Avaya CU-360 User manual

Avaya IX CU360
PoE Splitter
QUICK START GUIDE

2 3
Congratulations on purchasing your Avaya PoE
splitter for the CU360.
It provides over a single network cable power and
data connection to CU360.
In fact it allows a single Ethernet cable to carry
both data and power to the CU360.
It allows IT Professionals to mount the CU360
anywhere in a building.
1. AVAYA CU360 PoE Splitter
2. 20 cm CAT6 Ethernet Cable
3. 20 cm 18AVGx2 Power cable
OVERVIEW PACKAGE CONTENT

4 5
1. Connect the Lan Out PoE splitter connector
to CU360 Lan connector using the provided
CAT6 Ethernet Cable
2. Connect the DC Out PoE splitter connector
to CU360 power connector using the
provided 18AVGx2 Power cable
3. Connect your office Lan (PoE avaialble) to
the PoE in splitter connector
4. The CU360 turns on
When all possible peripherals are connected
to the CU360 a PoE+ power connection is
recommended
STEPS

6 7
Read all safety, installation, and user documentation
prior to installing or operating this product.
To view and download safety, installation, and user
documentation go to Avaya’s support web site at
support.avaya.com.Check this site frequently for
any updates.
