Avalue Technology ECM-QM77 User manual

Part No. E2047391203R
ECM-QM77
Intel® Ivy Bridge Processors 3.5” Micro Module
with Intel® QM77 Chipset
User’s manual
4th Ed –03 September 2013
Copyright Notice
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.

ECM-QM77
2 ECM-QM77 User’s Manual
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright 2013 Avalue Technology Inc., ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form
or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.
Disclaimer
Avalue Technology Inc. reserves the right to make changes, without notice, to any product,
including circuits and/or software described or contained in this manual in order to improve
design and/or performance. Avalue Technology assumes no responsibility or liability for the
use of the described product(s), conveys no license or title under any patent, copyright, or
masks work rights to these products, and makes no representations or warranties that

User’s Manual
ECM-QM77 User’s Manual 3
these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration
purposes only. Avalue Technology Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN
LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL
OF Avalue Technology Inc.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for
surgical implant into body, or (b) support or sustain life and whose failure to perform,
when properly used in accordance with instructions for use provided in the labeling, can
be reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure
to perform can be reasonably expected to cause the failure of the life support device or
system, or to affect its safety or effectiveness.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

ECM-QM77
4 ECM-QM77 User’s Manual
If you still cannot find the answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our dealers are well trained
and ready to give you the support you need to get the most from your Avalue’s products. In
fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Avalue’s engineers every business day.
We are always ready to give advice on application requirements or specific information on
the installation and operation of any of our products. Please do not hesitate to call or e-mail
us.
Headquarters and Branch
Avalue USA
Avalue Technology Inc.
7F, 228, Lian-cheng Road, Zhonghe Dist.,
New Taipei City 235, Taiwan
Tel:[phone]
Fax : [phone]
Information :[e-mail]
Service: [e-mail]
Avalue Technology Inc.
9 Timber Lane, Marlboro, NJ 07746-1443
Tel : [phone]
Fax : [phone]
Information : [e-mail]
Service : [e-mail]
BCM Advanced Research
Avalue Europe
BCM Advanced Research
an Avalue Company
7 Marconi, Irvine, CA92618
Tel: [phone]
Fax: [phone]
Information: [e-mail]
Web: www.bcmcom.com
Avalue Europe A/S
Moelledalen 22C, 3140
Aalsgaarde, Denmark
Tel: [phone]
Fax:[phone]
Information: sales.e[email protected]
Service: service.europ[email protected]
Avalue China
Avalue Japan
Avalue Technology Inc.
Room 805, Building 9,No.99 Tianzhou Rd.,
Caohejing Development Area,
Xuhui District, Shanghai
Tel: [phone]
Fax:[phone]
Information: sales.chi[email protected]
Service: [e-mail]
Avalue Technology Inc.
3F Ishiyama-Bldg, 1-6-1 Taito,
Taito-ku, Tokyo 110-0016 Japan
Tel : [phone]
Fax : [phone]
Information : sales.j[email protected].tw
Service : [e-mail]

User’s Manual
ECM-QM77 User’s Manual 5
Product Warranty
Avalue warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Avalue, or which have been subject to
misuse, abuse, accident or improper installation. Avalue assumes no liability under the
terms of this warranty as a consequence of such events. Because of Avalue’s high
quality-control standards and rigorous testing, most of our customers never need to use our
repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according
to the cost of replacement materials, service time, and freight. Please consult your dealer
for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and
speed, Avalue’s products model name, hardware & BIOS revision number, other
hardware and software used, etc.) Note anything abnormal and list any on-screen
messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any
helpful information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization)
number from your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card
and a photocopy proof of purchase date (such as your sales receipt) in a shippable
container. A product returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.

ECM-QM77
6 ECM-QM77 User’s Manual
Content
1. Getting Started...........................................................................................................9
1.1 Safety Precautions ................................................................................................9
1.2 Packing List...........................................................................................................9
1.3 Document Amendment History............................................................................10
1.4 Manual Objectives...............................................................................................11
1.5 System Specifications .........................................................................................12
1.6 Architecture Overview –Block Diagram ..............................................................14
2. Hardware Configuration..........................................................................................15
2.1 Product Overview................................................................................................16
2.2 Installation Procedure..........................................................................................18
2.2.1 Main Memory........................................................................................................................... 19
2.3 Jumper and Connector List..................................................................................21
2.4 Setting Jumpers & Connectors............................................................................23
2.4.1 Clear CMOS (JBAT1).............................................................................................................. 23
2.4.2 COM 1 pin 9 signal select (JRI1)............................................................................................. 23
2.4.3 AT/ ATX Input power select (JAT1)......................................................................................... 24
2.4.4 5VSB connector in ATX (PWR_SB1)...................................................................................... 24
2.4.5 Battery connector (BAT1)........................................................................................................ 25
2.4.6 CPU fan connector (CPU_FAN1)............................................................................................ 25
2.4.7 System fan connector (SYS_FAN1)........................................................................................ 26
2.4.8 COM 1 RS-422-485 mode (J422/1)......................................................................................... 26
2.4.9 Audio connector (JAUDIO1).................................................................................................... 27
2.4.9.1 Signal Description –Audio connector (JAUDIO1)............................................. 27
2.4.10 LCD inverter connector (JBKL1) ............................................................................................. 28
2.4.11 LCD backlight brightness adjustment (JVR1).......................................................................... 28
2.4.12 Low pin count connector (JLPC1) ........................................................................................... 29
2.4.13 Serial port 2 connector (JCOM2)............................................................................................. 29
2.4.14 General purpose I/O connector (JDIO1) ................................................................................. 30
2.4.15 Miscellaneous setting connector (JFP1) ................................................................................. 30
2.4.16 SPI connector (JSPI1)............................................................................................................. 31
2.4.17 Power connector (PWR1)........................................................................................................ 31
2.4.18 LVDS connector (JLVDS1)...................................................................................................... 32
2.4.19 On-board box header for USB3.0 (JUSB3/1).......................................................................... 33
2.4.20 On-board box header for USB2.0 (JUSB1)............................................................................. 33
2.4.21 PS/2 keyboard & mouse connector (JKB/ MS1) ..................................................................... 34
2.4.22 HD power connector (HD_PWR1)........................................................................................... 34

User’s Manual
ECM-QM77 User’s Manual 7
2.5 Audio / USB Daughter Board User’s Guide .........................................................35
2.5.1 Jumper and Connector Layout................................................................................................ 35
2.5.2 Jumper and Connector List ..................................................................................................... 35
2.5.3 Setting Jumper and Connector................................................................................................ 36
2.6 Installing the CPU................................................................................................37
2.6.1 Locate the CPU socket on the board....................................................................................... 37
2.6.2 Separate CPU cooler and its base first by screw drawer........................................................ 38
3. BIOS Setup...................................................................................................................40
3.1 Introduction..........................................................................................................41
3.2 Starting Setup......................................................................................................41
3.3 Using Setup.........................................................................................................42
3.4 Getting Help.........................................................................................................43
3.5 In Case of Problems............................................................................................43
3.6 BIOS setup..........................................................................................................44
3.6.1 Main Menu............................................................................................................................... 44
3.6.1.1 System Language.............................................................................................. 45
3.6.1.2 System Date...................................................................................................... 45
3.6.1.3 System Time...................................................................................................... 45
3.6.2 Advanced Menu....................................................................................................................... 45
3.6.2.1 APCI Settings .................................................................................................... 46
3.6.2.2 S5 RTC Wake Settings...................................................................................... 46
3.6.2.3 Trusted Computing............................................................................................ 47
3.6.2.4 CPU Configuration............................................................................................. 48
3.6.2.5 SATA Configuration........................................................................................... 49
3.6.2.6 Thermal Configuration....................................................................................... 49
3.6.2.7 Intel(R) Rapid Start Technology........................................................................ 51
3.6.2.8 Intel TXT (LT) Configuration.............................................................................. 51
3.6.2.9 PCH-FW Configuration...................................................................................... 52
3.6.2.10 Intel(R) Anti-Theft Technology Configuration.................................................... 53
3.6.2.11 AMT Configuration............................................................................................. 54
3.6.2.12 USB Configuration............................................................................................. 55
3.6.2.13 Super IO Configuration...................................................................................... 56
3.6.2.13.1 Serial Port 0 Configuration ................................................................................ 57
3.6.2.13.2 Serial Port 1 Configuration ................................................................................ 58
3.6.2.14 Hardware Monitor.............................................................................................. 59
3.6.2.15 Intel® Smart Connect Technology .................................................................... 60
3.6.2.16 CPU PPM Configuration.................................................................................... 60
3.6.3 Chipset................................................................................................................................... 61
3.6.3.1 PCH-IO Configuration...................................................................................... 62
3.6.3.1.1 PCI Express Configuration .............................................................................. 63

ECM-QM77
8 ECM-QM77 User’s Manual
3.6.3.1.1.1 PCI Express Root Port 1 ................................................................................... 63
3.6.3.1.1.2 PCI Express Root Port 6 ................................................................................... 64
3.6.3.1.1.3 PCI Express Root Port 7(82574 LAN)............................................................... 65
3.6.3.1.2 USB Configuration........................................................................................... 66
3.6.3.1.3 PCH Azalia Configuration................................................................................ 67
3.6.3.2 System Agent (SA) Configuration.................................................................... 67
3.6.3.2.1 Memory Configuration ..................................................................................... 68
3.6.3.2.2 GT –Power Management Control................................................................... 69
3.6.3.3 Graphics Configuration.................................................................................... 70
3.6.4 Boot........................................................................................................................................ 72
3.6.4.1 CSM parameters.................................................................................................................... 73
3.6.5 Security.................................................................................................................................. 74
3.6.6 Save and exit......................................................................................................................... 75
3.6.6.1 Save Changes and Exit..................................................................................... 75
3.6.6.2 Discard Changes and Exit................................................................................. 75
3.6.6.3 Save Changes and Reset.................................................................................. 76
3.6.6.4 Discard Changes and Reset ............................................................................. 76
3.6.6.5 Save Changes................................................................................................... 76
3.6.6.6 Discard Changes............................................................................................... 76
3.6.6.7 Restore Defaults................................................................................................ 76
3.6.6.8 Save as User Defaults....................................................................................... 76
3.6.6.9 Restore as User Defaults .................................................................................. 76
4. Drivers Installation.......................................................................................................77
4.1 Install Chipset Driver (For Intel QM77)................................................................78
4.2 Install ME Driver (For Intel QM77).......................................................................79
4.3 Install USB 3.0 Driver (For Intel QM77)...............................................................81
4.4 Install VGA Driver (For Intel QM77).....................................................................82
4.5 Install Audio Driver (For Realtek ALC892)...........................................................84
4.6 Install Ethernet Driver (For Intel 82579LM and 82574L)......................................85
5. Mechanical Drawing ....................................................................................................87

User’s Manual
ECM-QM77 User’s Manual 9
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x 3.5” ECM-QM77 Micro Module
1 x Quick Installation Guide for ECM-QM77
1 x AUX-056 daughter board
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
1 x Cable set contains the followings:
—1 x Audio cable (12pin,2.0 pitch)
—1 x USB 2.0 cable (10P/2.0mm-10P/2.0mm)
—1 x USB 3.0 cable ((20P/2.0mm-20P/2.0mm)
—1 x Serial ATA cable (7-pin, standard)
—1 x Wire SATA power cable (15-pin,4P/2.5mm)
—1 x Flat cable 9P(M)-PHD 10P/2.0mm)
3M foam (VHB-4622 10mm*20mm*1.1mm)

ECM-QM77
10 ECM-QM77 User’s Manual
1.3 Document Amendment History
Revision
Date
Comment
1st
October 2012
Initial Release
2nd
December 2012
Connector List Update
3rd
January 2013
Increase Installing the CPU
4th
September 2013
Update Mechanical Drawing

User’s Manual
ECM-QM77 User’s Manual 11
1.4 Manual Objectives
This manual describes in detail the Avalue Technology ECM-QM77 Single Board.
We have tried to include as much information as possible but we have not duplicated
information that is provided in the standard IBM Technical References, unless it proved to
be necessary to aid in the understanding of this board.
We strongly recommend that you study this manual carefully before attempting to interface
with ECM-QM77 series or change the standard configurations. Whilst all the necessary
information is available in this manual we would recommend that unless you are confident,
you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that
make booting impossible. If this should happen, clear the CMOS settings, (see the
description of the Jumper Settings for details).
If you have any suggestions or find any errors concerning this manual and want to inform
us of these, please contact our Customer Service department with the relevant details.

ECM-QM77
12 ECM-QM77 User’s Manual
1.5 System Specifications
System
CPU
Intel® rPGA988B（Socket G2）supports Intel® Ivy Bridge Processors （35 ～45W
CPU）
BIOS
AMI uEFI BIOS, 64Mbit SPI Flash ROM
iAMT8.0 Supported
System Chipset
Intel® QM77 Chipset
I/O Chip
Nuvoton NCT6776F
System Memory
One 204-pin DDR3 SODIMM Socket Supports Up to
8GB DDR3 1333/ 1600 SDRAM
Watchdog Timer
Reset: 1sec. ~ 255sec./min. and 1sec. or 1min./step
H/W Status
Monitor
Monitoring System Temperature, Voltage with
Auto Throttling Control
Expansion
1 x Mini PCIe
TPM
TPM 1.2 supported
I/O
MIO
1 x RS-232, 1 x RS-232/ 422/ 485, LPC, 2 x SATA III
USB
2 x USB 2.0, 4 x USB 3.0
DIO
4-bit GPI, 4-bit GPO
Display
Chipset
Intel® QM77
Resolution
VGA Mode: 1920 x 1200 @ 60Hz
HDMI Mode: 1920 x 1200 @ 60Hz
LVDS Mode: 1920 x 1200 @ 60Hz
Multiple
Display
VGA + LVDS + HDMI
LCD
Interface
Dual-channel 18/ 24-bit LVDS
Audio
HD Codec
Realtek ALC892 Supports 7.1-CH Audio
Audio Interface
Mic-in, Line-in, Line-out
Ethernet
LAN Chip
1 x Intel® 82574L Gigabit Ethernet
1 x Intel® 82579 Gigabit Ethernet
Ethernet Interface
10/ 100/ 1000 Base-Tx Gigabit Ethernet Compatible
Mechanical &
Environmental

User’s Manual
ECM-QM77 User’s Manual 13
Power Requirement
+12V
ACPI
Single Power ATX Support S0, S1, S3, S4, S5
ACPI 3.0 Compliant
Power Type
AT/ATX
Operating Temp.
0 ~ 60°C (32 ~ 140°F)
Storage
Temperature
-40 ~ 75°C (-40 ~ 167°F)
Operating Humidity
0%~90% Relative Humidity, Non-condensing
Size (L x W)
5.7" x 4" (146mm x 101mm)
Weight
0.44lbs (0.2kg)

ECM-QM77
14 ECM-QM77 User’s Manual
1.6 Architecture Overview –Block Diagram
The following block diagram shows the architecture and main components of ECM-QM77.

User’s Manual
ECM-QM77 User’s Manual 15
2. Hardware
Configuration

ECM-QM77
16 ECM-QM77 User’s Manual
2.1 Product Overview

User’s Manual
ECM-QM77 User’s Manual 17

ECM-QM77
18 ECM-QM77 User’s Manual
2.2 Installation Procedure
This chapter explains you the instructions of how to setup your system.
1. Turn off the power supply.
2. Insert the SODIMM module (be careful with the orientation).
3. Insert all external cables for hard disk, floppy, keyboard, mouse, USB etc. except for flat
panel. A CRT monitor must be connected in order to change CMOS settings to support
flat panel.
4. Connect power supply to the board via the ATXPWR.
5. Turn on the power.
6. Enter the BIOS setup by pressing the delete key during boot up. Use the “LOAD BIOS
DEFAULTS” feature. The Integrated Peripheral Setup and the Standard CMOS Setup
Window must be entered and configured correctly to match the particular system
configuration.
7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before
connecting the display cable and turning on the power.
Note: Make sure the heat sink and the CPU top surface are in total contact to
avoid CPU overheating problem that would cause the system to hang or
unstable

User’s Manual
ECM-QM77 User’s Manual 19
2.2.1 Main Memory
ECM-QM77 provides one 204-pin DDR3 SODIMM socket, supports up to 8GB DDR3
1333/1600 SDRAM.
(Rear side)
Make sure to unplug the power supply before adding or removing SODIMMs
or other system components. Failure to do so may cause severe damage to
both the board and the components.
Locate the SODIMM socket on the board.
Hold two edges of the SODIMM module carefully. Keep away of touching its
connectors.
Align the notch key on the module with the rib on the slot.
Firmly press the modules into the socket automatically snaps into the mounting notch.
Do not force the SODIMM module in with extra force as the SODIMM module only fit
in one direction.
SODIMM

ECM-QM77
20 ECM-QM77 User’s Manual
To remove the SODIMM modules, push the two ejector tabs on the slot outward
simultaneously, and then pull out the SODIMM module.
Note:
(1) Please do not change any DDR3 SDRAM parameter in BIOS setup to increase
your system’s performance without acquiring technical information in advance.
(2) Static electricity can damage the electronic components of the computer or
optional boards. Before starting these procedures, ensure that you are
discharged of static electricity by touching a grounded metal object briefly.
