Avenview SPLIT-HDM2-T4K-2 User manual

VIDEO WALLS VIDEO PROCESSORS
VIDEO MATRIX SWITCHES
EXTENDERS SPLITTERS WIRELESS
CABLES & ACCESSORIES
Control Your Video...
1x2 HDMI TRUE 4K@60 SPLITTER
W/ EDID & HD Support
© 2015Avenview Inc. All rights reserved.
The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or
warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications
and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted
by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and claims any
express or implied warranty, relating to its products are is strictly prohibited.
Model #: SPLIT-HDM2-T4K-2/4/8

Military Residential
Medical Aviation
Education Industrial
Corporate House Of Worship
www.avenview.com
Product Application & Market Sectors

www.avenview.com Page 3
TABLE OF CONTENTS
1. GETTING STARTED ..........................................................................................................................1
1.1 IMPORTANT SAFEGUARDS..............................................................................................................1
1.2 SAFETY INSTRUCTIONS ..................................................................................................................1
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........................... 2
2. INTRODUCTION ..............................................................................................................................3
2.1 PACKAGE CONTENTS .....................................................................................................................4
2.2 BEFORE INSTALLATION...................................................................................................................4
2.2 CABLE SPECIFICATION ....................................................................................................................5
2.3 APPLICATION DIAGRAM..................................................................................................................6
2.4 PANEL DESCRIPTION.......................................................................................................................7
......................................................................7
2.4.1 INPUT PANEL (SPLIT-HDM2-T4K-2) BACK PANEL
2.4.2 INPUT PANEL (SPLIT-HDM2-T4K-2)FRONT PANEL .....................................................................7
3. INSTALLATION
(SPLIT-HDM2-T4K-2)..............................................................................................8
4 GENERAL TROUBLESHOOTING..................................................................................................... 9
5. SPECIFICATIONS ...............................................................................................................................10

www.avenview.com Page 1
SECTION 1: GETTING STARTED
1.1 IMPORTANT SAFEGUARDS
Please read all of these instructions carefully before you use the device. Save this manual for future reference.
What the warranty does not cover
•Any product, on which the serial number has been defaced, modified or removed.
•Damage, deterioration or malfunction resulting from:
•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to
follow instructions supplied with the product.
•Repair or attempted repair by anyone not authorized by us.
•Any damage of the product due to shipment.
•Removal or installation of the product.
•External causes to the product, such as electric power fluctuation or failure.
•Use of supplies or parts not meeting our specifications.
•Normal wear and tear.
•Any other causes which does not relate to a product defect.
•Removal, installation, and set-up service charges.
1.2 SAFETY INSTRUCTIONS
The SPLIT-HDM2-T4K-2 Port HDMI Splitter has been tested for conformance to safety regulations and requirements, and has
been certified for international use. However, like all electronic equipments, the SPLIT-HDM2-T4K-2should be used with
care. Read the following safety instructions to protect yourself from possible injury and to minimize the risk of damage to the
unit.
!Do not dismantle the housing or modify the module.
!Dismantling the housing or modifying the module may result in electrical shock or burn.
!Refer all servicing to qualified service personnel.
!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage
or other hazards
!Keep the module away from liquids.
!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on
to the housing, unplug the module immediately.
!Have the module checked by a qualified service engineer before using it again.
!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
1. GETTING STARTED

www.avenview.com Page 2
1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
Warning symbols Description
ONLY USE THE PROVIDED POWER CABLE OR POWER
ADAPTER SUPPLIED. DO NOT TAMPER WITH THE
ELECTRICAL PARTS. THIS MAY RESULT IN ELECTRICAL
SHOCK OR BURN.
DO NOT TAMPER WITH THE UNIT. DOING SO WILL
VOID THE WARRANTY AND CONTINUED USE OF THE
PRODUCT.
THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.
PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON A
SURFACE, IT SHOULD BE IN A GROUNDED ENVIROMENT.

www.avenview.com Page 3
2. INTRODUCTION
The Avenview SPLIT-HDM2-T4K-2port HDMI Splitter can support the new industry of video signals 4K@60 and
UHD. This device allows the INPUT (source as 4K GPU graphic card or UHD Digital Player) to be duplicated onto 2
4K@60 or UHD displays. Supporting both video and audio signal simultaneously reproducing the same quality via HDMI
cable with EDID management.
Video Signals: 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth.
Audio Signals: DTS-HD Master Audio, Dolby TrueHD Dolby Digital,DTS, DVD-Audio, LPCM, SACD, MPCM
The SPLIT-HDM2-T4K-2includes one unit: 2Port SPLITTER with one(1) HDMI Input that can be up to 5m (16ft) and eight
(8) output ports which allows the user to extend over HDMI cable video and audio up to 5m (16ft).
- INPUT: HDMI 2.0 /DVI 1.0 support
- INPUT 4K@60 HDR(4:2:0 10bits) / (4:4:4 8bits), 4K@30, UHD, 3D, Deep Color, and 1080p 24-bit color depth;
- HDCP 2.2 Compliance;
- COLOR SPACE: xvYCC, x.v.Color & Deep Color;
- VIDEO RESOLUTIONS: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz/3D,
1080i@50/60Hz,1080p @ 24Hz /50/60Hz/3D, ULTRA HD (3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- PC RESOLUTIONS: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz,
- 1280x768@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz,
1600x900@60Hz,1680x1050@60Hz, 1920x1080@60Hz 1920x1200@60Hz ULTRA HD
(3840x2160)@24/30/60Hz 4K (4096x2160)@24/30/60Hz
- FREQUENCY RANGE: 25MHz~600MHz
- LINK TRANSMISSION: Up to 18Gbps (600MHz)
- DISTANCE: Up to 5meters (16ft) w 24AWG High Speed Ethernet HDMI Cable
- EDID: Multi mode selection & EDID learning from Display
- FIRMWARE: Update by mini USB connector
- PLUG & PLAY
NOTE: HDR- (High-dynamic-range imaging)
High-dynamic-range imaging (HDRI or HDR) is a technique used in imaging and photography to reproduce a greater
dynamic range of luminosity than is possible with standard digital imaging or photographic techniques. The aim is to present
the human eye with a similar range of luminance to that which, through the visual system, is familiar in everyday life. The
human eye, through adaptation of the iris and other methods, adjusts constantly to the broad dynamic changes ubiquitous
in our environment. The brain continuously interprets this information so that a viewer can see in a wide range of light
conditions.

www.avenview.com Page 4
2.1 PACKAGE CONTENTS
Before you start the installation of the splitter, please check the package contents.
1SPLIT-HDM2-T4K-2X 1
4
POWER ADAPTER 5V 2AX1
USER’S MANUAL X 1
2.2 BEFORE INSTALLATION
•Put the product in a level and stable location. If the product falls, it may cause damage or malfunction to components
within the casing.
•Do not place the product in temperatures under 0˚C or over 50˚C. High humidity may also cause the unit to malfunction.
•Use the DC power adapter with correct specifications supplied with the unit. If the improper power supply is used, this
may result in malfunction of the unit and may cause fire.
•Do not twist or pull by force the ends of the HDMI cable. It can cause malfunction.
2
3Mounting Brackets X 2

www.avenview.com Page 5
2.2 CABLE SPECIFICATION
We highly recommend achieving best results with our SPLIT-HDM2-T4K-2you acquire a high quality 26 or 24 AWG HDMI
cable with the below specifications to maintain signal integrity and distances.
Features
•Full UHD 4K/ 60 to 18Gbps High Speed at up to 48 Bit
Deep Color
•UHD 4K/60 to 10.2 Gbps High Speed Deep Color up to 50ft
(Active Series), 25ft Passive
•Full HD Up to 1080p/60 up to 75ft
•True Professional grade heavy-duty 24 or 26 gauge oxygen-
free construction
•ProGrip connector utilizes up to 16 lbs of retention force to
help keep connector in place
•SureLength length indicators on the connector heads make
•it easy to organize for installations
•Available in 7 colors for easy cable identification
•Up to 32 audio channels and 21:9 aspect ratio
•Simultaneous delivery of dual video and audio streams
to multiple users
•Pro Grade Triple Shielding with 2x 100% coverage and 85%
Premium Tinned Copper Braid construction
•Ethernet Capable
•3D Ready
•Supports Deep Color and x.v. Color (Up to 48 Bit)
•5.1/7.1 Lossless Dolby TrueHD and DTS-HD Surround Sound
•Audio Return Channel & Lip-sync
•ATC Certified
•99.9% High Purity Copper Center Conductor
•Molded 24k Gold Plated HDMI male connectors on each end
•X-tra Flex CL3 rated jacket for easy installation
•RoHS Certified
•Lifetime Warranty

www.avenview.com Page 6
2.3 APPLICATION DIAGRAM

www.avenview.com Page 7
2.4 PANEL DESCRIPTION
2.4.1 INPUT PANEL (SPLIT-HDM2-T4K-2)Front Panel
1. LED INDICATOR:Illuminates RED when the supplied 5V 2A power adapter is plugged into AC wall outlet.
2. LED INDICATOR: When the source is connected to the unit and processing.
2.4.2 INPUT PANEL (SPLIT-HDM2-T4K-2) RearPanel
3. HDMI INPUT:HDMI Type B Female Connector for connecting HDMI compilant source.
4. HDMI OUTPUT: 1-2 port HDMI Type B Female Connector for connecting HDMI compilant display monitor.
34567
5.MINI USB :USB Type B Female Connector for Manufacturer Firmware upgrade.(Official use only).
6.EDID MODE: 0-F The 15 mode dial allows the user to easily sync between source, unit and display timings.
0 - F/W update mode
1 - EDID Ultra-HD(4K/UHD@60) - 24bit 2D & 7.1ch audio
2 - EDID Ultra-HD(4K/UHD@60) - 24bit 2D & 2ch audio
3 - EDID Ultra-HD(4K/UHD@30) - 24bit 2D & 7.1ch audio
4 - EDID Ultra-HD(4K/UHD@30) - 24bit 2D & 2ch audio
5 - EDID Full-HD(1080p@60) - 24bit 2D & 7.1ch audio
6 - EDID Full-HD(1080p@60) - 24bit 2D & 2ch audio
7 - EDID Full-HD(1080p@60) - 24bit 3D & 7.1ch audio
8 - EDID Full-HD(1080p@60) - 24bit 3D & 2ch audio
9 - EDID Full-HD(1080p@60) - 36bit 2D & 7.1ch audio
A - EDID Full-HD(1080p@60) - 36bit 2D & 2ch audio
B- EDID HD(1080p@30)/1080i@60/720p@60)-24bit 2D & LPCM7.1ch/Dolby Digital
C - EDID HD(1080p@30/1080i@60/720p@60) - 24bit 2D & 2ch audio
D - Auto EDID analysis learning mode
E - Learn EDID from output1(DEFAULT)
F - Learn EDID from output 4
7.POWER JACK:Power Soucre connection
1
2

www.avenview.com Page 8
3. INSTALLATION (SPLIT-HDM2-T4K-2)
To setup the Avenview SPLIT-HDM2-T4K-2please follow the steps below to experience the best results:
1.
Connect the HDMI video source to the INPUT(HDMI IN)- Example Bluray or 4K Digital player or Camera
Connect (2) two HDMI cablesto the desired HDMI Displays
Please ensure all connections are seated securely and placed in the corresponding connections.
2.
3.
Please ensure the connecting devices are powered off before proceeding.
4.
5. IMPORTANT- Please ensure the dial is not on 0 (F/W upgrade)
6. Firstly Power on the HDMI Source, after the boot sequence and the resolution is sync with the dial mode
7.Power on the compatible HDMI displays and experience the clear duplicated images on the 1 to 4
displays connected.
1. When connecting a new monitor to the SPLIT-HDM2-T4K-2 when the dial mode is on D (auto EDID)
or mode E and F (EDID learning), the user may experience a blank screen for a short period. The
Automatic EDID learning process will analyzes the connected monitor to verify the EDID table versus the
HDMI input to calculate any changes to be made.
2. For firmware update through Mini-USB, users MUST first power off the unit , set the rotary switch to
“0”, and then connect the Mini-USB cable between PC and device.
Open the firmware update software-:
[STEP 1] set the correct com port and baud rate (57600 is recommended);
[STEP 2] click the “File” button to direct to the firmware HEX or BIN file, power on the device and press
“Program MCU” symbol to firmware update. Once update process is done, please power off the device
and set the rotary switch back to other mode (NOT to “0”).
EDID LEARNING MODE
FIRMWARE UPGRADE

4 GENERAL TROUBLESHOOTING
PROBLEM POSSIBLE SOLUTION
NO IMAGE
•Check if ALL connection to the source and the display are in the correct position.
•Ensure that display device supports 720p and 1080p, UHD, 4K@30/60 resolution
•Please use the supplied power supply-DC 5V 2A
•Check LED light on Front Panel see (Section 3 Panel Description)
•Check EDID mode dial see (Section 3 Panel Description)
5M OR LONGER HDMI
CABLE NO 4K2K IMAGE
•Ensure the HDMI Cable is 26 or 24 AWG High quality cable and supports Ultra
HD video and audio
Notice
Resolutlions
3840×2160, also known as Ultra HD, is commonly known to be four times the resolution of 1080p, resulting from
doubling both the horizontal and vertical pixel count of 1920×1080. Therefore, it has the same aspect ratio as FULL
HD – 16:9. Most, but not all, 4K display devices have a native resolution of 3840×2160.
4096×2160, referred to as 4K DCI, is used manily in movie production and in commercial cineplexes. There are some
display devices with a native resolution of 4096×2160, but it is not as common as 3840×2160.
Many 4K cameras and source devices can be set to either of the two resolutions listed.
In the AV world professionals will recall the SXGA PC resolution of 1280×1024, which had a non-standard aspect ratio
of 5:4 when nearly every other signal was 4:3. This led to problems – displays and sources had to be carefully
matched and correctly configured in order to display all of the information without unwanted cropping or stretching.
Please ensure your source device and the displays are fully compatible before attempting to connect and provide a full
solution.
Extended display identification data EDID Readers -Monitor Asset Manager -http://www.entechtaiwan.com/util/moninfo.shtm
High-bandwidth Digital Content Protection (HDCP) Compliance with source and display.
www.avenview.com Page 9

www.avenview.com Page 10
SECTION 11: SPECIFICATIONS
5. SPECIFICATIONS
Item Description
UNITS SPLIT-HDM2-T4K-4 SPLIT-HDM2-T4K-8
UNIT DESCRIPTION ULTRA HD/4K@60 SPLITTER
HDCP COMPLIANCE HDCP 2.2
VIDEO BANDWIDTH Single-Link 600MHz (18 Gbps)
HDMI SUPPORTED RESOLUTIONS HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits)
HDMI CABLE 5-15meter (50feet)
AUDIO SUPPORT Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
Dolby Digital, DTS, DVD-Audio,LPCM,SACD, MPCM
ESD PROTECTION Human body model — ±19kV (air-gap discharge)
& ±12kV (contact discharge) Core Chipset— ±2kV
INPUT 1 x HDMI Type A (19 pin female)
OUTPUT 2x HDMI Type A
LED
DIMENSIONS (L X W X H) 5.46” x 3.67” x 1”
WEIGHT 1.3 lbs 0.58 kg
POWER SUPPLY 5V / 2A DC , CE/FCC/UL certified)
POWER CONSUMPTION 10 Watt (max)
Environmental
OPERATING TEMPERATURE 32˚ ~ 104˚F (0˚ to 40˚C)
STORAGE TEMPERATURE -4˚ ~ 140˚F (-20˚ ~ 60˚C)
RELATIVE HUMIDITY 20~90% RH (non-condensing)
ROTARY CONTROL SWITCH EDID Mode Selection
1 x HDMI Type A (19 pin female)
8x HDMI Type A (19 pin female)
3.5 lbs 1.58 kg
9.5” x 3.9” x 1”
SPLIT-HDM2-T4K-2
Front Panel Indicators
2x HDMI Type A
4.4” x 2.5” x 1”
1.01 lbs 0.46 kg
5V / 4A DC , CE/FCC/UL certified)
11 Watt (max)

www.avenview.com
Avenview Warranty Certificate
AVENVIEW CORP. (“Avenview”) warrants Avenview-branded product(s) contained in the original packaging against defects in materials and workmanship when used
normally in accordance with Avenview's enclosed manual guidelines for a period of THREE (3) YEARS from the date of original retail purchase - Warranty Period. Avenview’s
published guidelines include but are not limited to information contained in technical specifications, user manuals and service communications.
LABOR: During the Warranty Period of THREE (3) YEARS, Avenview will repair or replace the product(s) at no cost using new or used parts equivalent to novel performance
and reliability if the product(s) is determined to have abide by Avenview’s published guidelines. Cost of Labor applicable to product(s) after Warranty Period. For labor costs,
please contact s[email protected].
PARTS: During the Warranty Period of of THREE (3) YEARS, Avenview will supply new or rebuilt replacements in exchange for defective parts of the product(s) at no cost if
the product(s) is determined to have abide by Avenview’s published guidelines. Cost of Parts applicable to product(s) after Warranty Period. For part(s) costs, please contact
[email protected].
To obtain Warranty: (a) proof of purchase in the form of a bill of sale or receipted invoice reflecting that the registered product(s) is within warranty period must be presented
to obtain warranty service; (b) product(s) must be registered at time of purchase. Failure to do so will result in applicable parts and labor charges. Returning product(s) must
be shipped in Avenview’s original packaging or in packaging pertaining equal degree of protection to Avenview’s. Both Avenview and purchaser are responsible for freight
charges and brokerages when shipping the product(s) to the receiver.
NOT COVERED BY THIS WARRANTY
This warranty does not apply to any non-Avenview branded product(s); non-registered Avenview product(s). This warranty does not apply: (a) to cosmetic damage, including
but not limited to scratches, dents and broken cords; (b) to damage caused by use with another product; (c) to damage caused by accident, abuse, misuse, liquid contact, fire,
earthquake or other external cause; (d) to damage caused by operating the Avenview product(s) outside Avenview’s manuals or guidelines; (e) to damage caused by service
performed by anyone who is not a representative of Avenview or an Avenview authorized personnel; (f) to defects caused by normal wear and tear or otherwise due to the
normal aging of the Avenview product(s), or (g) if any serial number has been removed or defaced from the Avenview product(s).
AVENVIEW IS NOT LIABLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS (INCLUDING LOSS OF PROFITS ON CONTRACTS); LOSS OF THE USE OF MONEY; LOSS OF ANTICIPATED SAVINGS; LOSS OF BUSINESS;
LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT
OR CONSEQUENTIAL LOSS OR DAMAGE REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
Some states do not allow the inclusion or limitation of incidental or consequential damages, or allow limitations on duration implements of the Warranty Period; therefore the above limitations or
exclusions may not be applicable to you. This warranty gives you specific legal rights, and you may have other rights which vary from state to state.
1100 Military Road, Kenmore, NY 14217
1.866.508.0269

TECHNICAL SUPPORT
Disclaimer
While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of
Avenview hardware, software or other products and documentation described herein, for any act or omission of Avenview concerning such products or this
documentation, for any interruption of service, loss or interruption of business, loss of anticipatory profits, or for punitive, incidental or consequential damages
in connection with the furnishing, performance, or use of the Avenview hardware, software, or other products and documentation provided herein.
Avenview Inc. reserves the right to make changes without further notice to a product or system described herein to improve reliability, function or design.
With respect to Avenview products which this document relates, Avenview disclaims all express or implied warranties regarding such products, including but
not limited to, the implied warranties of merchantability, fitness for a particular purpose, and non-infringement.
Control Your Video
Avenview Canada
151 Esna Park Drive, Unit 11-12
Markham, ON L3R 3B1
Phone: [phone]
Email: [email protected]
Sales: [email protected]
Avenview USA
1100 Military Road
Kenmore, NY 14217
Phone: [phone] x223
Fax: [phone]
Email: [email protected]
Avenview Europe
Phone: [phone]
Email: [email protected]
Avenview Asia
Email: [email protected]
Sales: [email protected]
