Aventura MD-HH-UHS User manual



USER’SMANUAL
FOR
HIGHPERFORMANCE
HANDHELDMETALDETECTOR
MD‐HH‐UHS






RevisionDateDescription Initials
02017‐01‐02Newtemplate LR
‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐
‐‐‐ ‐‐‐ ‐‐‐ ‐‐‐

Page2of6


Index

Chapter1–INTRODUCTION.........................................................................................................................3
1.1.Precautions........................................................................................................................................3
1.2.Features.............................................................................................................................................3
1.3.Detectionrange.................................................................................................................................4
Chapter2–OPERATIONINSTRUCTIONS......................................................................................................4
2.1.Devicecomponents............................................................................................................................4
2.2.Poweron............................................................................................................................................5
2.3.Detectionandsensitivityscanning....................................................................................................5
2.4.Poweringandchargingthedevice.....................................................................................................5
Chapter3–TROUBLESHOOTINGANDSUPPORT..........................................................................................6




Page3of6

Chapter1–INTRODUCTION

TheAventurahandheldmetaldetectorcanbeusedinavarietyoflocationsfordifferent
purposes.Itcanbeusedby:
‐police,courts,prisonsandhighsecurityfacilities;
‐airportsecurity,bordercontrol,customs,militaryfacilitiesandsecuritycheckpoints;
‐publicplaceslikeconventionandexhibitioncenters,entertainmentandcultural
locations,sportsfacilities,etc.;
‐highsecurityfacilitieswherepreciousmetaldetectionisrequired,likemines,jewelry
factories,orotherfacilitiestopreventtheft;
‐medicalandfoodqualityinspection;
‐metaldetectioninfactories,sawmillorplaygrounds.

1.1.Precautions

Turnoffpowerafteruse.ThemetaldetectorhasagreenLEDthatwillstayonwhilethe
powerisON.Ifnotturnedoff,theLEDwilldrainthebattery.
Ifthemetaldetectorisinconstantcontactwithametalsurface,itwillnotsoundor
vibrate.Itwillsendalarmswhenusedforrepetitivescans.
Usecautionwhenchargingthebatteries.Useonlyrechargeablebatteries,asnon‐
rechargeableonescanexplodeandcausefire.
Ifexternalpowerisused,batteriescanberemoved.
Batteriesarenotincluded.IfbatteriesareusedAventurarecommendstheuseof
rechargeablebatteries.

1.2.Features

Thehandheldmetaldetectorhasthefollowingfeatures:
‐Streamlineappearance,smallandeasytocarry;
‐Easytouse,convenientandnoneedforadditionalsetting;
‐Batterylevelindicator;
‐Externalchargingportforcontinuousoperation;
‐AdjustableHighandLowsensitivitylevels.Lowsensitivitycanbeusedinareas
wherethere’stoomuchinterferencefromothermetalstructuresorobjects;
‐Shockresistant.Canwithstand40inches[1meter]drops;



Page4of6

1.3.Detectionrange

Thehandheldmetaldetectorissetuptodetectthefollowingobjectswiththese
distances:
Pinorstaple1‐2inches[30‐60mm]
0.75inch[20mm]diametersteelball 4inches[100mm]
Pistol7.75‐10inches[200‐250mm]
Sixinch[150mm]dagger  7.75inches[200mm]

Chapter2–OPERATIONINSTRUCTIONS

2.1.Devicecomponents

TheMD‐HH‐UHShandheldmetaldetectorisrepresentedintheimagebelow.SeeTable
1forcomponentpartdetails.


Image2.1.a–Metaldetector

1Detectingsurface
2Lowbatteryindicator(yellowLED)
3Alarmindicator(redLED)
4Chargingport
5Batterycover(rear)
6Signalstrengthindicator(colorchangingLED)
7Audiobuzzer
8Ready(greenLED)
9Sensitivityswitch(reset)
10Threepositionswitch(SoundAlarm,PowerOffandVibrationAlarm)

Table2.1.a–Details

Page5of6

2.2.Poweron

Thehandheldmetaldetectorhasapowerswitchwiththreepositions(seecallout10on
Image2.1.andTable2.1.a).ThecenterpositionwillturnOFFthepowertothedevice.TheUP
position(towardsthefrontofthewand)willturnthedeviceon,andwillenableonlythe
vibration.TheDOWNposition(towardsthebottomofthewand)willturnthedeviceon,andwill
enableonlythesoundalarm.
Whenthedeviceison,thegreenLEDwillturnonandwillblink(callout8),andwillstay
on(blink)untildeviceisturnedoff.
IfthepowerLEDdoesnotturngreen,orthereisacontinuoussoundorvibration,the
batteryisdepletedandneedstobereplaced.Replaceorrechargethebatteryandthentryagain.
Youcanalsocheckthelowbatteryindicator(seecallout2).IftheLEDisyellow,replacethe
battery.

2.3.Detectionandsensitivityscanning

Oncethepoweristurnedon,andthedeviceissettovibrationoraudioalarm,usethe
detectionareaofthemetaldetector(callout1).Ifmetalisdetected,thewandwillvibrateor
makeasound.
Therearealsotwovisualindicators:aredLED(callout3)andasignalstrengthindicator
(callout6).Thesewillautomaticallyturnononcemetalisdetected.
TheHighsensitivitycanbeusedindaytodayoperations.Inspecialcases,theLow
sensitivitycanbeused.Usethesensitivitybutton(callout9)toreducethewandsensitivityina
ratioof1:5(sensitivitywillbereducedfivetimes).Thisisrecommendedwhentheareaofinterest
issurroundedmymetalobjectsthatcouldtriggeranalarm.

2.4.Poweringandchargingthedevice

Thehandheldmetaldetectorhasthreewaysofoperation:battery,rechargeablebattery
andpoweredoperation.Nobatteriesaresuppliedwiththeunit.Theunitoperateswith9V(orE)
sizebatteries.
Beforebatteryinstallation,observethebatterypolarity.Thebatterysocketismarked
withPositive(+)andNegative(‐)symbols.
Whenusedwithnon‐rechargeablebatteries,donotconnecttheunittothe120Vac
[220Vac]charger.Thiscancauseafireorexplosion.
Whenusedwithrechargeablebatteries,theyellowLED(seecallout2)willindicatewhen
batteryisrunninglow.Connecttheunittothechargerusingthepowerjack(seecallout4).
Rechargingtimedependsontheselectedbatterycapacity.
Whenusedcontinuously,connectchargertotheunit.



Page6of6

Chapter3–TROUBLESHOOTINGANDSUPPORT

ForTroubleshootingandSupport,pleasecontactAventuraTechnologiesInc.:
Tel: +1.631.300.4000
Fax: +1.631.434.7000
Email: [email protected]
Skype: aventurasupport
Web‐site:http://www.aventuracctv.com
