Avaya CU-360 User manual

CU360 AV Grabber and
Optional Cables
QUICK START GUIDE

2 3
Congratulations on purchasing your Optional
Cable Kit for Avaya IX CU360. This kit extends the
features and experience of CU users. It provides a
video grabber that allows you to connect a wired
computer output to the CU360 as a presentation
source.
1. 1x 4m Ethernet cable
2. 1 video grabber. It includes a 2.5m USB cable
3. USB 3.0 adapter Type A/F to Type C/M
OVERVIEW PACKAGE CONTENT

4 5
1. Connect the computer to be used as a
presentation source to the HDMI INPUT
connector on the Video Grabber.
2. Connect the USB 3.0 adapter type C to
CU360 USB type C connector.
3. Connect the USB connector on the Video
Grabber to the USB connector on the USB
3.0 adapter.
The computer will be used as video source for
content on the CU360.
Note: Not all resolutions from the computer are
supported. Once the HDMI Grabber is connected
as described in this guide, just press the Present
Button.
During a call, a menu on screen will show the
available options: Just select “USB” and the CU360
will start sharing the content of the computer
connected to the HDMI port of the device.
Note: Connect the USB connector on the AV
Grabber to USB 3.0 connector on CU360 using
the provided USB cable.
Important!
• If you need to use an USB hub to connect the
AV grabber to the CU360, ensure that it is 3.0
and properly powered on.
• When the grabber is in use the device could
reset unexpectedly due to excessive power
consumption from the grabber if the USB
hub is not 3.0 or is not properly powered.
VIDEO GRABBER

6 7
HARDWARE SETUP
Computer
CU360
USB 3.0
HDMI INPUT
Video Grabber
CU360
HDMI Ethernet Cable
USB 3.0 adapter
type C to type A

8 9
Read all CU360 safety, installation, and user
documentation prior to installing or operating this
product. To view and download safety, installation,
and user documentation, go to Avaya’s support
web site at support.avaya.com.Check this site
frequently for updates.
IMPORTANT NOTICE
Avaya offers a full set of services to help maximize a
video investment. Strategic and technical consulting
along with deployment and customization services
help ensure that video collaboration rollouts are
successful and aligned to business requirements.
Avaya support services maximizes up time with
software updates, upgrades, remote maintenance
and expert repairs.
Support Services

10 11
Businesses are built on the experiences they provide
and every day millions of those experiences are
built by Avaya (NYSE:AVYA). For over one undred
years, we’ve enabled organizations around the globe
to win—by creating intelligent communications
experiences for customers and employees. Avaya
builds open, converged and innovative solutions
to enhance and simplify communications and
collaboration—in the cloud, on premise, or a hybrid
of both. To grow your business, we’re committed
to innovation, partnership, and a relentless focus
on what’s next. We’re the technology company you
trust to help you deliver Experiences that Matter.
Visit us at www.avaya.com.
