpose I/O connector (JDIO1) ............................................................................... 23
2.4.9 SATA Power header (SATA_PWR1)..................................................................................... 24
2.4.10 Low pin count interface (JLPC1) ........................................................................................... 24
2.4.11 LVDS connector (JLVDS1).................................................................................................... 25
2.4.12 On-board header for USB2.0 (JUSB1).................................................................................. 26
2.4.13 EC Debug connector (JEC_ROM1)....................................................................................... 26
2.4.14 Serial port 1 in RS-422/485 mode (J422_485)...................................................................... 27
2.4.15 Miscellaneous setting connector (JFP1) ............................................................................... 27
2.4.16 BIOS SPI header (BIOS_SPI1)............................................................................................. 28
2.4.17 PC Buzzer header (JBZ1) ..................................................................................................... 28
2.4.18 Battery connector (BT1) ........................................................................................................ 29

LPC-0833
4 LPC-0833 Quick Reference Guide
2.4.19 Audio connector (JAUDIO1).................................................................................................. 29
2.4.19.1 Signal Description –Audio connector (JAUDIO1) ............................................................ 29
3.BIOS Setup....................................................................................................................30
3.1 Introduction .............................................................................................................31
3.2 Starting Setup .........................................................................................................31
3.3 Using Setup ............................................................................................................32
3.4 Getting Help............................................................................................................33
3.5 In Case of Problems................................................................................................33
3.6 BIOS setup..............................................................................................................34
3.6.1 Main Menu............................................................................................................................. 34
3.6.1.1 System Language ............................................................................................................. 35
3.6.1.2 System Date...................................................................................................................... 35
3.6.1.3 System Time ..................................................................................................................... 35
3.6.2 Advanced Menu..................................................................................................................... 35
3.6.2.1 Trusted Computing............................................................................................................ 36
3.6.2.2 APCI Settings.................................................................................................................... 36
3.6.2.3 IT8528 Super IO Configuration......................................................................................... 38
3.6.2.3.1 Serial Port 1 Configuration................................................................................................ 39
3.6.2.3.2 Serial Port 2 Configuration................................................................................................ 39
3.6.2.3.3 Serial Port 3 Configuration................................................................................................ 40
3.6.2.3.4 Serial Port 4 Configuration................................................................................................ 40
3.6.2.3.5 Serial Port 5 Configuration................................................................................................ 41
3.6.2.3.6 Serial Port 6 Configuration................................................................................................ 41
3.6.2.4 H/W Monitor ...................................................................................................................... 42
3.6.2.5 S5 RTC Wake Settings ..................................................................................................... 42
3.6.2.6 Serial Port Console Redirection........................................................................................ 43
3.6.2.6.1 Legacy Console Redirection Settings............................................................................... 43
3.6.2.7 CPU Configuration ............................................................................................................ 44
3.6.2.7.1 Socket 0 CPU Information................................................................................................. 45
3.6.2.7.2 CPU Power Management Configuration........................................................................... 46
3.6.2.8 Network Stack Configuration............................................................................................. 47
3.6.2.9 CSM Configuration............................................................................................................ 47
3.6.2.10 NVMe Configuration.......................................................................................................... 48
3.6.2.11 USB Configuration............................................................................................................. 48
3.6.2.12 Security Configuration....................................................................................................... 49
3.6.3 Chipset................................................................................................................................. 50
3.6.3.1 North Bridge ...................................................................................................................... 50
3.6.3.2 South Bridge...................................................................................................................... 51
3.6.3.3 Uncore Configuration ........................................................................................................ 52
3.6.3.4 South Cluster Configuration.............................................................................................. 53

Quick Reference Guide
LPC-0833 Quick Reference Guide
5
3.6.3.4.1 HD-Audio Configuration....................................................................................................... 54
3.6.3.4.2 PCI Express Configuration.................................................................................................. 54
3.6.3.4.2.1 PCI Express Root Port 3(i210/211).................................................................................. 55
3.6.3.4.2.2 PCI Express Root Port 4(i210/211).................................................................................. 56
3.6.3.4.2.3 PCI Express Root Port 5(mPCIe)..................................................................................... 57
3.6.3.4.2.4 PCI Express Root Port 6(M.2).......................................................................................... 58
3.6.3.4.3 SATA Drivers....................................................................................................................... 59
3.6.3.4.4 USB Configuration............................................................................................................... 60
3.6.4 Security................................................................................................................................ 61
3.6.4.1 Secure Boot ........................................................................................................................ 62
3.6.4.1.1 Key Management ................................................................................................................ 63
3.6.5 Boot...................................................................................................................................... 63
3.6.6 Save and exit....................................................................................................................... 64
3.6.6.1 Save Changes and Reset ................................................................................................. 65
3.6.6.2 Discard Changes and Reset ............................................................................................. 65
3.6.6.3 Restore Defaults................................................................................................................ 65
3.6.6.4 Launch EFI Shell from filesystem device.......................................................................... 65
4. Drivers Installation.......................................................................................................66
4.1 Install Chipset Driver...............................................................................................67
4.2 Install TXE Driver....................................................................................................68
4.3 Install VGA Driver....................................................................................................69
4.4 Install Audio Driver (For Realtek ALC888S)............................................................71
4.5 Install Ethernet Driver..............................................................................................72
4.6 Install Touch Driver.................................................................................................74

LPC-0833
6 LPC-0833 Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x LPC-0833 Panel PC
1 x Power Adapter
4 x screws for VESA

Quick Reference Guide
LPC-0833 Quick Reference Guide
7
1.3 System Specifications
Component
Mother Board
ECM-APL(B)
CPU
Onboard Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor (Apollo Lake
Platform J3455/N3350 CPU)
CPU Cooler (Type)
Fanless Heatsink
Memory
One 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1866MTs
SDRAM (Non-ECC)
Power Supply
DC in
Adapter
+12 Vdc / 5 A (60W) power adaptor
(ACC-ADP-060N-07R)
Wireless LAN
Option by mini PCIe module
Bluetooth
Option by mini PCIe module
Operating System
Windows 10
Android x86 8.1
Ubuntu 16.04
Expansion Card
1 x Full-Size Mini PCI Express Mini Card (for PCIe &USB2.0)
1 x M.2 (2242) B-Key
Storage
Other Storage
Device
1 xM.2 B key (2242 support SATA/PCIex1/USB interface & with Micro SIM card
connector) for SSD
Panel
LCD Panel
8", 4:3, SVGA
B/L
Inverter/Converter
Built in LED backlight
Touch Screen
5 Wires resistive
Touch Controller
USB (EETI)
External I/O
Serial Port
1 x DB-9 male connector for COM1 supports RS232 (BOM option for RS422/485
1 x DB-9 male connector for COM2 supports RS232
USB Port
4 x USB 3.2 (Gen1x1, 5Gbps)
LAN Port
2 x RJ-45 (Dual Intel® I211AT Gigabit LAN)
Wireless LAN
Antenna
Reserved 1 for WiFi or 4G antenna
Switch
1 x power switch
Indicator Light
LED for Power, HDD
Expansion Slots
1 x Mini PCIe (for PCIe & USB2.0)

LPC-0833
8 LPC-0833 Quick Reference Guide
1 x M.2 (2242) B-Key
Mechanical
Power Type
12 ~ 24V, AT/ATX
Power Connector
Type
DC in
Dimension
202.5 x 159.5 x 46.5 mm
Weight
1.39 Kgs
Color
Front Silver & Rear panel Black
Fanless
Yes
OS Support
Windows 10
Android x86 8.1
Ubuntu 16.04
Reliability
EMI Test
CE/FCC Class B
Vibration Test
Random Vibration Operation
1 Test PSD : 0.00454G²/Hz , 1.5 Grms
2 System condition : operation mode
3 Test frequency : 5~500 Hz
4 Test axis : X,Y and Z axis
5 Test time : 30 minutes per each axis
6 IEC60068-2-64 Test Fh
6 Storage : mSATA
Sine Vibration test (Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package Vibration Test:
1 Test PSD : 0.026G²/Hz , 2.16 Grms
2 Test frequency : 5~500 Hz
3 Test axis : X,Y and Z axis
4 Test time : 30 minutes per each axis
5 IEC 60068-2-64 Test Fh
Mechanical Shock
Test
1 Wave from : Half Sine wave
2 Acceleration Rate : 10g for operation mode

Quick Reference Guide
LPC-0833 Quick Reference Guide
9
3 Duration Time : 11ms
4 No. of shock : Z axis 300 times
5 Test Axis : Z axis
6 operation mode
7 Reference IEC 60068-2-27 testing procedures
Test Eb : Shock Test
Drop Test
Package drop test
Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed
Test Ea : Drop Test
1 Test phase : One corner, three edges, six faces
2 Test high : 96.5cm
3 Package weight : 1.39Kg
4 Test drawing
Operating
Temperature
0°C ~ 40°C (32°F ~ 104°F)
Operating Humidity
40°C @ 95% Relative Humidity, Non-condensing
Storage
Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Note: Specifications are subject to change without notice.

LPC-0833
10 LPC-0833 Quick Reference Guide
1.4 System Overview
1.4.1 Right View
1.4.2 Bottom View
Connectors
Label
Function
Note
POWER
Power on button
COM1/2
Serial port 1/2 connector
DB-9 male connector
USB
4 x USB 3.2 connector
LAN1/2
RJ-45 Ethernet connector 1/2
HDMI
HDMI connector
HDD
HDD indicator
PWR
System power indicator
DC-IN
DC Power-in connector

Quick Reference Guide
LPC-0833 Quick Reference Guide
11
1.5 System Dimensions
(Unit: mm)

LPC-0833
12 LPC-0833 Quick Reference Guide
2.Hardware
Configuration
For advanced information, please refer to:
1- ECM-APL-B1 User’s Manual
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
LPC-0833 Quick Reference Guide
13
2.1 LPC-0833 connector mapping
2.1.1 Serial port 1 connector (COM1)
* Default
Note:
supports RS232 (BOM option for RS422/485)
RS-232*
Signal
PIN
PIN
Signal
NDCD#
1
6
NDSR#
NRXD
2
7
NRTS#
NTXD
3
8
NCTS#
NDTR#
4
9
NRI#
GND
5
RS-422(BOM option)
Signal
PIN
PIN
Signal
TxD-
1
6
NC
TxD+
2
7
NC
RxD+
3
8
NC
RxD-
4
9
NC
GND
5
RS-485(BOM option)
Signal
PIN
PIN
Signal
DATA-
1
6
NC
DATA+
2
7
NC
NC
3
8
NC
NC
4
9
NC
GND
5

LPC-0833
14 LPC-0833 Quick Reference Guide
2.1.2 Serial port 2 connector (COM2)
RS-232
Signal
PIN
PIN
Signal
NDCD#
1
6
NDSR#
NRXD
2
7
NRTS#
NTXD
3
8
NCTS#
NDTR#
4
9
NRI#
GND
5

Quick Reference Guide
LPC-0833 Quick Reference Guide
15
2.2 Installing Memory
Step 1. Unfasten 6 screws to remove the bottom chassis.
Step 2. Unlock 2 coppers from the rear I/O of VGA & COM ports.
Step 3. Release 4 screws to take off the board, and install the RAM module into the memory
slot.

LPC-0833
16 LPC-0833 Quick Reference Guide
Step 4. Assemble the board and bottom chassis back as step 3 to step 1.

Quick Reference Guide
LPC-0833 Quick Reference Guide
17
2.2 ECM-APL-B1 Overview

LPC-0833
18 LPC-0833 Quick Reference Guide
2.3 ECM-APL-B1 Jumper and Connector List
You can configure your board to match the needs of your application by setting jumpers. A
jumper is the simplest kind of electric switch.
It consists of two metal pins and a small metal clip (often protected by a plastic cover) that
slides over the pins to connect them. To “close” a jumper you connect the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1,
2, and 3. In this case, you would connect either two pins.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers.
Connectors on the board are linked to external devices such as hard disk drives, a
keyboard, or floppy drives. In addition, the board has a number of jumpers that allow you to
configure your system to suit your application.
If you have any doubts about the best hardware configuration for your application, contact
your local distributor or sales representative before you make any changes.
The following tables list the function of each of the board’s jumpers and connectors.
Jumpers
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.00 mm
JRI1
Serial port 1 pin9 signal select
3 x 2 header, pitch 2.00 mm
JAT1
AT/ ATX Input power select
3 x 1 header, pitch 2.00 mm
JBKL_SEL1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.00 mm
Connectors
Label
Function
Note
BT1
Battery connector
2 x 1 wafer, pitch 1.25 mm
CPU_FAN1
CPU fan connector
4 x 1 wafer, pitch 2.54 mm
JAUDIO1
Audio connector
6 x 2 header, pitch 2.00 mm
JBKL1
LCD inverter connector
5 x 1 wafer, pitch 2.00 mm

Quick Reference Guide
LPC-0833 Quick Reference Guide
19
Matching Connector: JST PHR-5
J422_485
Serial port 1 in RS-422/485 mode
3 x 2 header, pitch 2.00 mm
COM1
Serial port 1 connector
D-sub 9-pin, male
JCOM2/3/4/5/6
Serial port 2/3/4/5/6 connector
5 x 2 header, pitch 2.00 mm
JDIO1
General purpose I/O connector
6 x 2 header, pitch 2.00 mm
JFP1
Miscellaneous setting connector
5 x 2 header, pitch 2.00 mm
JLPC1
Low pin count interface
5 x 2 header, pitch 2.00 mm
JLVDS1
LVDS connector
20 x 2 wafer, pitch 1.25 mm
Matching Connector: Hirose
DF13-40DS-1.25C
USB12/34
On-board connector for USB3.0 x 4
JUSB1
On-board header for USB2.0
5 x 1 wafer, pitch 2.00 mm
JEC_ROM1
EC Debug connector
3 x 1 header, pitch 2.00 mm
ULAN1/2
RJ-45 Ethernet connector 1/2
LED1
HDD/Power LED indicator
JBZ1
PC Buzzer header
2 x 1 wafer, pitch 2.00 mm
SATA_PWR1
SATA power header
2 x 1 wafer, pitch 2.00 mm
SATA1
Serial ATA connector 1
HDMI1
HDMI connector
BIOS_SPI1
BIOS SPI header
4 x 2 header, pitch 2.00 mm
NGFF1
M.2 B key slot
MINI_PCIE1
Mini-PCI connector
SO_DIMM1
DDR3 SODIMM connector
USIM1
Sim card slot

LPC-0833
20 LPC-0833 Quick Reference Guide
2.4 ECM-APL-B1 Jumpers & Connectors settings
2.4.1 AT/ ATX Input power select (JAT1)
* Default
AT*
ATX
2.4.2 Serial port 1 pin9 signal select (JRI1)
* Default
Ring*
+5V
+12V
