Avaya P334T-ML Operator's manual

Avaya
Installation and Configuration Guide
AVAYA P334T-ML
STACKABLE SWITCH
SOFTWARE VERSION 4.5
January 2004

avaya.com
© 2004 Avaya Inc. All rights reserved. All trademarks identified by the ® or TM are registered trademarks or
trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners
Document no. 10-300128

Avaya P334T-ML User’s Guide i
Contents
Preface Before you Install the P330-ML ISafety Information ..................................... I
FCC Notice........................................................................................................... I
Conventions Used in the Documentation ....................................................... I
CLI Conventions ......................................................................................I
Notes, Cautions, and Warnings ........................................................... II
Warranty ............................................................................................................ II
Notice................................................................................................................. III
Avaya Support ................................................................................................. III
Section 1 Overview
Chapter 1 Avaya P334T-ML Overview............................................................................. 1
Introduction ........................................................................................................ 1
About the P334T-ML ......................................................................................... 1
Avaya P334T-ML Features ............................................................................... 1
Layer 3 Features P330-ML ................................................................................ 2
Network Management and Monitoring ......................................................... 2
Device Manager (Embedded Web) ......................................................2
Command Line Interface (CLI) .............................................................2
Avaya Integrated Manager ................................................................... 3
Port Mirroring ......................................................................................... 3
SMON ....................................................................................................... 3
Fans, Power Supply, and BUPS-ML Monitoring ...............................4
Chapter 2 Standards and Compatibility ........................................................................... 5
Avaya P330 Standards Supported................................................................... 5
IEEE .......................................................................................................... 5
IETF - Layer 2 ..........................................................................................5
IETF - Layer 3 ..........................................................................................5
IETF - Network Monitoring.............................................................................. 6
Chapter 3 Specifications ...................................................................................................... 7
P334T-ML Switch............................................................................................... 7
Physical .................................................................................................... 7
Power Requirements ............................................................................. 7
Environmental ......................................................................................... 7
Safety ........................................................................................................ 8
Safety - AC Version ................................................................................8
Safety - DC Version ................................................................................ 8

Table of Contents
ii Avaya P334T-ML User’s Guide
EMC Emissions .......................................................................................8
Emissions ......................................................................................8
Immunity ......................................................................................8
Interfaces ..................................................................................................9
Basic MTBF ..............................................................................................9
Stacking Sub-module......................................................................................... 9
Basic MTBF ..............................................................................................9
Approved SFF/SFP GBIC Transceivers........................................................ 10
Safety Information ................................................................................10
Laser Classification ....................................................................10
Usage Restriction .......................................................................10
Installation .............................................................................................11
Installing and Removing a SFF/SFP GBIC Transceiver ......11
Specifications .........................................................................................11
LX Transceiver ...........................................................................11
SX Transceiver ............................................................................11
Agency Approval ..................................................................................12
Gigabit Fiber Optic Cabling............................................................................ 12
Console Pin Assignments................................................................................ 13
Section 2 Installation
Chapter 4 Installation......................................................................................................... 17
Required Tools.................................................................................................. 17
Site Preparation ................................................................................................ 17
Rack Mounting (Optional).............................................................................. 19
Installing the X330STK-ML Stacking Sub-Module (Optional) .................. 20
Connecting Stacked Switches......................................................................... 20
To connect stacked switches: ...............................................................20
Making Connections to Network Equipment.............................................. 23
Prerequisites ..........................................................................................23
Connecting Cables to Network Equipment ......................................23
Chapter 5 Powering Up the Avaya P330......................................................................... 25
Powering On – Avaya P330 Module AC ...................................................... 25
Powering On – Avaya P330 Switch DC ........................................................ 25
Post-Installation................................................................................................ 26
Chapter 6 Avaya P334T-ML Front and Rear Panels...................................................... 27
Avaya P334T-ML Front Panel ........................................................................ 27
Avaya P334T-ML Back Panel ......................................................................... 31
BUPS-ML Input Connector ..................................................................32
Chapter 7 Establishing Switch Access ............................................................................. 33
Establishing a Serial Connection.................................................................... 33

Table of Contents
Avaya P334T-ML User’s Guide iii
Configuring the Terminal Serial Port Parameters ...........................33
Connecting a Terminal to the Avaya P330 Serial port ....................33
P330 Sessions .................................................................................................... 34
Assigning P330’s IP Stack Address ............................................................... 34
Establishing a Telnet Connection .................................................................. 35
Establishing an SSH Connection.................................................................... 35
Establishing a Modem (PPP) Connection with the P330 ........................... 36
Overview ................................................................................................ 36
Connecting a Modem to the Console Port ........................................ 36
Security Levels.................................................................................................. 37
Entering the Supervisor Level ............................................................37
Defining new local users .......................................................... 38
Exiting the Supervisor Level ....................................................38
Entering the CLI .................................................................................... 38
Chapter 8 User Authentication......................................................................................... 39
Introduction ...................................................................................................... 39
SNMP Support ................................................................................................. 39
Introduction to SNMP ..........................................................................39
SNMP Versions .......................................................................... 39
Managers and Agents ............................................................... 39
Manager/Agent Communication ........................................... 40
SNMPv1 ...................................................................................... 40
SNMPv2c .................................................................................... 41
SNMPv3 ...................................................................................... 41
SNMP Commands ................................................................................ 43
SSH Protocol Support...................................................................................... 46
Introduction to SSH ..............................................................................46
SSH Commands .................................................................................... 47
SCP Protocol Support...................................................................................... 48
RADIUS............................................................................................................. 49
Introduction to RADIUS ...................................................................... 49
Radius Commands ............................................................................... 51
Telnet Client Support ...................................................................................... 52
Introduction to Telnet ..........................................................................52
Telnet Commands ................................................................................ 52
Recovery Password.......................................................................................... 53
Introduction ........................................................................................... 53
Recovery Password Commands ......................................................... 53
Allowed Managers........................................................................................... 54
Allowed Managers Introduction ........................................................ 54
Allowed Managers CLI Commands .................................................. 54
Allowed Protocols............................................................................................ 55
Allowed Protocols Introduction ......................................................... 55
Allowed Protocols CLI Commands ...................................................55

Table of Contents
iv Avaya P334T-ML User’s Guide
Section 3 Configuration
Chapter 9 P330 Default Settings ....................................................................................... 59
Configuring the Switch ................................................................................... 59
Avaya P330 Default Settings ...............................................................59
Chapter 10 Switch Configuration....................................................................................... 63
Introduction ...................................................................................................... 63
Basic Switch Configuration .................................................................63
System Parameter Configuration .......................................................64
Identifying the system ..............................................................64
Operating parameters ...............................................................64
Network Time Acquiring Protocols Parameter Configuration ......65
Uploading and Downloading Device Configurations and Images .......... 65
Layer 2 Configuration File ...................................................................66
Layer 3 Configuration File ...................................................................68
System Logging ................................................................................................ 70
System Logging Introduction ..............................................................70
System Logging Messages ........................................................70
Sinks .............................................................................................71
Applications ...............................................................................71
Syslog Servers ............................................................................72
Syslog Configuration CLI Commands ...................................73
Monitoring CPU Utilization ........................................................................... 75
Chapter 11 Avaya P330 Layer 2 Features.......................................................................... 77
Overview ........................................................................................................... 77
Ethernet.............................................................................................................. 78
Fast Ethernet ..........................................................................................78
Gigabit Ethernet ....................................................................................78
Configuring Ethernet Parameters .......................................................78
Auto-Negotiation .......................................................................78
Full-Duplex/Half-Duplex ........................................................78
Speed ...........................................................................................79
Flow Control ...............................................................................79
Priority ........................................................................................79
MAC Address ............................................................................80
CAM Table ..................................................................................80
Ethernet Configuration CLI Commands ...........................................81
Ethernet Implementation in the Avaya P334T-ML ..........................82
VLAN Configuration....................................................................................... 83
VLAN Overview ...................................................................................83
VLAN Tagging ......................................................................................84
Multi VLAN Binding ............................................................................84
Automatic VLAN Learning .................................................................86

Table of Contents
Avaya P334T-ML User’s Guide v
Ingress VLAN Security ........................................................................ 86
VLAN CLI Commands ........................................................................ 86
VLAN Implementation in the Avaya P334T-ML ............................. 87
Port Based Network Access Control (PBNAC) ........................................... 88
How “Port Based” Authentication Works ........................................ 88
PBNAC Implementation in the P330 Family .................................... 88
Configuring the P330 for PBNAC ...................................................... 89
PBNAC CLI Commands ...................................................................... 90
Spanning Tree Protocol................................................................................... 92
Overview ................................................................................................ 92
Spanning Tree Protocol ........................................................................ 92
Spanning Tree per Port ........................................................................92
Rapid Spanning Tree Protocol (RSTP) ............................................... 93
About the 802.1w Standard ..................................................... 93
Port Roles .................................................................................... 93
Spanning Tree Implementation in the P330 Family ........................94
Spanning Tree Protocol CLI Commands ..........................................95
MAC Security ................................................................................................... 97
MAC Security Implementation in P330 .............................................97
MAC Security CLI Commands ........................................................... 98
MAC Aging....................................................................................................... 99
Overview ................................................................................................ 99
Configuring the P330 for MAC Aging .............................................. 99
MAC Aging CLI Commands .............................................................. 99
LAG.................................................................................................................. 100
LAG Overview .................................................................................... 100
LAG CLI Commands .........................................................................100
LAG Implementation in the Avaya P330 Family of Products ..... 101
Port Redundancy ........................................................................................... 102
Port Redundancy Operation ............................................................. 102
Intermodule Port Redundancy .........................................................103
Port Redundancy CLI Commands ................................................... 103
IP Multicast Filtering ..................................................................................... 105
Overview .............................................................................................. 105
IP Multicast CLI Commands .............................................................106
IP Multicast Implementation in the Avaya P334T-ML .................106
RMON.............................................................................................................. 107
RMON Overview ................................................................................ 107
RMON CLI Commands .....................................................................107
SMON .............................................................................................................. 109
SMON Overview ................................................................................ 109
Port Mirroring Configuration ...................................................................... 110
Port Mirroring Overview .................................................................. 110
Port Mirroring CLI commands ......................................................... 110

Table of Contents
vi Avaya P334T-ML User’s Guide
Port Mirroring Constraints ................................................................110
Multilayer Policy ............................................................................................ 111
About Multilayer Policy .....................................................................111
Access Lists ...............................................................................111
DSCP-to-COS Maps .................................................................112
Trust Modes ..............................................................................112
Multilayer Policy Implementation in the P334T-ML .....................112
Configuring the P334T-ML for Multilayer Policy ..........................113
Configuration Requirements .................................................113
Configuration File Management ...........................................113
Multilayer Policy CLI Commands ....................................................114
Weighted Queuing......................................................................................... 116
Implementation of Weighted Queuing in the P330-ML ................116
Weighted Queuing CLI Commands ................................................116
Port Classification .......................................................................................... 117
Overview ..............................................................................................117
Port Classification CLI Commands ..................................................117
Stack Redundancy.......................................................................................... 118
Stack Health .................................................................................................... 118
Overview ..............................................................................................118
Implementation of Stack Health in the P330 Family .....................118
Stack Health CLI Commands ............................................................119
Chapter 12 Avaya P330 Layer 3 Features........................................................................ 121
Introduction .................................................................................................... 121
What is Routing? .................................................................................121
Routing Configuration .................................................................................. 123
Forwarding ..........................................................................................123
Multinetting (Multiple Subnets per VLAN) ...................................123
IP Configuration............................................................................................. 124
IP Configuration CLI Commands ....................................................124
Assigning Initial Router Parameters ................................................125
Obtaining and Activating a License Key .........................................126
Obtaining a Routing License Key ..........................................127
Activating a Routing License Key .........................................129
License Key CLI Commands ..................................................129
RIP (Routing Interchange Protocol) Configuration................................... 131
RIP Overview ......................................................................................131
RIP2 .......................................................................................................132
RIP CLI Commands ............................................................................132
OSPF (Open Shortest Path First) Configuration........................................ 134
OSPF Overview ...................................................................................134
OSPF CLI Commands ........................................................................135
Static Routing Configuration........................................................................ 136
Static Routing Overview ....................................................................136

Table of Contents
Avaya P334T-ML User’s Guide vii
Static Routing Configuration CLI Commands ...............................136
Route Preferences ............................................................................... 137
Route Redistribution ..................................................................................... 138
Route Redistribution Commands .....................................................138
ARP (Address Resolution Protocol) Table Configuration ....................... 139
ARP Overview .................................................................................... 139
The ARP Table .........................................................................140
ARP CLI Commands ..........................................................................140
BOOTP/DHCP (Dynamic Host Configuration Protocol) Relay
Configuration ................................................................................................. 141
BOOTP/DHCP Overview ................................................................. 141
BOOTP ...................................................................................... 141
DHCP ........................................................................................ 141
DHCP/BOOTP Relay ............................................................. 141
BOOTP/DHCP CLI Commands ...................................................... 142
NetBIOS Re-broadcast Configuration......................................................... 143
NetBIOS Overview ............................................................................. 143
NetBIOS Re-broadcast Configuration CLI Commands ................143
VRRP (Virtual Router Redundancy Protocol) Configuration ................. 144
VRRP Overview .................................................................................. 144
VRRP Configuration Example 1 .......................................................145
Case#1 ....................................................................................... 145
Case #2 ...................................................................................... 146
VRRP CLI Commands ....................................................................... 146
SRRP Configuration....................................................................................... 148
SRRP Overview ................................................................................... 148
SRRP Configuration Example ........................................................... 148
SRRP CLI Commands ........................................................................ 149
Policy Configuration ..................................................................................... 150
Policy Configuration Overview ........................................................ 150
Policy Configuration CLI Commands ............................................. 150
Policy Configuration Example .......................................................... 152
Policy Configuration Example .......................................................... 153
IP Fragmentation and Reassembly.............................................................. 154
IP Fragmentation and Reassembly Overview ................................ 154
IP Fragmentation/Reassembly CLI Commands ............................154
Section 4 Troubleshooting and Maintenance
Chapter 13 Troubleshooting the Installation.................................................................. 157
Troubleshooting the Installation.................................................................. 157
Chapter 14 Maintenance.................................................................................................... 159
Introduction .................................................................................................... 159
Replacing the Stacking Sub-module ........................................................... 159

Table of Contents
viii Avaya P334T-ML User’s Guide
Chapter 15 Updating the Software .................................................................................. 161
Software Download ....................................................................................... 161
Obtain Software Online .....................................................................161
Downloading Software ......................................................................161
Download New Version without Overwriting Existing Version............ 162

Avaya P334T-ML User’s Guide I
Before you Install the P330-ML
Safety Information
Caution: Avaya P330 switches and modules contain components sensitive to
electrostatic discharge. Do not touch the circuit boards unless instructed to do so.
Caution: Do not leave any slots open. Cover empty slots using the blanking plates
supplied.
Warning: The fans are on whenever the power is on in the chassis.
FCC Notice
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Changes or modifications to this equipment not expressly approved by Avaya Inc.
could void the user’s authority to operate the equipment.
Conventions Used in the Documentation
Documentation for this product uses the following conventions to convey
instructions and information:
CLI Conventions
• Mandatory keywords are in the computer bold font.
Preface

II Avaya P334T-ML User’s Guide
• Information displayed on screen is displayed in computer font.
• Variables that you supply are in pointed brackets <>.
• Optional keywords are in square brackets [].
• Alternative but mandatory keywords are grouped in braces {} and separated by
a vertical bar |.
• Lists of parameters from which you should choose are enclosed in square
brackets [ ] and separated by a vertical bar |.
• If you enter an alphanumeric string of two words or more, enclose the string in
inverted ”commas”.
Notes, Cautions, and Warnings
LNotes contain helpful information or hints or reference to material in other
documentation.
Caution: You should take care. You could do something that may damage
equipment or result in loss of data.
Warning: This means danger. Failure to follow the instructions or warnings may
result in bodily injury. You should ensure that you are qualified for this task and
have read and understood all the instructions
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales
agreement or other applicable documentation to establish the terms of the limited
warranty. In addition, Avaya’s standard warranty language as well as information
regarding support for this product, while under warranty, is available through the
following website: http://www.avaya.com/support.

Avaya P334T-ML User’s Guide III
Notice
Every effort was made to ensure that the information in this document was
complete and accurate at the time of printing. However, information is subject to
change.
Avaya Support
Avaya provides a telephone number for you to use to report problems or to ask
questions about your contact center. The support telephone number is 1-800-242-
2121 in the United States. For additional support telephone numbers, see the Avaya
Web site: http://www.avaya.com

IV Avaya P334T-ML User’s Guide

Avaya
SECTION 1: OVERVIEW

Avaya P334T-ML User’s Guide 1
Chapter 1
Avaya P334T-ML Overview
Introduction
The P334T-ML is a powerful Multilayer Policy 10/100 BASE-T and Gigabit Ethernet
stackable switch. It enhances the P330 line to support high density multilayer
10/100 BASE-T and Gigabit Ethernet solutions.
The Avaya P330 family of stackable Ethernet workgroup switches includes a range
of modules with 10/100/1000 Mbps ports, a Layer 3 capability, and ATM and WAN
expansion modules.
An Avaya P330 stack can contain up to 10 switches and backup power supply units.
The stacked switches are connected using stacking Modules which plug into a slot
in the back of the Avaya P330. They are connected using the X330SC or X330LC
cable (if the stack is split between two racks). The Avaya X330RC cable connects the
top and bottom switches in the stack; this connection provides redundancy and
hot-swappability. A P330 stack is managed as a single IP entity.
About the P334T-ML
Basic information about the P334T-ML follows:
• The Avaya P334T-ML has forty-eight 10/100BASE-T and two GBIC (SFP) ports,
and provides Layer 2 and optional Layer 3 Ethernet switching. Like other
members of the Avaya P330 family, the P334T-ML is available in AC and DC
versions.
• Multilayer switching with QoS, Policy Management, and multiple levels of
security and redundancy make the Avaya P334T-ML an ideal part of a
converged network. The P334T-ML is ready for voice and data applications, and
supports IEEE standards for VLAN Tagging, Gigabit Ethernet, Spanning Tree,
and Flow Control.
The Avaya P334T-ML can be deployed with other products in the P330-ML family
in stacks of up to ten switches. This makes increasing port density or adding new
technologies as simple as “plug and play.”
Avaya P334T-ML Features
• Up to 480 10/100Base-T ports in a stack.
• Octaplane™ 8 Gbps stacking fabric
• Stack, Port & LAG Redundancy
• Multiple VLANs per port

Chapter 1 Avaya P334T-ML Overview
2Avaya P334T-ML User’s Guide
• RADIUS protocol for security
• Rapid spanning tree
• Port based network access control
• IP Multicast filtering
•Multi-layerPolicy
• Terminal and modem interface
•ACandDCversions
• Backup Power Supply
Layer 3 Features P330-ML
• RIP v.1, RIP v.2, OSPF. ARP, ICMP, DHCP/BOOTP relay
• VRRP and SRRP Redundancy
•QualityofService
• Access control
Network Management and Monitoring
Comprehensive network management and monitoring are key components of
today’s networks. Therefore we have provided multiple ways of managing the
P330-ML to suit your needs.
Device Manager (Embedded Web)
The built-in P330 Device Manager (Embedded Web Manager) allows you to manage
a P330 stack using a Web browser without purchasing additional software. This
application works with the Microsoft Internet Explorer and Netscape Navigator
web browsers and Sun Microsystems Java Plug-in.
Command Line Interface (CLI)
The P330CLI provides a terminal type configuration tool for configuration of
P330-ML features and functions. You can access the CLI locally, through the serial
interface, or remotely via Telnet.

Chapter 1 Avaya P334T-ML Overview
Avaya P334T-ML User’s Guide 3
Avaya Integrated Manager
When you need extra control and monitoring or wish to manage other Avaya
equipment, then the Integrated Manager network management suite is the answer.
This suite provides the ease-of-use and features necessary for optimal network
utilization.
• MSNM is available for Microsoft Windows 95/NT/2000 and Solaris 2.8
• MSNM can operate in Stand-Alone mode with Windows NT/2000 and
Solaris 2.8.
• MSNM operates under HP OpenView for Windows 95/NT/2000
Port Mirroring
The P330-ML provides port mirroring for additional network monitoring
functionality. You can filter the traffic and mirror either incoming traffic to the
source port or both incoming and outgoing traffic. This allows you to monitor the
network traffic you need.
Ports which are members in a Link Aggregation Group (LAG) cannot also be used as
Port Mirroring Destination or Source ports.
Within the P334T-ML switch, port mirroring can be configured between ports in the
three following groups:
• 1-12, 25-36
• 13-24, 37-48
• 51, 52
On the stack level, port mirroring pairs can be configured between any Giga port,
and between any Giga port on the P334T-ML and any 10/100Mbps port not residing
on a P334T-ML.
SMON
The P330-ML switches support Avaya’s ground-breaking SMON Switched
Network Monitoring, which the IETF has now adopted as a standard (RFC2613).
SMON provides unprecedented top-down monitoring of switched network traffic
at the following levels:
• Enterprise Monitoring
• Device Monitoring
• VLAN Monitoring
• Port-level Monitoring
This top-down approach gives you rapid troubleshooting and performance
trending to keep the network running optimally.
LAn Avaya Integrated Manager Licence is required to run SMON monitoring.
LYou need to purchase one SMON License per P330 Stack

Chapter 1 Avaya P334T-ML Overview
4Avaya P334T-ML User’s Guide
Fans, Power Supply, and BUPS-ML Monitoring
P330-ML switches have integrated sensors which provide advance warnings of fan
failure, power supply failure or Backup Power Supply (BUPS-ML) failure via
management.
