AVer AVerVision F17+ User manual

©20
23
AVer Information Inc. All rights reserved.
AVerVision F17+
Quick Start Guide
(1)
(3)
(2)
AVerVision F17+ Port Display Device Port
(4)
RGB OUTPUT
>
RGB INPUT
HDMI OUTPUT
>
HDMI INPUT
(5)
Output Display
Set the resolution to display the image
on screen.

Remote Control and Control Panel
The remote control requires two (2) “AAA” size batteries (supplied); make sure batteries are installed
properly before use. You can access all the features of AVerVision F17+ with the remote control.
(18)
(14)
(11)
(7)
(8)
(5)
(2)
(1)
(22)
(13)
(4)
(3)
(15)
(12)
(17)
(23)
(20)
(19)
(9)
(6)
(16)
(10)(21)
(1)
(9/19)
(2)
(14)
(8)
(20)
(7)
(10)
(3)
(21)
(4/23)
(12)
(10)
(21)
(24)
Name
Function
(1) POWER
Turn the unit on/standby.
(2) CAMERA
Camera mode displays the video signal
from the built-in camera.
(3) RECORD
Start/Stop audio & video recording.
Video recording can only be saved either
in a SD memory card or a USB flash
drive.
(4) CAPTURE
Capture still image in Camera mode. In
continuous capture mode, press this
button again to stop.
(5) VISOR
Not supported
(6) ROTATE
Rotate the image by 0/180° in Camera
mode.
(7) MENU
Open and exit the OSD menu.
(8)
▲,▼,◄, & ►
- Pan and zoom-in image (above digital
zoom level) in live mode.
- Select options in OSD menu.
- Use ▲&▼to increase and decrease
the video playback volume.
- Use &to play the video backward
and forward.
(9) AUTO FOCUS
Adjust the focus automatically.
(10) ZOOM +/-
Increase/decrease the image
magnification in camera and picture
playback mode.
(11) ZOOM 1X
Reset zoom level to 100%.
(12) PLAYBACK View the captured picture/video from the memory in images.
(13) PC 1/2
PC mode displays the video signal from the RGB/HDMI INPUT port of
F17+.
(14) FREEZE / STOP
- Freeze live images.
- Stop video playback.
(15) SPOTLIGHT
Not supported
(16) SPLIT SCREEN
Not supported
(17) MODE
Press to switch between Normal (Microscope), Motion, and High quality.
(18) TIMER
Call the Timer submenu. Select to Start/Pause/Stop the timer
countdown. Select Timer Interval to set the timer duration.
(19)
- Make a selection in Playback mode and OSD menu.
- Play/Pause video playback.
(20) LAMP
Turn the overhead light on/off.
(21) BRIGHTNESS +/-
Adjust the brightness.
(22) DEFAULT
Reset to factory default setting.
(23) DEL
Delete the selected picture/video in Playback mode.
(24) Power LED INDICATOR
-Red:Standby
-Green:On
For warranty information, please visit the link below.
https://communication.aver.com/warranty
WARNING:
This is a class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
CAUTION:
Risk of Explosion if Battery is Replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions.
Refer to the following website for Taiwan RoHS information of our products：
限用物質含有情況標示資訊參考下列網址：
https://tw.aver.com/page/RoHS
警告使用者：
這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，
在這種情況下，使用者會被要求採取某些適當的對策
遙控器電池安全資訊
- 請將電池存放在涼爽與乾燥的位置。
- 不要將電量用盡的電池棄置在家庭廢棄物中。
請將電池棄置在特定回收處，或送回原購買的商店。
- 如果長時間不使用電池，請將其取出。電池漏液與腐蝕
可能會損壞遙控器，請以安全方式棄置電池。
- 不可混用新舊電池。
- 不可混用不同類型的電池：鹼性、標準（碳鋅）或可
充電（鎳鎘）電池。
- 不可將電池棄置於火源中。
- 請勿嘗試讓電池端子短路。
VCCI-A
この装置は、クラス A機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。この場合には使用者が
適切な対策を講ずるよう要求されることがあります。
