Avantree BTTC-200X User manual

1. Product Description
Avantree BTTC-200X is a 2-in-1 Bluetooth stereo audio transceiver, which can
easily switch between receive and transmit modes. With standard 3.5mm audio
jack, it's plug & play, no software installation required. And it is very simple to use
and allows your audio devices to send or receive stereo audio via Bluetooth
wireless.
2. Product Overview
(1) LED Indicator
(2) Multi-Function Button (MFB)
(Power on / Off / Pairing)
(3) Micro USB charging socket
(4) 3.5 mm audio jack
(5) TX/RX switch button
What’s in the box:
zAvantree BTTC-200X
z3.5mm to 3.5mm audio cable
zUSB charging cable
zUser Manual
zWarranty card
3. Charging
BTTC-200X comes with a built in rechargeable battery that provides a very long
standby time and working time. We recommend charging the battery fully before
using it for the first time.
1) Insert one Micro USB charging cable end to Saturn Micro USB socket, and
put the other end into a standard USB power outlet, such as laptop or
desktop.
2) It takes 3 hours to charge full and reaches its full capacity for the first time.
Each subsequent charge cycle take around 2 hours.
3) LED will indicate red when charging, and goes off when charging is
complete.
4) If you have not used the device for a few months, LED might not turn red
when first charging. It might take 15-35 minutes before the LED turns red.
5) We suggest to fully charge the device at least every two months
Notice:
zWhen battery power is low, the indicator light will flash red. Please recharge
the battery.
3
4. Transmitter, Turn On / Off
Please push the click button to TX mode from TX / RX positon, before power on.
TX or RX mode can not be changed after powering on Saturn.
Turn On: press and hold the MFB button for about 5 seconds until the blue LED
is on for 1 second
Notice: For the first time use or first time turn on after clear connection list, transmitter
Saturn will automatically enter into pairing mode, the LED light flashes blue quickly.
Turn Off: press and hold the MFB button for about 3 seconds until the red LED is
on for 1 second, and then go off.

5. Transmitter, Pairing with a Bluetooth device (Tutorial online)
After BTTC-200X, under TX mode, has connected to a bluetooth stereo device,
you can enjoy music wirelessly. Before pairing, please make sure your Bluetooth
stereo device supports Bluetooth A2DP profile. ( such as Bluetooth stereo
headset Avantree Jogger, Bluetooth speaker Avantree Pacifica.)
Pairing procedure:
A．Plug the 3.5 mm audio cable into BTTC-200X’S 3.5 mm audio socket; and
put plug the other end into the audio output of an audio source system.
B. Ensure BTTC-200X has pushed into TX mode, and the device is off.
C. Put BTTC-200X and your Bluetooth stereo receiver device within 1 meter.
D. Power on your Bluetooth stereo receiver device and put it into pairing
mode.
E．Press and hold BTTC-200X’S MFB button for about 5 -7 seconds until the
LED light flashes blue quickly, indicating it is in pairing mode.
(Notice: For the first time use or first time power on after clear connection list,
BTTC-200X will automatically enter into pairing mode, the Blue LED light
flashes quickly.)
F. Then BTTC-200X will automatically search, pair and connect your Bluetooth
stereo device.
G. After successful connection, the LED light will flash blue twice every 4
seconds.
H．Pairing is completed. Now you can enjoy wireless music.
Note:
1. The pairing mode will last 2 minutes. The transmitter will enter standby mode
if no devices can be connected with 2 minutes
2. The BTTC-200X can pair with stereo Bluetooth devices with PIN code “0000”,
“1111”, “8888” or “1234”.
3. Once power on, the BTTC-200 will be automatically connected with the last
connected device.
4. The transmitter BTTC-200 will automatically switch off if no devices can be
connected within 5 minuters.
5. Clear the pairing list: From off, press and hold the MFB button for about 12
seconds until red LED is on for 1 second and then blue LED is on for 1
second.
6. LED indicator instruction:
LED indicator TC200 of TC200 under TX mode
Blue LED blinks continuously Pairing mode, lasts for 2 minutes
Blue LED flashes every 1 second Standby mode, not connected with
device
Blue Led flashes twice every 4
seconds Connected with a device
Red LED blinks Low Power
We found most of the online technical support questions are caused by improper
pairing. Please follow the instruction step-by-step.
6. Receiver, Turn On / Off
Pls. push the click button to RX mode from TX / RX positon, before power on.
TX or RX mode can not be changed after powering on Saturn.
Turn On: press and hold TC200X’s MFB button for around 5 - 7 seconds until the
blue LED is on for 1 second.
Turn Off: press and hold the MFB button of Saturn for around 3 - 4 seconds until
the red LED is on for 1 second, and then go off.
7. Receiver, working with a Bluetooth device (Tutorial online)
7.1 Pairing procedure:
A. Plug the 3.5 mm audio cable into BTTC-200X’S 3.5 mm audio socket. Plug the
other end into the audio input of your home hi-fi stereo system.
B．Ensure BTTC-200X has pushed to RX mode and the device is off.
C．Put BTTC-200X and your Bluetooth enabled phone within 1meter.
D．Press and hold BTTC-200X’s MFB button for about 6-8 seconds until the
LED light flashes blue and red alternatively, which is in pairing mode.
E．Make your phone into Bluetooth mode and Search the available device
F．Once found “Avantree BTTC-200X’’, follow the steps and enter pin code
0000 to pair when requested.
(Note: Different phone / tablets have different procedure to activate the
Bluetooth function, and please make sure the device is visible to nearby
device, for the device Bluetooth version above 2.1 no need to input pin
code when pairing)
G. Connect the BTTC-200X to your phone.

H. After successful connection, the LED light will flash blue twice
every 4 seconds.
Note:
1. The pairing mode will last 2 minutes. The receiver will enter standby
mode if no devices can be connected with 2 minutes.
2. The receiver BTTC-200X can pair with stereo Bluetooth devices with PIN
code “0000”, “1111”, “8888” or “1234”.
3. Once power on, the receiver BTTC-200X will be automatically connected
with the last connected device.
4. The receiver BTTC-200X will automatically power off if no devices can be
connected within 5 minuters.
5. Clear the pairing list: From off, press and hold the MFB button for about
12 seconds until red LED is on for 1 second and then blue LED is on for
1 second.
LED indicator TC200 of TC200 under RX mode
Blue and Red LED blinks continuously
and alternatively Pairing mode, lasts for 2 minutes
Blue LED flashes every 1 second Standby mode, not connected with
device
Blue Led flashes twice every 4
seconds Connected with a device
Red LED blinks Low Power
7.2 Stream the music
After the receiver BTTC-200X is connected to the Bluetooth device, you can
connect it to a 3.5mm stereo headset or stereo speaker with a 3.5mm to 3.5mm
audio cable. Now you can listen to music and control pause / play of music by
short pressing the MFB button once.
8. Product Specification
zBluetooth V2.1+EDR
zBluetooth profile supported: A2DP and AVRCP
zOperation Range: Class 2, 10 meters
zTX mode working time: 10 hours
zRX mode working time: 9 hours
zStandby time: up to 400 hours
zCharging time: about 2 hours
zCharging input voltage: DC 5V
zBattery: 270mAH rechargeable LI-polymer battery
zWeight: 48.5g
zSize: 50mm(L)x37mm(W)X13mm(H)
The working and standby times may vary when used with different mobile phones
or other compatible Bluetooth devices, usage settings, usage styles and
environments.
9. Safety Information
zTo avoid any damage or malfunction of the device do not drop device from
high places.
zKeep device away form humidity, water and any other liquid. If the device is
exposed to water, moisture and other liquid, do not operate it to avoid any
electrical shock, explosion and damage to the device or yourself.
zDo not place or keep this device near any heat source, such as, direct sun
light, radiators, stoves or other apparatus which produces heat. It may cause
explosion, degrade the performance and/or reduce battery life.
zDo not modify, repair or disassemble device at discretion (Especially battery: It
may cause an explosion). Doing this will avoid the warranty.
zDo not place heavy objects on the device.
zUse only supplied and approved charger.
zReplacement or service must be done by qualified service center or
manufacturer.
zUnplug this device when unused for long periods of time or during lightning
storms.
CAUTIONS: ELECTRIC SHOCK HAZARD
The battery used in this device may present a risk of fire or chemical burn if
mistreated.

10. Declaration of Conformity
10.1. EU
This product is CE certified according to the provision of the R&TTE Directive
(99/5/EC).
Declare that this product is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
10.2. Trademark Statement
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
Avantree is a trademark owned by Avantronics limited.
10.3 FCC Warning
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
11. Warranty
zTo avoid any damage or device malfunction, do not drop the device from high
places.
zKeep the device away from humidity, water and any other liquid. If the device
is exposed to water, moisture and other liquid, do not operate it to avoid any
electrical shock, explosion and damage to the device or yourself.
zDo not place or keep this device near any heat source, such as, direct sun
light, radiators, stoves or other apparatus which produces heat. It may cause
explosion, degrade the performance and/or reduce battery life.
zDo not modify, repair or disassemble the device (Especially battery: It may
cause an explosion). Doing so will void the warranty.
zDo not place heavy objects on the device.
zUse only the supplied and approved charger.
zService must be done by qualified service center or manufacturer.
zUnplug this device when unused for long periods of time or during lightening
storms.
CAUTIONS: ELECTRIC SHOCK HAZARD
The battery used in this device may present a risk of fire or chemical burn if
mistreated.
Online Tutorial & Technical Support
More information about this product and other Avantree Bluetooth products,
including the video user guide, product tutorial and online technical support,
please refer to www.avantree.com website.
Due to software update, there could be some changes on operations.
Please always refer to Product Tutorial page in Avantree website for the
latest features.
QDID:B015006
FCC ID: WJ5-BTTC-200
Z-PKMN-TC200-0000V2
